Hellermann Tyton Autotool 2000 CPK User manual

Autotool 2000 CPK
TOC-Cover
Operating Instructions

2
Translation of the original operating instructions 3

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004 3
Table of contents
1 Notes for the user ................... 5
1.1 Information about the product ....... 5
1.2 Warranty ........................ 5
1.3 Contact data ..................... 5
1.4 Information about these Operating
Instructions ...................... 5
1.5 Copyright and intellectual property
rights........................... 5
1.5.1 Keeping and dissemination of the
Operating Instructions .............. 5
1.6 Target group of these Operating
Instructions ...................... 5
1.7 General information ............... 5
1.8 Conventions adopted in these
Operating Instructions .............. 6
1.8.1 Classification of the precautionary
notices ......................... 6
1.8.2 Other notational conventions ........ 6
2 Safety warnings .................... 6
2.1 General power tool safety warnings ... 6
2.1.1 Occupational health and safety ....... 6
2.1.2 Electrical safety ................... 6
2.1.3 Safety of persons.................. 7
2.1.4 Use and handling of the power tool ... 7
2.1.5 Service. . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Intended use ..................... 7
2.3 Misuse. . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.4 Personnel qualification.............. 8
2.4.1 Specialist personnel for operation ..... 8
2.4.2 Specialist personnel for maintenance
and servicing ..................... 8
2.4.3 Qualified electrician ................ 8
2.4.4 Authorised specialist for repair and
testing.......................... 8
2.5 Underlying hazards associated with
use of the AT2000 CPK ............. 8
2.5.1 Cleanliness at the workplace ......... 8
2.5.2 Spare parts and accessories .......... 8
3 Design and function ................. 9
3.1 Overview of the device ............. 9
3.1.1 Scope of supply................... 9
3.1.2 Serial number .................... 9
3.1.3 Checking scope of supply ........... 9
3.2 Functional description ............. 10
3.2.1 AT2000 CPK .................... 10
3.2.2 Power pack CPK ................. 10
4 Transport, disposal and storage ....... 11
4.1 Transporting the device ............ 11
4.2 Disposal ....................... 11
4.3 Storage ........................ 11
5 Installation ....................... 11
5.1 Installing the accessories ........... 11
5.2 Connecting the device............. 11
6 Operation ........................ 11
6.1 Switching on .................... 11
6.2 Switching off.................... 11
6.3 Loading cable ties ................ 11
6.4 Positioning and binding items for
bundling ....................... 12
6.4.1 Emptying the waste box ........... 12
7 Settings in the display menu .......... 12
7.1 Accessing the settings ............. 13
7.2 Accessing the parameter set ........ 13
7.3 Setting the force level ............. 13
7.4 Setting the binding quality.......... 13
7.5 Setting the loop diameter .......... 14
7.6 Setting the cutting mode........... 14
7.7 Setting tension-free cutting ......... 14
8 Settings in the main menu ........... 15
8.1 Languages menu................. 15
8.2 Status menu .................... 15
8.3 Settings menu ................... 15
8.3.1 Interruption front sensor ........... 16
8.3.2 Date / time ..................... 16
8.3.3 Check of binding ................. 16
8.4 Contact menu ................... 16
9 HT Data Management............... 17
9.1 First steps ...................... 17
9.2 Access levels .................... 17
9.2.1 Binding menu ................... 17
9.2.2 Service menu.................... 17
9.2.3 Memory menu. . . . . . . . . . . . . . . . . . . 17
9.2.4 Update menu ................... 17
9.2.5 Measurement environment menu .... 17
9.2.6 Parameter set menu. . . . . . . . . . . . . . . 17
Operating Instructions
Translationof the original operating instructions

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004 4
9.3 Binding menu ................... 18
9.3.1 Entering password................ 18
9.3.2 Select a language ................ 18
9.3.3 Synchronising time and date ........ 19
9.3.4 Display binding information......... 19
9.3.5 Select parameter set .............. 19
9.3.6 Set interruption front sensor ........ 19
9.3.7 Setting the binding check .......... 19
9.3.8 Activating consecutive trigger ....... 19
9.3.9 Status indicators ................. 19
9.4 Service menu.................... 20
9.4.1 Updating service information........ 20
9.4.2 Changing the access code in the
AT2000 CPK .................... 20
9.5 Memory menu. . . . . . . . . . . . . . . . . . . 21
9.5.1 Refresh memory of the tool......... 21
9.5.2 Limit the time period of the bindings .. 21
9.5.3 Limit the time period of the
messages ...................... 22
9.5.4 Select bindings .................. 22
9.5.5 Select messages ................. 22
9.5.6 Read and export the process data
on the HTDM ................... 22
9.5.7 Export data ..................... 22
9.5.8 Display exported data in the HTML
format......................... 22
9.6 Update menu ................... 23
9.6.1 Update firmware ................. 23
9.6.2 Change password ................ 24
9.6.3 Update binding parameters ......... 24
9.6.4 Install other languages. . . . . . . . . . . . . 24
9.7 Measurement environment menu .... 25
9.7.1 Using measurement mode.......... 25
9.7.2 Deleting measurement results ....... 26
