heat-timer NM User manual




Wireless
Enclosure
HT# 059286-00 A

HT# 059286-00 A


TheWirelessEnclosureisusedtohouseanyoftheHeat-TimerWirelessNetworkSystemcomponentsandtheirpowersources
withoutreducingthewirelesssignalstrength.Itisusedprimarilytohelpprotectthewirelesscomponentsfromvandalism.Itis
designedtobemountedindoorsonawalloraceiling.TheprimarycomponentsoftheWirelessEnclosureincludestheBase,the
Cover,andthePlate.
TheBasehasalargenumberofvaryingsizeknockoutsavailableoneachsidetotavarietyofconduitsizes.Itmustbemountedto
thewallorceiling.ThePlatemountstothebaseusing4screws.SeeOppositepagediagram.Ithaspre-drilledholesformounting
theNM(Networkmanager),TRV(Transceiver),orWTM(WirelessTemperatureModule)andthetransformer.Seediagramsbelow.
TheCoversealstheenclosure.Ithasfourplasticscrews.Allscrewsareprovidedaspartofthepackage.
Base
Cover
Plate
Plastic Screws

Plate Screws
Transformer
Transformer
Screws
Plate
Wireless
Device
Wireless
Device Screws

• TheEnclosureisdesignedtobemountedindoorstoeitherawalloraceiling.
• Themountinglocationanddirectionmustmatchthelocationanddirectionassignedbythewirelessmappingsurvey.
• Usetheanchoredscrewsprovidedtomountthebasetothewallorceiling.
• MountthePlatetotheBaseusingthescrewsprovided.Forbestwirelessperformance,makesurethatthewirelessantenna
locationisawayfromthetransformer.
• MountthetransformerandwirelesscomponenttothePlate.
• TheCoverwillmounttotheBaseusingtheplasticscrewsprovided.
Mount Transformer and
Wireless Device using 4 Screws
Mount Plate into
Enclosure using 4 Screws

HT# 059286-00 A
  
Mount Transformer and
Wireless Device using 4 Screws
Mount Plate into
Enclosure using 4 Screws

Knockouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ½",¾",1",1-¼"
Dimensions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  10"x7"x3.5"
Mounting:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . WallorCeilingMount

HT# 059286-00 A
