The Handy THLC User manual

05-07-2017
LOG CART
(100KG MAX LOAD CAPACITY)
Model No: THLC -- Product No: 1938149001
ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
Please read & understand this manual, paying attention to the safety instructions before
use.
We reserve the right to change the product specification & livery according to continued
product improvements.
INSTRUCTION MANUAL

CONTENTS
SPECIFICATION
IMPORTANT INFORMATION
GENERAL SAFETY INSTRUCTIONS
ASSEMBLY
MAINTENANCE & STORAGE
PARTS LIST
WARRANTY
If you require any assistance with regards to the contents or operation of
your machine, please contact us:
Tel: [phone]
Email: [e-mail]
Monday to Friday 8.00am to 5.30pm (excl. Bank Holidays)
SPECIFICATION
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
Model
THLC
Product No.
1938149001
Max. Load Capacity
100kg
Overall Dimensions
L 35 x W 46 x H 105cm
Wheel Size
8in x 1.75in Solid Wheel
Weight
N.W 6.6kg
Consistent with our policy of continuous improvement, GJ Handy & Co. Ltd reserves the right to
change the design and configuration of any of its products without notice or obligation.
Therefore, please treat the text and images in this manual as being for illustrative purposes only.
They may in no case serve as a basis for any legal claim.

IMPORTANT INFORMATION
WARNING
Read this instruction manual carefully before operating this machine. Make sure that you are familiar
with the controls and properly operate the machine. Following these instructions can reduce the risk
of fire, electric shock and personal injury.
IF NOT USED PROPERLY THIS MACHINE CAN BE DANGEROUS!
This machine can cause serious injury to the operator and others, the warning and safety instructions
must be followed to ensure reasonable safety and efficiency in using this product. The operator is
responsible for following the warning and safety instructions in this manual and on the machine.
DESIGNED FOR DOMESTIC USE ONLY.
The Log Cart is designed for use in private gardens and primarily used around GRASS OR LAWN
AREAS, but not in public facilities, parks or sports grounds and not for agricultural or forestry use.
This product is not intended for commercial use.
This is a garden log cart, therefore extended use over abrasive surfaces (e.g. concrete, tarmac etc.)
could cause premature wear on the cart wheels. Commercial or industrial environments are not
recommended.
Compliance with this manual supplied by the manufacturer is a prerequisite for the proper usage of
the machine. The operating manual contains servicing and maintenance instructions as well as
directions for use.
TRAINING
Read the instructions carefully: Be familiar with the controls and the proper use of the equipment.
Never allow children or people unfamiliar with these instructions to use the product. Local
regulations can restrict the age of the operator.
Never operate while people, especially children, or pets are nearby.
Keep in mind that the operator or user is responsible for accidents or hazards involving the machine
that occur to other people or their property.
GENERAL SAFETY INSTRUCTIONS
It is important that you read and understand the owner’s manual and labels affixed to the
machine. Learn its application and limitations as well as the specific potential hazards. Retain
these instructions for future reference. The operator is responsible for following the warnings &
instructions in this manual and on the product.
SYMBOLS
Read & understand operator’s manual
before using the machine. Failure to
follow instructions could result in
death or serious injury.
Do not expose to rain or damp
conditions for extended periods of
time.
Wear gloves to protect your hands.
Wear sturdy non-slip foot protection.
Safety alert symbol. Used to alert you
to potential personal injury hazards.
Obey all safety messages that follow
this symbol to avoid possible injury.
DANGER
Indicates an imminently hazardous
situation which, if not avoided, will
result in serious injury.
WARNING
Indicates a potentially hazardous
situation which, if not avoided, could
result in serious injury.
CAUTION
Indicates a potentially hazardous
situation which, if not avoided, may
result in minor or moderate injury.
CAUTION
Used without the safety alert symbol,
indicates a potentially hazardous
situation which, if not avoided, may
result in property damage.

