HEPER MINIKA 4x90 Installation and operating instructions

1/2 2022-1 / 23/09/2022
Installation & Maintenance
Instructions
HEPER USA LLC
W227 N546 Westmound Drive Waukesha, 53186
Wisconsin, United States
[phone]
[email protected]
MINIKA 4x90° (LR9014.515-4x90-US)
1.45 lbs
https://heperlighting.com/us/lr9014.515-4x90-us/

2/2
English ( USA )
Safety
- The product must be installed in accordance with applicable
NEC standards by a qualified electrician familiar with the
installation of exterior lighting fixtures.
- The product must be operated under specified voltage at all
times.
- Do not install if parts are damaged.
- Power must be disconnected while installing or servicing to
avoid electrical shock.
- Failing to comply with warnings and installation steps in this
document might void warranty.
- Do not touch the light source.
- Make sure that temperature of the product is at a safe level before
touching.
- Do not allow cables to touch sharp edges of metal parts or other sharp
objects to avoid damage or abrasion.
- Check all of the cable connections including grounding before
powering the product.
- Check the proper grounding of the metal housing before powering the
product.
- Only use the product for its intended purposes.
- Do not use accessories not approved or recommended by
HEPER.
- Installation of inground luminaires shouldn't be done during periods
of excessive rain.
- The product is suitable for walk-over with a maximum load of
200 kg.
- Replace any broken/cracked protective surface with a new
one
Installation
- Install pea gravel below luminaire to provide drainage. If the luminaire
will be completely encased in concrete or a substrate that has
questionable drainage, then the use of a drainage pipe to re-direct rain
or water flowing into the luminaire is required
- Prepare cavity and be sure that certain conduit and power supply
cable are accessible and have ample slack to make appropriate
connections.
- Install the luminaire into prepared cavity.
- Utilize appropriate IP 68 or NEMA-rated box and fittings to make all
electrical connections. Note: IP 68 or NEMA-rated box and epoxy resin
are not provided with the product.
Cleaning - Maintenance
- The product was designed and manufactured to operate for a long
period of time. To ensure maximum lifespan of the product, regular (i.e.
every six months) visual inspection and cleaning with a solvent-free
cleaner using a soft cloth is recommended.
- Do not clean or service while the product is power connected.
Disposal
- In accordance with EU Directive WEEE (Waste Electrical and
Electronic Equipment), luminaires must not be disposed of with
other household waste. At the end of their life, luminaires must
be taken to the appropriate local facility available for the
disposal or recycling of electronic products.
Wiring Color Codes
- Ground - GREEN
- Line - BLACK
- Neutral - WHITE
- Dim(+) - RED/PURPLE
- Dim (-) - GRAY/ORANGE
Disclaimer
- HEPER reserve the right to make technical and design changes.
