Hi-Target A8 Series User manual

A8 GNSS RTK System operation Manual
Manual Revision Situation
Revision Revision Description
Date Level
Mar.2013 1 A8 GNSS RTK System
Operation Manual
I

A8 GNSS RTK System Operation Manual
Table of Contents
Preface.............................................................................................................................1
Instruction..............................................................................................................2
Relative Information......................................................................................2
Your Suggestions.............................................................................................2
Summary.......................................................................................................................3
Introduction..........................................................................................................4
Product Features................................................................................................5
Usage and Notes................................................................................................5
Receiver Introduction.........................................................................................7
Introduction..........................................................................................................8
Receiver Appearance.....................................................................................8
Control Panel.......................................................................................................9
Upper Cover...................................................................................................... 10
Lower Cover..................................................................................................... 11
Communication Module........................................................................... 12
Battery................................................................................................................... 13
Environmental Requirement................................................................. 14
Electrical Interference................................................................................ 15
General Operations........................................................................................... 16
Introduction....................................................................................................... 17
Button functions............................................................................................. 18
II

A8 GNSS RTK System Operation Manual
Led Status Instructions.............................................................................. 21
Turn On/Off Receiver................................................................................ 27
Static Data Storage....................................................................................... 27
RTK Data Storage......................................................................................... 27
Reset Receiver................................................................................................. 28
Module checking........................................................................................... 28
Format Receiver............................................................................................. 28
Power Supply System................................................................................ 29
Communication Module........................................................................... 37
SIM Card/ USIM Card.............................................................................. 39
Firmware.............................................................................................................. 41
Configuration of Fieldwork....................................................................... 43
Introduction....................................................................................................... 44
Diagram for base working...................................................................... 44
Diagram for rover working.................................................................... 47
Fast Operation Guide.................................................................................. 48
Static Collecting.................................................................................................... 52
Instruction........................................................................................................... 53
The procedure of A8 static survey.................................................... 53
Download data with USB drive.......................................................... 54
Management software operation for static survey................ 54
Technical Parameters...................................................................................... 57
Introduction....................................................................................................... 58
III

A8 GNSS RTK System Operation Manual
Receiver................................................................................................................58
Ports.........................................................................................................................61
Function Key and LED..............................................................................61
Intelligent Voice Module.........................................................................61
Accuracy...............................................................................................................61
Physical Feature..............................................................................................62
Environment.......................................................................................................62
Ports and Main Accessory............................................................................63
Introduction........................................................................................................64
Five-pin Port and Eight-pin Port.........................................................64
Differential Antenna....................................................................................66
Y Type Data Cable........................................................................................67
Regulatory Information.................................................................................69
Notes........................................................................................................................70
IV

A8 GNSS RTK System Operation Manual
C H A P T E R
1
Preface
Chapter Instruction
■Instruction
■Relative Information
■Your Suggestions
1

Perface
Instruction
Welcome to Hi-Target A8 Series GNSS RTK system
manual. This manual is designed for A8 GNSS RTK system,
and use A8 GNSS RTK as an example to explain the
installation, setup, and usage of the GNSS RTK system.
If you have used other GNSS RTK system before, Hi-
Target suggests you read this manual carefully and this manual
will help you to understand our A8 GNSS RTK system easily.
If you do not familiar with GNSS RTK, please check Hi-
Target website: http://www.hi-target.com.cn/en/
Relative Information
You can get the manual from: 1, the complement CD
when purchasing Hi-Target A8 equipment. You can get this
manual from folder named Manual; 2, Download from Hi-
Target website, Go to “Support”-> “Manual”-> “Surveying
Products”.
Your Suggestions
If you have any suggestions or comments on the manual,
please feel free to contact us, it will help us to improve our
manual quality greatly.
2

A8 GNSS RTK System Operation Manual
C H A P T E R
2
Summary
Chapter Introduction
■Introduction
■Products Features
■Usage and Notes
3

Summary
Introduction
A8 GNSS RTK system adopts modularized design, so as
to enable users to change into different differential
transmission modules according to various requirements.
Those are traditional radio transmission, GPRS and 3G
communication functions. Meanwhile the designed self-
diagnosis function can autom atically check the working status
of all hardware and software of the A8 receiver while working,
and arouse the problem part by its intelligent voice messenger
in case of some problem .
Data collection controller can be connected with receiver
mainframe via Bluetooth or cable; built-in high-capacity
battery is suitable for long-time field work; static data can be
stored in the built-in memory card of receiver and downloaded
via USB port to your PC.
Tips: 1. A8 GNSS RTK system has many modules.
This manual does not represent standard
configuration. Users need to notify their
own requirements for the different
configuration due to different appplications.
2. And before using, we suggest users firstly
to check whether the package box is
damaged, and then open careful and check
whether inner items matched with the
order list of their own. If there are some
missing or damaging cases exist for
products and accessories, please contact
with the local
4

A8 GNSS RTK System Operation Manual
distributor or Hi-Target Foreign Trade Dep.
Immediately.
3. Last but not least, please carefully read
manual before carrying, handling and using!
Product Features
1. BD970 mother board of Pacific Crest, a Trimble Company,
multi-satellite, multi-system kernel.
2. 1+X multi-module communication units.
3. PCC Radio module (optional) compatible with
Trimble/Leica RTK.
4. Double battery capacity as 4400mAh, 12 hours for RTK
operating.
5. The highest performance in waterproof, dustproof and
anti-drop.
6. Adjustable to be single GNSS system or multi-GNSS
system: GPS, GLONASS, GALILEO.
Usage and Notes
Although A8 receiver using chemical and impact resistance
material, but necessary taking care and maintenance is still
required for such a precise instrument.
5

