GefenTV GTV-HDMI1.3-144 User manual

1:4 Gefen TV Splitter
User Manual
www.gefentv.com
GTV-HDMI1.3-144

Technical Support:
Telephone [phone]
[phone]
Fax [phone]
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefentv.com
[email protected]
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
1:4 Gefen TV Splitter is a trademark of Gefen Inc.
HDMI™ is a trademark of HDMI.org
© 2008 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE

TABLE OF CONTENTS
Introduction / Operation Notes1.
Features / HDMI 1.3 Features / Package Includes2.
Panel Descriptions3.
Connecting and Operating the 1:4 Gefen TV Splitter / EDID Button /4. Reset Button
Wiring Diagram5.
Specifications6.
Warranty7.

INTRODUCTION
1
Congratulations on your purchase of the 1:4 Gefen TV Splitter. Your complete
satisfaction is very important to us.
Gefen TV
Gefen TV is a unique product line catering to the growing needs for innovative
home theater solutions. We specialize in total integration for your home theater,
while also focusing on going above and beyond customer expectations to en-
sure you get the most from your hardware. We invite you to explore our distinct
product line and hope you find your solutions.. Don’t see what you are looking for
here? Please call us so we can better assist you with your particular needs.
The Gefen TV Splitter
The Gefen TV 1:4 Splitter for HDMI™ allows set-top boxes, DVD players and
other HDTV devices to be connected to up to four HDTV displays. When two or
more Gefen TV HDMI™ 1:4 splitter units are connected together, they can be
used to create a larger video signal distribution. This unit supports HDMI™ 1.3
features and passes the higher bandwidth HDMI™ 1.3 signal for the ultimate in
state-of-the-art HDMI™ signal duplication.
How It Works
The Gefen 1:4 Splitter for HDMI™ 1.3 is connected using an HDMI™ cable from
the HDMI™ source to the HDMI™ splitter input. There are four HDMI™ outputs.
Each output is connected to an HDMI™ display. Power is cycled for all equip-
ment, then all connected displays will show a crisp, clear replica of the source
video signal.
READ THESE NOTES BEFORE INSTALLING OR
OPERATING THE 1:4 GEFEN TV SPLITTER
Display information (EDID) is sent from the display connected to HDMI output• port 1 to the source. If there is no display connected to HDMI output port 1, the
remaining HDMI output ports will be scanned in succession and use the first
EDID that it detects. (See note on page 4 for additional information)
HDMI 1.3a compliant (please see the next page for supported HDMI 1.3• options)
HDCP compliant•
Compatible with all HDMI and DVI* displays•
*When used with a HDMI to DVI adapter
OPERATION NOTES

FEATURES
2
Features
HDMI and HDCP compliant•
Connects up to four HDMI™ / DVI displays at the same time to one video• source
Maintains beautiful, sharp HDTV resolutions up to 1080p, 2k, and computer• resolutions up to 1920 x 1200 are easily achieved
Small, light and compact•
HDMI 1.3 Features
Lip-Sync Pass Through•
225 MHz (up to 12 bit YUV 444 supported @ 1080p)•
Deep Color Supported (XV Color Supported)•
Color Space Conversion Supported•
Dolby TrueHD & DTS HD Master Audio Supported•
CEC Pass Through•
Package Includes
(1) Gefen TV Switcher
(1) 6' HDMI cable (M-M)
(1) 5V DC Power Supply
(1) User Manual

PANEL DESCRIPTIONS
3
IR Eye
HDMI
Input
EDID and
Reset
Button* Output 4Output 3Output 2Output 1*
*Please see page 4 for additional information
Power Supply
Input
Power
LED Indicator Link Indicator
Internal EDID
Indicator

CONNECTING AND OPERATING THE 1:4 GEFEN TV SPLITTER
DEVICE BUTTONS
4
How to Connect the 1:4 Gefen TV Splitter
Connect the HDMI source to the 1:4 Gefen TV Splitter using the supplied1. HDMI cable.
Connect the displays (up to four) to the 1:4 Gefen TV Splitter using user2. supplied HDMI cables.
Plug the 5VDC power supply into the Gefen TV Switcher and power outlet.3.
NOTE: Display information (EDID) is sent from the display connected to HDMI
output port 1 to the source. If there is no display connected to HDMI output port
1, the remaining HDMI output ports will be scanned in succession and use the
first EDID that it detects. The source will output resolutions and timings according
to the EDID that is being fed by the display connected to output port 1. Therefore, all
of the connected displays must be capable of accepting the timings and resolution
output by the source. It is recommended that the display with the lowest native
resolution be connected to HDMI output port 1. This is to ensure that a compatible
video signal will be able to be displayed on all connected monitors. Optionally, you
can use a generic 1080i EDID that is pre-stored on the 1:4 Gefen TV Splitter. Please
see the below section on how to use this EDID instead of using the EDID from
display output 1.
EDID Button
There is a generic 1080i EDID stored in the 1:4 Gefen TV Splitter. This can be
used instead of the EDID from display output 1. Press the EDID button on the
rear panel of the unit. The INT LED on the front panel should be lit. This will
indicate that the onboard EDID is being used in lieu of any display EDID.
Reset Button
Pressing the button will reset the unit, effectively reverting the unit to its normal
EDID routing logic.

5
WIRING DIAGRAM
HDMI IN
HDMI OUT

6
SPECIFICATIONS
Video Amplifier Bandwidth ....................................................................... 225 MHz
Input Video Signal .............................................................................. 1.2 Volts p-p
Input DDC Signal ......................................................................... 5 Volts p-p (TTL)
Single Link Range ................................... 1080p/60 12 bit color depth, 1920x1200
HDMI Connector ................................................................... TypeA, 19 pin female
Dimensions ....................................................................... 12”W x 1.25”H x 4.25”D
Power Consumption .............................................................. 10 watts (maximum)
Power Supply .............................................................................................. 5V DC
Shipping Weight ............................................................................................ 5 lbs.