9.7.3 Saving measurement results......... 26
9.8 Parameter set menu. . . . . . . . . . . . . . . 27
9.8.1 Synchronise parameter sets ......... 27
9.8.2 Save parameter sets............... 28
9.8.3 Load parameter sets .............. 28
9.9 Export process data from the power
packCPK....................... 29
10 Troubleshooting ................... 29
10.1 Important notes ................. 29
10.2 Performing a reset ................ 30
10.3 Display messages................. 30
10.4 Possible fault .................... 33
10.4.1 Troubleshooting a cable-tie bandoleer
malfunction..................... 33
10.4.2 Changing back-up battery .......... 34
11 Maintenance ...................... 34
11.1 Important notes ................. 34
11.2 Accessories and extras............. 34
11.3 Servicing by manufacturer .......... 35
11.4 Maintenance schedule............. 35
11.5 Repair ......................... 35
11.5.1 Checking upper jaw............... 35
11.5.2 Replacing upper jaw .............. 35
11.5.3 Checking front cap and position of
cutter ......................... 36
11.5.4 Checking tie advancer ............. 36
11.5.5 Replacing tie advancer............. 36
12 Technical data ..................... 37
12.1 AT2000 CPK .................... 37
12.2 PowerpackCPK ................. 38
12.3 Noise and vibration information...... 38
13 Declarations of conformity ........... 39
13.1 AT2000 CPK automatic tool system ... 39
13.2 Power pack CPK ................. 40

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Notes for the user
5
1 Notes for the user
These Operating Instructions are very important for
correct use of the device.
They contain important information and safety
instructions that will enable you to utilise the product
correctly and economically for its intended use.
The instructions help avoid hazards, reduce repair costs
and downtimes, and enhance the dependability and
durability of the device.
Non-compliance of any nature whatsoever can lead to
accidents with fatal consequences, injury or damage to
property.
1.1 Information about the product
Product designation: AT2000 CPK
Article number: 106-00000
1.2 Warranty
The warranty is in accordance with statutory require-
ments. Warranty entitlement applies only in the country
in which the device was originally purchased.
Batteries, fuses and light sources are not covered by the
warranty.
1.3 Contact data
The manufacturer of the product described in these
Operating Instructions is:
HellermannTyton GmbH
Grosser Moorweg 45
D-25436 Tornesch, Germany
Tel. [phone]
www.HellermannTyton.de
[e-mail]
1.4 Information about these Operating Instructions
Last change: 20.11.2019
1.5 Copyright and intellectual property rights
The manufacturer retains the copyright to these
Operating Instructions. Under no circumstances may
these instructions be reproduced or electronically
processed, replicated or disseminated, in whole or in
part, without the prior written consent of
HellermannTyton GmbH (hereinafter referred to as
HellermannTyton). Any breach or infringement of these
stipulations will result in liability for damages.
1.5.1 Keeping and dissemination of the Operating
Instructions
These Operating Instructions must be kept in the
immediate vicinity of the workplace and must be
available at all times to all operating personnel. The
operating company shall inform the operating personnel
of the location of these Operating Instructions.
The operating company shall obtain replacement from
the manufacturer if these instructions are, become or are
rendered no longer easily legible.
If the device is acquired by or sold on to a third party the
following documents must be handed over to the new
owner:
• Operating Instructions
• Documents relating to repair work
• Logs of maintenance work undertaken
fProtect these Operating Instructions from moisture,
direct sunlight and extreme heat.
1.6 Target group of these Operating Instructions
These Operating Instructions must be read and complied
with by every person charged with any of the following
tasks:
• Installation
• Operation
• Maintenance
• Repair
• Fault rectification
1.7 General information
Subject to technical modifications.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Safety warnings
6
1.8 Conventions adopted in these Operating
Instructions
1.8.1 Classification of the precautionary notices
Precautionary notices in these Operating Instructions
draw attention to hazards associated with use of the
device and indicate how they can be avoided.
The precautionary notices are subdivided into three
groups according to the severity of the potential hazard:
DANGER
Text accompanied by the signal word "DANGER" indicate
hazardous situations which, in the event of non-compliance
with the appropriate precautions, will cause death or severe
injury.
WARNING
Text accompanied by the signal word "WARNING" indicate
hazardous situations which, in the event of non-compliance
with the appropriate precautions, can cause death or serious
injury.
CAUTION
Text accompanied by the signal word "CAUTION" indicate
hazardous situations which, in the event of non-compliance
with the appropriate precautions, can cause slight or serious
injury.
1.8.2 Other notational conventions
fIndicates an instruction
• Indicates a list
;Indicates the result of an action
This text highlight is used for names of menus,
clickable on-screen buttons, pushbuttons and switches.
This text highlight is used for display
messages.
àThis text highlight is used for cross-references.
