1. Overview
1.1 General Information
The HDL-MTIRW IR/RF Remote Controller supports both IR/RF output and IR learning.
After setting the control targets in RF receiver via the HDL-Bus Pro Setup Tool, the RF
output will be able to transmit signals to its RF receiver.
1.2 Functions
The Remote Controller has built-in HDL IR codes, this gives the user immediate control
over all the HDL panels
For IR control, ability to control 48 targets
Icons can be changed via PC-based tool software
Supports key tones
Large LCD display makes menu navigation simple
Multiple display pages can be supported
Display can be hidden
 Supports upgrading via USB interface
1.3 Device Description
○aIR output and IR learning：The IR transceiver can output, and learn from other IR
remote controls.
○
bReset：Press this button to reset the Remote Control.
○
cUSB interface：The battery can be charged via USB, the firmware for the Remote
○
a
○
b
○
c
○
d
○
e
○
f
○
h
○
g
○
i

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 2
Control can be updated.
○
dSwitch：The remote can be powered on or off via its dedicated switch. The remote
also has a power saver function that darkens the LCD display if there is no input
for more than 10 seconds. If there is no input for a further 13 seconds the Remote
Control goes into standby mode, pressing any button will resume normal
operation.
○
eChange button：Change between the home page and panel page.
○
fReturn button：Return to the previous step/page.
○
gControl button：Buttons 1 to 8 control the corresponding buttons present on a HDL
DLP panel, buttons 9 and 0 are invalid in this function.
○
h：: Scroll up and down to select one of 6 various panels, or set parameters.
: Scroll left and right to set parameters, or select from the many pages
present on each panel.
: Confirmation button, after the parameters have been set pressing ok will
confirm and save them.
○
i: LCD interface.
2. Technical Data
Electric Parameter ：
Charge power supply
300mA/DC5V (USB interface)
Working current
45mA
Standby current
1mA
Frequency of IR
38KHz
Frequency of RF
433.1580MHz/433.93MHz
IR sending distance
5m
RF sending distance
100m
Battery
Lithium (3.7V, 1050mA)
USB interface
Firmware upgrade and battery charging
Environmental Condition：
Working temperature
0℃~45℃
Working relative humidity
Up to 90%
Storage temperature
-20℃~+60℃
Storage relative humidity
Up to 93%

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 3
3. Setting device parameters
3.1 Hide or display a page
The example below demonstrates how to hide the 2nd page of a DLP panel. The process
is the same regardless of page type or number.
Approved
CE
RoHS
Production information：
Dimensions
154.2×60×24.2 (mm)
Weight
115.5(g)
Housing material
ABS, PC, Silica gel
Protection degree
IP20
Fig. 1 Home page
BL Level：Set the brightness of the LCD backlight
Sound EN：Enable or disable the button tones.
Language ：Select the display language of the remote,
choose from either Chinese or English.
Page Disp：Choose to hide or display pages, by default all
pages are displayed.
IR Learn：Program the buttons on the IR control page
RF Addr：Set the RF address of the remote. The address
range is 1 to 65534, any address chosen must be
replicated on the RF receiver, see the Fig.4 and Fig.5.
Upgrade：To upgrade the firmware connect the remote via
USB to a PC, after this is completed the remote must be
reset.
The 4 directional buttons allow scrolling to select various
functions and parameters.
Fig. 2 Hide the DLP panel page

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 4
When the process is complete the 2nd page of the DLP panel will not be visible on the
menu of the Remote Control.
3.2 IR code learning
Steps：
a) Enter the IR code learning interface, see Fig.3
b) Point the front of the remote controller 1-2cm away from the front of the 3rd party
remote controller.
c) Press the relevant button on the 3rd party remote controller that you wish your HDL
controller to learn. If the operation is successful the remote will display “Learn OK, Key
enter try code”, If the operation fails, the display will show “Learn interfere, try again”.
d) Test Code: Check that the code has been learnt successfully, Press Test Code to
return to the previous menu.
3.3 RF address setting
Each RF Remote Controller has an address, the address range is 1~65534.
You can set up to four "receiving address" in each RF receiver, correspondingly, the RF
receiver can receive control commands from four matched RF Remote Controllers.
Fig.3 IR code learning
IR code
learning
interface
Fig. 4 RF remote controller’s address setting
RF remote controller’s
address

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 5
3.4 Firmware Upgrade
To upgrade the Remote Controller firmware it is necessary to connect it via USB to a PC.
When the device remote is connected open ‘my computer’, double click to open mobile
devices ‘CRP DISABLED’. Simply replace the new existing ‘firmware.bin’ with the new
‘.bin’ file. To complete the upgraded disconnect the Remote Control from the computer
and then reset it.
3.5 Universal code
The Remote Controller has built-in HDL IR codes, which can be used to control all HDL
panels and no need to learn the IR codes.
For example:
1) In ‘1 Col panel’ page, you can control of 1 Col panels, 2 Col panels, touch panels, and
even LCD DLP panels is possible.
2) But in “DLP panel” page, you just can control DLP panels.
3.6 Changing Icons
To change the Icon shown on the Remote Control, please use the HDL Easy
Engineering Editor (Icon “Remote Controller” on the menu bar).
Icon size: (pixel)
DLP panel: 64*25
IR panel: 64*25
RF pane: 64*25
Fig.6 Firmware Upgrade
Fig. 5 Setting the RF receiver address

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 6
Touch panel: 32*32
Single-Col panel: 64*22
Double-Col panel: 64*22
Icon type: “*.bmp”
3.6.1 How to design the Icons
Method one:
Use 3rd party software to design the icons, the icon type should be .bmp, remember to pay
careful attention to the icon size.
After the icon has been designed put it in the ‘DIY’ folder
You can find this folder by right clicking on the software’s icon -> Properties (R) -> Find the
targets -> the “DIY” folder.
Method two:
a) Open the ‘HDL Easy Engineering Editor’ software and click on the button. After
this enter the IR Remote Icon window.
b) Click the “DIY” icon, the window shown below will then pop up.

