Henderson SHUTTER SLIDE User manual

SHUTTER SLIDE
2 and 3 Panel Telescopic System - Manual or Automated
Fitting Instructions
No. of Panels Operation Min. Panel Width Max. Panel Width
Panel Thickness
Range
Max Panel
Weight
Manual 500mm 1200mm 35 - 47mm 120kg
Automatic 500mm 1200mm 35 - 47mm 80kg
Manual 500mm 1200mm 35 - 47mm 120kg
Automatic 500mm 1200mm 35 - 47mm 60kg
SYSTEM AND PANEL SPECIFICATION
2
3
SYSTEM COMPONENTS
120 Track
2 Door (x2)
3 Door (x3)
HH4/AN Track Stop
2 Door (x2)
3 Door (x2)
GSSUR Channel
2 Door (x2)
3 Door (x3)
WP**T Wall Fixing
Profile (x1)
WP**F Fascia
(x1)
WP***/EC End
Caps (x2)
GSSULR Channel
2 Door (x2)
3 Door (x3)
Toothed Belt
(x1)
Datum Block
(x1)
GSS/MK** L Plate
2 Door (x2)
3 Door (x3)
Short Arm
2 Door (x1)
3 Door (x2)
Long Arm
2 Door (x1)
3 Door (x2)
Additional Belt Clamp
2 Door (x1)
3 Door (x2)
GSS/SBK10 Guide
2 Door (x2)
3 Door (x3)
E/B10 Belt Clamp (x1)*
E120/24V
Motor (x1)*
Control Panel (x2)*
E/PA10 Pulley
(x1)*
Note: Fixings not supplied by P C Henderson, please choose suitable
fixings for the relevant application environment.
* Automated only
**Full short code depends on system installed
Components vary depending on specification
OR
GSS/SSK10 Guide
2 Door (x2)
3 Door (x3
GSS/SL Guide 2
Door (x2) 3
Door (x3)
OR
OR
GSS/RH Offset
Angle Plate Right
(x1)
GSS/LH Offset
Angle Plate Left
(x1)
E120/230V Motor
(x1)*
OR
E2/RCK Remote
(x1)
OR
Page 1

SYSTEM OVERVIEW & TRACK INSTALLATION
TOOLS REQUIRED
Scissors
Tape
Measure
2, 3, 4 & 5 mm
Allen Keys
Posi Drive
Screwdriver Spirit Level
Shutter Slide
Elevation
KEY
DT = Door Thickness
TSH = Track Set Height
DH = Door Height
S = Gap Required Between Tracks
X = PCH Recommended Top Clearance (63.5mm)
2 Door Telescopic 3 Door Telescopic
Page 2

TWO PANEL TELESCOPIC SYSTEM OVERVIEW
THREE PANEL TELESCOPIC SYSTEM OVERVIEW
= Apron plate position
PCH RECOMMEND OL = 70mm
APP = 2 X DW –140
DW = (APP + 140) / 2
Shutter Open Final Position
= Apron plate position
PCH RECOMMEND OL = 70mm
APP = 3 x DW –210
DW = (APP + 210) / 3
Shutter Open Final
Position
KEY
DW = Door Width
APP = Maximum Clear Opening Width
OL = Overlap of doors
(recommended 70mm)
Page 3

AUTOMATED TELESCOPIC OVERVIEW
Motor
Short Arm Long Arm
Hanger
Belt Clamp
(Automation)
Belt Clamp
(Additional Door)
Datum Point
Pulley Wheel
End Stop
Belt Component Overview
Belt Overview
2 DOOR SYSTEM
3 DOOR SYSTEM
Motor
Short Arm Long Arm
Hanger
Belt Clamp
(Automation)
Belt Clamp
(Additional Door)
Datum Point
Pulley Wheel
End Stop
Component Overview
Belt Overview
Page 4

