XDP Recreation Firefly 75115 User manual

24 Bright, Flashing, Blinking, Strobing Multi-Colored LED LIGHTS
MODEL 75115 PRODUCT MANUAL
By XDP RECREATION, LLC
XDP RECREATION, LLC
Alpharetta, GA, 30005 USA
1.866.884.0535
www.xdp-recreation.com
[email protected]
• Attaches to any frame or swing set
• Ropes, Chain and Hardware Included
• For Children Ages 3+
• Maximum Weight: 150 lbs / 68 kg
• For use under Adult Supervision
• Adult Assembly required, per these instructions
1
Do not return to retailer
Included In Kit:
1) LED Swing
2) Rope / Chain
3) Carabiners (2 Each)
4) Hardware For Assembly (Washer, Cap Washer, Nut. 2 Each Of Each Component)
5) Assembly Instructions
WARRANTY: Limited – 90 Day Warranty from Purchase Date.
Motion
Activated
Fun Day or Night!
LED Lighted Swing
Adult supervision & installation is required.
See product manual for complete assembly
and usage instructions.
This product is for children ages 3+
Maximum user weight is 150 lbs
NOT FOR COMPLETE DARKNESS
Requires 3 AA batteries. When lights start
to dim, replace batteries as shown in manual.
Rev. February 12, 2019
®
PATENT PENDING

2
Tools Required:
1) Adjustable Wrench Or Wrenches
Assembly:
PARTS LISTING for Assembly:
J1 – Rope/Chain (2 each)
(Attach to Swing via J3)
J3 – Eye Bolt with Attachment Bolt.
(Pre-Assembled to ROPE) (2 each)
K1 – LED SWING (1 each)
J6 – Nut (2 each)
J7 – Flat Washer (2 each) **
MUST be ON the ASSEMBLY
J9 - Plastic Cap / Washer (2 each)
C1 – CARABINERS, Locking (2 each)
attaches to Chain, on Top
J7
J6
J9
J7
J6
J9
K1
Images and illustrations not to scale.
All images shown are for illustration
purpose only. Actual product may vary
due to product enhancement.
J9
J3
J1
J1
C1
J3
J1
J1
C1

Battery Acid Leakage can cause severe
injury to people and cause significant
damage to the product and to property that
comes within contact with it. If battery
leakage occurs, wear hand & Eye
protection and wash with water and baking
soda (if available) and make sure to not
get any acid on you or your clothing. If you
get acid on your clothing – wash them
immediately or damage may occur. If you
get acid on your body, rinse with water
immediately and seek medical attention.
Dispose all batteries according to Local,
State and Federal Law
BATTERY WARNING:
3
Battery Installation
(Adult installation required)
3 AA Batteries are required but not included.
The Battery Compartment is located on bottom of swing.
Two screws are used to secure the Battery Cover.
Use #1 Phillips screwdriver to remove screws and cover.
Insert 3 "AA" Batteries.
Make sure to match polarity of batteries with polarity of unit.
Replace Battery Cover and secure with screws.
Make sure Cover is properly seated to keep out moisture.
Operation/Activation
Press RED button under swing to activate LED lights.
Swinging motion of the swing will keep lights enabled/on.
Lights will automatically turn off after 8-10 minutes of non-use / non-motion.
When lights get dim or go out, replace with new or re-charged AA batteries.
All images shown are for illustration purpose only. Actual product may vary due to product enhancement.
“ON”
Button
Battery
Cover
Screws
(#1 screwdriver)
Cover
removed

Since it is a Front to Back Swing Movement only (no side-to-side movement) there are a few rules
to use.
• The Location should be on Level Ground and a minimum of 6’ away from any structure or object
nearby, Such as Fences, Houses, Separate Garages, Tress and Tree branches, Laundry Lines,
Electrical Wires, etc. If on a Swing Set Frame, allow 17” of space, on both sides of the Firefly
Swing, and /or between the other ‘rides/swings’. The lowest part of the Swing is 8” from the
Ground, MINIMUM.
• Do NOT install over Cement or Asphalt, hardened packed down earth, grass, carpet or any HARD
Surface. A fall on any hard surface can result in injury or death to the user.
• Be certain that the structure the FIREFLY Swing is being attached to can support over 400 lbs /
182 kgs. Weight includes User, and Firefly Swing, and accounts for swing torque motion.
USAGE RULES and OBSERVATIONS to Abide By:
• Age use for this Product is 3+ years, with a maximum
weight of user being 150 lbs or less.
• Setup and assembly of the product should be handled
and done by an ADULT. Adult Supervision is required at
all times during usage.
• Children must NOT use the Firefly Swing until it is
completely assembled and installed by an Adult.
• One (1) user at a time – 3+ years of age with a weight
limit of 150 lbs.
• An Adult should instruct the user/child how to swing, front
to back, on the seated swing. Centered properly on the
swing and holding firm to the Rope/Chain.
• Do not loop the Rope/Chain over any top bar or tree
limb, etc.
• Do not Twist or ‘helicopter’ the rope/chain while swinging.
This cause weakness for the Rope/Chain.
• Instruct Children to remove their bike helmets/sports
helmet, and not to wear any helmets while swinging on
the Firefly Swing.
• Dress Children in well fitted and full foot enclosed
footwear. Examples of inappropriate footwear are:
Clogs, Sandals, Flip-Flops, etc.
• Wait until you have completely stopped before
dis-mounting the Firefly Swing.
• If you have worn or damaged components, contact
XDP Recreation for replacement parts at the noted
Service phone numbers, email addresses and web
site.
• Do Not Use in WET CONDITIONS or when Lightning
is present.
• Keep people away from the Child using the Firefly
Swing.
THANK YOU for your purchase of the “FIREFLY” LED SWING.
For Best and Safe usage and results, please follow the assembly
instructions above/ below and if there are any questions please
contact XDP RECREATION LLC, Service Department at
1.866.884.0535, [email protected]
or on the website at www.xdp-recreation.com.
DO NOT RETURN your
Product to the Retailer
if help is needed. Please
contact XDP Recreation
at the Phone/Email/WEB
SITE noted above.
Choosing the Location for the FIREFLY LED Swing:
4
XDP Recreation Recommends you review this Handbook for your Outdoor play product:
OUTDOOR HOME Playground Safety Handbook
https://www.cpsc.gov/s3fs-public/324.pdf
RECOMMENDATION:
