Heatilator CONSTITUTION C-40 User manual

www.heatilator.com Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
DO NOT DISCARD THIS MANUAL
CAUTION
• Important operating
and maintenance
instructions included.
• Leave this manual with
party responsible for
use and operation.
• Read, understand and
follow these instructions
for safe installation and
operation.
DO NOT
DISCARD
WARNING
If the information in these instruc-
tions is not followed exactly, a
re may result causing property
damage, personal injury, or death.
• Donotstoreorusegasolineorotheram-
mable vapors and liquids in the vicinity of this
or any other appliance.
• Donotoverre-Ifheaterorchimneyconnec-
torglows,youareoverring.Overringwill
void your warranty.
• Comply with all minimum clearances to com-
bustiblesasspecied.Failuretocomplymay
causehousere.
Installation and service of this appliance should
beperformedbyqualiedpersonnel.Hearth&
HomeTechnologiesrecommendsNFIcertied
professionals, or technicians supervised by an NFI
certiedprofessional.
C-40
Fire Risk.
WARNING
For use with solid wood fuel only.
Otherfuelsmayoverreandgenerate
poisonous gases (i.e. carbon monoxide).
CONSTITUTION
EPA CERTIFIED
WOODBURNING FIREPLACE
Owner’s Manual
Installation and Operation
Model:
HOT SURFACES!
Glass and other surfaces are
hot during operation AND
cool down.
WARNING
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in the same room
as appliance
• Alert children and adults to hazards of high
temperatures
High temperatures may ignite clothing or other
ammable materials.
• Keep clothing, furniture, draperies and other
combustibles away.

Page 2 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
Read this manual before installing or operating this appliance.
Please retain this owner’s manual for future references.
Congratulations
Congratulations on selecting a Heatilator wood burning
fireplace. The Heatilator fireplace you have selected is
designed to provide the utmost in safety, reliability, and
efficiency.
As the owner of a new fireplace, you'll want to read and
carefully follow all of the instructions contained in this
Owner's Manual. Pay special attention to all Cautions and
Warnings.
ThisOwner'sManualshouldberetainedforfuturereference.
We suggest that you keep it with your other important
documents and product manuals.
Your new Heatilator wood burning fireplace will give you
years of durable use and trouble-free enjoyment. Welcome
to the Heatilator family of fireplace products!
Model Name: ___________________________________________ Date purchased/installed:__________________
Serial Number:__________________________________________ Location on appliance: ____________________
Dealership purchased from: _______________________________ Dealer Phone: __________________________
Notes: _______________________________________________________________________________________
_____________________________________________________________________________________________
We recommend that you record the following pertinent
information about your appliance.
Homeowner Reference Information
Serial No.
Model Name
Test Lab
& Report No.
Manufactured
Date
Model:
CONSTITUTION
EPA CERTIFIED FIREPLACE
Serial No / Numéro De Série
OMNI-Test Laboratories, Inc.
Report #061-S-40-2
LISTED FIREPLACE, SOLID FUEL TYPE, ALSO SUITABLE FOR MOBILE
HOME INSTALLATION. (UM) 84 HUD.
"For Use with Solid Wood Fuel Only."
Install and use only in accordance with manufacturer's installation, venting and operating instructions.
Any area incorporating warm or cold air ducts shall be enclosed in accordance with the manufacturer's
installation instructions.
Contact Your Local Building Or Fire Officials Or Authority Having Jurisdiction About Restrictions,
Installation Inspection And Permits Required In Your Area.
WARNING - For Mobile Homes: Do not install in a sleeping room. An outside combustion air inlet must
be provided and unrestricted while unit is in use. The structural integrity of the mobile home floor, ceiling
and walls must be maintained. The fireplace needs to be properly grounded to the frame of the mobile
home.
Components required for installation: HTI SLSeries Pipe, Termination Cap, Hearth Extension and required
accessory Chimney Air Kit Part CAK4A.
Do not connect this unit to a chimney serving another appliance.
DANGER: Risk of electrical shock. Disconnect power supply before servicing.
Electrical Rating: 115 VAC <3.0 AMPS 60 Hz
Do not use grate or elevate fire. Build wood fire directly on firebrick.
Do not overfire. If heater or chimney connector glows, you are overfiring.
Do not use a fireplace insert or other products not specified for use with this product.
WARNING - THIS FIREPLACE HAS NOT BEEN TESTED WITH AN UNVENTED GAS LOG SET OR ANY LOG SET.
TO REDUCE RISK OF FIRE OR INJURY, DO NOT INSTALL AN UNVENTED GAS LOG SET OR ANY LOG SET INTO
FIREPLACE.
Must provide a source of air to prevent air starvation from combustion which could result of high levels of
carbon monoxide.
Replace glass only with 5mm ceramic available from your dealer.
Optional Fire Screen Part Mesh-EPA, may be used ONLY in USA
Chimney sections at any level require a 2” (51mm) minimum
air space clearance between the framing and chimney section.
Minimum Clearances To Combustible Material
WITHIN ENCLOSURE AREA
Appliance to backwall 1" (25mm)
Appliance to sidewall 1" (25mm)
Duct boots to framing 0" (0mm)
Top standoffs to header 0" (0mm")
EXPOSED SURFACES
Faceplate to sidewall 16" (406mm)
Remote outlet air grills to ceiling 12"(305mm)
MANTEL
Mantel from base of fireplace 60" (1524mm)
Maximum mantel depth 12" (305mm)
FLOOR PROTECTION
Combustible flooring 20" (508mm) in front of and 8" (203mm) to
either side of the fuel opening must be insulated with
non-combustible floor protection with a minimum thickness of 1"
(25mm) and ("k" value = 0.43
).
In Canada: The hearth extension must be installed according to
the installation instructions.
U.S. ENVIRONMENTAL PROTECTION AGENCY - Certified to comply with July 1990 particulate emission standards.
2008 2009 2010 Jan Feb Mar Apr May June July Aug Sept Oct. Nov. Dec.
Made in U.S.A
DO NOT REMOVE THIS LABEL 480-1110
Mfg by:
www.heatilator.com
TESTED TO
UL 127, ULC-S610-M87
SAMPLE
007
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
Listing Label Information/Location Themodelinformationregardingyourspecicappliancecan
be found on the rating plate usually located in the control
area of the appliance.