Summary
Warning: The receiver must be used and stored
in the specified temperature. More
details please refer to Chapter 7:
Technical Parameters.
To ensure the quality of continuous tracking satellites
and signals, surveying work should be in open air, while there
should no any obstacle in space above 15°altitude angle; in
order to reduce all kinds of electrical interference to the
GNSS satellite signals. Besides, there should not be strong
electrical interference around within about 200m range, such
as the television tower, microwave stations, high voltage
transmission line. Also, in order to avoid or reduce the
occurrence of multi-path effect, stations should be away from
terrain or geographical objects, which will strong effect
electrical signal, such as high-rise buildings, big pool, etc.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user?ÿs authority to
operate the equipment.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
The device must be operated to provide a separation distance of
at least 20cm from User.
6

A8 GNSS RTK System Operation Manual
C H A P T E R
3
Receiver Introduction
Chapter Introduction
■Introduction
■Receiver Appearance
■Control Panel
■Upper Cover
■Lower Cover
■Communication Module
■Battery
■Environmental Requirement
■Electric Interference
7

Receiver Introduction
Introduction
This Chapter mainly introduces A8 receiver appearance, buttons
and indicator led and so on.
Receiver Appearance
Receiver Appearance mainly including 4 parts: upper cover, lower
cover, guard collar and control panel, as Figure 3-1
Upper Cover
Guard Collar
Screw
Control Panel Lower Cover
Figure 3-1 Receiver Appearance
8

A8 GNSS RTK System Operation Manual
Control Panel
Figure 3-2, in the middle of red frame of A8 receiver is control
panel. And the control panel contains the F1 key (function key 1), F2
key (function key 2) and the power button, 3 indicator leds which are
respectively satellite led, the status led (dual-color led ), the power led
(dual-color led). The simple three buttons include all th e features
setting of the A8 receiver.
Control Panel
Figure 3-2 Control Panel
Satellite led（green led）
Status led（red-green dual-color led）
Power led(red-green dual-color led)
9

Receiver Introduction
Function Key: settings of working mode,
transmitting power,satellite elevation angle,automatically base
setting, reset receiver and so on.
Function Key: settings of data link, collection interval, back to
original setting.
Power Key: setting confirmation, automatically base setting
and so on.
Upper Cover
Figure 3-3 indicates the upper cover of A8 receiver, the main
function of which is anti-dro p and anti-scratch.
Raised Plate
Raised Point
Figure 3-3 U pper Cover
Raised Point: anti-wear point to avoid instrument being scratched

Raised Plate: 5 raised plates can avoid wear-out and falling
10

A8 GNSS RTK System Operation Manual
Lower Cover
As figure 3-4, lower cover of A8 includes communication
module slot, battery groove, fiv e-pin port, eight-pin port,
loudspeaker and so on.
Communication
Module Connector
Communication
Module position
Loudspeaker
Eight-pin Port
Joint Nut
and Protection
Plug SLC Power Supply Block
Battery Groove
Five-pin Port and
Protection Plug
SIM Card Slot
Figure 3-4 Lower Cover
Communication Module: according to different
requirements, traditional communication module can be
chosen

Communication module connector: connect communication
module and mainframe
11

Receiver Introduction
Battery Groove: install 4400m Ah lithium battery
Five-pin port: connect mainfra me with external data link or
with external power supply
Eight-pin Port: connect A8 receiver with computer, or controller for
data download and delete
Protection Plug: anti-dust and waterproof for socket
SIM card slot: when choose G SM communication, install SIM card.
Joint Nut: fix instrument with tribrach and centering pole.
Loudspeaker: voice broadcast for real-time operation and status.
Tips: 1. if no need to use five-pin port, eight-pin port
and differential antenna port, please affix
rubber plugs to achieve waterproof and
dustproof.
2. when water comes in loudspeaker, maybe it
becomes silent or sound hoarse. But it will
be back to normal after drying.
Communication Module
As figure 3-5 of the appearance of communication module,
according to different re quirements.
13

Receiver Introduction
Close Open
Figure 3-7 Battery Front
Anode
Cathode
Figure 3-8 Battery Back
Environmental Requireme nt
Even though A8 receiver uses waterproof materials, maintaining
in a dry environment is still helpful. In order to improve the stability,
and duration of the receiver, please avoid exposing the receiver in
extreme environments, such as:
Moist

Temperature higher than 65 Celsius degrees

Temperature lower than -40 Celsius degrees

Corrosive liquid or ga


14

A8 GNSS RTK System Operation Manual
Electrical Interference
Do not place GNSS receiver around a strong power interference
signal source, such as:
Oil duct ( spark plug )

Television and computer monitor

Generator

Electric motor

DC-AC power conversion equipment

Fluorescent Light

Power switcher
15

General Operations
C H A P T E R
4
General Operations
Chapter Introduction
■Introduction
■Button Functions
■Led Status Instructions
■Turn On/Off Receiver
■Static Data Storage
■RTK Data Storage
■Reset Receiver
■Back to Original Settings
■Format Receiver
■Power Supply System
■Communication Module
■SIM Card/ USIM Card
■Firmware
16

A8 GNSS RTK System Operation Manual
Introduction
Most of the operations of A8 receiver can be done by the three
buttons on the mainframe pa nel.
Buttons on the panel:
Satellite Led Status Led
Power Led
Function Button F1 Function Button F2 Power Button
Figure4-1 Mainframe Panel
Explanations of buttons operations and leds hints as below:
Operations Explanation
Single click button Press a button less than 0.5 second
Double click button Double click the button while the
clicking interval should be between 0.2 to 1
second
Long pressing button Pressing button more than 3 second
17
