Heatilator Direct Vent System Eclipse User manual

Direct Vent System
Eclipse

Eclipse Direct Vent System
a brand of Hearth & Home Technologies Inc.
1915 West Saunders Street • Mt. Pleasant, Iowa 52641
800-927-6841 • heatilator.com
e information provided in this literature is for planning purposes only.
Please consult the installation manual for actual installation. Actual product
appearance may differ from product images.
*For a complete list of options, please consult the Heatilator MSRP book.
HTL-1047U-0308
AVAILABLE FROM
The Eclipse is competitively priced in its category
so it can now be included as standard—even in
floor plans that previously couldn’t afford one
The Eclipse creates a great opportunity to sell
a second fireplace in a home design
Top direct-vent system only
20,000 Btu/Hour input for comfortable
heat output
Direct vent system uses only outside air for
combustion and vents outside for better indoor
air quality and a healthy home
Optional fan available
Comes standard in natural gas or LP models
Models available in both standing pilot and
IntelliFire™ ignition systems
Utilizes SL-D venting components
Tested and listed to ANSI standards
•
•
•
•
•
•
•
•
•
•
e best-valued hearth system in the industry.
Eclipse Direct Vent System shown
with custom tile surround
10-7/8 in.
276 mm
10-7/8 in.
276 mm
17-1/8 in.
435 mm
33 in./838 mm
35-1/2 in./902 mm
20-5/8 in.
524 mm
33-1/2 in.
851 mm
3 in.
76 mm
6-1/2 in.
165 mm 3/4 in.
19 mm
5-3/8 in.
137 mm
2-3/16 in.
56 mm
12-5/8 in.
321 mm
Alternative
Gas
Access
Models
EDV3633 Standing pilot, natural gas
EDV3633I IntelliFire ignition, natural gas
EDV3633IL IntelliFire ignition, LP gas
Options*
Fan Kit
Conversion Kits
Remote Controls