Section 1: Listing and Code Approvals
A. ApplianceCertication ....................4
B. MobileHomeApproved....................4
C. GlassSpecications ......................5
D. BTU&EfciencySpecications .............5
Section 2: Getting Started
A. Design and Installation Considerations. . . . . . . .6
B. Negative Pressure. . . . . . . . . . . . . . . . . . . . . . . .6
C. Typical Fireplace System . . . . . . . . . . . . . . . . . .8
D. Tools and Supplies Needed . . . . . . . . . . . . . . . .9
E. Inspect Fireplace and Components . . . . . . . . . .9
Section 3: Framing and Clearances
A. Selecting Fireplace Location. . . . . . . . . . . . . . .10
B. Clearances............................11
C. Frame the Fireplace . . . . . . . . . . . . . . . . . . . . .12
D. Electrical Access and Wiring Diagram . . . . . . .13
E. Construct the Chase . . . . . . . . . . . . . . . . . . . . .14
Section 4: Installation of Fireplace
A. InstalltheOutsideAirKit..................15
B. Secure the Fireplace. . . . . . . . . . . . . . . . . . . . .17
Section 5: Chimney Assembly
A. Chimney Requirements. . . . . . . . . . . . . . . . . . .20
B. Chimney Termination Requirements . . . . . . . . .20
C. UsingOffsets/Returns ....................21
D. Assemble the Chimney Sections . . . . . . . . . . .22
E. Assembling Chimney Sections
forSL-300Series .......................22
F. Install the Ceiling Firestops. . . . . . . . . . . . . . . .23
G. Install the Attic Insulation Shield . . . . . . . . . . . .24
H. Double-check the Chimney Assembly. . . . . . . .24
I. Secure the Chimney . . . . . . . . . . . . . . . . . . . . .24
Section 6: Complete the Enclosure
A. Chimney Termination (2-10-3 Rule) . . . . . . . . .25
B. SL-300SeriesCeiling/RoofThimble .........27
C. ChaseTop.............................28
D. Install the Termination Cap . . . . . . . . . . . . . . . .28
Section 7: Accessories
A. Fan Replacement . . . . . . . . . . . . . . . . . . . . . . .30
B. BafeRemovalandInstallation. . . . . . . . . . . . .31
C. Door and Door Gasket . . . . . . . . . . . . . . . . . . .31
D. HeatZoneKit ..........................32
E. Timer Assembly Replacement . . . . . . . . . . . . .35
F. ManualTimerOverride ...................37
Section 8: Finishing
A. Hearth Extension. . . . . . . . . . . . . . . . . . . . . . . .38
B. Alternate Floor Protection Worksheet . . . . . . . .38
C. Position the Hearth Extension. . . . . . . . . . . . . .41
D. FinishingMaterial .......................41
E. Non-CombustibleFacingMaterialInstallation. .42
F. Mantel ................................43
Section 9: Operating Instructions
A. Over-ringYourAppliance. . . . . . . . . . . . . . . . .44
B. General Information . . . . . . . . . . . . . . . . . . . . .44
C. OutsideAir. . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
D. Clear Space Near the Fireplace . . . . . . . . . . . .46
E. Firescreen.............................46
F. GlassDoors ...........................46
G. FanOperation ..........................46
H. HeatZoneOperation. . . . . . . . . . . . . . . . . . . . .46
I. WoodFuel.............................47
J. StartingaFire..........................48
K. CorrectBafe&BlanketPlacement .........50
L. BurningProcess........................51
M. AutomaticCombustionControl(ACC) . . . . . . .51
N. Burning Guidelines . . . . . . . . . . . . . . . . . . . . . .52
O. BurnRates ............................52
P. Opacity ...............................52
Q. Overring..............................53
R. ChimneyFire...........................53
Section 10: Troubleshooting
A. Understanding Vent Problems . . . . . . . . . . . . .54
B. DraftProblems .........................54
C. Diagnostics and Problem Solving . . . . . . . . . . .56
Section 11: Maintenance and Servicing the
Fireplace
A. GeneralMaintenance ....................58
B. Glass Replacement. . . . . . . . . . . . . . . . . . . . . .59
C. Brick Replacement . . . . . . . . . . . . . . . . . . . . . .60
D. Care and Cleaning of Plated Surfaces . . . . . . .61
E. MaintenanceTaskList....................61
F. Service&MaintenanceLog ...............62
Section 12: Reference Materials
A. Fireplace Dimensions . . . . . . . . . . . . . . . . . . . .63
B. Chimney Components. . . . . . . . . . . . . . . . . . . .64
C. PartsDiagrams.........................66
D. ServiceParts...........................67
E. WarrantyPolicy.........................70
F. Contact Information. . . . . . . . . . . . . . . . . . . . . .72
TABLE OF CONTENTS
November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 3

