HDL HDL-MTIRW User manual

Manual
IR/RFRemotecontroller
HDL-MTIRW

HDL MTIRWIR/RFRemoteController
1
TABLEOFCONTENTS
1.Overview...................................................................................................................................1
1.1 Features......................................................................................................................1
1.2 Performanceparameter........................................................................................1
1.3 Layout .........................................................................................................................2
2.Setparameters..........................................................................................................................3
2.1 Hideordisplay page...............................................................................................3
2.2 IRcodelearning.......................................................................................................3
2.3 Wireless address setting.......................................................................................4
2.4 FirmwareUpgrade..................................................................................................4
2.5 Universalcode..........................................................................................................4
3. HowtouseRemoteController.............................................................................................5
3.1 DLPpanelcontrol.......................................................................................................5
3.2 1Row,2Rowandtouchpanel scontrol...................................................................6
3.3 Learnpanelcontrol ....................................................................................................7
3.4Wireless panel control..................................................................................................7

HDL MTIRWIR/RFRemoteController
1
1. Overview
HDL-MTIRW,IR/RFremotecontroller,supportIR andRFremotecontroland
IR learning.RFremotecontrolmustworkwithHDL-MWH6,aftersetthe
controltargetsintheHDL-Busprotoolssoftware,you cancontrolany
HDL-BUSdevicebythe remotecontroller.
1.1 Features
uSupport allHDLpanels
uTheremotecontrollerhasembedded infraredcodesofallHDLpanels,
Noneedtolearnagain.
uItcanlearn48 IRcodes,controlupto48targets.
uIconcanbechanged viaPC-basedtoolsoftware.
uSupportkeytone
uLCD display, menu-typeoperation,easytouse.
uSupport multiplepages,canhide/displaypage
uSupport upgradingbyUSB interface
1.2 Performanceparameter
uFrequency of IR:38KHz
uFrequency of RF: 433.1580MHz/433.92MHz
uIR remotecontroldistance:5m
uRFremotecontroldistnabce:100m
uBattery: Lithium 3.7V,1050mA）
uUSB interface: Firmwareupgradeandbatterycharging
uCharge powersupply:300mA/DC5V USB interface ）
uWorkingcurrent: 45mA
Standbycurrent: 1mA
uDimension:154.2×60×24.2 mm）
uIPProtection: IP20
uCEcertificated
uWorkingTemperature:0℃～+45℃
uWorkingRelativeHumidity: 40%-90%
uStorageTemperature: -40℃-+55℃

HDL MTIRWIR/RFRemoteController
2
uStorageRelativeHumidity:10%-93%
1.3 Layout
Functions
ØIR remotecontroland IRlearning IRremotecontrolandlearncodesofotherIRremote
controller,effectiveIR remotecontroldistance 5m
ØReset Canrestarttheremotecontroller
ØUSB interface:Batterycharging andupdatefirmwareforremotecontroller.
ØSwitch:controltheremotecontroller sstate.Incasenooperationmorethan10s,the
LCDwill darken,ifnooperationmorethan13s,itwillenterintostandbystate.Intheoff
state,Press anybuttoncanrestarttheremotecontroller.
ØChangebutton,changebetweenhomepageandDLP panel.
ØReturnbutton,returntothepreviousstep
ØControlbutton:thoseNo.1toNo.8buttonscancontrolcorrespondingbuttonsinHDL
panel.NO.9and.0areinactive.
Øupand downchangeparametersneedtoset, andselectHDLpanel whenyouare
control,thereare6kindsofpanel canselect.
Øsetparameters,and selectpagewhenyouarecontrol,somepanel hasmany
pages,eachpanel hasdifferentpagesanddifferentbuttons,youcanselectbythosetwo
buttons.
ØOK:confirmbutton, whenyouaresetparameters,youshouldpress OK toconfirm.
Reset
154.2
ForIRcode emittingandIRlearning
USB interface
24.2
60
switch of
remote
Change button
Bac
k button
Function
Control button
LCD display

HDL MTIRWIR/RFRemoteController
3
2. Setparameters
2.1 Hideordisplaypage
Nowhide the 2ndpage of DLPpanel,setting asfollow:
After that,youcantfind thepage ontheremotecontroller,soyoucan t
controlthe DLPpanelssecondpageviaremotecontroller.
2.2 IR codelearning
Fig. 1Homepage
ØBL Level setthebrightness oftheLCD, therangeis0to10
ØSoundEN ifthereisavoicewhenpress thebutton.
ØLanguage selectChineseor Englishoftheremote
ØPageDisp hideor displaypage,thedefaultisalldisplay
ØIRLearn TowardotherIRremote,canlearnIRcode.
ØWifiAdd setthewifi address oftheremote. Theaddressrange
is1to65534,you canchoice oneaddress.
ØUpgrade connectUSBtoPC,thenupgradefirmware,you must
resettheremoteafter upgradefirmware.
ØThe4direction buttonsareselectfunctionsand parameters.
Fig.2HidetheDLP panel page
Fig.3IR codelearning
Step
1.EnterintotheinterfaceofIRcodelearning, seeFig.3
2.Transmitterport oflearnedremotecontrollerfacetothatremotecontrollerwithin1-2cm
Press thebutton inlearnedremotecontrollertostartlearning IRcode,Iflearnsuccess
willdisplay“LearnOK,Keyentertrycode.Iffailedwilldisplay“Learninterfere,tryagain”.
3.TestCode: checkif learnedsuccessfully,PressTest Code tobackpreviousmenu
IR codelearning
interface

