Henry Schein 570-0606 Installation instructions

Stadiometer
570-0606
R1.0

Table of Contents
Safety Cautionary Information ......................................................................................................................2
Important Information ..............................................................................................................................2
Before you start.........................................................................................................................................2
Installation .....................................................................................................................................................4
Height Rod Operation....................................................................................................................................4
Technical Data ...........................................................................................................................................5
Technical Support ..........................................................................................................................................6
Warranty........................................................................................................................................................6

Safety Cautionary Information
Before using your new Stadiometer, please take time to read the following safety
instructions.
CAUTION! Properly assemble scale and follow all directions in the user manual.
CAUTION! Use the assembly material supplied
CAUTION! Ensure that screws are tightened
CAUTION! Make sure to fold down the height lever after measurement has been take
Important Information
• Have repairs carried out onlybyauthorized persons.
Before you start
Carefully remove the stadiometer from the shipping carton. If you notice any shipping damage
to the product, please contact the shipper immediately. Please retain all shipping material in
case the product needs to be returned or the scale needs to be shipped to another location.
Remove the packaging and place the scale on a firm, level surface. Contents include:
•Height Rod
•Anchor screws
•Metal screws
•Bracket

Installation
Markings will need to be made so the height rod is properly installed. Make a cross at
54cm off the ground. Take your bracket and align the top hole with the first marking and
then take a pencil and put through the bottom hole until the tip touches the wall to make
the 2nd mark. When both markings are in place begin drilling through both markings.
Insert the anchor screws to the wall. Note: You may need to adjust the hole size by using
a drill bit. Screw bracket to the wall. Screw the height rod on the bracket through the
middle hole. (Refer to drawing)

Height Rod Operation
Measuring over 51 inches
Picture 1 Picture 2 Picture 3
1.) Engage height rod by pulling up on the top rod as noted in Picture 1
2.) Flip the height rod lever up so that it is in a horizontal position as shown in Picture 2
3.) Adjust the height rod lever by lowering until it touches the top of the patients head
4.) Measurement can be read by the Red marking as shown in Picture 3
Measuring under 51 inches
Picture 4 Picture 5 Picture 6
With the height rod lever flipped down, begin to slide the height rod downward until it stops
1.) Press the release button that is found on the front of the height rod lever bracket. Refer to Picture
5. When pressing the release button, begin to slide the height rod lever down as shown in Picture
5 and 6
2.) Measurement can be read by the Red marking as shown in Picture 6

Technical Data
Item #
570-0606
Range of measurement
2ft to 6ft 6.75 inches
Division
21.6 x 308.6 x 13.4 inches
Weight
1.54 lbs