NOTE
Texts accompanied by the signal word "NOTE" indicate
situations which, in the event of non-compliance with the
appropriate precautions, can cause damage to the device
orthe surroundings.
Text accompanied by this symbol contain useful additional
information.
2 Safety warnings
2.1 General power tool safety warnings
The safety warnings in this section contain general power
tool safety warnings to be set out in the Operating
Instructions as required by EN 62841. Consequently, some
instructions might not be relevant for the AT2000 CPK.
WARNING
Read all safety warnings and all instructions.
Failure to follow the warning and instructions may
result in electric shock, fire and/or serious injury.
Save all safety warnings and other instructions for
future reference. The term "power tool" in the
warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
2.1.1 Occupational health and safety
a) Keep your workplace clean and tidy and well
illuminated. Poor lighting or a lack of orderliness at the
workplace can lead to accidents.
b) Do not work with the power tool in surroundings
where there is a risk of explosion, where flammable
liquids, gases or dust are present. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and other persons well clear while the
power tool is in use. Distractions can cause you to lose
control of the power tool.
2.1.2 Electrical safety
a) The plug of the power tool must match the socket
outlet. Do not use a plug that has been modified in
any way. Do not use an adapter plug together with
apower tool that has a protective earth. Unmodified
plugs and matching socket outlets reduce the risk of
electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as those of pipes, radiators, cookers
and refrigerators. The risk of electric shock is higher
when your body is earthed.
c) Protect power tools from rain and moisture. Water
penetrating into a power tool increases the risk of
electric shock.
d) Never misuse the cable for carrying the power tool
or hanging it up, or for pulling the plug out of the
socket outlet. Keep the cable away from heat, oil,
sharp edges and moving parts.
e) When you work outdoors with a power tool, use
only an extension lead that is suitable for outdoor
use. Using an extension lead that is suitable for outdoor
use reduces the risk of electric shock.
f) If operation of a power tool in a damp environment
is unavoidable, use a portable residual current device
(PRCD). Using a PRCD reduces the risk of electric shock.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Safety warnings
7
2.1.3 Safety of persons
a) Stay alert, attend to the task in hand and use
common sense when you work with a power tool.
Do not use a power tool when you are tired or while
under the influence of drugs, alcohol or medication.
A moment of inattention while using a power tool can
result in serious injuries.
b) Wear appropriate personal protective equipment
(PPE). Depending on the type of power tool and the
way in which it is used, wearing PPE such as a dust
mask, non-slip safety shoes, a hard hat and ear
defenders reduces the risk of injury.
c) Prevent accidental starting. Make sure that the
power tool is switched off before you connect it to
the power source and/or battery pack, and also
before picking up or carrying the tool. Touching the
switch while carrying the power tool or connecting the
power tool to the electricity supply while it is switched
on can lead to accidents.
d) Remove adjusting tools or wrenches before
switching the power tool on. A tool or wrench
engaged in a part that starts to rotate when the power
tool is switched on can cause injuries.
e) Avoid adopting an awkward posture when working.
Maintain a firm footing and keep your balance at all
times. This will enable you to control the power tool
better if an unexpected situation occurs.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing well away
from moving parts. Loose clothes, jewellery or long
hair can be snagged by moving parts.
g) If it can be fitted, dust extraction and filtration
equipment must be connected and used correctly.
Using a dust extractor can reduce hazards associated
with dust.
h) Do not permit yourself to be lulled into a false sense
of security and do not disregard the safety
regulations for working with power tools, even after
frequent or repeated use has made you familiar with
the power tool. Carelessness can result in series injuries
within a fraction of a second.
2.1.4 Use and handling of the power tool
a) Do not overload the power tool. Use the correct
power tool for the task in hand. Using the right power
tool for the job will enable you to work better and in
greater safety in the stated performance range.
b) Never use a power tool that has a faulty switch. A
power tool that cannot be switched on or off at the
switch intended for this purpose is dangerous and must
be repaired.
c) Disconnect the plug from the socket outlet and/or
remove the battery pack from the power tool before
making adjustments, changing accessory tools or
laying the power tool aside. This precaution prevents
accidental starting of the power tool.
d) When not in use, store power tools out of reach of
children. Do not permit anyone to work with the
power tool who is not familiar with it or has not
read and understood these instructions. Power tools
in the hands of inexperienced persons are dangerous.
e) Keep power tools and accessory tools in good
condition at all times. Check that moving parts are
infull working order and do not jam. Check for
partsthat are broken or damaged to the extent that
operation of the power tool is impaired. Have
damaged parts repaired before using the power tool.
Many accidents involving power tools are due to poor
maintenance.
f) Keep cutting tools sharp and clean. Carefully
maintained cutting tools with sharp cutting edges are
less likely to jam and are easier to control.
g) Use the power tool, accessory tools, etc. in
accordance with these instructions. Take working
conditions and the task to be undertaken into
account in this respect. Using power tools for other
than the intended use can lead to hazardous situations.
h) Keep handles and gripping surfaces dry, clean and
free of oil and grease. Slippery handles and gripping
surfaces do not permit safe operation and control of the
power tool in unexpected situations.
