Heat & Glo Gas Fireplace GATEWAY User manual

Multi-Sided
Gas Fireplaces
HNG-1034X-0208.indd 1 2/22/2008 1:28:31 PM

Gateway™(cover and top) Shown with custom finishing
Electric ember bed provides a
warm glow with or without flame.
A different angle
another
point of view.
&
HNG-1034X-0208.indd 2 2/22/2008 1:28:36 PM

You can see a fireplace as simply the
wonderful source of warmth and
renewal that it is, but look again. A
multi-sided fireplace can also be a
room divider, a window, or a dramatic
architectural element.
• In popular, flexible sizes—along with a variety of models and options—our multi-sided family is ideal
for new construction, renovations and additions alike.
• Pier, See-Through and Corner vent off either the side or top, inspiring creative installation and design
ideas.
• Pier, See-Through, Corner and Passage offer a direct vent, completely sealed system that draws air
for combustion from the outdoors only and expels any combustion by-products outside, maintaining
clean indoor air.
• Standard electric ember beds in the Pier, See-Through, Corner and Passage provide year-round
enjoyment of the fireplace, with or without flame.
Gateway
Gateway goes where other multi-sided fireplaces might not. Our
patented draft-assist technology combined with its smaller size means
Gateway can be installed virtually anywhere.
There’s more than one way to look at a gas fireplace.
Multi-Sided
Pier
HNG-1034X-0208.indd 3 2/22/2008 1:28:41 PM

Pier
The Pier provides three-sided viewing, and it works perfectly as a
room divider or even the base of a bar.
Pier Shown with Esteem front, custom bar top and Cultured Stone
Country Ledgestone.
Firescreen Companions
Prairie Ridge Firescreen companions
shown on Firescreen front (DF-6-FS)
Carriage Hill Firescreen companions
shown on Firescreen front (DF-6-FS)
See-Through
The See-Through brings two rooms together while letting you
design each side differently.
See-Through Shown with Classic front and custom black granite.
Corner
Put a dark, dull corner to better use.This multi-sided model
adds light and warmth to any corner, left or right.
Corner Shown with Classic front and end panel, custom beige marble and
custom bar top.
The Firescreen front can be enjoyed unadorned, or you can purchase
one of these two Firescreen companions to attach to the front’s exterior,
adding a distinctive touch of corner detail.Available in black, bronze or
pewter to match or contrast with the front.
HNG-1034X-0208.indd 4 2/22/2008 1:28:46 PM

Options, options &more options
With multiple fronts and finishes, plus interchangeable panels and
companions, you define and design your own style.
Interchangeable Decorative Panels
Mission interchangeable
decorative panel shown
attached to Essence door.
Waverly Mission
Classic
Essence doors and Firescreen fronts accept these three interchangeable
panels. Buy one or several, they’re easy to change.Think of them as
decorating accessories for different seasons or events. Each is available in
five finishes to match or contrast with fronts.
Decorative Fronts available for
Pier, See-Through and Corner
Basic Front
DF-6000
Classic Front
DF-Classic-B
Esteem Front
DF-Esteem-B
Firescreen Front
DF-6-FS
Accepts interchangeable decorative
panels and Firescreen companions.
Essence Doors
DF-6-Essence
Accepts interchangeable decorative
panels.
End panels for Pier and
Corner models
(DF-6-EP, DF-CLASSIC-EP-B,
DF-ESTEEM-EP-B)
must be ordered separately.
Decorative Fronts available for See-Through
Finishes
Five rich finishes.
High on style, long on
durability. Available on
select fronts. Black Bronze Pewter Polished Brass Brushed Nickel
Black only Black only
Black only
HNG-1034X-0208.indd 5 2/22/2008 1:28:54 PM

