Heat & Glo SL-550TV-D User manual

1Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
Models:
SL-550TV-D, SL-550TV-IPI-D
SL-750TV-D, SL-750TV-IPI-D
SL-950TV-D, SL-950TV-IPI-D
Owner’s Manual
Installation and Operation
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• What to do if you smell gas
- Do not try to light any appliance
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor’s phone. Follow the gas suppli-
er’s instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed
byaqualifiedinstaller,serviceagency,orthe
gas supplier.
WARNING: If the informationinthese
instructions is not followed exactly, a fire
or explosionmay result causingproperty
damage, personal injury, or death.
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high
temperatures.
• Do NOT operate with protective barriers open or
removed.
• Keep clothing, furniture, draperies and other
combustibles away.
Installation and service of this appliance should be
performed by qualified personnel. Hearth & Home
TechnologiessuggestsNFIcertifiedorfactory-trained
professionals, or technicians supervised by an NFI
certified professional.
In the Commonwealth of Massachusetts:
• installation must be performed by a licensed plumber
or gas fitter;
• a CO detector shall be installed in the room where the
appliance is installed.
Thisappliance is onlyfor use with thetype(s) of gasindicated
on the rating plate.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fixed glass panel. Do
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
WARNING
DO NOT DISCARD THIS MANUAL
CAUTION
• Leave this manual with
party responsible for use
and operation.
DO NOT
DISCARD
• Important operating
and maintenance
instructions included.
• Read,understandandfollow
these instructions for safe
installation and operation.

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/072
Congratulations
Listing Label Information/Location
Model Name:___________________________________________ Date purchased/installed:__________________
Serial Number:__________________________________________ Location on appliance: ____________________
Dealership purchased from: _______________________________ Dealer Phone: __________________________
Notes: _______________________________________________________________________________________
_____________________________________________________________________________________________
Congratulations on selecting a Heat & Glo gas appliance
—an elegant and clean alternative to wood burning
appliances. The Heat & Glo gas appliance you have
selected is designed to provide the utmost in safety,
reliability, and efficiency.
As the owner of a new appliance, you’ll want to read and
carefully follow all of the instructions contained in this
Owner’s Manual. Pay special attention to all Cautions and
Warnings.
This Owner’s Manual should be retained for future
reference. We suggest that you keep it with your other
important documents and product manuals.
The information contained in this Owner’s Manual, unless
noted otherwise, applies to all models and gas control
systems.
Your new Heat & Glo gas appliance will give you years of
durable use and trouble-free enjoyment. Welcome to the
Heat & Glo family of appliance products!
Read this manual before installing or operating this appliance.
Please retain this owner’s manual for future reference.
We recommend that you record the following
pertinent information about your appliance.
Gas and Electric
Information
Model Number
Serial Number
Type of Gas
The model information regarding your specific appliance can be found on
the rating plate usually located in the control area of the appliance.
Homeowner Reference Information
Heat & Glo, a of Hearth & Home Technologies, Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
brand
Heat & Glo, a of Hearth & Home Technologies, Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
brand
Not
Not
for
for
use
use
with
with
solid
solid
fuel.
fuel.
(
Ne
Ne
doit
doit
pas
pas
entre
entre
utilise
utilise
avec
avec
un
un
combustible
combustible
solide).
solide).
This
This
appliance
appliance
must
must
be
be
installed
installed
in
in
accordance
accordance
with
with
local
local
codes,
codes,
if
if
any;
any;
if
if
not,
not,
follow
follow
ANSI
ANSI
Z223.1
Z223.1
in
in
the
the
USA
USA
or
or
CAN/CGA
CAN/CGA
B149
B149
installation
installation
codes.
codes.
(Installer
(Installer
l’appareil
l’appareil
selon
selon
les
les
codes
codes
ou
ou
reglements
reglements
locaux
locaux
ou,
ou,
en
en
l’absence
l’absence
de
de
tels
tels
reglements,
reglements,
selon
selon
les
les
codes
codes
d’installation
d’installation
CAN/CGA-B149.)
CAN/CGA-B149.)
Type
Type
of
of
Gas
Gas
(Sorte
(Sorte
De
De
Gaz)
Gaz):
NA
TURAL
TURAL
GAS
GAS
MADE
MADE
IN
IN
USA
USA
Minimum
Minimum
Permissible
Permissible
Gas
Gas
Supply
Supply
for
for
Purposes
Purposes
of
of
Input
Input
Adjustment.
Adjustment.
Approved
Approved
Minimum
Minimum
(De
(De
Gaz)
Gaz)
Acceptable
Acceptable
0.0
0.0
in
in
w.c.
w.c.
(Po.
(Po.
Col.
Col.
d’eau)
d’eau)
Maximum
Maximum
Pressure
Pressure
(Pression)
(Pression)
0.0
0.0
in
in
w.c.
w.c.
(Po.
(Po.
Col.
Col.
d’eau)
d’eau)
Maximum
Maximum
Manifold
Manifold
Pressure
Pressure
(Pression)
(Pression)
0.0
0.0
in
in
w.c.
w.c.
(Po.
(Po.
Col.
Col.
d’eau)
d’eau)
Minimum
Minimum
Manifold
Manifold
Pressure
Pressure
(Pression)
(Pression)
0.0
0.0
in
in
w.c.
w.c.
(Po.
(Po.
Col.
Col.
d’eau)
d’eau)
Model:
Model:
(Modele):
(Modele):
Serial
Serial
(Serie):
(Serie):
ANSI
ANSI
Z21XX-XXXX
Z21XX-XXXX
·
·
CSA
CSA
2.XX-MXX
2.XX-MXX
·
·
UL307B
UL307B
XXXXXXXX
XXXXXXXX
IN
IN
CANADA
CANADA
ALTITUDE:
ALTITUDE:
0-0000
0-0000
FT.
FT.
0000-0000FT.
0000-0000FT.
MAX.
INPUT
INPUT
BTUH:
BTUH:
00,000
00,000
00,000
00,000
MIN.
MIN.
INPUT
INPUT
BTUH:
BTUH:
00,000
00,000
00,000
00,000
ORIFICE
ORIFICE
SIZE:
SIZE:
#XXXXX
#XXXXX
#XXXXX
#XXXXX
XXXXXXXX
XXXXXXXX
Total
Total
Electrical
Electrical
Requirements:
Requirements:
000Vac,
000Vac,
00Hz.,
00Hz.,
less
less
than
than
00
00
Amperes
Amperes
This product may be covered by one or more of the following patents: (Nos produits sont couverts par un ou plusieurs des brevets suivants): (United States)
4593510, 4686807, 4766876, 4793322, 4811534, 5000162, 5016609, 5076254, 5113843, 5191877, 5218953, 5263471, 5328356, 5341794, 5347983, 5429495,
5452708, 5542407, 5601073, 5613487, 5647340, 5688568, 5762062, 5775408, 5890485, 5931661, 5941237, 5947112, 5996575, 6006743, 6019099, 6048195,
6053165, 6145502, 6170481, 6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2,
6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada)1297749, 2195264, 2225408; or other U.S. and foreign patents pending (ou
autres brevets americains et etrangers en attente).

3Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
-Table of Contents -
Section 1: Listing and Code Approvals
A. Appliance Certification................................... 4
B. Glass Specifications...................................... 4
C. BTU Specifications........................................ 4
D. High Altitude Installations .............................. 5
E. Non-combustible Materials Specification....... 5
F. Combustible Materials Specification.............. 5
Section 2: Getting Started
A. Design and Installation Considerations......... 6
B. Negative Pressure......................................... 7
C. Tools and Supplies Needed........................... 8
D. Inspect Appliance and Components.............. 8
Section 3: Framing and Clearances
A. Selecting Appliance Location......................... 9
B. Constructing theAppliance Chase .............. 10
C. Clearances .................................................. 10
D. Mantel Projections........................................11
Section 4: Termination Locations
A.Vent Termination Minimum Clearances....... 12
Section 5: Vent Information and Diagrams
A. Vent Guidelines ........................................... 13
B. Vent System Configuration.......................... 13
Section 6: Vent Clearances and Framing
A. Pipe Clearances to Combustibles............... 15
B. Wall Penetration Framing............................ 15
C. Vertical Penetration Framing....................... 15
Section 7: Appliance Preparation
A. Installing Outside Air Kit Damper Assembly..16
B. Gas/Electrical Connections ......................... 16
C. Securing and Leveling Appliance................ 17
Section 8: Installing Vent Pipe
A. Assembly of Vent Sections.......................... 18
B. Attaching Vent to Firebox ............................ 18
C. Securing Vent Sections .............................. 18
Section 9: Gas Information
A. Fuel Conversions......................................... 19
B. Gas Pressures............................................. 19
C. Gas Connection........................................... 19
Section 10: Electrical Information
A. Recommendation for Wire........................21
B. Connecting to theAppliance..................... 21
C. Intellifire Ignition System Wiring................21
D. Standing Pilot Ignition System Wiring....... 22
E. Junction Box Installation...........................23
F. Wall Switch Installation for Fan................. 23
Section 11: Finishing
A. Mantel Projections .................................... 24
B.Facing Material ......................................... 24
Section 12: Appliance Setup
A. Remove Shipping Materials...................... 25
B. Remove Grate Shipping Support.............. 25
C. Clean the appliance.................................. 25
D. Accessories .............................................. 25
E. Install the Refractory................................. 25
F. Lava Rock, Vermiculite, Rockwool
and Ember Placement.............................. 25
G. Positioning the Logs ................................. 26
H. Glass Assembly ........................................ 30
I. Screen Mesh............................................. 30
J. Grilles and Trim......................................... 30
K. Hood......................................................... 30
L. Shutter Settings ........................................ 30
Section 13: Operating Instructions
A. Before Lighting Appliance......................... 31
B. Check Appliance Draft .............................. 31
B. Lighting Appliance..................................... 32
C. After Appliance is Lit ................................. 34
D. Frequently Asked Questions..................... 34
Section 14: Troubleshooting
A. Standing Pilot Ignition System.................. 35
B. Intellifire Ignition System........................... 37
Section 15: Maintaining and Servicing Appliance........... 39
Section 16: Reference Materials
A. Appliance Dimension Diagram ................. 41
B. Service Parts ............................................ 42
C. Warranty ................................................... 52
D. Contact Information .................................. 53
Î
Î