DURING OPERATION
•This is a garden cart, therefore extended use over abrasive surfaces (e.g. concrete, tarmac etc.)
could cause premature wear on the trolley tyres.
•Always ensure that your load is evenly distributed over both wheels.
•Do not at any time allow anyone to sit or stand on the Cart.
•Do not allow children to play on, stand upon or climb in the Cart.
•Always inspect the Cart before use to ensure it is in good working condition.
•Immediately replace or repair damaged or worn parts before using the Cart.
•Always check and tighten hardware and assembled parts before operation.
•Do not exceed the equipment maximum load capacity of 100kg.
•Do not try to carry loads that make the Cart unstable.
•Avoid large holes and ditches when using the Cart.
•Be careful when operating on steep gradients (hills) the Cart may tip over.
•Always operate at a reduced speed in rough terrain, along creeks, ditches and on hillsides.
•Do not operate close to creeks, ditches and public roads.
•To avoid personal injury and/or equipment damage DO NOT EXCEED 5 MPH.
•Always use caution when loading and unloading the Cart.
CRUSH AND CUT HAZARDS
•Always keep your hands and feet clear from moving parts while operating the equipment.
•Always keep the work area clean and clear when operating
STAY ALERT
Do not operate the machine while under the influence of drugs, alcohol, or any medication that
could affect your ability to use it properly. Do not use this machine when you are tired or distracted
from the job at hand. Be aware of what you are doing at all times. Use common sense.
AVOID DANGEROUS CONDITIONS
Make sure there is adequate surrounding workspace. Cluttered areas invite injuries.
Keep your work area clean with sufficient light. Keep the area around the machine clear of
obstructions, grease, oil, rubbish and other debris which could cause persons to fall onto moving
parts.
INSPECT YOUR MACHINE
Check all bolts, nuts, and screws for tightness before each use, especially those securing guards and
drive mechanisms. Vibration during use, may cause these to loosen.
Form a habit of checking to see that all other tools/equipment are removed from the working area
before turning it on.
Replace damaged, missing or failed parts before using it. Warning labels carry important
information. Replace any missing or damaged warning labels.
DRESS PROPERLY
Do not wear loose clothing, gloves, scarfs, neckties or jewellery (rings, wrist watches), which can be
caught in moving parts. Non-skid heavy-duty footwear are highly recommended when working.
Wear protective hair covering to contain long hair, preventing it from getting caught in machinery.
KEEP BYSTANDERS AND CHILDREN AWAY
Keep unauthorised persons a minimum distance of 10 metres away from the machine. If
approached, stop the machine immediately. Do not allow children to handle, climb on or in the
machine. Do not at any time allow anyone to sit or stand on the Cart. Do not allow children to play
on, stand upon or climb in the Cart.
DO NOT OVERREACH
Always keep proper footing and balance when using the machine. Never stand on the machine.
Serious injury could occur if the machine is tipped or if the moving parts are unintentionally
contacted. Do not store anything above or near the machine, where anyone might stand on the
machine to reach them.

AVOID INJURY FROM UNEXPECTED ACCIDENT
Keep hands & feet out of the way of all moving parts. Do not place any part of your body or any tool
e.g. in the machine during operation.
DO NOT FORCE TOOL
Do not exceed the equipment maximum load capacity of 100kg
Always ensure that your load is evenly distributed over both wheels.
Do not try to carry loads that make the Cart unstable.
NEVER LEAVE MACHINE RUNNING UNATTENDED
Do not leave your machine unattended until it has come to a complete stop.
MAINTAIN YOUR MACHINE WITH CARE
Clean the machine immediately after use. Keep the machine clean to ensure it operates to its full &
safest performance. When maintaining this machine, only the manufacturer’s original replacement
parts should be used. The use of non-original manufacturer parts may invalidate your warranty.
PROTECT THE ENVIRONMENT
Take left over materials to an authorised collection point or follow the stipulations in the country
where the machine is used. Do not discharge into drains, soil or water.
STORE IDLE EQUIPMENT
When not in use, the machine should be stored in a dry location. Keep the machine away from
children and others not qualified to use it.
PREPARATION
Thoroughly inspect the area where the equipment is to be used and remove all objects which can be
thrown by the machine.
Only use accessories approved by the manufacturer (if applicable).
Do not operate the machine while under the influence of alcohol or drugs.
Never operate the machine in wet grass or conditions. This could cause you to slip while using.
MAINTENANCE AND STORAGE
Keep all nuts, bolts and screws tight to be sure the equipment is in safe working condition.
Replace worn or damaged parts for safety.
Keep the machine free of leaves, or other debris build-up.