2.1.5 Service
a) Have your power tool repaired only by a qualified
specialist using only the manufacturer’s genuine
spare parts. This ensures that the safety of the power
tool is maintained.
2.2 Intended use
Use the AT2000 CPK only when it is in full working order
and safe, always be safety-conscious and aware of the
hazards.
The AT2000 CPK is suitable for and intended for the
following uses:
• Automatic binding of bundles up to a diameter of max.
80mm
• Use indoors and, under rainproof roofing, outdoors
• Industrial use

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Safety warnings
8
2.3 Misuse
Use other than as stated in the section entitled
"à"Intended use" on page7" is misuse. The
operator of the AT2000 CPK bears sole responsibility
forinjury and damage resulting from misuse.
The following are specifically prohibited:
• Use with faulty parts
• Use in explosive environments or in the presence of
afirehazard
• Use in high humidity and/or direct sunlight
• Simultaneous use by two or more persons
• Unauthorised alterations and modifications to the
AT2000 CPK and its accessories without the prior
consent of HellermannTyton
• Use of spare parts and accessories not tested and
approved beforehand by HellermannTyton
• Operation of the AT2000 CPK with the housing open
2.4 Personnel qualification
Underage persons and trainees are permitted to use the
device only under the supervision of an experienced
specialist and only with the express permission of the
operating company.
2.4.1 Specialist personnel for operation
The tasks and authorisations assigned to specialist
personnel for extended operation are as follows:
• Operating the AT2000 CPK
• Rectification of faults or, as applicable, initiation of
measures for the rectification of faults
• Cleaning the AT2000 CPK
These individuals have the specialist training or practical
experience that will ensure correct handling.
2.4.2 Specialist personnel for maintenance and
servicing
Always have maintenance and servicing carried out by
duly qualified specialist personnel. These individuals have
the specialist training that affords sucient knowledge
of the AT2000 CPK for them to judge when it is in safe
working order.
These individuals are also familiar with the following
rules and regulations:
• Applicable national health and safety regulations
• Accident prevention regulations
• Generally accepted rules of engineering practice (e.g.
employers' liability insurance association codes, DIN
standards, VDE regulations, technical rules of other
European Union Member States or other signatories of
the Agreement on the European Economic Area).
2.4.3 Qualified electrician
Work on the electrical supply and on parts that are live
when the device is in operation should always be carried
out by a trained electrician.
2.4.4 Authorised specialist for repair and testing
Only service technicians from HellermannTyton or service
technicians certified by HellermannTyton are permitted
to carry out repairs and safety checks.
a.1 Underlying hazards associated with use of the
AT2000 CPK
2.4.5 Cleanliness at the workplace
Orderliness, good lighting and cleanliness at the
workplace all help to make work easier, minimise
hazards and reduce the risk of injury.
Always comply with the following principles of
orderliness and cleanliness at the workplace:
fPut tools away as soon as they are no longer needed.
fAvoid trips (e.g. immediately dispose of waste by placing
it in the containers provided for the purpose).
fImmediately remove spillages of grease, oil and other
liquids.
fClean smears off the controls.
2.4.6 Spare parts and accessories
fUse only original replacement parts.
fAfter parts have been replaced, always check that
everything is in full working order.
fUse only accessories approved by HellermannTyton.
Accessories can affect the way in which the AT2000 CPK
works.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Design and function
9
3 Design and function
3.1 Overview of the device
3.1.1 Scope of supply
Data Signal Power
Power pack CPK
187 2
3456
1 AT2000 CPK
2 Case, complete with 2 keys
3 Safety instructions CPK and short guide CPK
4 USB connecting cable A/B (separate delivery)
5 Connecting cable for connecting power pack and AT2000 CPK
6 power pack CPK (separate delivery)
7 Power cord (separate delivery)
8 Tie advancer
3.1.2 Serial number
1
Serial number 1 is inside the AT2000 CPK. It is visible
when the gate is open.
3.1.3 Checking scope of supply
fCheck that nothing is missing and that there are no
visible signs of damage in transit or other damage. Have
damage confirmed by the freight forwarder and notify
HellermannTyton immediately in writing.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Design and function
10
3.2 Functional description
3.2.1 AT2000 CPK
8 6 5 47
13
3
2
11
12
10
9
1
1 Actuator service flap left
2 Actuator bandoleer cutter
3 Socket for connection to power pack
4 Enter button to confirm a selection in the navigation menu and increment switch
for display settings
5 Select and reset button for selecting a menu for display settings
6 LED status indicator
7 Start trigger
8 Box for waste material
9 Display with touch-sensitive controls
10 Front cap with level sensor, upper and lower jaws
11 Catch
12 Drum
13 Cable tie bandoleer
The AT2000 CPK is an electrically powered system for
bundling electrical wires, for example, and for securing
parts of various kinds with T18RA cable ties, 100mm ×
2.5mm × 1mm (L×W × H).