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/074
B. Glass Specifications
Hearth&HomeTechnologiesappliancesmanufacturedwith
tempered glass may be installed in hazardous locations
such as bathtub enclosures as defined by the Consumer
Product Safety Commission (CPSC). The tempered glass
has been tested and certified to the requirements of ANSI
Z97.1and CPSC 16 CFR 1202 (SafetyGlazingCertification
Council SGCC# 1595 and 1597.Architectural Testing, Inc.
Reports 02-31919.01 and 02-31917.01).
This statement is in compliance with CPSC 16 CFR
Section 1201.5 “Certification and labeling requirements”
which refers to 15 U.S. Code (USC) 2063 stating “…Such
certificate shall accompany the product or shall otherwise
be furnished to any distributor or retailer to whom the
product is delivered.”
Some local building codes require the use of tempered
glass with permanent marking in such locations. Glass
meeting this requirement is available from the factory.
Please contact your dealer or distributor to order.
A. Appliance Certification
NOTE: Thisinstallationmustconformwith local codes. In the
absence of local codes you must comply with the National
Fuel Gas Code, ANSI Z223.1-latest edition in the U.S.A.
and the CAN/CGA B149 Installation Codes in Canada.
NOTINTENDEDFORUSEASAPRIMARY HEATSOURCE.
Thisapplianceistestedandapprovedaseither supplemental
room heat or as a decorative appliance. It should not be
factored as primary heat in residential heating calculations.
Listing and Code Approvals
C. BTU Specifications
1
MODELS: SL-550TV-D, SL-750TV-D, SL-950TV-D,
LABORATORY: Underwriters Laboratories, Inc. (UL)
TYPE: B-Vent Decorative
STANDARD: ANSI Z21.50-2002 • CGA2.2
Model(s)
U.S. (0-2000 ft.) or Canada (2000-4500 ft.) Maximum
Input BTU/h Minimum Input BTU/h
Orifice
Size
(DMS)
SL-550TV-D
SL-550TV-IPI-D
US 21,000 12,000 44
CAN 18,900 10,800 45
SL-550TV-D (LP)
SL-550TV-IPI-D (LP)
US 20,000 N/A 54
CAN 18,000 N/A 55
SL-750TV-D
SL-750TV-IPI-D
US 23,000 16,000 42
CAN 20,700 14,400 43
SL-750TV-D (LP)
SL-750TV-IPI-D (LP)
US 23,000 N/A 53
CAN 20,700 N/A 54
SL-950TV-D
SL-950TV-IPI-D
US 30,000 21,000 36
CAN 27,000 18,900 37
SL-950TV-D (LP)
SL-950TV-IPI-D (LP)
US 30,000 21,000 51
CAN 27,000 N/A 52
This product is listed to ANSI standards for “Vented Gas
Fireplaces” and “Gas Fired Appliances for Use at High
Altitudes”.
This model (natural gas and propane) can be installed in a
bedroom(inthe United States) whichhasa total volume of
unconfinedspaceappropriate to the particular installation.
Refer to the National Fuel Gas Code ANSI Z223.1/
NFPA54 (current edition), The Uniform Mechanical
Code - (current edition),and localBuilding Officialsfor the
options allowed in obtaining an effective bedroom volume
of unconfined space.
This model (natural gas and propane) can be installed in
a bedroom (in Canada) if a thermostat (Model WH-STAT)
is installed with the unit. Consult local code authorities.
Detailed installation instructions for Model WH-STAT are
included with the kit.
Heat & Glo Quality Systems
registered by SGS ICS

5Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
D. High Altitude Installations
U.L.Listed gasappliances aretestedand approvedwithout
requiring changes for elevations from 0 to 2000 feet in the
U.S.A. and Canada.
When installing this appliance at an elevation above 2000
feet, it may be necessary to decrease the input rating by
changing the existing burner orifice to a smaller size. Input
rate should be reduced by 4% for each 1000 feet above
a 2000 foot elevation in the U.S.A., or 10% for elevations
between 2000 and 4500 feet in Canada. If the heating
value of the gas has been reduced, these rules do not
apply. To identify the proper orifice size, check with the
local gas utility.
If installing this appliance at an elevation above 4500 feet
(in Canada), check with local authorities.
Do NOT use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
E. Non-Combustible Materials Specification
Material which will not ignite and burn. Such materials are
those consisting entirely of steel, iron, brick, tile, concrete,
slate, glass or plasters, or any combination thereof.
Materials that are reported as passing ASTM E 136,
Standard Test Method for Behavior of Materials in a
Vertical Tube Furnace at 750oC, shall be considered
non-combustible materials.
F. Combustible Materials Specification
Materialsmadeoforsurfacedwithwood,compressedpaper,
plant fibers, plastics, or other material that can ignite and
burn, whether flame proofed or not, or whether plastered or
unplastered shall be considered combustible materials.
WARNING

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/076
A. Design and Installation Considerations
Heat & Glo B-type vent gas appliances are designed to
operate with all exhaust gases expelled to the outside of
the building, and combustion air pulled from the room.
Getting Started
2
When planning an appliance installation, it’s necessary to
determine the following information before installing:
• Where the appliance is to be installed. See Sections 3
and 4.
• Theventsystem configurationtobe used. See Sections
5 and 6.
• Gas supply piping. See Sections 7 and 9.
• Electrical wiring. See Sections 7 and 10.
• Framing and finishing details. See Sections 3, 6 and 11.
• Whetheroptionalaccessories—devicessuchasafan,wall
switch, or remote control—are desired. See Section 10.
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult local building, fire officials or authorities having
jurisdictionaboutrestrictions,installation inspection, and
permits.
CAUTION
Fire Risk
Explosion Risk
Keep appliance dry.
• Water may damage controls.
• Mold or rust may cause odors.
WARNING

7Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
Recommended
Location
Marginal
Location
Location
Not
Recommended
Recommended
Location
Location NOT
Recommended
Multi-level Roofs
Windward
Leeward
Figure 2.1
B. Negative Pressure
Draft is the pressure difference needed to vent fireplaces
successfully. Considerations for successful draft include:
• Preventing negative pressure
• Location of fireplace and chimney
Negative pressure results fromtheimbalanceof air avail-
able for the fireplace to operate properly. Causes for this
imbalance include:
• Exhaust fans (kitchen, bath, etc.)
• Range hoods
• Combustionair requirementsfor furnaces,waterheaters
and other combustion appliances
• Clothes dryers
• Location of return-air to furnace or air conditioning
• Imbalances of the HVAC air handling system
• Upper level air leaks (recessed lighting, attic hatch
opening, duct leaks)
To minimizetheeffectsofnegative air pressure, thefollow-
ing must be considered:
• Install the fresh air kit. Install the intake on the side of
the house towards prevailing winds during the heating
season.
• Ensureadequate outdoor airissupplied for combustion
appliances and exhaust equipment.
• Ensurefurnace and airconditioning return ventsarenot
located in the immediate vicinity of the fireplace.
• Avoid installing the fireplace near doors, walkways or
small isolated spaces.
• Recessedlighting shouldbe of“sealed can”design; attic
hatches weather stripped or sealed; and attic mounted
ductwork and air handler joints and seams taped or
sealed.
• Basement installations should be avoided due to stack
effect. Stack effect creates negative pressure in lower
levels. Hearth & Home Technologies recommends the
use of direct vent fireplaces in basements.
Location of the fireplace and chimney will affect perfor-
mance. As shown in Figure 2.1, the chimney should:
• Be installed through the warm space enclosed by the
building envelope. This helps to produce more draft,
especially during lighting and die-down of the fire.
• Penetrate the highest part of the roof. This minimizes
the effects of wind turbulence.
• Belocated awayfrom trees,adjacentstructures,uneven
roof lines and other obstructions.
Offsets can restrict draft so their use should be minimized.
Consider the fireplace location relative to floor and ceiling
and attic joists.
Asphyxiation Risk.
•Negative pressure can cause spillage of
combustion fumes and soot.
• Fireplace needs to draft properly for safety.
WARNING