Page 4 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
1 Listing and Code Approvals
A. Appliance Certication
This appliance is approved for mobile home installations
when not installed in a sleeping room and when an outside
combustion air inlet is provided. The structural integrity of
themobilehomeoor,ceiling,andwallsmustbemaintained.
Thereplacemustbeproperlygroundedtotheframeofthe
mobile home and use only listed double-wall connector pipe.
OutsideAirmustbeinstalledinamobilehomeinstallation.
B. Mobile Home Approved
An outside air termination cap is supplied with your
Constitution Fireplace for installation in a mobile home.
If you use an alternative material it must be designed to
prevent material from dropping into the area beneath
the mobile home, and to prevent rodents from entering
from the outside.
This replace system has been tested and listed in
accordance with UL127 and ULC-S610-M87 standards,
and has been listed by OMNI Test Laboratories, Inc., for
installation and operation in the United States and Canada
asdescribedinthismanual.Thisreplacehasbeentested
and listed for use with the SL-300 Series chimney (with
thetheCAK4AAirKit)andreplace components listedin
Section 12.
Check with your local building code agency before you begin
your installation to ensure compliance with local codes,
including the need for permits and follow-up inspections. Be
surelocalbuildingcodesdonotsupersedeULspecications
and always obtain a building permit so that insurance protec-
tionbenetscannotbeunexpectedlycancelled.
1. An outside air inlet must be provided for combustion and
must remain clear of leaves, debris, ice and/or snow. It
must be unrestricted while unit is in use to prevent room air
starvation which can cause smoke spillage and an inability
tomaintainare.Smokespillagecanalsosetoffsmoke
alarms.
2.Thereplaceistobesecuredtothemobilehomestructure.
Usesameholesthatattachedthereplacetothepalletto
secureittotheoorusing1/4in.x2in.(6mmx51mm)
lag bolts or equivalent.
3. Unit must be grounded with #8 solid copper grounding
wire or equivalent and terminated at each end with N.E.C.
approved grounding device.
4. RefertoMinimumClearancestoCombustiblesonpages
11-12 and chimney components on pages 64-65.
5. Floor protections requirements on pages 38-40 must be
followed precisely.
6. Use silicone to create an effective vapor barrier at the
location where the chimney or other component penetrates
to the exterior of the structure.
7. Follow the chimney and chimney connector manufacturer’s
instructionswheninstallingtheuesystemforuseinamobile
home.
8. If unit burns poorly while an exhaust fan is on in home,
(i.e., range hood), increase combustion air.
NOTE: Top sections of chimney must be removable to
allow maximum clearance of 13.5 ft (411 cm) from ground
level for transportation purposes.
Fire Risk.
WARNING
For use with solid wood fuel only.
Otherfuelsmayoverreandgenerate
poisonous gases (i.e. carbon monoxide).
CAUTION
Maintainstructuralintegrityofmobilehome:
• Floor,wall,ceilingand/orroof.
DoNOTcutthrough:
• Floor joist, wall, studs or ceiling trusses.
• Any supporting material that would affect the structural
integrity.
• Never install in a sleeping room.
Consumes oxygen in the room.
WARNING
Asphyxiation Risk.
Model: ConstitutionEPACertied
Woodburning Fireplace
Laboratory: OMNITestLaboratories,Inc.
Report No: 061-S-50-2
Type: Wood Fireplace
Standard: UL127andULC-S610-M87and
(UM)84-HUD,MobileHome
Approved.

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 5
Improper installation, adjustment, alteration, ser-
vice or maintenance can cause injury or property
damage. Refer to the owner’s information manual
providedwiththisreplace.Forassistanceoraddi-
tionalinformationconsultaqualiedinstaller,service
agency or your dealer.
WARNING
C. Glass Specications
D. BTU & Efciency Specications
Thisreplaceisequippedwith5mmceramicglass.Replace
glass only with 5mm ceramic glass. Please contact your
dealer for replacement glass.
NOTE: This installation must conform with local codes. In the
absence of local codes you must comply with the UL1482, (UM)
84-HUD and NFPA211 in the U.S.A. and the ULC S627 and
CAN/CSA-B365 Installation Codes in Canada.
Hearth&HomeTechnologiesdisclaimsanyresponsibility
for, and the warranty and agency listing will be voided by
the above actions.
Fire Risk
• Do not installoroperatedamagedreplace.
• Do notmodifyreplace.
• InstallationotherthanasinstructedbyHearth&
Home Technologies Inc. is strictly prohibited.
• Do notoperatethereplacewithoutfullyassembling
all components.
• Do not overre.
• Do not install an unvented gas log set. This
replacehasnotbeentestedforusewithunvented
gas log sets.
• Installationand/oruseofanycomponentpartnot
approvedbyHearth&HomeTechnologies.
WARNING
NOTE: Hearth&HomeTechnologies,manufacturerof
this appliance, reserves the right to alter its products,
theirspecicationsand/orpricewithoutnotice.
EPA Certied: 3.25 grams per hour
Efciency: up to 77.8%
BTU Output
with EPA test fuel:
with cord wood:
51,400/hr.
70,000/hr
Vent Size: 8 inches
Firebox Size: 2.7 cubic feet
Max Wood Length: 24 inches
Fuel: Cord Wood
Shipping Weight: 650 lbs