HDL MTIRWIR/RFRemoteController
4
2.3Wirelessaddress setting
Eachwirelessremotecontrollerhasanaddress,theaddressrange is
1~65534.
You can setuptofour"receivingaddress"ineachwirelessreceiver,
correspondingly,sothewirelessreceivercanreceivecontrol
commandsfrommaximumfourmatchedwifiremotecontrollers.
2.4FirmwareUpgrade
When upgrading firmware,you need connectUSB toPC. Doubleclick
toopenMobiledevices"CRPDISABLD"in"mycomputer",then use
thenew".Bin"filetoreplaceexisted"firmware.bin".afterthat, reset
theRemotecontrollertomakeyourupgradingeffective
2.5 Universalcode
Theremotecontrollerhasbeen fixedinfraredcodesaboutHDLall
panels,don't needtolearn.
“DLPpanel”page can tcontrolotherpanelexcept DLPpanel.
wecanusethe "1rowpanel"pageofIR&RFcontrollertocontrol1Row
panels,2Rowpanels,touchpanelsand evenLCDDLPpanels,and
thoseIR codeswecallit Universalcodes
Fig.6Upgradefirmware
Fig.5wirelessreceiver saddress setting
Fig.4wifi remotecontroller saddress setting
Wiferemotecontroller saddress

HDL MTIRWIR/RFRemoteController
5
Theremotecontroller sIcon canbe changedviaHDLEasyEngineering
Editor.
3.HowtouseRemoteController
3.1DLPpanelcontrol
Fig.7DLPpanelinterface
DLPpanelcontrol
1) Press thebutton or forselecttheDLP panel.
2) Press thebutton or , changeDLP panel spage
3) Remotecontroller sbutton,thoseNo.1to
No.8buttonsofRmotecontroller cancontrolcorresponding
buttonsinwall panels
4) Ifthebuttonsmodeissingon/off,thetargetissingle
channellighting, longpress thebuttonincreaseordecrease
thebrightness
Air-conditioncontrol
ØButton1/2 HVACON/OFF
ØButton3/4 reduce/increasetemperature
ØButton5/6 changefanspeed
ØButton7/8 changemode
Musiccontrol
ØButton1/2 setsoundsource/ONorstop
ØButton3/4 selectprevious/next playlist
ØButton5/6 selectprevious/next song
ØButton7/8 reduce/increasesound
Fig.8HVACinterface
Fig.9Z-audiointerface
press button1for2seconds，DLPpanelwill enterintothepage
ofsetparameters.
ØButton1/2: infirmbutton,whenyouarechangeparameter
youmustcontrolthesebuttons.
ØButton3/4:changeparameter
ØButton5/6:changeparameter
ØButton7/8:exit,backtothepreviouspage

HDL MTIRWIR/RFRemoteController
6
3.21Row, 2Rowandtouchpanel scontrol
1Rowpanelcontains:1/2/3/4/6buttonswitch
2Rowpanelcontains:2/4/6/8button switch
Touchpanelcontains: 1/2/3/4buttonswitch
Floor heatingcontrol
ØButton1/2 switchfloor heating
ØButton3/4 settemperature
ØButton5/6 displayindoororoutdoor stemperature
ØButton7/8 changemode,Normal,Day,Night,Away,Time
Fig.10Floorheating interface
Press button1for2seconds,DLPpanelwillenterintothepage
ofsetparameter.
ØButton1/2 confirmbutton
ØButton3/4 changeparameter
ØButton5/6 changeparameter
ØButton7/8 exit, backtothepreviouspage
Fig.101/2Row panel interface
1Row/2Row/Touchpanel scontrol
1) Press thebutton or forselectthepageof
HDL panel(1Row, 2Row orTouchpanel).
2) Press thebutton or , changethepanel with
differentbuttonnumber
3) press No.1toNo.8buttonscan
controlHDL panel
4) At last,you canpress thebutton or control
other panels.

HDL MTIRWIR/RFRemoteController
7
3.3Learnpanel control
Beforeuselearnpanel,youmustinsurethatthe remotecontrollerhas
learnedtheIR codes.
3.4Wireless panelcontrol
Beforeusewifipanel，youmustinsurethatwireless receiver sreceiving
address matchedwifiremotecontroller s.
Fig.11learnpanelinterface
Fig.12 wifipanelinterface
How touselearnpanel
1) Press thebutton or forselectthe
pageoflearnpanel.
2) Press thebutton or , changethepageof
learnpanel,thedefaultis6pagesandeach
pagehas8controlbuttons.
3) press No.1toNo.8buttons
cancontroltheother devices(youmustlearn
thedevicesIR code.eg.TV,DVD and soon)
4) At last,youcanpress thebutton or
controlotherpanels.
Howtousewifipanel:
1) Selectthepageofwifi panel.
2) Press thebutton or ,changethepageofwifi
panel,thedefaultis6pagesandeachpagehas8
controlbuttons.
3) press No.1toNo.8buttonscancontrol
theHDL wireless receiverthencontrolobjects.
4) Atlast,you canpressthebutton or control
otherpanels.
