HELGI HLGMOVMIFMOTMN Programming manual

HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: [email protected] | [email protected] | Web: www.HELGI-solutions.com
1
HLGMOVMIFMOTMN
ASSEMBLING MANUAL
1000
700
242
1345-1795
25
144
38°
720
996
871
100 kg
MAX

HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: [email protected] | [email protected] | Web: www.HELGI-solutions.com
2
HLGMOVMIFMOTMN
ASSEMBLING MANUAL
x2 x2
x2
x4
DIN 912 M10x20
CONTENIDO/CONTENTS/CONTENUTO/SISÄLLYS/CONTENU:
HERRAMIENTAS NECESARIAS/TOOLS NEEDED/ATTREZZI
NECESSARI/TARPEELLISET TYÖKALUT/OUTILS NÉCESSAIRES:
ALLEN M8
ALLEN M6 ALLEN M10
x1
x1
x1
x1
DIN 912 M10x20 (x1)
DIN 912 M8x20 (x2)
DIN 912 M8x50 (x1)
LOCKER (x1)

HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: [email protected] | [email protected] | Web: www.HELGI-solutions.com
3
HLGMOVMIFMOTMN
ASSEMBLING MANUAL
1
2
x4
DIN 912 M10x20
3
ALLEN M6

HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: [email protected] | [email protected] | Web: www.HELGI-solutions.com
4
HLGMOVMIFMOTMN
ASSEMBLING MANUAL
45
DIN 912 M8x50
=ñN
DIN 912 M10x20 (x1)
DIN 912 M8x20 (x2)
=ñP
ALLEN M6 ALLEN M8
ALLEN M6
DIN 912
M10
DIN 912
M8
Para un mayor ajuste, utilice un nivelador.
To ensure screen is straight, please use a spirit
level.
Si consiglia l’uso di una livella per una maggiore
precisione.
Jos tarpeellista, varmista vesivaa’an avulla, että
näyttö on täysin vaakasuorassa.
Pour une parfaite installation, utilisez un niveau.

HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: [email protected] | [email protected] | Web: www.HELGI-solutions.com
5
HLGMOVMIFMOTMN
ASSEMBLING MANUAL
68
7
9
x1
=ñQ

HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: [email protected] | [email protected] | Web: www.HELGI-solutions.com
6
HLGMOVMIFMOTMN
ASSEMBLING MANUAL
10 11 ?
12
ON
OFF
Enganchar el mando a distancia en la columna.
Remote control will magnetically stick to metal column .
Il telecomando si aggancerà magneticamente alla colonna in metallo.
Kauko-ohjain kiinnittyy automaattisesti metalliseen pylvääseen.
La télécommande sera maintenue magnétiquement sur la colonne.
ALLEN M6

HELGI - The Digital Courtyard Via Artigiani 29/31 29020 Vigolzone (PC) Italy
E-mail: [email protected] | [email protected] | Web: www.HELGI-solutions.com
7
HLGMOVMIFMOTMN
ASSEMBLING MANUAL
/ SCHÉMA ÉLÉCTRIQUE DU SYSTÈME DE REHAUSSE.
DIAGRAMA ELÉCTRICO D EL M OTOR / ELECTRICAL DIAGRAM O F THE LIFTING SYSTEM /
DIAGRAMMA D ELL’IMPIANTO ELETTRICO D I SOLLEVAMENTO / NOSTOJÄRJESTELMÄN TEKNINEN K AAVA
Input: AC 100V-240V, 1.500mA;
50/60Hz
Output: DC29V - 2A
Max. Load: 6.000N; IP44
Power Rating 24 DVC, Max: 2AMP