Page 6 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
2 Getting Started
A. Design and Installation Considerations
Draft is the pressure difference needed to vent replaces
successfully.Considerationsforsuccessfuldraftinclude:
• Preventing negative pressure
• Locationofreplaceandchimney
B. Negative Pressure
Negative pressure results from the imbalance of air avail-
able for the replace to operate properly. Causes for this
imbalanceinclude:
• Exhaust fans (kitchen, bath, etc.).
• Range hoods.
• Combustion air requirements for furnaces, water heaters
and other combustion appliances.
• Clothes dryers.
• Location of return-air vents to furnace or air
conditioning.
• Imbalances of the HVAC air handling system.
Asphyxiation Risk
Negative pressure can cause spillage of
combustion fumes and soot. Fire needs to draft
properly for safe operation.
WARNING
Check building codes prior to installation.
• Installation MUST comply with local, regional,
state and national codes and regulations.
• Consult insurance carrier, local building inspector,
reofcialsorauthoritieshavingjurisdictionabout
restrictions, installation inspection and permits.
CAUTION
Whenplanningareplaceinstallation,itisnecessarytode-
termine the following information beforeinstalling:
• Where the fireplace is to be installed. See Sections
3 and 4.
• Theventsystemcongurationtobeused.SeeSections
5 and 6.
• Electrical wiring. See Section 3.
• Framingandnishingdetails.SeeSections3,6and8.
• Whether optional accessories are desired. See
Section 12.
TheConstitutionFireplacerequiresaminimumuedraftof
-0.10 inches of water column on High, and -0.04 inches of
watercolumnonLow,asmeasuredwithadraftmeter.Most
dealershavedraftmetersavailabletomeasureyouruedraft
if you suspect a problem.
Ifthereisdifculttostart,andsmokespillsoutofthedoor,
or you nd it hard to establish and maintain a moderately
highburnrate,thentheuedraftistoolowandcorrective
measures must be taken.
NOTE: Cold air inltration can cause frosting on glass.
• Upper level air leaks: recessed lighting, attic hatch
opening, duct leaks.
To minimize the effects of negative air pressure, the follow-
ingmustbeconsidered:
• Install the outside air kit.
• Ensure adequate outdoor air is supplied for combustion
appliances and exhaust equipment.
• Ensure furnace and air conditioning return vents are not
locatedintheimmediatevicinityofthereplace.
• Avoidinstallingthereplaceneardoors,walkwaysorsmall
isolated spaces.
• Recessed lighting should be a “sealed can” design; attic
hatches weather stripped or sealed; attic mounted duct
work and air handler joints and seams taped or sealed.
Locationofthereplaceandchimneywillaffectperformance.
AsshowninFigure7.1,onpage7,thechimneyshould:
• Be installed through the warm airspace enclosed by the
building envelope. This helps to produce more draft,
especiallyduringlightinganddie-downofthere.
• Penetrate the highest part of the roof. This minimizes the
effects of wind turbulence.
• Be located away from trees, adjacent structures, uneven
roof lines and other obstructions.
Offsetscanrestrictdraftsotheiruseshouldbeminimized.
Consider the replace location relative to oor and ceiling
and attic joists.

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 7
Figure 7.1 Recommended Chimney Locations
Recommended
Location
Marginal
Location
Location
Not
Recommended
Recommended
Location
Location NOT
Recommended
Multi-level Roofs
Windward
Leeward

Page 8 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
Figure 8.1 Typical Fireplace System
Note: Junction box should be installed during initial setup
NOTE: Illustrations used throughout these instructions
reect“typicalinstallations”andare for designpurposes
only. Actual installation may vary slightly due to individual
design preferences. However, minimum clearances must
be maintained at all times.
The illustrations and diagrams used throughout these instal-
lation instructions are not drawn to scale.
C. Typical Fireplace System
TheHeatilatorreplacesystemconsistsofthefollowing:
• Fireplace
• Firebrick
• Chimney termination cap
• Chimney system
• Hearth extension
• Outsideair
Requiredcomponentsinclude:
• Chimney Air Kit (with SL 300 Series Pipe)
Optionalcomponentsinclude:
• Firescreen
• Lintel Bar
• Heat Zone Kit
• Top Vent Kit
to avoid major reconstruction.
Termination Cap
Chimney penetrates roof
preferably without affecting
roof rafters
Offset/Return
(with hanger straps)
Attic insulation shield
(not shown) must be
used here to keep
insulation away
from chimney if
attic is insulated
Storm Collar
Framing headed
off in ceiling joists
Mantel
Decorative facing
and trim
Protective metal
hearth strip(s)
Hearth extension
Factory-built fireplace
Non-combustible
roof flashing maintains
minimum clearance
around chimney
Additional lateral
support for chimney
above roof (or enclosed
in chase) if needed
Chimney system
Combustible
framing/header
on top of V-shaped
standoffs (spacers)
Enclosed space above
and around fireplace
Support straps
on rafter supports
chimney (not shown)
Outside
combustion air
Outside
combustion air

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 9
Before beginning the installation be sure the following tools
andbuildingsuppliesareavailable:
Reciprocating saw Framing material
Pliers High temp caulking material
Hammer Gloves
Phillips screwdriver Framing square
Flat blade screwdriver Electric drill and bits
Plumb line Safety glasses
Level Tape measure
1/2-3/4in.length,#6or#8self-drillingscrews
Misc.screwsandnails
• Keepreplacedry.
• Moldorrustmaycauseodors.
CAUTION
E. Inspect Fireplace and Components
• Carefullyremovethereplaceandcomponentsfromthe
packaging.
• Doorsareshippedonthereplace.
• Report to your dealer any parts damaged in shipment.
Fire Risk
Explosion Risk
Inspect fireplace and components for
damage. Damaged parts may impair safe
operation.
• DoNOTinstalldamagedcomponents.
• DoNOTinstallincompletecomponents.
• DoNOTinstallsubstitutecomponents
Report damaged parts to dealer.
WARNING
D. Tools and Supplies Needed
Fire Risk.
WARNING
• Do not operate appliance before reading and
understanding operating instructions.
• Failure to operate appliance properly may
causeahousere.

