Hi-Tec AXION 2 User manual

HITEC 2.4GHz
Hitec Customer Service
Help is available from the Hitec oce through phone support and e-mail inquiries.
Our US oce is generally open Monday thru Friday, 8:00AM to 4:30PM PST.
These hours and days may vary by season. Every attempt is made to answer every incoming service call.
Should you get voice mail, leave your name and number and a sta member will return your call.
Hitec Website
Make plans to visit the Hitec website, www.hitecrcd.com, on a regular basis. Not only is it full of specs and other inform
ation about the entire Hitec product line, our FAQ pages will eventually hold valuable information and program update
about the AXION Series receiver.
One of the benets of the extensive R/C online community is the vast wealth of archived knowledge available.
Hitec sponsors forums on most of the popular R/C web sites where a Hitec sta member or representative tries to
answer all manner of product related questions.
Bringing together strangers with common interests is proving to be one of the greatest gifts of the internet. If past history
is any guide to the future, we are certain forums will be started about the Hitec 2.4 system and several are certain to
stand out as valuable archives of information
All Hitec products carry a two year from date of purchase warranty against manufactures defects.
Our trained and professional service representative will determine if the item will be repaired or replaced.
To provide all the necessary information we need to administrate your repair, visit our website at www.hitecrcd.com and
download the repair form, ll it out and send in your item for repair.
Operating Voltage: Rechargeable four to six cell NiMH, NiCd, or LiPo batteries (4.8~7.4V). From the receiver battery
power or speed control (ESC) power. Select the suitable voltage depends on the servos capability.
Current Consumption: 30mA
Note
Servo manufacturer will specify maximum voltage of their servo model.
Please refer each servo’s specication.
Compatibility
The Tachyon Series receivers are compatible with transmitters using the Hitec Surface 2.4G AFHSS system
1. Function Button
Used for linking the receiver to a Transmitter, To select response.
2. LED Status Indicator
Indicates the set-up process codes and current status of Tachyon receivers..
See 2 page for more detail
3. Channel Output and Battery Input Ports
The ports for battery, servos and other accessories
Fail safe / Hold
The positions of the servos and other accessories can be set with a FAIL-SAFE point, if power to the receiver is Lost within
1 sec. See page 2 more detail
The On-Line Community
Warranty and Non-Warranty Service
1. The receiver antenna should not be placed near the engine, metal parts, or high current batteries.
2. The receiver Antenna should not get damaged. To prevent antenna damage, do not install the
antenna near the sharp edge or bend it more than 90 degree in angle.
3. Use a Velcro or think double sided tape to install to absolve the shock during the operation.
4. When LED indicator irregularly blinks, indicates unstable frequency environment, stop operating and
look for the possible cause of problems.
Warning
Axion Series Receiver Specications & Features
Full Range AFHSS 2.4GHz Receivers
Receiver Model Size Weight Stock Number
AXION 2 1.26 x 0.87 x 0.43in (32 x 22.3 x 11mm) 0.25oz (7.0g) 27724
AXION 4 1.26 x 0.87 x 0.43in (32 x 22.3 x 11mm) 0.25oz (7.0g) 27824
2&4
• Risk of explosion if battery is replaced by an incorrect type. Dispose of used battery according to the instructions.
European CE notice to users and product statements
- Frequency Range : 2409.2 MHz ~ 2474.0 MHz
- Hereby, HITEC RCD INC, declares that our (RE type : PROTON 4e) is in compliance with RED 2014/53/EU.
The full text of the EU DoC is available at the following internet address:
www.multiplex-rc.de
• FRANCE Frequency Range : 2.4056GHz~ 2.4482GHz
FCC notice to users and product statements
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
Operation is subject to the following two conditions; (1) this device may not cause harmful interference,
and
(2) this device must accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Instruction Manual
Version 2.0

Note
Note
When you try to have Link, please located TX & RX less than a 3 feet distance.
Receiver Connection Diagrams (AXION2)
Electric powered car with Electronic Speed Control
Use this method on electric car using ESC’s
providing power to the receiver and servo functions.
How to Link (ID-Set)
When you purchase a radio set that Transmitter and receiver include together in the box, each device
are linked already from the factory.
If you purchase extra receivers or transmitter, you need to have Link with current your device together.
How to Link LYNX 4S with AXION receivers
1. Surface AFHSS 2.4GHz Transmitter (LYNX 4S)
(1) Select [RX-BIND] from LYNX 4S system menu
(2)Select receiver type from menu
(3) Run Bind Mode
(4) When Blue LED on receiver is solid on, Link is complete.
(5) Turn off the Bind Mode pressing ESC button twice
(6) Turn off the receiver and Turn on again.
2. AXION Series Receiver
(1) Run Bind Mode in Transmitter.
(2) Press and hole the LINK button and turn on the receiver.
(3) release button, and then LED will be blink Blue and Red rapidly..
(4) When LED turn on Solid Bleu, Link set up is complete
Fail-safe or Hold Mode Switch
If you use the FAIL-SAFE function, and set it up properly, should the receiver signal somehow be
interrupted or interference were to occurred, the servos will move to your pre-set FAIL-SAFE position
you previously stored in the receiver during the FAIL-SAFE set-up.
If FAIL-SAFE has not been activated, the signal is switched off after the HOLD period of 1 sec. This
means that the servos become “soft” and remain in their last commanded position under no load
(this may equate to full-throttle!), until a valid signal is picked up again.
In the interests of safety, we recommend that FAIL-SAFE should always be activated, and the FAIL-SAFE
settings should be selected so as to bring the model to a non-critical situation (e.g. motor idle / electric
motor OFF, control surfaces neutral, or full brake, etc.)
HHR
Power Battery Motor
BEC
ESC
SERVO
Steering
AMB
AMB
SERVO SERVO SERVO
Steering
Engine
AUX
SERVO
AUX
Receiver
Battery
Fail Safe- / Hold Set up (AXION 2&4)
Receiver Connection Diagrams (AXION4)
Glow, gas or electric powered car using a separate
receiver battery supply.
Follow this connection diagram when using a regulated
2cell Li-Po/Li-Fe, or 4.8~7.2V (4~6cell) NiMh/NiCd.
Receiver battery,
Turn on Transmitter and receivers..
Select [FAIL SAFE] from transmitter menu,
and then you can select Fail safe or Hold.
After you set, please press ‘SEND’ button
Fail safe and Hold function of AXION Receivers
can be set by Lynx 4S transmitter.
When you press ‘SEND’ on transmitter, LED on receivers will be blink in ‘BLUE’ rapidly.
If LED turn on solid Blue, set up is completed.
Set up the fail safe position of trigger/ steering wheel/ switch before you set up
(ie. Full brake, engine idle),
Make sure to check Fail Safe set properly, turn off the transmitter and check the position.
After 1sec, if there is no signal, Fail Safe function will be activated.
Please check Fail Safe position every time before you run
The FAIL-SAFE settings should be checked every time before you run the engine/motor.
This product is designed to be used as a R/C hobby product and should be operated under
local regulation.
Hitec Service
12115 Paine St. Poway CA 92064
1-858-748-6948
E-mail: [email protected]