Force and quality of the binding can be software-
controlled or set by means of the display on the device,
à"Operation" on page11.
The items to be bundled have to be positioned between
the jaws and against the front cap. The device then
closes the tie as soon as the trigger is pressed.
If a fault occurs, messages appear on the display to
guide the user through the recommended fault-
diagnosis routine, à"Troubleshooting" on page29.
Process data of various kinds are collected during use.
These data can be analysed by PC software and used to
document process capability, for example. In addition,
the operator is notified if the tension force exceeds the
preset, à"HT Data Management" on page17.
3.2.2 Power pack CPK
Data Signal Power
Power pack CPK
6
2345
1
1 Main switch
2 LED indicator Power:
Green: Power pack ON
3 LED indicator Signal:
Green: AT2000 CPK connected and ready,
Red: Fault
Yellow: Binding cycle active
Blue: Navigation in main menu, binding not possible
4 LED indicator Data:
Green: PC connected; AT2000 CPK connected; USB stick found; USB stick can be
removed,
Red/blue flashing: Data are being written to USB stick
5 USB port for exporting process data to USB memory stick
6 Socket for connection to AT2000 CPK
max. 250V~
In: Last Tie Out: Error Out: Busy
Serial port
3
1
2
1 Socket for foot pedal
2 USB port for connection to PC (for the HTDM)
3 Socket for power supply
In automatic systems, the AT2000 CPK can be integrated
with the separate power pack with control box (106-00110)
via a serial interface.
.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Transport, disposal and storage
11
4 Transport, disposal and storage
4.1 Transporting the device
fAlways use the case that comes with the device to
transport the AT2000 CPK.
4.2 Disposal
End-of-life (EOL) disposal of the device and individual
subassemblies and the disposal of consumables and
auxiliaries are subject in part to statutory regulations.
Detailed information is available on request from the
appropriate authorities (e.g. regional or national water
boards or environmental authorities).
fDispose of packaging materials.
Always dispose of packaging materials in accordance with
the currently valid materials-disposal and environmental
protection regulations.
fAlways take materials for disposal to certified collection
points.
fContact the manufacturer if there is any uncertainty
regarding disposal.
3.1 Storage
fStore the tool and the power pack in a cool, dry place.
fAvoid direct sunlight.
fStore the tool and the power pack in dustproof
packaging.
fStore electrical components (tool and power pack) in
impact-absorbing packaging and separately from the
accessories.
fConsult and comply with the appropriate data sheets for
storage of the accessories.
5 Installation
5.1 Installing the accessories
fAlways proceed in accordance with the instructions
supplied with the accessory in question.
5.2 Connecting the device
In: Last Tie Out: Error Out: Busy
Serial port
1 2
fConnect power pack 2 to power-supply outlet 1 .
Data Signal Power
Power pack CPK
3
2
fUse connecting cord 2 to connect the power pack to
tool AT2000 CPK 3 .
6 Operation
6.1 Switching on
fThe power-supply outlet must be readily accessible so
that the power pack and the AT2000 CPK can be de-
energised if the need arises.
fKeep the main switch OFF when the AT2000 CPK is not
in use or being replaced.
fSwitch the power pack ON at the main switch.
;The Signal and Power LEDs on the power pack
illuminate in green.
;The LED status display on the AT2000 CPK lights up
green.
;The start menu appears on the display, à"Settings in
the display menu" on page12.
;The AT2000 CPK is ready for use.
6.2 Switching off
fSwitch the power pack OFF at the main switch.
6.3 Loading cable ties
1 2
3
fInsert cable tie bandoleer 1 parallel with the drum.
;Make sure that cable-tieheads 2 are facing up.
fPress the trigger 3 .
fIf there are no cable ties in the device three blank shots
are fired.
;The cable ties are loaded.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Settings in the display menu
12
6.4 Positioning and binding items for bundling
fSelect the Force level and/or Quality parameters,
à"Accessing the parameter set" on page13 or
à"Select parameter set" on page19.
fCheck the time and date; set if necessary,à"Date /
time" on page16.
The device is suitable for the following bundle
geometries:
42 mm
20 mm
1
2
3
The distance from front cap 1 to flat 2 must be at least
42mm. Bundle 3 can be no more than 20mm in
diameter.
CAUTION
Crush hazard when jaws close.
fDo not insert fingers between upper and lower jaws and
do not keep your finger on the trigger.
fAlways keep the power pack switched OFF when
clearing a blockage.
1
3
2
fCentre the bundle 1 in line with front-cap screws 3 .
Space adjacent cable ties at least 10mm apart.
fPress the trigger 2 .
;The bundle 1 is secured by the cable tie.
6.4.1 Emptying the waste box
The waste box has to be emptied after a maximum of
120 bindings at a bundle diameter of 3mm. As the
bundle diameter increases, so does the number of
bindings until the waste box has to be emptied.