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/078
D. Inspect Appliance and Components
C. Tools and Supplies Needed
Before beginning the installation be sure that the following
tools and building supplies are available.
Reciprocating saw Framing material
Pliers Hi temp caulking material
Hammer Gloves
Phillips screwdriver Framing square
Flat blade screwdriver Electric drill and bits (1/4 in.)
Plumb line Safety glasses
Level Tape measure
Manometer Voltmeter
Non-corrosive leak check solution
1/2 - 3/4 inch length, #6 or #8 Self-drilling screws
One 1/4 inch female connection (for optional fan).
Inspect appliance and components for
damage. Damaged parts may impair safe
operation.
• Do NOT install damaged components.
• Do NOT install incomplete components.
• Do NOT install substitute components.
Report suspected damaged parts to dealer.
• Carefully remove the appliance and components from
the packaging.
• Thevent systemcomponentsand trimdoors areshipped
in separate packages.
• The gas logs may be packaged separately and must be
field installed.
• Report to your dealer any parts damaged in shipment,
particularly the condition of the glass.
Hearth & Home Technologies disclaims any
responsibility for, and the warranty will be voided
by, the following actions:
• Installation and use of any damaged appliance or vent
system component.
• Modification of the appliance or vent system.
• Installation other than as instructed by Hearth & Home
Technologies.
• Improper positioning of the gas logs or the glass door.
• Installation and/or use of any component part not
approved by Hearth & Home Technologies.
Any such action may cause a fire hazard.
Figure 2.2 Typical Vertical Installation
The following B-vent components are needed for installa-
tion (see Figure 2.2).
• Fireplace Box
• Pipe Components
• Firestops
• Attic Insulation Shield
• Elbows
• Strapping
• Roof Flashing or Chase Top
• Termination Cap
• Storm Collar
•Read all of the instructions before starting the instal-
lation. Follow these instructions carefully during the
installation to ensure maximum safety and benefit.
V
ERTICAL TERMINATION CAP
STORM COLLAR
ATTIC INSULATION SHIELD
GAS B-VENT
PIPE SECTION (S)
FIRESTOP SPACER
ROOF FLASHING
OR CHASE TOP
WARNING
WARNING

9Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
3Framing and Clearances
NOTE:
•Illustrations reflect typical installations and are FOR
DESIGN PURPOSES ONLY.
•Illustrations/diagrams are not drawn to scale.
• Actual installation may vary due to individual design
preference.
Fire Risk
Provide adequate clearance:
• Around air openings
• To combustibles
• For service access
Locate appliance away from traffic areas.
A. Selecting Appliance Location
Whenselectinga locationforyour applianceitisimportantto
consider the required clearances to walls (see Figure 3.1).
Figure 3.1 Appliance Locations
Model A B C D E F
SL-550TV-D Inches 41-1/2 37 58-3/4
36 Inches
914 Millimeters
Maximum
16-1/4 1/2
Millimeters 1054 940 1492 413 13
SL-750TV-D Inches 45 42 63-3/4 16-1/4 1/2
Millimeters 1143 1067 1619 413 13
SL-950TV-D Inches 50 49 70-3/4 16-1/4 1/2
Millimeters 1270 1245 1792 413 13
A
A
B
E
B
ALCOVE
INSTALLATION
TOP VENT
TOP VENT
D
F
BC
TOP VENT
NOTE: For actual appliance dimensions refer to
Section 16.
In addition to these framing dimensions, also reference the following sections:
• Clearances and Mantel Projections (Sections 3.C and 3.D)
• Vent Clearances and Framing (Section 6).
WARNING
Î

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/0710
C. Clearances
Figure 3.2 Clearances to Combustibles
C
B
D
A
Fire Risk.
•Construct chase to all clearance specifications
in manual.
•Locate and install appliance to all clearance
specifications in manual
Fire Risk.
Odor Risk.
•Installapplianceonhardmetal or wood surfaces
extending full width and depth of appliance.
•Do NOT install appliance directly on carpeting, vinyl, tile
or any combustible material other than wood.
• DoNOTplace furnitureoranyothercombustible household
objects within 36 inches of the appliance front.
B. Constructing the Appliance Chase
A chase is a vertical boxlike structure built to enclose the
gasappliance and/orits ventsystem.Verticalvents thatrun
on the outside of a building may be, but are not required
to be, installed inside a chase.
Construction of the chase may vary with the type of building.
These instructions are not substitutes for the requirements
of local building codes. Local building codes MUST be
checked.
Chasesshouldbe constructed in themannerof all outside
walls of the home to prevent cold air drafting problems.
The chase should not break the outside building envelope
in any manner.
Walls, ceiling, base plate and cantilever floor of the chase
should be insulated. Vapor and air infiltration barriers
should be installed in the chase as per regional codes for
the rest of the home. Additionally, in regions where cold
air infiltration may be an issue, the inside surfaces may be
sheetrocked and taped for maximum air tightness.
To further prevent drafts in cold climates, the firestops
shouldbe caulkedwithhightemperaturecaulktosealgaps.
Gas line holes and other openings should be caulked with
high temp caulk or stuffed with unfaced insulation. If the
appliance is being installed on a cement slab, a layer of
plywood may be placed underneath to prevent conducting
cold up into the room.
GI
H
E
F
J
Models A B C D E F G H I J
SL-550TV-D Inches 10 33 16-1/4 37 31 0 0 1/2 1/2 36
mm 254 838 413 940 787 0 0 13 13 914
SL-750TV-D Inches 10 38-1/4 16-1/4 42 31 0 0 1/2 1/2 36
mm 254 971 413 1067 787 0 0 13 13 914
SL-950TV-D Inches 10 42-1/4 16-1/4 49 31 0 0 1/2 1/2 36
mm 254 1073 413 1245 787 0 0 13 13 914
WARNING
WARNING
Î

11Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
D. Mantel Projections
Figure 3.3 Clearances to Mantels or other
Combustibles above Appliance
1/2 INCH
(13mm)
12 INCHE
S
(305mm)
TOP FRONT EDGE
OF FIREPLACE
12 INCHES
(305mm)
NON-COMBUSTIBLE
MATERIAL ONLY

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/0712
A. Vent Termination Minimum Clearances
Fire Risk.
Explosion Risk.
Maintain vent clearance to combustibles as
specified.
• Do not pack air space with insulation or
other materials.
Failure to keep insulation or other materials
away from vent pipe may cause fire.
Roof Pitch H (Min.) Ft.
Flat to 6/12...........................................................1.0*
Over 6/12 to 7/12.................................................1.25*
Over 7/12 to 8/12.................................................1.5*
Over 8/12 to 9/12.................................................2.0*
Over 9/12 to 10/12...............................................2.5*
Over 10/12 to 11/12.............................................3.25
Over 11/12 to 12/12.............................................4.0
Over 12/12 to 14/12.............................................5.0
Over 14/12 to 16/12.............................................6.0
Over 16/12 to 18/12.............................................7.0
Over 18/12 to 20/12.............................................7.5
Over 20/12 to 21/12.............................................8.0
Figure 4.1 Minimum Height from Roof to Lowest Discharge
Opening
Termination Locations
4
Figure 4.2 Multiple Vertical Termination
Figure 4.1 specifies minimum vent heights for various
pitched roofs.
* 3 foot minimum in snow regions
GAS OR WOOD
TERMINATION 8 FEET
(MINIMUM) TO
PERPENDICULAR
WALL (GAS ONLY)
18 IN.
A
GAS
TERMINATION
VERTICAL
WALL
TERMINATION
CAP
12 X
ROOF PITCH
IS X/ 12
LOWEST
DISCHARGE
OPENING
H (MIN.) - MINIMUM HEIGHT FROM ROOF
TO LOWEST DISCHARGE OPENING
8 FEET
Termination Clearances
Gas Wood
A6 inches 20 inches
WARNING

13Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
5Vent Information and Diagrams
Fire Hazard.
Explosion Risk.
Asphyxiation Risk.
Do NOT connect this gas appliance to a
chimney flue serving a separate solid-fuel or
gas burning appliance.
• Vent this appliance directly outside.
• Use separate vent system for this appliance.
May impair safe operation of this appliance or
other appliances connected to the flue.
CAUTION
ALL vent configuration specifications MUST be followed.
• This product is tested and listed to appliance and vent
manufacturer’s specifications.
• Appliance performance will suffer if specifications are not
followed.
B. Vent System Configuration
Figure 5.1
A. Vent Guidelines
Figure 5.2
Rise to Run Ratio = 2:1
Maximum Total Horizontal Run = 15 Feet
Minimum Total Vertical Rise = 9 Feet
Maximum Total Vertical Rise = 30 Feet
Maximum Number of Elbows: Two 900or Four 450
These models require the following size B-vent double
wall, or single wall rigid or flex vent pipe.
Fire Risk.
Asphyxiation Risk.
This appliance requires the specified pipe for
operation.
• Incorrectpipemaycausespillage,condensation
and overheating.
METAL
PLUMBERS' STRAP
MAXIMUM HORIZONTAL RUN IS 50%
OF VERTICAL. HORIZONTAL RUN
CANNOT BE MORE THAN 15 FT.
VENT SUPPORTS
ARE PER VENT
MANUFACTURER'S
SPECIFICATIONS.
9 FEET
MINIMUM
VENT SUPPORTS ARE PE
R
VENT MANUFACTURER’S
SPECIFICATIONS
MINIMUM CLEARANCES
ARE PER VENT
MANUFACTURER’S
SPECIFICATIONS
• B-vent pipe MUST be used when the vent system is
within combustible construction.
• Single wall rigid or flexible vent may be used ONLY
if the vent system is installed within non-combustible
construction such as a masonry chimney.
• Follow pipe manufacturer’s installation guidelines when
installing the appliance.
Models Pipe Size
SL-550TV-D, SL-550TV-IPI-D 5 inches
SL-750TV-D, SL-750TV-IPI-D 5 inches
SL-950TV-D, SL-950TV-IPI-D 6 inches
WARNING
WARNING