Multi-sided Specifications
MODEL HEIGHT FRONT WIDTH BACK WIDTH DEPTH GLASS SIZE BTU/HOUR INPUT (NG)
GATEWAY
Actual Framing Actual Framing Actual Framing Actual Framing
30-1/4 X 20-3/4 35,000
39-3/16 40-1/4 39-1/4 40-1/4 39-1/4 40-1/4 22-5/8 21-5/8
Healthy Hearth
Our direct vent fireplaces will not alter the quality of indoor room air
in any way.They utilize a sealed combustion chamber that draws in fresh
air from outdoors and discards all combustion by-products back outside.
Limited Lifetime Warranty
The strongest in the industry, Heat & Glo guarantees protection for all
gas units, including a lifetime warranty of the most important aspects:
fiber logs, stainless steel burner, firebox and heat exchanger.
IntelliFire®
Our exclusive, state-of-the-art IntelliFire ignition system reduces gas
consumption and thermogenerator wear by providing a pilot flame
only when needed. It also supplies a back-up battery system to run the
fireplace during a power outage.
Dimensions above are in inches and millimeters. Reference dimensions only. We recommend measuring individual units at installation. Assumes the use of 1/2" drywall.
NOTE: Non-combustible material is allowed over this dimension. Make sure you do NOT cover the decorative door opening.
Refer to installation manual for detailed specifications on installing this product. Heat & Glo reserves the right to update units periodically. The flame and ember appearance may
vary based on the type of fuel burned and the venting configuration used. Pictures in this brochure are not a true representation of the fireplace, flames and/or finishes.
GATEWAY
22-5/8
[575]
GAS LINE
ACCESS
ELECTRICAL
ACCESS
2 [51]
2-1/8 [55]
2-5/8 [67]
5-1/8 [132]
3-1/8
[80]
37-3/4
[959]
39-1/4
[995]
38-1/8
[968]
39-9/16
[1005]
31-1/4
[794]
3-5/8
[93]
14-1/16 [357]
Top Side Front Side
21-5/8 [549] WITH 1/2 [13] SHEETROC
K
21-3/8 [543] WITH 5/8 [16] SHEETROCK
39-3/4
[1010]
40-1/4
[1022]
FEATURES GATEWAY PIER SEE-THROUGH CORNER
Max BTU/Hour Input (NG) 35,000 25,000-37,500 25,000-38,500 25,000-38,500
Remote control/Multi-function wall switch Optional Optional Optional Optional
IntelliFire technology • • • •
UL Listed • • • •
Electric ember bed N/A • • •
Installed junction box for optional fans and remotes • • • •
Fan kit Optional Optional Optional Optional
Ceramic fiber campfire style logs N/A • • •
Sealed combustion chamber N/A • • •
FireBrick®log burner N/A • • •
Decorative fronts N/A Required Required Required
Brick refractory N/A • • •
Multi-sided Model Features
HNG-1034X-0208.indd 6 2/22/2008 1:28:56 PM

Multi-sided Specifications
Dimensions above are in inches and millimeters. Reference dimensions only. We recommend measuring individual units at installation. Assumes the use of 1/2" drywall.
NOTE: Non-combustible material is allowed over this dimension. Make sure you do NOT cover the decorative door opening.
Refer to installation manual for detailed specifications on installing this product. Heat & Glo reserves the right to update units periodically. The flame and ember appearance may
vary based on the type of fuel burned and the venting configuration used. Pictures in this brochure are not a true representation of the fireplace, flames and/or finishes.
MODEL HEIGHT FRONT WIDTH BACK WIDTH DEPTH GLASS SIZE BTU/HOUR INPUT (NG)
PIER Actual Framing Actual Framing Actual Framing Actual Framing 32-5/16 x 21-9/16
17-5/16 x 21-9/16 25,000 - 37,500
42 42-1/2 42-5/8 42-1/8 42-5/8 42-1/8 24 23
SEE-THROUGH 42 42-1/2 46-5/8 47-5/8 46-5/8 47-5/8 24 23 32-5/16 x 21-9/16 25,000 - 38,500
CORNER 42 42-1/2 42-5/8 42-1/8 42-5/8 42-1/8 29-1/4 28-3/4 32-5/16 x 21-9/16
17-5/16 x 21-9/16 25,000 - 38,500
Top View Side View Front View
PIER
5-1/4
[134]
1/2
[13]
12
[306]
8
[204]
12
[306] 8
[204]
ELECTRICAL
ACCESS
GAS LINE
ACCESS
34-3/4
[882]
4-1/16
[102]
4-1/2 [114]
4-3/4 [121]
2-5/16 [58]
42-5/8
[1081]
42
[1067] 32-5/16
[820] 21-9/16
[547]
37-7/16
[950]
8-1/2
[216]
Side View
21-9/16
[547]
17-15/16
[455]
24
[610]
23
[584]
42-1/8
[1070]
42-1/2
[1080]
Framing
Top View Side View Front View
SEE-THROUGH
5-1/4
[133]
12
[306]
8
[204]
1/2
[13]
(4)
Side View
Framing
12
[306]
8
[204]
34-3/4
[882]
4-1/16
[102]
4-1/2 [114]
4-3/4 [121]
2-5/16 [58]
ELECTRICAL
ACCESS
GAS LINE
ACCESS
46-5/8 [1183]
42
[1067]
32-5/16
[820] 21-9/16
[547]
8-1/2
[216]
36-3/16
[919]
4-1/2
[114]
24
[610] 2-9/16
[64]
23
[584]
42-1/2
[1080]
47-5/8
[1210]
Top View Side View Front View
CORNER
5-1/4
[133]
8
[204]
12-1/16
[306]
1/2
[13]
(4)
Side View
Framing
34-3/4
[882]
8
[204]
12
[306]
ELECTRICAL
ACCESS
GAS LINE
ACCESS
10 [254]
7-15/16 [202]
4-3/4 [121]
2-5/16 [58]
2-9/16 [64]
42-5/8 [1082]
8-1/2
[216]
42
[1067]
21-9/16
[547]
32-5/16 [820]
37-7/16 [950]
17-7/8
[455]
21-9/1
6
[547]
24-1/8
[612]
29-1/4 [743]
42-1/2
[1080]
42-1/8
[1070] 28-3/4
[730]
HNG-1034X-0208.indd 7 2/22/2008 1:29:01 PM