Page 10 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
3 Framing and Clearances
A. Selecting Fireplace Location
Several options are available to you when choosing a loca-
tionforyourreplace.Thisreplacemaybeusedasaroom
divider, installed along a wall, across a corner or used in an
exterior chase. See Figure 10.1.
Locatingthereplaceinabasement,nearfrequentlyopened
doors, central heat outlets or returns, or other locations
Figure 10.1 Fireplace Locations
Fire Risk
Provide adequate clearances.
• Around air openings
• To combustibles
• For service access.
Locatereplaceawayfromtrafcareas.
WARNING Note:
• Illustrationsandphotosreecttypicalinstallationsand
are FORDESIGNPURPOSESONLY.
• Illustrations/diagramsarenotdrawntoscale.
• Actualinstallation/appearancemayvaryduetoindividual
design preference.
• Hearth&HomeTechnologiesreservestherighttoalter
its products.
of considerable air movement can affect the performance
and cause intermittent smoke spillage from the front of the
replacewhennooutsideairisused.Outsideairmustbe
used for combustion. The Constitution comes equipped with
an outside air inlet to feed combustion air from outside the
home, along with an outside air termination cap. Consider-
ation should be given to these factors before deciding on a
location. See Sections 2 and 10.
Model:
Constitution
(Dimensions for
nished walls)
A B C D E F G H I
in. 41-7/8 16 89-1/2 63-5/16 22-7/16 44-3/4 14-1/16 55-15/16 50-7/8
mm 1063 406 2273 1608 570 1137 357 1421 1292
D
C
A
E
F
A
H
G
B
A
B
B
A
I
In an exterior chase
or projecting into a
garage
Across a corner
Along a wall
As a
room
divider
24 in.
(610mm)
24 in.
(610mm)
24 in.
(610mm)
48 in.
(1219mm)
Note: A minimum 1 in. air clearance must be maintained at the back
andtothesidesofthereplaceassembly.
Chimney sections at any level require a 2 in. minimum air
space clearance between the framing and chimney sections.
Note: In addition to these framing dimensions, also reference the
followingsections:
• Clearances (Section 3.B.)
•Mantel(Section8.F.)
• Fireplace Dimensions (Section 12.A.)

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 11
B. Clearances
Figure 11.1 Clearances to Combustible Materials
Fire Risk
• Complywithallminimumclearancestocombustiblesasspecied.
• Framingornishingmaterialusedonthefrontof,orinfrontof,the
appliance closer than the minimums listed, must be constructed entirely
of non-combustible materials (i.e., steel studs, concrete board, etc.).
Failuretocomplymaycausere.
WARNING
2 in. (51 mm) min.
Attic
Insulation
Shield
Ceiling Firestop
(ceiling)
(roof)
(attic)
(ceiling)
Ceiling Firestop Offset/Return with
hanger straps
Storm Collar
Roof Flashing
2 in. (51 mm) min.
2 in. min.
(51 mm)
Must have 2 in. (51 mm)
minimum clearance
to header
2 in. (51 mm) min.
2 in. (51 mm) min. 2 in. (51 mm) min.
2 in. (51 mm) min.
1 in. (25mm) to side of appliance
(except at nailing flanges where it is 1/2 in. [13 mm])
1 in. (25 mm) to back
of appliance
0 in.
to floor
0 in. to level
of standoffs

Page 12 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
Figure 12.1 Framing the Fireplace
WITHIN ENCLOSURE AREA:
Appliance to backwall 1 in. (25 mm)
Appliance to sidewall 1 in. (25 mm)
Duct boots to framing 0 in. (0 mm)
Top standoffs to header 0 in. (0 mm)
Dooropeningtosidewall22-7/8in.(581mm)
EXPOSED SURFACES
Faceplate to sidewall 16 in. (406 mm)
Heat zone air grills to ceiling 12 in. (305 mm)
MANTEL
Combustible and non-combustible mantel minimum height
frombaseofreplacetoundersideofmantel
60 in. (1524 mm)
Maximummanteldepth   12in.(305mm)
C. Frame the Fireplace
NOTE: Wiring for fans must be done before framed
enclosure is completed. If using a Heat Zone kit, it also
must be installed before enclosure is complete.
TheConstitutionFireplacewilltaframedopeningheightof
43-7/8in.(1114mm)tallandwidthof42in.(1067mm).The
nishedcavitydepthmustbenolessthan24in.(610mm).
Framing must extend straight up all the way to the ceiling.
Figure 12.1 shows a typical framing (using 2 x 4 lumber)
ofthereplace,assumingcombustiblematerialsareused.
Allrequiredclearancestocombustiblesaroundthereplace
must be adhered to. See Figure 11.1, on page 11. Any fram-
ingacrossthetopofthereplacemustbeabovethelevelof
the top standoffs. (No recess above standoffs.)
OPTIONAL FRAMING CONSTRUCTION / REDUCED
MANTEL HEIGHT:
Non-combustible mantel material minimum height from base
ofreplacetoundersideofmantel46in.(1168mm)whenthe
followingenclosureconstructionmaterialsareused:
Non-combustibleframingmaterialsmustbeusedabovere-
placetoheightof84in.(2134mm)frombaseofreplacefor
all construction materials, framing members, sheeting, and
allnishmaterials.
CHIMNEY SECTIONS
Chimney sections at any level require a 2 in. (51 mm) mini-
mum air space clearance between the framing and chimney
section.
Fire Risk
Hearth & Home Technologies is not respon-
sible for discoloration, cracking or other mate-
rialfailuresof nishing materialsdueto heat
exposure or smoke.
• Choosenishingmaterialscarefully.
WARNING
1. Minimum Clearances to Combustibles
Materialswhichwillnotigniteandburn.Suchmaterialsare
those consisting entirely of steel, iron, brick, tile, concrete,
slate, glass or plasters, or any combination thereof.
MaterialsthatarereportedaspassingASTME136,Stan-
dard Test Method for Behavior of Materials, in a Vertical
Tube Furnace at 750°C, shall be considered non-combus-
tible materials.
Materialsmadeoforsurfacedwithwood,compressedpaper,
plantbers,plastics,orothermaterialsthatcanigniteand
burn,whetherameproofedornot,orwhetherplasteredor
un-plastered shall be considered combustible materials.
Non-Combustible Materials
Combustible Materials
Fire Risk
• Non-combustible mantels installed at a
reducedheightmayGETEXTREMELY
HOTduringuseofthereplace.
• DONOTTOUCHorplaceheatsensitive
combustible items on the mantel.
WARNING
12 in.
(305mm)
42 in.
(1067mm)
43-7/8 in.
(1114mm)
24 in.
(610mm)
2 in.
(51mm)
Position combustible /
non-combustible mantel
60 in. (1524mm) from
base of the replace

