Heaven Fresh HF 610 NATUROPURE User manual

© 2013, HFEF -CAN | US | UK | FR- HF 610 - 05/13
HF 610 NATUROPURE DEHUMIDIFIER
DÉSHUMIDIFICATEUR NATUROPURE HF 610
INSTRUCTION MANUAL
MODE D’EMPLOI

Heaven Fresh HF 6102
SAFETY PRECAUTIONS
Thank you for purchasing the innovative Heaven Fresh HF 610 Dehumidier. We wish
you many years of healthy indoor air with this efcient and effective product.
Ensure that all safety precautions are followed when using this electrical appliance for
the proper operation of the device. These instructions describe the safety precautions
to be observed during operation. They are designed to prevent injuries or damage to
this device.
•AC 115V/60Hz (North America)
AC 220~240V/50~60Hz (Europe & Asia)
Over voltage may cause re hazard or electric shock.
•Close supervision is necessary when the appliance is used by or near
children.
•Do not allow children to play with any product packaging, such as plastic
bags etc.
•Do not subject the device to direct sunlight or near high temperature
objects.
•Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner.
• NEVER tilt, move, or attempt to empty unit while it is operating.
•DO NOT attempt to repair or adjust any electrical or mechanical functions
on this unit. Doing so will void your warranty. All servicing should be
performed by qualied personnel only.
• Do not plug in the cord with wet hands.
• Never pour or spray water over the unit.
• Household user only.
CAUTION
Do not use this unit at ambient temperatures below 5°C, to prevent the possibility of a
heavily ice up evaporating coil.

Heaven Fresh HF 6103
HOW IT WORKS
PLACEMENT
CONDENSER
DRY WARMER AIR
EVAPORATER
MICRO SWITCH
COMPRESSOR
WATER
TANK WATER
TANK
MOTOR
FAN
MOIST
SATURATED AIR
Dehumidier controls relative humidity by passing the air through the unit, forcing
the excess moisture to condensate over the cooling elements. Contact with this cold
surface causes the moisture in the air to condense. This condensed water then drains
safely into the water tank. The dried air then passes through the condenser where it is
slightly warmed and re-enters the room at a slightly elevated temperature.
Excess moisture will travel throughout your home, in the same way that cooking smells
waft to every room in the house. For this reason, the dehumidier should be positioned,
so that it can draw this moist air towards it from all over the home.
Alternatively, if you have a serious problem in one area you can begin by positioning
the dehumidier close to this area and later moving it to a more central point.
When positioning the dehumidier, ensure that it is placed on a level surface and that
there is a minimum of 10 cm (4”) of space on either side of the unit to allow for efcient
airow.
This dehumidier is tted with castors for extra mobility, if you move the unit, it should
rst be switched off and the water tank emptied. We do not recommend the use of
an extension lead, so please try to ensure that the unit is sufciently close to a xed
mains socket. If it is necessary to use am extension lead, please ensure the diameter
of the wires of the cable is at least 1 mm2.
When the dehumidier is in operation, outside doors and windows should be closed
when necessary for most efcient use.

Heaven Fresh HF 6104
COMPONENTS
Front
1. Control panel
2. Cover for air outlet
3. Air outlet
4. Water full indicator
5. Water tank
6. Handle
Rear
7. Air lter / air inlet
8. Power cord
9. Handle
10. Hole for continuous drainage
11. Water tank
12. Caster
Grill Washable Pre-Filter
Activated
Carbon Filter
Filter Fixer
Assembly of the lters

Heaven Fresh HF 6105
PRE OPERATING INSTRUCTIONS
Control panel
Display window
1. UV Light button
2. Timer
3. Display window
1. Humidity display: continuous de-humidifying , 50%, 60%, 70%, 80%
2. Ambient humidity condition: good fair bad
• means 50% ≤ambient room humidity ≤70%
• means 30% ≤ambient room humidity < 50% or 70% < ambient room
humidity ≤80%
• means the ambient room humidity is higher than 80%.
3. compressor is in progress. In case the de-frost function is working, the water
drops will ash.
compressor is not in progress.
Tank full.
4. UV (ultraviolet) indicator (to kill bacteria in the air)
5. Timer indicator, 1 to 24 hours.
6. Room humidity indicator, can also display the room temperature.
7. Fan speed/ventilation indicator: high speed low speed.
4. Speed (ventilation) button
5. Humidity selection button
6. ON/OFF button

