Enable-IT 860 W PRO User manual

!
Enable-IT 860 W PRO Weatherproof
Professional Grade Ethernet Extender Kit
Quickstart Guide
All Rights Reserved © 1997 - 2015 Enable-IT™, Inc.

INSTALLING THE 860 W PRO WEATHERPROOF ETHERNET
EXTENDER KIT
The Enable-IT 860 W PRO Weatherproof Ethernet Extenders have a distance restriction of
6,000ft (1,829m) over 1-pair of Category 2, up to 4-pair CAT5e / CAT7, wiring from device
extension to device extension. Therefore a site survey of the wiring and installation planning
are highly recommended. For highest performance use CAT5e rated or higher spec for
interlink wiring.
Perform an Out Of The Box Test (OOTBT)
We highly recommend that you perform a quick test to ensure the working order of
your Enable-IT 860 W PRO Weatherproof Ethernet Extender units prior to installing. !
This will also serve to familiarize you with how easy the process should be. Using an
Ethernet patch cord attach each end to the Interlink port of each 860 W PRO unit. Next
use another Ethernet patch cord to connect the Power & Data Out jack on the 360 PoE
Injector to the 860 W PRO CO port as labeled. Using the power cord, power up the 360
Injector. The Green Sync LEDs will start flickering slowly and then fast as the units talk
to each other. After a few seconds you should see a solid Green Interlink Sync LED on
each unit to confirm a link is established. This confirms basic proper operation of the
units.
For a more detailed test and to confirm your LAN Equipment works with the 860 W PRO
units, connect your Ethernet LAN to the PoE injector LAN in port and remote device to
the 860 W PRO CPE LAN port and test connectivity. The Green Interlink Sync LED will
pulse rapidly as it detects traffic.
You will need a long flathead screwdriver to carefully remove the Ethernet patch
cables from the deeply recessed ports prior to installing.
All Rights Reserved © 1997 - 2015 Enable-IT™, Inc. Page !of !2 6
860 W PRO CPE Unit
860 W PRO CO unit
Pin 1 & 2
Pin 1 & 2

LED indicators will provide visual operational status of the 860 W PRO Weatherproof units.
Mode – Yellow Solid LED
Off = CO unit
On = CPE unit!
Sync – Green slow to fast flicker LED on power up – indicates negotiation of a link
– Green solid LED indicates link established and rapid pulse is traffic!
Act – Yellow LED
Off = No device attached or detected
On = Solid, indicates the presence of local LAN
On = Blinking, indicates the presence of local LAN traffic!
Power – Green Solid LED indicates the unit is receiving PoE power
Performing the On-Site Installation
After removing the Enable-IT 860 W PRO Weatherproof Ethernet Extender Kit from the box,
and performing the Out Of The Box Testing (OOTBT), all that remains to install the unit on-site
is to mount the unit, build the interconnect wiring and attach the LAN device cabling with
Ethernet Patch cords.
Mounting the Enable-IT 860 W PRO Weatherproof Ethernet Extender Units!
The Enable-IT 860 W PRO Weatherproof extended Ethernet solution is designed for quick
wall mounting. Choose a location to mount each of the Enable-IT 860 W PRO
Weatherproof’s where the maximum distance does not exceed 6,000ft (1,829m) total
between devices to be connected. When wall-mounting the Enable-IT 860 W PRO
Weatherproof unit it is recommended that you use the appropriate screw anchors for your
mounting surface. If mounting on existing plywood use wood screws; if mounting onto drywall
or sheetrock, use plastic drywall anchors to secure your installation.
Building the 860 W PRO Weatherproof Interlink Wiring!
The most important aspect of the installation is the correct wiring of the Interlink cabling.
The 860 W PRO Weatherproof Interlink port (RJ-45 interface) carries this 1-pair signaling over
the RJ-45 (pins 1 & 2) - used as transport for 240Mbps VDSL2 data. If you use more than 1-
pair of wiring, such as a CAT5 segment, the remaining RJ-45 pins can transport native
802.3af PoE, or are unused.
For all wiring you will need to crimp a RJ-45 Male head to each end of the contiguous wire run
and using the following (pins 1 & 2) straight through. We recommend using a category rated
twisted pair cable as it is optimized for high throughput frequencies isolated from cross-talk
noise. Insert the completed RJ-45 ends into the 860 W PRO Weatherproof Interlink port on
each 860 W PRO Weatherproof unit.
All Rights Reserved © 1997 - 2015 Enable-IT™, Inc. Page !of !3 6