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 13
Fire Risk
Donotapplycombustiblenishingmaterials
overanypartofthefrontofthisreplace.
• The metal replace face may only be
covered with noncombustible materials
such as ceramic tile, brick, or stone.
• Do not cover or block any cooling air
slots.
The decorative fascia must be removable
for future serviceability of the Automatic
Combustion Control.
WARNING
Fire Risk
Comply with all minimum clearances speci-
ed.
• A minimum 1/2 in. (13mm) air clearance
must be maintained at the back and 1
in. (25mm) to the sides of the fireplace
assembly.
• Chimney sections at any level require a 2
in. (51mm) minimum air space clearance
between the framing and chimney section.
WARNING
D. Electrical Access and Wiring Diagram
NOTE: The manual override switch, rheostat
speed control and cover plate are supplied. You
willneedtosupply:14-3wirewithground;14-2
wire with ground; standard wall mount junction
box; wire nuts.
1. Remove junction box cover plate on the
bottomrightsideofthereplace.
2. Thread the 14-3 with ground wire through
the opening with the strain relief on the cover
plate.
3. Match colors to wire harness, (red to red,
white to white, etc) and secure with wire
nuts.
NOTE: Wiring for fans must be done before
framed enclosure is completed. If using a
Heat Zone kit, it also must be installed before
enclosure is complete. Figure 13.2 Fan Wiring Diagram
14-2 w/ground
Standard wall mount with
Junction Box
14-3 w/ground
WIRE NUT
WHITE
GREEN
BLACK
BLACK
RED
WHITE
Match colors to wire
harness (red to red,
white to white, etc) and
secure with a wire nut
Incoming Power
(110V)
Power to the Fireplace
Snap Disc
bypass switch
Suggestions:
1. Insulate chase.
2. Finishchasewallswithdrywall5/8in.(16mm)TypeX
face tape.
3. Alldimensionsaretonishedwallsandceilings.
Figure 13.1 Sheetrocked Chase
Fire Risk
• Maintainclearances.
• Use only non-combustible material below
standoffs, material such as cement board
is acceptable.
WARNING
• Framingornishingmaterialusedonthefront
of, or in front of, the appliance closer than the
minimums listed, must be constructed entirely of
noncombustible materials (i.e., steel studs, concrete
board, etc.).

Page 14 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
E. Construct the Chase
Achaseisaverticalboxlikestructurebuilttoenclosethere-
placeand/oritsventsystem.Verticalchimneysthatrunon
the outside of a building must be installed inside a chase.
In cold climates, it is recommended that the chase insulated
using batt type insulation between the joists.
Construction of the chase may vary with the type of build-
ing. These instructions are not substitutes for the require-
mentsoflocalbuildingcodes. LocalbuildingcodesMUST
be checked.
Chases should be constructed in the manner of all outside
walls of the home to prevent cold air drafting problems. The
chase should not break the outside building envelope in any
manner. All outer walls need to be insulated.
Buildingcodesrequirefalseceilingandceilingrestopsat
each oor of the chase or every 10 ft (3048 mm) of clear
spacetocontrolspreadofre.
Walls,ceiling,baseplateandcantileveroorattherstlevel
of the chase should be insulated. See Figure 14.1. Vapor
andairinltrationbarriersshouldbeinstalledinthechase
as per regional codes for the rest of the home. Additionally,
Hearth& HomeTechnologies recommends that the inside
surfaces be sheet rocked and taped (or the use of an equiv-
alent method) for maximum air tightness.
Holes and other openings should be caulked with high tem-
peraturecaulkorstuffedwithunfacedberglassinsulation.
Ceiling
Firestop
Metal Chase Top
Round Termination Cap
False Ceiling
Insulation in the
outside walls
of the chase
Attic
Insulation
Shield
Chimney
Ceiling
Firestop
Tabs
False Ceiling
False Ceiling
Insulation
Insulation
Storm Collar
Figure 14.1 Chase Assembly
1 2 3
All outside walls should be insulated.
Figure 14.2 Chase Constructions
1. Fireplace and chimney enclosed in an exterior chase.
2. Chimney offset through exterior wall and enclosed in
chase.
3. Chase constructed on roof.
Materials
a. The chase is constructed using framing materials
much the same as the walls in your home. A variety
of siding materials may be used including brick, stone,
veneer brick, or standard siding materials.
b. In constructing the chase, several factors must be
considered:
1) Maintaina2in.(51mm)airspacearoundthe
chimney.
2) The chase top must be constructed of non-com-
bustible material.
3) In cold climates, a restop spacer should be
Three examples of chase applications are shown in Fig-
ure 14.2.
Fire Risk
• DO NOT pack insulation or other
combustibles:betweenceilingrestops;
between chimney and attic insulation
shield.
WARNING
• ALWAYSmaintainspeciedclearancesaroundchimney
andceilingrestopsystems.
• Installceilingrestopsasspecied.
Failure to keep insulation or other material away from
chimneypipemaycausere.
installed in an insulated false ceiling at the 8 ft.
(2438mm)levelabovethereplaceassembly.
This reduces heat loss through the chase.
4) In cold climates, the walls of the chase should
be insulated to the level of the false ceiling as
shown in Figure 14.1. This will help reduce heat
lossfromthehomearoundthereplace.

