Soho®
Direct Vent Gas Fireplace

A. Reective rebox interior
B. Black onyx pebbles replace traditional logs
C. IntelliSwitch100 wall control ships standard
Cover photo: Soho shown with Studio front in brushed nickel nish with glass
Top photo: Soho shown with Studio front in black nish with mesh
Our ideas
your dreams
&
A B C

It’s time to change the way you think about fireplaces—where they
should go and what they should look like. Because now there’s Soho.
It’s not like other fireplaces. Its small, square shape and shallow depth
make creative installation opportunities huge.
Now what you can do with a fireplace
is limited only by your imagination.
Soho
• The smallest and shallowest firebox ever offered by Heat & Glo,
coupled with low heat output, lets you install Soho in places you
never thought possible.
• Sleek modern Soho replaces traditional bricks and
logs with a reflective firebox interior and black onyx
pebbles.
• Install it on a wall, just like a piece of modern art,
framed in a Studio front.
Soho shown with
Studio front with glass
Studio Fronts
Studio front in brushed nickel
with glass
Studio front in brushed nickel
with mesh
Studio front in black with mesh

Soho Features IntelliFire™
Our exclusive, state-of-the-art IntelliFire ignition system reduces gas
consumption by providing a pilot flame only when needed. It also
supplies a back-up battery system to run the fireplace during a power
outage.
Healthy Hearth
Our direct vent fireplaces will not alter the quality of indoor room air
in any way. The sealed combustion chamber draws in fresh air from
outdoors and discards all combustion by-products back outside.
Limited Lifetime Warranty*
The strongest in the industry, Heat & Glo guarantees protection for all
gas units, including a lifetime warranty of the most important aspects:
fiber logs, stainless steel burner, firebox and heat exchanger.
* For full warranty details, go to www.heatnglo.com.
Dimensions above are in inches. Reference dimensions only. We recommend measuring individual units at installation. Assumes the use of 1/2" Sheetrock. NOTE: Non-combustible
material is allowed over this dimension. Make sure you do NOT cover the decorative door opening.
Refer to installation manual for detailed specifications on installing this product. Heat & Glo reserves the right to update units periodically. Actual product appearance, including
flame, may differ from product images..
Soho Specifications
MODEL HEIGHT FRONT WIDTH BACK WIDTH DEPTH GLASS SIZE BTU/Hour Input (NG)
Soho24
Actual Framing Actual Framing Actual Framing Actual Framing
17-1/2 x 19-3/8 14,000
37-3/16 44-3/16 29-1/8 29-5/8 23-1/16 29-5/8 11 11-1/2
Glass Studio Front 32-5/8 32-1/2 3-1/2
20802 Kensington Boulevard, Lakeville, MN 55044
[phone] [phone]
Web: www.heatnglo.com
A brand of Hearth & Home Technologies Inc.
For complete information and valuable assistance on
this model, please contact us at:
SPECIAL FRAMING REQUIRED FOR VERTICAL VENTING,
SEE INSTALLATION MANUAL.
WHEN VENTING TO THE REAR WITH A 90° ELBOW INTO A
2 X 4 EXTERIOR WALL, THE SLK01TRD TERMINATION KIT
IS REQUIRED.
SEE INSTALLATION MANUAL FOR FRAMING REQUIREMENT.
WHEN VENTING
WITH A 90° ELBOW
A HEAT SHIELD
MUST BE USED
Top View Corner Installation
Top View
Front View Side ViewSide View
Glass Studio Front
Reflective firebox interior
Black onyx pebbles
IntelliSwitch100 wall control
Choice of Studio fronts
Energy saving,“green friendly” IntelliFire ignition system
Sealed combustion chamber, top vent
14,000 Btu/Hour Input (NG)
13,000 Btu/Hour Input (LP)
•
•
•
•
•
•
•
•
17-1/2
[445]
19-3/8
[493]
32-5/8
[828]
32-1/2
[826]
2-5/8
[65]
7/8
[22]