1
fPull waste box 1 in the direction indicated by the arrow
and empty the box.
fClose the waste box 1 .
7 Settings in the display menu
After switching on the AT2000 CPK at the connected
power pack, the start screen appears on the display.
The additional device functions (e.g. clock time) are
configured on the main menu, à"Settings in the main
menu" on page15.
AT 2000 CPK
001
1
3
2
1 Enter button to confirm a selection in the navigation menu and increment switch
for display menu settings
2 Select and reset button for AT2000 CPK settings in the display menu
3 LED status indicator Signal:
Green: AT2000 CPK connected and ready
Red: Error
The functions for setting the bindings with the AT2000 CPK
can be directly accessed and configured in the display menu.
These include:
• Parameter set
• Force level
• Binding quality
• Loop diameter
• Cutting mode
• Cut with the tension released

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Settings in the display menu
13
fUse the Select button 2 to select the desired setting in
the display menu.
fPress the Enter button 1 .
fPress the Enter button 1 several times to return to the
start screen.
fCheck the LED status indicator 3 , à"Troubleshooting"
on page29.
A printed short guide is included with the AT2000 CPK which
schematically explains how to configure the functions.
7.1 Accessing the settings
000Access code
Settings 1
2
fPress the Select button 2 .
;The access code settings are displayed, à"Settings
menu" on page15.
;Access to the Settings menu is protected by a three-digit
access code that can be changed in the HT Data
Management software, à"Changing the access code in
the AT2000 CPK" on page20.
The default access code is 000.
When configuring settings in the display menu, the start
screen will be displayed after 10 seconds of inactivity.
7.2 Accessing the parameter set
The preset parameter sets can be accessed or transferred
to the AT2000 CPK when the HTDM is connected. The
parameter sets comprise settings which are gathered
into groups. They are managed in the HTDM,
à"Parameter set menu" on page17.
AT 2000 CPK
001
1
2
3
fAccess the settings, à"Accessing the settings" on
page13.
fPress the Select button 2 .
fThe parameter set 3 is indicated with a blue border.
fPress the Enter button 1 until the desired parameter set
3 is displayed.
;The settings of the selected parameter set are displayed.
7.3 Setting the force level
The setting corresponds to the force applied by the
AT2000 CPK when binding, and it can be set from
Level1 (lowest force) to Level 5 (highest force).
AT 2000 CPK
001
1
2
3
fPress the Select button 2 .
fThe force level 3 is indicated with a blue border.
fPress the Enter button 1 until the desired force level is
reached.
;The force level 3 is indicated by the number of red
arrows.
7.4 Setting the binding quality
The setting corresponds to the quality of binding and it
can be set from Level1 (lowest quality) to Level 3
(highest quality). The higher the level the longer the
cycle time, so the bundle has more time to settle.
AT 2000 CPK
001
1
2
3
fPress the Select button 2 .
fThe binding quality 3 is indicated with a blue border.
fPress the Enter button 1 until the desired binding quality
is reached.
;The binding quality 3 is indicated by the number of red
stars.
;The binding speed is indicated by the “speedometer
needle” position.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Settings in the display menu
14
7.5 Setting the loop diameter
The actual diameter may deviate from the set value as
the gearing and the state of the tool and processing
material have an impact on the binding.
Make sure that the binding does not produce a circular loop.
AT 2000 CPK
001
0.1
1
2
3
fPress the Select button 2 .
;The loop diameter 3 is indicated with a blue border.
fPress the Enter button 1 .
;The loop diameter value is activated.
fPress the Select button 2 .
;The adjustable value is underlined.
fPress the Enter button 1 several times until the desired
value is displayed.
fPress the Select button 2 .
;The selection jumps forward one digit.
fRepeat the setting until the desired values is reached.
7.6 Setting the cutting mode
AT 2000 CPK
001
1
2
3
Flush cutting
fPress the Select button 2 .
;The strip section 3 is indicated with a blue border.
fPress the Enter button 1 to activate flush cutting.
;No strip section is displayed when flush cutting is
activated.
Cut-free binding
fPress the Enter button 1 to deactivate flush cutting.
;The projecting cable-tie end is indicated with a blue
border.
Projecting cable-tie ends
The actual projecting cable-tie end may deviate from the
set value as the gearing and the state of the tool and
processing material have an impact on the binding.
AT 2000 CPK
001
3.1
1
2
3
fPress the Select button 2 .
fPress the Enter button 1 to activate the projecting cable-
tie end value.
;The adjustable value 3 is underlined.
fPress the Enter button 1 several times until the desired
value is displayed.
fPress the Select button 2 .
;The selection jumps forward one digit.
fRepeat the setting until the desired values is reached.
7.7 Setting tension-free cutting
AT 2000 CPK
001
1
2
3
fPress the Select button 2 .
;Tension-free cutting 3 is indicated with a blue border.
fPress the Enter button 1 .