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 15
A. Install the Outside Air Kit
Thisreplacewilloperatecorrectlyonlyifadequateventila-
tionisprovidedtoallowproperdrafttothereplacesystem.
See Section 2.
Using an outside air kit must be used for combustion to mini-
mize the effects of negative pressure within the structure.
We recommend you utilize the shortest duct run to optimize
the performance of the outside air kit. The outside air kit inlet
should be positioned in a manner that will not allow snow,
leaves, etc. to block the inlet. In some installations the air
duct may need to be run vertically. In such an installation, a
3 ft (914 mm) height difference must be maintained from the
top of the uppermost chimney section to the outside com-
bustion air inlet. See Figure 16.1 on page 16.
See Figure 17.1 on page 17 for proper placement of outside
air inlet.
The outside air kit is installed on the right hand side of the
replace.SeeFigure15.1forhandlelocation/operation.
4 Installation of Fireplace
Figure 15.1 Outside Air Installation
1. Cut a 6 in. (152 mm) hole in outside wall to accommodate
air piping. The outside air is located on top, auxiliary
convection air intake is located on the bottom. See Figure
15.1.
2. Use6in.(152mm)metalexorrigidpiping(not supplied)
todirectlyconnectoutsideairtoreplaceintake.Insulate
the pipe to prevent frost condensation.
3. Use the supplied termination caps.
4. Seal between the wall and the pipe with silicone to prevent
moisture penetration and air leaks.
5. Seal between the termination cap and the house with
siliconetopreventairinltration.
NOTE: A control knob allows you control of the outside air
inlet. Use of outside air for combustion is required to
conserve heated air within the structure and to provide
makeupairtokeepthereplaceventingproperly.
IMPORTANT!
TURN COUNTER-CLOCKWISE TO “OPEN”
POSITION.
OUTSIDE AIR KNOB MUST BE IN THE “OPEN” POSI-
TION TO OPERATE FIREPLACE PROPERLY.
MAY BE CLOSED WHEN NOT IN USE TO PREVENT
COLD AIR INFILTRATION.
Termination Cap
supplied with
fireplace
6 in. (152mm) rigid
or flex pipe
Open/Close
Knob for
outside air
CLOSE
OPEN
CAUTION
Sharp Edges
• Wear protective gloves
and safety glasses during
installation.

Page 16 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
Risk of Smoke Spillage
Outside air inlet must be located to prevent blockage
from:
• Leaves
 • Snow/ice
 • Otherdebris
Blockage may cause combustion air starvation.
CAUTION
Fire Risk
Asphyxiation Risk
Donotdrawoutsidecombustionairfrom:
• Wall,oororceilingcavity.
• Enclosed space such as an attic or
garage.
• Close proximity to exhaust vents or
chimneys.
Fumes or odor may result.
WARNING
Figure 16.1 Outside Air Inlet Locations
Attic insulation shield
must be used to keep
insulation away from
chimney.
Ceiling firestop
on floor of attic.
3 ft min. from top of
uppermost chimney
section to air inlet.
Figure 16.2 Locating the Outside Air Control
Handle Left - Closed
Handle Right - Open

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 17
Figure 17.1 Outside Combustion Air Placement
Outlet blocked by
snow, leaves, etc.
NO
Garage or
combustible
liquids storage
NO
Attic space
NO
Outlet placed
higher than 3 ft
below the
termination cap
NO
Use only duct materials
specified by manufacturer
Note: When elevating the fireplace above the hearth
extension the front of the elevated platform must be
protected with a protective metal hearth strip (not included)
as shown in Figure 18.2.
• Place the Protective Metal Hearth Strips
Included with your replace you will nd two metal
hearth strips measuring approximately 23 in. x 4 in.
(584 mm x 102 mm). These strips are used to provide
addedprotectionwherethereplaceandthehearthex-
tension meet.
Slide each metal strip 2 in. (51 mm) under the front edge
ofthereplace.Theindividualpiecesmustoverlapeach
otherby1in.(25mm)minimuminthemiddleofthere-
place to provide continuous coverage of the oor. See
Figure 18.1. These metal strips should extend from the
frontandsidesofthereplaceopeningby2in.(51mm).
Screw metal strips in place.
Fire Risk!
• Prevent contact with sagging, loose
insulation.
• DoNOTinstallagainstvaporbarriersor
exposed insulation.
WARNING
Fire Risk!
• MetalhearthstripsMUST be installed.
Sparksorembersmayigniteooring.
WARNING
B. Secure the Fireplace
• Position the Fireplace
Thisreplacemaybeplacedoneitheracombustibleor
noncombustible continuous at surface. Follow the in-
structionsforframinginSection3.C.Slidethereplace
into position. Be sure to provide the minimum 1 in. air
clearance at the sides and at back of the replace as-
sembly. See Section 3.B.
CAUTION
Sharp Edges
• Wear protective gloves
and safety glasses during
installation.

Page 18 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
• Level the Fireplace
Levelthereplace side-to-side andfront-to-back.Shim
with noncombustible material, such as sheet metal, as
necessary.Securethereplace(usingthepalletmount-
ingbracketslocatedoneithersideofthereplace)tothe
verticalsuboor.
Raised Platform
Floor
2 in.
(51 mm)
1 in. (25 mm) min.
overlap
2 in.
(51 mm)
T
op p
i
ece must over
l
ap
bottom piece
Nail or screw metal strips in place.
Figure 18.2 Protect the Front of an Elevated Platform
Figure 18.1 Position the Protective Metal Hearth Strips
Metal strips 2 in. (51mm) under edge of
Fireplace and Hearth Extension and 2 in.
(51mm) on both side of fireplace opening.
Nail or screw metal strips in place.
PalletMounting
Brackets
1in.(25mm)Overlap

November 11, 2008 Heatilator • Constitution EPA Fireplace • 480-1091C Page 19
NOTE:
•Chimney performance may vary.
•Trees, buildings, roof lines and wind conditions affect
performance.
•Chimney height may need adjustment if smoking or
overdraft occurs.
Chimney must extend
beyond combustible
roof structure
Maintain minimum
height of chimney
above roof
Additional
support for
tall chimneys
Install roof flashing
according to minimum
requirements
Maintain minimum
clearances to
combustibles as
specified
Offsets/returns
may not exceed
30° from vertical
Ceiling firestops
are required where
chimney passes
through ceiling or
fl
oo
r
Support straps for offsets/
returns must be secured
to adequate framing
Termination
C
ap
Storm Collar
Figure 19.1 Typical Chimney System - Guidelines for Chimney System Installation
5 Chimney Assembly

Page 20 Heatilator • Constitution EPA Fireplace • 480-1091C November 11, 2008
A. Chimney Requirements
Verticaldistancesaremeasuredfromthebaseofthere-
place as shown in Figure 20.1. To determine the chimney components needed to complete
yourparticularinstallation,followthestepsbelow:
• Determine the total vertical height of the fireplace
installation. This dimension is measured from the base of
thereplaceassemblytothepointwherethesmokeexits
the termination cap.
• Subtracttheeffectiveheightofthereplaceassemblyfrom
theoverallheightofthereplaceinstallation (measured
from the base of the fireplace to the bottom of the
termination cap, 13 ft. (4m).
• Refer to Table 20.2 to determine what components must
beselectedtocompletethereplaceinstallation.
• Determine the number of ceiling restops, stabilizers,
roof flashing, etc. required to complete the fireplace
installation.
6 ft (1.8 m) max.
unsupported
run
20 ft (6.10 m) max.
pipe between an
offset & return
Ceiling firestop
35 ft (10.7 m)
max. straight
unsupported
chimney height
14.5 ft (4.42 m) min. height/single offset-return
20 ft. (6.10 m) min. height/double offset-return
50 ft (15.24 m) max. height
6
f
t
(
1.83 m
)
max.
unsupported chimney
above roof
44 in.
(1118 mm)
to top of
standoffs
Figure 20.1 Chimney Requirements
Table 20.2
Fire Risk
• Mustmaintain2in.(51mm)airclearance
to insulation and other combustible
materials.
WARNING
HEIGHT OF CHIMNEY COMPONENTS in. mm
Chimney Stabilizer
SL3 4-3/4 121
Ceiling Firestops
FS338 0 0
FS339 0 0
FS340 0 0
Offsets/Returns
SL315 13-3/8 340
SL330 15-1/2 394
Roof Flashing
RF370 0 0
RF371 0 0
Chimney Sections*
SL306 4-3/4 121
SL312 10-3/4 273
SL318 16-3/4 425
SL324 22-3/4 578
SL336 34-3/4 883
SL348 46-3/4 1187
* Dimensions reect effective height.
Note: A maximum of two pairs of offsets and returns may
be used.
B. Chimney Termination Requirements
Minimumoverallstraightheight 13 ft 3.96 m
Minimumheightwithsingleoffset/
return
14.5 ft 4.42 m
Doubleoffset/returnminimumheight 20 ft 6.1 m
Maximumheight 50 ft 15.24 m
Maximumchimneylengthbetweenan
offset and return
20 ft 6.1 m
Maximumdistancebetweenchimney
stabilizers
35 ft 10.67 m
Maximumunsupportedchimney
length between the offset and return
6 ft 1.83 m
Maximumunsupportedchimney
heightabovethereplace
35 ft 10.67 m
Maximumunsupportedchimney
above roof
6 ft 1.83 m
WARNING
• DoNOTconnectthisunittoachimneyue
servicing another appliance.
• DoNOTconnecttoanyairdistributionductor
system.
Mayallowuegasestoenterthehouse.
Asphyxiation Risk.
