HDCVT TECHNOLOGY HDV-814H User manual

14HDMI Splitter
UserManual

1
Dear customer
Thank youforpurchasingthisproduct.For optimumperformance andsafety,please read these
instructionscarefullybefore connecting, operatingor adjustingthisproduct. Please keep thismanualfor
future reference.
. INTRODUCTION
14HDMI splitter distributes 1HDMI source to 4HDMI displays simultaneously.It offers HD video
solutionforsupermarket;shoppingMall;HDTV,STB, DVD andprojector factory; datacontrolcenter;
informationdistribution;conference room presentation;educationandtraining, corporationshow room,
luxurioushouse,etc.

2
SPECIFICATIONS:
InputVideo Signal 0.5 -1.0 volts p-p
InputDDC Signal 5 volts p-p (TTL)
MaxSingle Link Range 1920X1200, 1080P
HDMI Resolutions 480i/576i/480p/576p/720p/1080i/1080P
DVI Resolutions480p/576i/576p/720p/1080i/1080p
HDMI Version HDMI 1.3
Bandwidth Up to 225MHz
EDID Duration 6 seconds
Power supply DC 5V@2A

3
Ⅲ. CONNECTION AND OPERATION:
ⅰ). Connect theHDMI inputsource andoutputdevices into the HDMI Splitter.
*please refer to the ConnectionImage.
ⅱ). Connect theDC 5V power supply into the splitter. Please make sureno other voltage power supply
should be connected. Power supply withhigher voltage may damage the splitter.
ⅲ). Turnonthepower switch.
ⅳ). Whenall input and outputs are connected and turnedon, the corresponding LED willlight.
Attention: Insert and Extractcable gently.
. FAQ:Ⅴ
ⅰ). The splitter doesn’t appear to be functioning.
Firstly,check iftheLED lights, thepower supplyisconnected andthepower switchisturned on.
Secondly,make sureall cables are wellconnected, andareingood condition.Thirdly,make sure the

4
lengthof the cables iswithintheMAXsupported lengthof thissplitter.Lastly,please try to connectthe
inputdevice to the display directly to see ifit display normally.
ⅱ). If the maximumresolutionthefourdisplays supportedisnot thesame,what resolutionwillbe
displayed?
After anEDID process, the splitter willchoose the lowest one and output to all displays
Ⅵ. BOXCONTENTS:
Item Qty Remark
14 HDMI splitter 1pcs
Power supply 1pcs DC 5V@2A
User Manual 1pcs English