Cabling Devices to The Enable-IT 860 W PRO Weatherproof Extended Ethernet Kit!
Attach your remote LAN device to the 860 W PRO Weatherproof CPE unit LAN ports with
Ethernet patch cord provided. Attach your local LAN to the 860 W PRO Weatherproof CO
LAN ports with Ethernet patch cord provided. Attach the power adapters to both 860 W PRO
Weatherproof units.
Attach your local Interlink cabling end to the 860 W PRO Weatherproof CO unit Interlink port –
Then do the same for the remote end and plug into the 860 W PRO Weatherproof CPE unit
Interlink port. The Sync LED’s will flicker in a sequence talking to each other until they go
solid. Your equipment should now be powered up and functioning.
LED indicators will provide visual operational status of the 860 W PRO Weatherproof units.
TECHNICAL SUPPORT
Enable-IT, Inc.’s Customer Care Team support is available directly to customers and distributors. All
support requests are processed through the online support portal. This allows us to provide
assigned support ticket numbers in order to bring closure to any technical issues.
Online Technical Services
The Enable-IT Support Portal is available 24/7 to open a ticket or check the status of one. Please
use this support website as your first source for help as it contains an on-line knowledge base of
articles, documentation, FAQ's and other problem-solving resources. This web-based support
resource provides the quickest solution to the most common technical support issues.
World Wide Web Site
http://support.enableit.com
All Rights Reserved © 1997 - 2015 Enable-IT™, Inc. Page !of !4 6
860 W PRO CPE Unit
860 W PRO CO unit
RJ-45 Interlink Cabling up to 6,000 feet
Pin 1 & 2
Pin 1 & 2

Returning Products for Warranty Repair
Enable-IT, Inc. warrants to the original purchaser of the Product ("you" or the "End User") that, for
the four (4) year period commencing on the date the Product was purchased (the "Warranty
Period"), the Product will be substantially free from defects in materials and workmanship under
normal use and conditions. Electrical or water damage is not covered under this warranty,
extended warranties or Advanced Replacement Program (AREP).
In order to obtain an authorized RMA approval, the End User must complete the required
information online located at http://support.enableit.com. If you have questions or difficulty
completing this information you may contact the Customer Care Team at 888-309-0910 between
the hours of 8:00 a.m. and 5:00 p.m. PT.
Please ship Authorized RMAs to:
RMA Warranty Repair Processing Facility
16600 Harbor Blvd, Suites H & I
Fountain Valley, CA 92708-1363
Returning Products for Refund
Enable-IT, Inc. offers a generous 45-Day refund on a single Ethernet Extender Kit only, and is
subject to a 15% Restocking Fee. Shipments without a valid or authorized RMA number, or
sent to our corporate Las Vegas address, can be refused and / or billed for additional
shipping.
ENABLE-IT, INC. LIMITED WARRANTY
Enable-IT, Inc. warrants the Enable-IT 860 W PRO Weatherproof Ethernet Extender Kit solely
pursuant to the following terms and conditions.
1.ENABLE-IT PRODUCT WARRANTY.
a. Express Warranty.
Enable-IT warrants to the original purchaser of the Product ("you" or the "End User") that, !
forthefour(4)yearperiodcommencingonthedatetheProductwaspurchased(the
"WarrantyPeriod"),theProductwillbesubstantiallyfreefromdefectsinmaterialsand
workmanshipundernormaluseandconditions.ThiswarrantydoesnotapplytoProducts,
whichareresoldasused,repairedorreconditioned,orconsumables(suchasbatteries)
suppliedwiththeProduct.Electrical or water damage are not covered under this
warranty,extendedwarrantiesorAdvancedReplacementProgram(AREP).
!
Enable-IT does not make any warranty with respect to any third party product, software or
accessorysuppliedwithorusedinconnectionwiththeProductandsuchthirdparty
products,softwareandaccessories,ifany,areprovided"ASIS."Warrantyclaimsrelatedto
suchthirdpartyproducts,softwareandaccessoriesmustbemadetotheapplicablethird
partymanufacturer.
All Rights Reserved © 1997 - 2015 Enable-IT™, Inc. Page !of !5 6

CONTACT US
Sales and Customer Care:
Toll Free US and Canada 888 309-0910
866 389-8605 Fax
Other International [phone]
[phone] Fax
E Mail [email protected]
[email protected]
RMA Support:
http://support.enableit.com
All Rights Reserved © 1997 - 2015 Enable-IT™, Inc. Page !of !6 6
