Speaker Installation Manual:
Congratulations on your purchase of the Resound HDL-C65P architectural speakers.
The HDL-C65P speakers represent the best value in class for in-wall and in-ceiling
speakers for the home. High fidelity Audio quality components and Resound’s
state-of-the -art manufacturing capabilities are combined to create an exceptional
speaker. The HDL-C65P speakers are designed to provide years of audio equipment.
Speaker Placement:
Proper placement is crucial to enjoying the benefits of the HDL-C65P
speakers. Consider the optimal listening area in the room. The speakers
should ideally be placed facing that area with 8-10 feet of separation between them.
In-wall placement of the speakers should be at ear level or just slightly higher and
in-ceiling mounting should be placed to the left and right of the optimal listening area,
Graph. A
Note: In existing construction, care should be taken to not conflict with Speaker Wiring
with other Electrical wiring, heat ducts, or water lines. The HDL-C65P rough-in brackets
can be placed between studs and ceiling joists as a cutout template for the drywall
installation.

www.hdlchina.com
HDL Ceiling Speaker Manual –HDL-C65P 3
Installation
UStep 1U
Drill a speaker hole in the ceiling following a pencil cutout with the dimension of bit size
(200mm), Fig 1.
Fig.1
UStep 2U
Connect the wiring into its appropriate terminal as the positive wire from the amplifier
should be connected to: Red jack & while the negative wire to: Black jack. Fig 2.
Fig.2
UStep 3
Once wiring is connected to the speaker, center the speaker in place of the hole and
secure it by turning the mounting screws clockwise until the hooks holds the speaker
snug smoothly against the ceiling wall. Fig 3 & 4.
Note: Do not over tighten the hooks

www.hdlchina.com
HDL Ceiling Speaker Manual –HDL-C65P 4
Frequency Response Pattern
Graph. B
Specifications
6.5” Speaker with Tweeter, (Ceiling Mount)
Model HDL-C65P
Rated power: 50W (25W RMS)
Max power: 60W (30W RMS)
Impedance: 8Ω(8ohms)
Efficiency / Sensitivity: 85dB-95dB 1W/1M
Freq response: 55 hz -18 khz
Cutout Dimensions: Φ200 mm
Dimensions: (mm) 228 Dia X 85 Depth
Tweeter: 20mm Silk , 12db / Octave; 4khz
Dust Filter Cover: Polypropylene
Surround: Butyl Rubber
Cone Material: Woven Kevlar
Color: White / Off
Woofer Cross Over: 12dB / Octave; 3 / 4kHz
Magnet: 10 oz/ 80 x 30 x 15mm/ Y35
Note: Best Performance Compatibility with Z-Audio®
(Zone Audio Digital Distributed Audio)