STEP BY STEP INSTRUCTIONS
STEP 1: Cut track and track profile to the required length (cut an extra 16mm off track when installing an
automated system). Drill holes in the track (hole size depends on fixing method) and use "V" to ensure holes
are central. Fix the profile to the wall and fix the track to the underside of the profile. See diagram below for
recommended track height.
49mm
Note: It is the installer’s
responsibility to ensure that
the correct fixing/wall
insert is used and is suitable
- depending on the
wall/ceiling type and
quality.
Centre
Line
Midpoint of Track =
Top of Shutter + 49mm
Use "V" in track to ensure
hole is central
Page 5

STEP 4: Attach long arm along centre line
STEP 2: Manual: Fit apron plates 32mm (min.) from edge of door. Automated: Fit apron plates 150mm
from edge of door. Manual and Automated: Ensure apron plates are equal distance from either edge of
door. Once positioned correctly, screw into place.
STEP 3: Install the U-profile channel onto the base of the shutter, fixing at 200mm intervals along the
centre line
150mm
Centre Line
150mm
Belt clamp
150mm offset to
accommodate shutter
under motor unit
Lead Shutter
GSSUR
GSSULR
==
Min 32mm
MANUAL
AUTOMATED
4.5 x 30 Wood Screws
Follower Shutter
Page 6

STEP 5: Attach short arm in-line with edge of door.
STEP 6: Insert stops, hangers and pulley wheel into the track in the order shown.
STEP 7: Automated: Secure motor unit to track by inserting block into track and tightening bolts to clamp
over bottom of the track.
Follower Shutter
Note: Pulley wheel is for automated
installations only. Insert into the front
track only.
Connector Block Track
Spacer
M6x25 Bolts
Motor
Connector Block
Track
4.5 x 30 Wood Screws
Page 7

STEP 10: Check and adjust shutter height so that it is between 20mm -32mm from bottom of track.
STEP 8: Loop belt around bearing wheels and cut belt to length.
STEP 9: Hang the shutter onto the track, set the height and tighten into position.
i.
i. Set Shutter height by rotating strap
bolt on flats
ii. Once position set –tighten thin nut
against apron plate.
ii.
20mm –
32mm
Page 8

STEP 12: Using appropriate fixings, fit the L plate fixing guide to the edge of the opening. Next, attach the
guide using an allen key to tighten into place. Adjust door stop if required before fixing to ensure the door is
vertical.
STEP 11: Align shutters with spirit level to position fixed floor guide
Datum Wall Spirit Level
Using appropriate fixings, fit L
plate guide at the edge of the
opening.
Attach guide using an allen key to
tighten into place.
OR
Follower
Door
Lead
Door
29mm
Follower
Page 9

STEP 13: Floor guide overview
STEP 14: Automated: Loosen belt clamp, cut to length and tighten to secure belt.
STEP 15: Automated: Push tensios wheel assembly so that the belt is taut and secure assembly in position
by tighening the M6 grub screw
Tighten to clamp belt
Belt
Tighten once
position set
Lead Door Follower Door
Adjustable Floor Guide
Page 10

STEP 16: Set track stops to limit travel
STEP 17: Loop belt around follower shutter pulley wheel an clamp to lead shutter using the belt.
Belt clamped to bracket Bracket fixed to Door
Lead and follower shutter overview
Page 11

STEP 18: Follower shutter 1 and follower shutter 2 overview (3 door only)
STEP 19: With shutter in fully closed position, mark the position for the datum block.
Follower Shutter 2
Follower Shutter 1
Belt runs in front of belt bracket
Bracket to be fixed to
shutter
Mark position of datum
block by aligning with edge
of follower shutter
Page 12

P C Henderson Ltd, Durham Road, Bowburn, Co. Durham, DH6 5NG, UK 668667
UK Sales
Export Sales LVL01
t: [phone] t: [phone] Aug-19
e: [email protected]om e: [e-mail]
w: www.pchenderson.com w: export.pchenderson.com
STEP 20: Affix datum block, ensuring shutters are able to fully traverse the track. Connect belt to datum
block - esnruing shutters are able to fully traverse the track.
STEP 21: Position and secure track stops at both ends of the track to ensure all panels are aligned in the
fully open position.
STEP 22: Clip on fascia and screw on end caps
Datum block
Wall
Secure track stop
using allen key
Fascia
Page 13

Page 14