Heaven Fresh HF 6106
OPERATING INSTRUCTIONS
DRAINAGE
1. Plug the unit into a correct mains socket.
2. Press button ON/OFF to turn on the unit. The
compressor will start to work in continuous mode.
3. Press button HUMIDITY to set the room humidity
you need: continuous de-humidifying , 50%, 60%,
70% or 80%
4. Press the speed button to choose the ventilation
speed, high or low.
5. To turn off the unit, press button ON/OFF again.
6. The direction of the air outlet can be adjusted by hand.
While the water tank is full, the compressor will stop for self-protection and:
• The sign of water full will ash.
• The unit will start beeping. (you may press the ON/OFF button to turn
off the unit/beep)
• The water level window will turn into red.
To move the water tank, pull it out squarely from the unit by using the handle at the
water tank.
After emptying the water tank, place the water tank into space. Make sure it is
properly positioned, in order for the ‘water full’ sign to go out and your dehumidier is
operating.
Please note, in case, the water tank has not been positioned well, the water level
window will turn into red and the unit will beep, too.
As the water tank
is full or has not
been positioned
well, the water
level window will
turn into red.
To move the water tank, pull it out squarely
from the unit by using the handle at the
water tank.

Heaven Fresh HF 6107
CONTINUOUS DRAINAGE
When the dehumidier is operated at very high humidity levels, the water tank will require
more frequent drainage. In this situation, it may be more convenient to set the unit up for
continuous drainage with the following procedures:
1. Cut the outlet at the unit back. (FIG.1).
2. Connect the drain hole with a water tube of inner diameter 12mm. (FIG.2)*
Please note, the water tube is not supplied with the unit.
3. Ensure the water will always drain away freely and the tube will remain in place.
Note! In very cold weather conditions, precautions should be taken to prevent
the water tube from freeing.
Water tube of inner diameter 12 mm.
Please note, the tube is not supplied
with the unit.
FIG. 1
FIG. 2
CAUTION
When the outlet is cut off, the said portion would leave as a hole and cannot be covered
by any plug. If it is covered by any plug, the condensed water will not go down to the
water tank.

Heaven Fresh HF 6108
CLEANING AND MAINTENANCE
Always unplug the unit from the mains before carrying out any maintenance or cleaning of
the unit.
Cleaning Body
Use soft cloth to wipe the unit clean.
Don’t ever use volatile chemicals, gasoline, detergents, chemically treated clothes, or other
cleansing solutions. These all could possibly hurt the cabinet.
Cleaning Filter
For washable lter - Use a vacuum
cleaner or tap the lter lightly for easy
cleaning. If the lter is particularly dirty,
please use warm water for cleaning.
For active carbon lter - This lter is
not washable. Its life span is variable and
depends on the ambient conditions where
the appliance is used. The lter should
be checked periodically (about every 6
months) and replaced if necessary.
Grill Washable Pre-Filter
Activated
Carbon Filter
Filter Fixer

Heaven Fresh HF 6109
Model: HF 610
Power Supply: 115V, 60Hz (North America)
220-240V 50~60Hz (Europe and Asia)
Noise Level: 49dB (high setting)
Coverage Area: 140 m2(1500 ft2)
Water Tank Capacity: 5.5L
Power: 440W
Refrigerant: Environment Friendly R134a
Dimensions (L x W x H): 41.0 x 21.0 x 54.5 cm (16.14” x 8.27” x 21.46”)
Weight: 12.5 kg (27.6 lbs.)
SPECIFICATIONS
STORAGE
If the unit is not in use for an extended period of time. Then please:
1. Turn the unit off and unplug it from the socket
2. Drain the water tank and wipe it clean
3. Cover the unit and store it away from the direct sunlight

Heaven Fresh HF 61010
THE UNIT DOES NOT OPERATE:
• Is the unit plugged in?
• Is the house electricity on?
• Is the room temperature beyond the working temperature (41~95°F/
5°~ 35°C)?
• Ensure the humidistat (or ON/OFF switch) is turned on.
• Check the water tank is positioned properly in the unit and it is
not full.
• Make sure the air inlet and outlet are not obstructed.
THE UNIT SEEMS TO DO NOTHING:
• Is the lter dusty, contaminated?
• Is the air intake or outlet blocked up?
• Is the room humidity already quite low?
THE UNIT SEEMS TO DO LITTLE:
• Are too many windows or doors open?
• Is there something in the room producing lots of humidity?
THE UNIT IS TOO NOISY:
• Check whether the unit is sitting on a level surface.
THE UNIT IS LEAKING:
• Make sure the unit is in good shape.
• If you are not using continuous drainage, please remove the water
tube, so the condensed water can go down to the water tank.
TROUBLESHOOTING
At the end of the product life cycle, you should not throw this machine
into the normal household garbage but bring the product to a collection
point for the recycling of electrical and electronic equipment.
DISPOSAL OF THIS DEVICE