;Tension-free cutting is indicated with a crossed-out
tension spring.
fPress the Enter button 1 to deactivate tension-free
cutting.
fPress the Select button 2 to finish configuring the
settings.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Settings in the main menu
15
8 Settings in the main menu
After switching on the AT2000 CPK at the connected
power pack, the start screen appears on the display.
AT 2000 CPK
001
1
1 Enter button to confirm a selection in the navigation menu and increment switch
for display menu settings
The main menu in the AT2000 CPK enables the
configuration of additional device functions.
The menu covers:
• Languages settings in the display, à"Languages menu"
on page15
• Device status, e.g. counter reading of the bindings or
firmware version, à"Status menu" on page15
• Settings, e.g. date / time, à"Settings menu" on
page15
• Contact, à"Contact menu" on page16
Bindings cannot be triggered while you are navigating in the
main menu. The Signal LED on the power pack shows blue.
fPress the Enter button 1 .
;The Main menu appears on the display.
8.1 Languages menu
You use the Languages menu to select the language for
the displays.
English
Deutsch
Français
Español
Portuguese
Italiano
Dutch
Languages 1
2
fUse the Select button 2 to select the language.
fPress the Enter button 1 .
;The display switches to the language you selected.
;The Main menu appears on the display.
8.2 Status menu
00000005
1.70/ 8/ 3
01:11
00000013
28
06/02/2019
58
0000000
Counter reading
Tool software
Power-pack SW
Serial number
Temperature
Last service
Humidity
Cntr.rdng.lastSer
Status 1
2
The Status menu shows you the following status readings:
• Counter reading
• Software version of the AT2000 CPK and an index
number for the language version
• Software version of the power pack
• Serial number of the tool
• Ambient temperature and humidity
• Date of last service
• Counter reading at last service
fPress the Enter button 1 .
;The Main menu appears on the display.
8.3 Settings menu
You use the Settings menu to set important parameters
of the AT2000 CPK.
Access to the Settings menu is protected by a three-digit
access code that can be changed in the HT Data
Management software, à"Changing the access code in the
AT2000 CPK" on page20. The default access code is 000.
fUse the Select button in the Main menu to select the
Settings menu.
fPress the Enter button.
;The prompt for the access code appears on the display.
000Access code
Settings 1
2
fPress the Select button 2 .
fAfter reaching the desired number, press the Enter
button 1 .
;The selection jumps forward one digit.
fRepeat the setting until the desired access code is set.
fPress the Enter button 1 .
;The Settings menu appears on the display.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
Settings in the main menu
16
Settings
Interruption front sensor
Date / time
Check of binding
Back
8.3.1 Interruption front sensor
The Interruption front sensor setting enables you to
decide how long the level sensor can remain busy
without the Error, front cap message appearing on the
display.
This function is intended for use with the device integrated
into an automatic system.
0.0 sec.
0.3 sec.
0.5 sec.
0.7 sec.
0.9 sec.
Settings
Interruption front sensor
Level 1
Level 2
Level 3
Level 4
Level 5
Back
1
2
fUse the Select button 2 to select the level.
fPress the Enter button 1 .
;The setting changes to the level you selected.
8.3.2 Date / time
You can set the Date / time for process documentation.
Date and time can also be synchronised with the HTDM,
à"Synchronising time and date" on page19.
20.03.19
10:23
Settings
Date
Clock time
1
2
fUse the Select button 2 to change the date and time.
fPress the Enter button 1 to confirm each digit.
;The setting changes to the option you selected.
8.3.3 Check of binding
The Check of binding setting enables you to decide
whether or not the Error, binding force
message appears on the display, à"Display messages" on
page30.
The binding check can also be set with the HTDM,
à"Setting the binding check" on page19.
Check of binding
OFF
Error notification
Acknowledgement
Settings
Back
1
2
fUse the Select button 2 to select the desired setting.
fPress the Enter button 1 .
;The setting changes to the option you selected.
Setting Meaning
OFF The Error, binding force message does
not appear on the display.
Error notification The Error, binding force message
appears when applicable but does not require
confirmation.
Acknowledgement The Error, binding force message
appears when applicable and requires
confirmation. The next binding is not possible
until the trigger has been pulled to confirm the
message.
8.4 Contact menu
The Contact menu shows you the current website of
the manufacturer.
www.HellermannTyton.com
Contact 1
2

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
HT Data Management
17
9 HT Data Management
The HT Data Management software enables you to:
• Update the software for the power pack and
AT2000CPK.
• Export production data.
• Change parameters.
9.1 First steps
fInstall the HT Data Management software on a PC.
fSwitch on the AT2000 CPK, à"Switching on" on
page11.
In: Last Tie Out: Error Out: Busy
Serial port
1
fConnect the PC to the power pack with the provided
USB cable 1 .
fLaunch the HT Data Management software.
;The HT Data Management start page appears on the
screen, à"Binding menu" on page18.
NOTE
When the AT2000 CPK is connected, error messages may be
displayed in the HTDM while binding if the settings of the
AT2000 CPK display have been changed.
