Hedstrom VENUS M08605 User manual

IMPORTANT: Make sure you read the safety notice on the front page and always supervise
children while they are playing on the equipment. Once assembly is completed carefully check
equipment. In the unlikely event that you do find any problems, please contact us. Do not allow
children to use this product until the problem has been corrected.
SAFETY GUIDELINES
SWING PARTS LIST
VENUS - M08605
FOR CHILDREN AGED 3 TO 10 YEARS
Not suitable for children under three years, contains small parts
This equipment must be assembled and checked by an adult
For family domestic use only. This product has not been designed for commercial use in play centers, nurseries etc.
Adult supervision is required at all times.
Only one child per seat at any one time.
For outdoor use
Check all nuts, bolts and fittings for tightness and tighten if required.
Check all coverings for bolts and sharp edges and replace when required.
Check swing seats, chain, ropes and other means of attachments for evidence of deterioration. Replace when
required in accordance with the manufacturers instructions.
Place the product on level surface at least 2 metres from any structure or obstruction such as a fence, garage, house,
wall, overhanging branches, laundry line or electrical wires.
The items MUST be anchored firmly into the ground
DO NOT install the product over concrete, asphalt or any hard surface.
DO NOT orientate the product directly towards the sun
Leave all fittings finger tight until assembly is complete, for ease of construction. Then tighten firmly.
Children should not wear cycle helmets whilst on this equipment
The item is not designed for adults or for children weighing more than 45kg.
Do not allow children to stand on the swing or glider seats
Do not allow the children to get off the swings or glider while they are still moving
Do not twist swing ropes or wrap them over the top bar
Do not allow loose, hooded or baggy clothes to be worn since children can get trapped and may be unable to free
themselves.
Do not allow children to climb on parts of this equipment intended for this purpose
Do not allow children to wander into the play area when the equipment is in use
Do not allow children to slide head first down the chute or walk up the chute
Gliders and swings must not exceed an angle of 60 degrees from the ground
Regularly check the item for wear and damage, removing the item from use when necessary until replacement parts
are fitted.
Failure to assemble and maintain this item as per instruction may cause injury to the user.
Please keep the instructions in a safe place for future reference
Conforms to EN71
“left-hand” type top leg (x2)
top bar (x1)
swing seat (x1)
spanner (x1)
allen key (x1)
“right-hand” type top leg (x2)
side stay bar (x2)
ground peg (x4)
plain bottom leg (x4)
glider legs (x2)
glider bracket (x1)
glider seat (x2) glider footrest (x2)
glider seat tubes (x2)
2
4
5
6
10 11 12
89
15
glider handle tubes (x2)
7
1
1
3
2
3
7
5
2
4
4
4
4
6
8
9
3
14
11
10
12
13

STEP 1
Frame & Swing Assembly
STEP 2
Glider Assembly
F2
F1
14
13
2
1
3
F1
• Remember to attach the rope clamp to the U bolt
M8 BOLT 53mm (x2)
M6 BOLT 45mm (x4)
M8 U BOLT (x2)
ALLEN KEY
SPANNER
G1 M6 BOLT 42mm (x2)
G2
G8
M8 BOLT 39mm (x2)
THIN PLASTIC SPACER (x4)
S1
rope clamp
1
S1
12
2
5
5
5
4
4
5
4
3
3
2
2
1
F2
661
1
7
G8
G8
G2
G1

4
4
15 15
P1
G6 M6 BOLT 35mm (x2)
G6
G4
G5
G9
M6 BOLT 35mm (x8)
M6 BOLT 40mm (x2)
M8 BOLT 82mm (x2)
THICK PLASTIC SPACER (x4)
STEP 3
Anchoring the Gym to the ground
IMPORTANT: For safety reasons this gym MUST be anchored into the ground.
We recommend that it is concreted in. If you are uncertain about this procedure,
telephone our helpline number.
P1 M6 BOLT 59mm (x4)
26
7
7
8
8
8
G6
G6
G9
G4
G5
9
11
10
• Assemble seats (10) and attach to seat tubes (9) before tightening bolts (G4)
CUSTOMER SERVICES
MV has taken great care to ensure that this toy has reached
you in good condition. Should you have a query, please contact:
customer[email protected] where your query will be
dealt with promptly. Alternatively, you can call on 0870 8404255.
MV Sports & Leisure Ltd.
35 Tameside Drive
Castle Bromwich
Birmingham B35 7AG
United Kingdom
email: [email protected]
www.mvsports.com
