HELGI HI0372PRO User manual

HDMI Extender OVER NETWORK
User's manual
•Introduction
This HDMI extender over cat6 extends the HDMI content up to 60
meters for 1080p.
•Important safety notice
1. Do not mix up HDMI to RJ45 sender and RJ45 to HDMI receiver before
installation.
2. Do not hot plug when it is working.
3. Use DC5V power supply only. Make sure specification matched if using
adapters not supplied by factory.
•Package Contents

•Installation Requirements
1. HDMI source device(computer graphics card, DVD,PS3, HD monitoring
equipment etc).
2. HDMI display device like SDTV, HDTV, projector with HDMI port.
3. UTP/STP cat6/6A/7 cable, follow standard IEEE-568B.
•Panel Description
1. HDMI to RJ45 transmitter

2. RJ45 to HDMI receiver
•Installation Procedures
1. Cat6 network cable
Follow the stanard of IEEE-568B:
1- Orange/white 5- Blue/white
2- Orange 6- Green
3- Green/white 7- Brown/white
4- Blue 8- Brown

2. Connections
Connection instruction:
1) Connect TX HDMI input with source device HDMI output.
Connect TX HDMI output with HDTV HDMI input.
2) Connect TX CAT6 with RX CAT6.
3) Connect RX HDMI output with HDTV HDMI input.
4) Power on the device and it works

•FAQ
Q: No image output or audio and video display is not normal?
A: 1) Adjust RX “RESET” button to reset the device.
2) Try shorter network cable to reconnect.
Q: RX “LINK” led is flashing all the time?
A: 1) Make sure network cable connection follows the standard of IEEE-
568B.
2) Check whether TX has HDMI signal input.
3) Reset TX&RX and reconnect.
Q: RX “LINK” led lights on all the time but no image output?
A: 1) Press RX “RESET” button to reset the device.
2) Make sure HDMI cable is well connected with TV.
3) Make sure the network cable is fine copper wires.
•Specification
Items
Specifications
HDMI signal
Compatible with HDCP
Support resolution
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz,
720p@50/60Hz, 1080i@50/60Hz,
1080p@50/60Hz
Network cable
low resistance and consumption oxygen-
free
copper core (CAT6, CAT6A, CAT7)
Transmission length
CAT6: 60m at 1080p
IR remote control
Support 20~60KHz wide frequency IR
remote control
Working temperature
0
℃～
60
℃
Power supply
DC5V/1A
Power consumption
TX<3W; RX<2W
Product dimension
71.6mm(L)*66.6mm(W)*24.8mm( H )
*2pcs
Weight
83g+80.6g
Color
Black