9.2 Access levels
There are three access levels. Each level permits access
to the features available on the lower levels:
• Operator level
• Setup-specialist level
• Service level
9.2.1 Binding menu
Level Binding
information
Binding
parameters
Change
language
Synchronise
with PC time
Operator Read No Yes Yes
Setup
specialist
Read Yes Yes Yes
Service Yes Yes Yes Yes
9.2.2 Service menu
Level Change service pa-
rameter settings
Change para-
meter settings
Change
access code
Operator No No No
Setup
specialist
No Yes Yes
Service Yes Yes Yes
9.2.3 Memory menu
Level Export data Delete memory
Operator Yes No
Setup specialist Yes No
Service Yes Yes
9.2.4 Update menu
Level Perform
updates
Change
access code
Operator No No
Setup specialist Yes Yes
Service Yes Yes
9.2.5 Measurement environment menu
Level Visibility
Operator No
Setup specialist Yes
Service Yes
9.2.6 Parameter set menu
Level Create parameter sets
Operator No
Setup specialist Yes
Service Yes

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
HT Data Management
18
9.3 Binding menu
The Binding menu appears on the display when you
launch the software.
1
23
4
5
6
78
9
10 11
12
1 Version information and date of publication of the software
2 Entry box for password for access level
3 Language setting
4 Connection states and software versions
5 Time and date synchronisation
6 Menus
7 Display binding information
8 Select parameter set
9 Select interruption front sensor
10 Switch binding check on or off
11 Consecutive trigger
12 Status of the AT2000 CPK
9.3.1 Entering password
The password consists of four characters and the default
setting is 0000.
fEnter the password 2 .
fClick on Confirm.
;What you see in the “Menus” tab 6 depends on your
access rights, à"Access levels" on page17.
;Certain fields can be greyed, hidden or active, depending
on the access level.
9.3.2 Select a language
fSelect the display language in the Language drop-down
menu.
;The setting immediately changes to the language you
selected.

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
HT Data Management
19
9.3.3 Synchronising time and date
fClick on Synchronise with PC time 5 .
;Clock time and date of the power pack are synchronised
with the PC connected to the device.
Time and date are saved in the power pack and have to be
rechecked if the power pack is subsequently replaced.
9.3.4 Display binding information
Binding information 7 shows the process data of the
last binding performed with the connected AT2000 CPK.
9.3.5 Select parameter set
In the parameter sets, preset values are grouped and
transferred to the AT2000 CPK, à"Parameter set
menu" on page27
fSelect a configured parameter set in the Parameter set
8 field.
;The changed parameters are transferred to the AT2000
CPK.
9.3.6 Set interruption front sensor
The Interruption front sensor setting 9 enables you to
decide how long the level sensor can remain busy
without the Error, front cap message appearing on the
display, à"Display messages" on page30.
fSelect the level in the Interruption front sensor 9 field.
;There are five levels:
• Level 1: 0.0 seconds
• Level 2: 0.3 seconds
• Level 3: 0.5 seconds
• Level 4: 0.7 seconds
• Level 5: 0.9 seconds
;The setting is changed and transferred to the AT2000
CPK.
9.3.7 Setting the binding check
The Check of binding setting 10 enables you to decide
whether or not the Error, binding force message
appears on the display, à"Display messages" on
page30
fSet the binding in the Check of binding 10 field,
à"Check of binding" on page16. The following
options are available:
• OFF
• Error notification
• Acknowledgement
;The setting is changed and transferred to the AT2000
CPK.
9.3.8 Activating consecutive trigger
Consecutive trigger 11 effects continuous binding
without repeatedly actuating the start trigger. Bindings
will be carried out as long as the start trigger remains
pressed.
fActivate the consecutive trigger 11 .
9.3.9 Status indicators
The Tool Status 12 field displays the operating status of
the AT2000 CPK.
Colour Status
Connection to the
power pack CPK
Green Connection active
Red Error message active
Grey No connection / connection
interrupted
Connection to
AT2000 CPK
Green Connection active
Red Error message active
Grey No connection / connection
interrupted
Status of the
AT2000 CPK
Green Ready
Yellow Busy
Blue Main menu on AT2000 CPK active
Binding not possible
Red Error message active
Grey No connection / connection
interrupted

Operating Instructions • AT2000 CPK • 07-2019 • v03 • 106-29004
HT Data Management
20
9.4 Service menu
1
2
3
45
1 Serial number and counter reading display
2 Information for HellermannTyton service
3 Access code of the AT2000 CPK
4 Refresh the service information and parameters
5 Send data to the AT2000 CPK
9.4.1 Updating service information
fClick on Fetch data from tool.
;The information of the AT2000 CPK about the counter
reading and service is updated.
9.4.2 Changing the access code in the AT2000 CPK
fEnter the new code at Tool code. The code is a
three-digit number and the default setting is 000.
fClick on Send data to tool.
;The access code is changed and transmitted to the
AT2000 CPK.