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 7
: Adjust the position of words in the text box.
: Add a square frame to the icon.
: Add a circular frame to the icon.
: Select the font.
: Generate an icon.
: Switch between negative print and positive print.
: Save/delete the icon.
: Change the size of the Icon box.
: Left/ Right: Change the position of the text box in the
Icon box. Using percentages determine how much of the text box you want to be present
in the icon box.
If you are trying to add some text into an image icon, see step C and D below, if you are
trying to create a pure text icon, set the percentage at 100%.
Icon box: Drag the icon from the icon library, or open a file to find the icons and drop it
Icon library, the
“DIY” folder
Icon box
Text box
Text edit
box
The preview, icon
box & text box
Name
edit box
Icon box’s size and
Text box’s position
in Icon box.

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 8
into the icon box. (Right clicking can delete this icon.)
Text box: Show the text.
Text edit box: From the four text boxes shown, choose the first and write the desired text.
When you have finished press the ‘enter’ key, the edit box will jump to the
second box.
Preview box: To preview the generated icon.
Name edit box: Change the name of the icon by using the name edit box.
c) The size of a DLP is 64×25, if the size of your text exceeds this it needs to be changed.
For example, in the DIY preview, select Text Left and 49. This will make the text box
49% of the icon box.
In the example below how to change the icon and text is demonstrated;
1- Drag the icon from the icon library and drop it to the column immediately. The sun
icon has been dragged and dropped, you can add the text ‘DAY’ in the text edit box.
2- In text edit box type in ‘DAY’, and press the ‘enter’ key on the keyboard, then type in
‘FAN’.
3- Then change the name, and click the , to preview the newly generated icon.
d) Click the icon to save the setting of day.bmp, and fan.bmp. After this is complete
the icon can be found in the icon library.
drag

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 9
3.6.2 How to change the Icons
Take DLP page for example:
Steps:
a) Open the ‘HDL Easy Engineering Editor’ software, and click the icon, then enter
the IR Remote Icons window.
b) Connection: Use the USB cable to connect the controller to the pc.
c) Select the device: select the 1FC9—3
1.Click
2.Select

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 10
d) Select the picture and drag in the right position. Notice the icon size.
e) Upload the icon:
f) After the icon has been uploaded it can be viewed on the Remote Control.
1. Select DLP Page 1
2. Upload
Upload all
pages

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 11
4. How to use the Remote Control
4.1 DLP panel control
Fig. 7 DLP panel interface
DLP panel control：
Press the or button to select the DLP panel.
Press the or button to change the DLP panel’s page.
The Remote control has 10 buttons,
numbers 1-8 can control the corresponding buttons in
panels.
If the button’s mode is simple on/off switching, then the
target can be a single channel or lighting scene. If the
button is long pressed it can be used to increase or
decrease the brightness.
Air-conditioner control：
Button 1/2：HVAC ON/OFF
Button 3/4：reduce/increase temperature
Button 5/6：change fan speed
Button 7/8：change mode
Music control：
Button 1/2：set sound source/ON or stop
Button 3/4：select previous/next play list
Button 5/6：select previous/ next song
Button 7/8：reduce/increase sound
Fig. 8 HVAC interface
Fig. 9 Z-audio interface
Floor heating control：
Button1/2：switch for floor heating
Button3/4：set temperature
Button5/6：display indoor or outdoor temperature
Button7/8：change mode, Normal, Day, Night, Away,
Time
Fig. 10 Floor heating interface

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 12
4.2 1Col, 2 Col, and Touch panel control
1 Col panel contains: 1/2/3/4/6 button switch
2 Col panel contains: 2/4/6/8 button switch
Touch panel contains: 1/2/3/4 button switch
4.3 IR control panel
Before using the IR panel, you must ensure that the Remote Controller has learnt the IR
codes.
Fig. 11 2 Column panel interface
Fig .12 IR panel interface
1 Col /2 Col /Touch panel’s control：
Press the or button to select the panel (1
Col, 2 Col or Touch panel).
Press the or button to change the panel page.
Buttons 1-8 can control HDL panels.
Press the or button to control other panels.
How to use IR panel：
Press the or button to select the IR panel page.
Press the or button to change the IR panel
page, the default is 6 pages and each page has 8
control buttons.
Buttons 1-8 can control other devices, but first the
remote control must learn the device’s IR code.
The or buttons can also control other panels.

User Manual
MTIRW IR/RF Remote Controller
Remote Controller – User Manual 13
4.4 RF control panel
Before using the RF panel ，you must ensure that RF receiving address matches the
Remote Control RF address.
Fig. 13 RF panel interface
How to use RF panel:
Select RF panel page.
Press the or button to change the RF panel
page, the default is 6 pages with each page having 8
control buttons.
Buttons 1-8 can control the HDL RF
receiver, and the devices coupled to it.
Pressing the or button can also control other
panels.