ASSEMBLY
Follow the operating instructions step-by-step and use the pictures provided as a visual guide to
easily assemble the machine. Do not operate the machine until assembly has been completed.
Please ensure that you have all the below necessary parts, before commencing with the assembly.
In the unlikely event that you are missing a component, please do contact us on 01793 333212,
option 2 or email [e-mail] for assistance.
WHAT IS INCLUDED
Leg x2
PVC Cover
Axle
M8x40 Bolt x4
Front Frame
M8 Nut x4
Handle
M12 Wheel Washer x2
8x1.75
Wheel x2
2.5x40 Split Pin x2
STEP 1
Link the two Legs together, using the Axle.

STEP 2
Put a Wheel onto the Axle, following by a M12 Wheel Washer & secure by inserting a 2.5x40 Split
Pin through the hole at the end of the Axle. Split the legs of the Split Pin to secure. Repeat on the
opposite side.
STEP 3
Attach the Front Frame to the Legs, aligning the holes. Secure by using 1x M8 Bolt and M8 Nut.
Repeat on the other side. Do not fully tighten.
STEP 4
Attach the Handle to the Legs, align the fixing holes and using M8 Bolt and M8 Nut secure. Repeat
on the other side. Fully tighten all nuts and bolts from Steps 3 & 4.

STEP 5
Place the Bag/Cover over the Handle and side down to cover your logs. Secure by fastening the
Velcro strips.
OPERATION
WARNING!
Before operating the product, ensure that the wheels are secured correctly and all nuts and bolts are
fully tightened. The product should also be undamaged.
WARNING!
CAUTION: DO NOT overload the truck. Do not exceed the Maximum Load Capacity of 100kgs.
DO NOT attempt to carry loads which make the truck unstable
•Place the load on the toe plate (ensure the General Safety Instructions are followed).
•Once you’re happy the load is in position, take a moment to think about the area you will be
passing with the truck, to ensure no trip hazards or obstacles are in the way.
•Slowly lean the truck backwards to take the weight of the load, ensuring your feet are shoulder
width apart and one foot is slightly in front of the other, to assist with your balance.
•Proceed pushing the truck at a safe speed, especially at corners where the load could shift.
•On inclines and slopes, extra care should be taken.
•Always use a ramp for steps and curbs.
MAINTENANCE & STORAGE
WARNING
Improper maintenance & storage of the machine may void your warranty. Keep the machine clean
for better and safer performance.
MAINTENANCE
•Before each use, check all nuts & bolts to be sure they are sufficiently tightened.
•Keep all moving parts lightly greased/oiled, using multi-purpose grease or maintenance spray.
•We recommend only manufacturer original parts are used when maintaining this machine.
Failure to do so could invalidate your manufacturer’s warranty.

CLEANING
•Keep your cart clean.
•Thoroughly clean the machine at the end of each day’s operation.
•Brush any dirt, grime or dust off the cart.
STORAGE
•Store indoors or in a protected area during severe weather, winter months & avoid direct
sunlight.
•Ensure the truck is not accessible to bystanders, who may try to stand on the truck to reach
items which are up high.
PARTS LIST –THLC (1938149001)
Item
Part No.
Description/
Qty
Item
Part No.
Description/
Qty
TH233-1
Leg
x2
TH233-6
PVC Cover
X1
TH233-2
Axle
x1
TH233-7
M8x40 Bolt
x4
TH233-3
Front
Frame
x1
TH233-8
M8 Nut
x4
TH233-4
Handle
x1
TH233-9
M12 Wheel
Washer
x2
TH233-5
8x1.75
Wheel
x2
TH233-10
2.5x40
Split Pin
x2

