Tennsco Standard Combination Cabinet CVD7214 Instruction Manual

PK-2480918
ASSEMBLY INSTRUCTIONS & PARTS MANUAL
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE
Standard Combination Cabinet
Preassembled Model 7214 or CVD7214
GENERAL SAFETY INFORMATION
Some parts may have sharp edges. CARE must be taken when handling various pieces to avoid injury.
For safety, wear a pair of work gloves when assembling or performing any maintenance on products.
LIMITED WARRANTY
Tennsco warrants goods purchased hereunder to be free of defects in materials and workmanship for a period of one (1) year from the date of shipment, hereunder. This warranty shall not apply
in the event goods are damaged as a result of misuse, abuse, neglect, accident, improper application, modication or repair by persons not authorized by Seller, where goods are damaged during
shipment, or where the date stamps on the goods have been defaced, modied or removed. UNLESS CONSIDERED UNENFORCEABLE OR UNLAWFUL UNDER APPLICABLE LAW:
a. ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO WARRANTIES OR MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY EXCLUDED:
b. BUYERS REMEDY, IF ANY, FOR ANY DEFECTIVE GOODS SHALL BE LIMITED TO A REFUND BY SELLER OR REPLACEMENT OF THE GOODS AT SELLER’S OPTION, AND SHALL IN NO
EVENT INCLUDE DAMAGES OF ANY KIND, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE.
NO GOODS ACCEPTED FOR RETURN WITHOUT PRIOR APPROVAL. Seller shall have the right to inspect any goods claimed to be defective at Buyers place of business or require Buyer to return the
goods to Seller for inspection on Seller’s premises. Transportation charges covering returned goods will be borne by Seller only if such goods are proven to be defective, are covered by this warranty
and are returned within the warranty period stated above.
Tennsco LLC., Dickson, TN 37056-1888 • [phone]
LOAD CAPACITIES PER SHELF LEVEL
36w x 18d
18w x 18d
200 lbs.
75 lbs.
UNIT SIZE WEIGHT CAPACITY
EVENLY DISTRIBUTED

REPLACEMENT PARTS




Ref. No. 8
Ref. No. 9
Ref. No. 5
Ref. No. 7
Ref. No. 6
REF. NO. DESCRIPTION
1 Shelf 1 301
2 Partition Shelf 4 304
3 Left Door: Solid for 7214 1 944LD
Left Door: C-Thru for CVD7214 (not shown above) 1 CVD-72LD
4 Right Door: Solid for 7214 1 944RD
Right Door: C-Thru for CVD7214 (not shown above) 1 CVD-72RD
5 Locking Bar Set 1 944LB
6 Locking Handle w/keys & hardware 1 944LH
7 Locking Cam* 1 944LC
8 Cotter Pin* 1 CTRPN
9 Locking Bar Guide Insert (Nylon)* 2 944GI
10 Hinge Pins* 6 944HP
11 Partition 1 045CR
12 Coat Rod Bracket 2 045RB
13 Coat Rod 1 046CR
*Included in Ref. No. 5, locking handle with keys and hardware (Part No. 944LH). May be ordered alone or as part of the full hardware set.
QTY. PART NO.

1. To move the shelf, using your
hands apply pressure to the
underside of the shelf and
tap it off the tabs.
2. Place the shelves at the
desired level. Insert the shelf
edges into the tabs at the
new location. Be sure that
the shelf is securely tted
into the tabs at all points of
contact.
3. The cabinet must be level
in order for the doors to
close properly. Levelers may
be adjusted by placing the
nut driver through the hole
in each end of the sill and
adjusting the leveling screw.
Insert hex head driver
through hole (above) to
adjust leveler (below).
Ref.
No. 1
Ref.
No. 3
Ref.
No. 4


Ref.
No. 10


Ref.
No.13

Ref.
No. 12

Ref.
No. 11

NOTE: Additional hardware may be included for replacement purposes.
Tennsco makes every effort to ensure that all units ship complete with all parts and arrive undamaged.
However, should your unit contain missing or damaged parts, please contact your purchase location.
49B248