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/0714
Fire Risk.
Explosion Risk.
Insulation and other combustibles must not
infringe on clearances.
• ALWAYS maintainspecifiedclearancesaround
venting and firestop systems.
• Install firestops as specified.
Failure to keep insulation or other material away
from vent pipe may cause fire.
Figure 5.3
45 DEGREES
ELBOW
90 DEGREES
ELBOW
OFFSETS EXCEEDING
45 DEGREES ADAPT
HORIZONTAL LIMITATIONS
MAXIMUM
HORIZONTAL
15 FEET
MINIMUM
VERTICAL
9 FEET
Note: Maximum
horizontal distance
is 50% vertical vent
height.
WARNING

15Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
A. Pipe Clearances to Combustibles
Vent Clearances and Framing
6
Fire Risk.
Explosion Risk.
Maintain vent clearance to combustibles as
specified.
• Do not pack air space with insulation or other
materials.
• National building codes recommend using attic
shield to keep loose materials/insulation from
contacting vent.
Failure to keep insulation or other materials away from vent
pipe may cause fire.
Figure 6.1 Pipe Clearances
CLEARANCE
AROUND VERTICAL
SECTIONS
TOP
CLEARANCE
SIDE AND
BOTTOM CLEARANCE
Follow vent pipe manufacturer’s instructions for all clear-
ances around pipe.
C. Vertical Penetration Framing
Use B-vent manufacturer’s firestops to provide adequate
clearances.
Fire Hazard
Keep loose materials or blown insulation from
touching the vent pipe.
•National building codes recommend using
attic shield to keep loose materials/ blown
insulation from contacting vent.
•Hearth&HomeTechnologies requires the use
of an attic shield.
WARNING
WARNING

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/0716
A. Installing Outside Air Kit Damper Assembly
Appliance Preparation
7CAUTION
Sharp Edges
• Wear protective gloves
and safety glasses dur-
ing installation.
Asphyxiation Risk.
Fire Risk.
Do NOT draw outside combustion air from:
• Wall, floor or ceiling cavity.
• Enclosed space such as an attic or garage.
• Close proximity to exhaust vents or chimneys.
Fumes or odor may result.
• Remove and discard cover plate or knockout from side
of appliance.
• Open air kit damper slightly.
• Locate door hinge toward back of appliance (see Figure
7.1).
• Attach damper assembly to appliance using screws
provided (see Figure 7.2).
• Insert narrow end of handle through tab and into upper
slot of door.
• Check handle operation. Pull handle out to open, and in
to close.
Figure 7.2 Outside Air Kit Installation
Figure 7.1 Damper Assembly and Handle
HANDLE
HING
E
D
OO
R
B. Gas and Electrical Connections
Ifapplicable, ensurethat gasandelectrical connectionsare
installedatthis time. Refer toSections 9 (Gas Information)
and 10 (Electrical Information).
WARNING

17Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
C. Securing and Leveling Appliance
The diagram shows how to properly position, level, and
securethe appliance (seeFigure 7.3). Nailing tabs are pro-
vided to secure the appliance to the framing members.
• Place the appliance into position.
• Level the appliance from side to side and front to back.
• Shimthe appliance, as necessary.It is acceptabletouse
wood shims.
• Bend out nailing tabs on each side.
• Keep nailing tabs flush with the framing.
• Secure the appliance to the framing by using nails or
screws through the nailing tabs. Figure 7.3 Proper Positioning, Leveling and Securing of a
Appliance
Fire Risk.
• Prevent contact with sagging, loose insulation.
•Do NOT install against combustible materials
suchasexposedinsulation,plasticandinsulation
backer.
Do NOT notch into the framing around the appliance
spacers.
CAUTION
WARNING

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/0718
A. Assembly of Vent Sections
This B-Vent appliance requires 5-inch (SL-550/750TV-D)
or6-inch (SL-950TV-D) B-ventdouble-wallpipe. Followthe
pipe manufacturer’s installation guidelines when installing
the unit. This will ensure proper operation and prevent
safety hazards.
Installing Vent Pipe
8
Fire Risk
Exhaust Fumes Risk
Impaired Performance of Appliance
• Assemble pipe sections per B-vent manufac-
turer’s instructions.
• Use support tabs for screws.
• Screws must not exceed one inch long and
must not penetrate inner lining.
• Pipe may separate if not properly joined.
B. Attaching Vent to Firebox
Attach the first B-Vent component to the flue outlet collar
using 3 self-tapping screws. See Figure 8.1.
Figure 8.1
Fire Risk.
Explosion Risk.
Combustion Fume Risk.
Use vent run supports per vent manufacturer’s
installation instructions.
Connect vent sections per vent manufacturer’s
installation instructions.
• Maintain all clearances to combustibles.
• Maintain specified slope (if required).
Improper support may allow vent to sag or
separate.
C. Securing Vent Sections
Secure vent sections with vent supports following B-vent
manufacturer’s instructions.
B-VENT
SECURING
SCREWS
FLUE OUTLET
COLLAR
WARNING
WARNING

19Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/07
NOTE: Have the gas supply line installed in accordance
with local building codes, if any. If not, follow ANSI
223.1. Installation should be done by a qualified installer
approved and/or licensed as required by the locality. (In
the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fitter.)
A. Fuel Conversions
Before making gas connections ensure that appliance be-
ing installed is compatible with the available gas type.
Any natural or propane gas conversions necessary to
meet the appliance and locality needs must be made by
a qualified technician using Hearth & Home Technologies
specified and approved parts.
Fire Risk.
Explosion Hazard.
High pressure will damage valve.
• Disconnect gas supply piping BEFORE
pressure testing gas line at test pressures
above 1/2 psig.
• Close the manual shutoff valve BEFORE
pressuretestinggas line at testpressuresequal
to or less than 1/2 psig.
B. Gas Pressures
Properinput pressures arerequiredfor optimum appliance
performance. Gas line sizing requirements need to be
made following NFPA51.
C. Gas Connection
Verify inlet pressures.
• High pressure may cause overfire condition.
• Low pressure may cause explosion.
• Verifyminimumpressureswhenotherhousehold
gas appliances are operating.
Installregulator upstream of valve iflinepressure
is greater than 1/2 psig.
Gas Information
9
NOTE: Gaslinemayberunfrom either side of the appliance
provided the hole in the outer wrap does NOT exceed 2-1/2
inches in diameter and does not penetrate the firebox.
NOTE: A listed (and Commonwealth of Massachusetts
approved) 1/2 inch (13 mm) T-handle manual shut-off valve
and flexible gas connector are connected to the 1/2 inch (13
mm) control valve inlet.
• If substituting for these components, please consult
local codes for compliance.
NOTE: The gap between the supply piping and gas access
hole may be caulked with high temperature caulk or stuffed
with non-combustible, un-faced insulation to prevent cold
air infiltration.
Refer to Reference Section 16 for location of gas line
access in appliance.
Gas Leak Risk
• Support control when attaching pipe to
prevent bending gas line.
Pressure requirements for appliance are shown in the
table below. Minimum pressure must be met when other
household gas appliances are operating.
Pressure Natural Gas Propane
Minimum Inlet
Pressure 5.0 inches w.c. 11.0 inches w.c.
Maximum Inlet
Gas Pressure 14.0 inches w.c. 14.0 inches w.c.
Manifold Pressure 3.5 inches
w.c. 10.0 inches w.c.
WARNING
WARNING
WARNING

Heat & Glo • SL-550 / 750 / 950TV-D • 2053-985 Rev. J • 4/0720
Fire or Explosion Hazard
• Gas build-up during line purge may ignite.
• Purge should be performed by qualified technician.
• Ensure adequate ventilation.
• Ensure there are no ignition sources such as
sparks or open flames.
Fire hazard.
Explosion Risk.
Do NOT change the valve settings.
• This valve has been preset at the factory.
• Changingvalvesettings may result infirehazard
or bodily injury.
HIGH ALTITUDE INSTALLATIONS
U.L. Listed gas appliances are tested and approved
withoutrequiringchanges for elevationsfrom0 to 2000
feet in the U.S.A. and Canada.
When installing this appliance at an elevation above
2000 feet, it may be necessary to decrease the input
rating by changing the existing burner orifice to a
smaller size. Input rate should be reduced by 4% for
each 1000 feet above a 2000 foot elevation in the
U.S.A., or 10% for elevations between 2000 and 4500
feetinCanada. If theheatingvalue of thegashas been
reduced,these rules donot apply.To identify theproper
orifice size, check with the local gas utility.
If installing this appliance at an elevation above 4500
feet (in Canada), check with local authorities.
• Ensure that gas line does not come in contact with outer
wrap of appliance. Follow local codes.
• Incoming gas line should be piped into the valve com-
partment and connected to the 1/2 inch connection on
the manual shutoff valve.
CHECK FOR GAS LEAKS
Explosion Risk
Fire Risk
Asphyxiation Risk
• Check all fittings and connections.
• Do not use open flame.
•After the gas line installation is complete, all
connections must be tightened and checked
for leaks with a commercially-available, non-
corrosiveleakchecksolution.Besuretorinse
off all leak check solution following testing.
• A small amount of air will be in the gas supply lines.
When first lighting appliance it will take a short time for
air to purge from lines. When purging is complete the
appliance will light and operate normally.
Fittings and connections may have loosened during
shipping and handling.
WARNING
WARNING
WARNING