GJ HANDY & CO LTD USER WARRANTY POLICY
Users Statement of Warranty
Each new machine is warranted against defective material or assembly of material under normal
usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved
in replacing and repairing those parts, which are of original manufacture.
Period of Warranty
All Webb & Webb Pro machines plus Sanli engines.
a) 2 years from the original date of sale to the first domestic user.
b) 90 days from the original date of sale to the professional/commercial user.
c) 90 days from the original date of sale when used for hire.
d) A reduced warranty period of 90 days applies to those items which are subject to normal wear
and tear (e.g. but not limited to wheels, tyres, cutter bars, cylinders, bottom blades, belts,
cables, grass bags, spark plugs).
e) Engines as per the manufacturer’s warranty statement which will be supplied with the machine.
f) 90 days from the original date of purchase for Replacement Spare Parts (unless normal wear &
tear component, which are covered for 30 days).
g) All machines’ must be serviced within the first 12 months from the original date of purchase to
comply with the warranty, failure to do so will invalidate the 2nd year of the warranty.
All Handy, Mowerland and Q-Garden products.
a) 1 year from the original date of sale to the first domestic user.
b) 90 days from the original date of sale to the professional/commercial user.
c) 90 days from the original date of sale when used for hire.
d) A reduced warranty period of 90 days applies to those items which are subject to normal wear
and tear (e.g. but not limited to wheels, tyres, cutter bars, cylinders, bottom blades, belts,
cables, collection bags, spark plugs).
e) Engines as per the manufacturer’s warranty statement which will be supplied with the machine.
f) 90 days from the original date of purchase for Replacement Spare Parts (unless normal wear &
tear component, which are covered for 30 days).
All warranty repairs must be undertaken by an authorised service dealer. These dealers have been
accredited by GJ Handy & Co Ltd and agree to only use genuine parts and follow our repair
procedures.
Version 04 (10-16)

GJ HANDY & CO LTD USER WARRANTY POLICY
Not covered by this warranty
a) The warranty policy does not cover any depreciation or damages caused by ordinary wear,
rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of
transportation or accident.
b) The warranty policy does not cover any costs necessary for the standard periodic maintenance
services instructed by the operator’s manual, or service parts replacement which would include
oil, filters, tyres, belts, brake linings, fuses, blades, seals and other service parts unless it can be
proven that the item has evidence of faulty manufacture.
c) The warranty policy will not cover failure or damage caused as a result of parts or accessories
being modified without the written approval of GJ Handy & Co Ltd.
d) The warranty policy will not cover the unit if non-genuine parts have been fitted and as a result
damage has occurred to the unit.
e) The warranty policy is non-transferable and is only applicable to the original purchaser.
Disclaimer
a) This warranty is only a remedy for defect of products. GJ Handy & Co Ltd will never warranty in
terms of the merchantability or the fitness for a particular purpose.
b) No person is authorised to make any warranties, representations or promises, expressed or
implied, on behalf of GJ Handy & Co Ltd, or to modify the terms conditions or limitation of this
warranty policy in any way.
c) Neither GJ Handy & Co Ltd nor any company affiliated with GJ Handy & Co Ltd shall be liable in
any event or manner whatsoever for incidental or consequential damages or injuries, including,
but not limited to, loss of crops, loss of profit, out of pocket expenses or profits, rental of
substitute equipment or other commercial losses.
General
a) Most warrantable failures show up within the first few weeks of use. These failures are usually
straightforward and warranty assessment is relatively easy.
b) Failures relating to cutter decks and belts need careful investigation, as the cause may not
always be straightforward. Look for damage to blades and pulleys especially when the cutter
belt or blade boss have snapped or cracked as this could be due to impact damage.
c) Customers should always refer to the operator/instruction manual when any disputed problem
arises, you will find most areas covered within the manual.
Version 04 (10-16)

NOTES
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________

NOTES
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________
_____________________________________________

For spares or support of your Handy product,
please contact us:
Tel: [phone]
Email: [e-mail]
(Mon –Fri 8.00am to 5.30pm excl. Bank Holidays)
To see our range of garden machinery & equipment visit:
www.thehandy.co.uk
Making gardening easier & affordable since 1938
Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY
