SatKing DVBS2-800CA User manual

This manual will help you to install, use and maintain the receiver. Please read this manual
carefully before operating your unit and keep it for future reference.
Thank you for purchasing DVBS2 800CA Digital Satellite Receiver.
Warning & Note
In this manual, pay special attention to the following marks that indicate hazardous situations.
Warning:Alert user to the operation which could result in device damage or data loss, and
the presence of a hazardous situation which could result in serious injury.
Note:Remind user of presence of possible problems and information of any importance to
help understand, use and maintain the installation.
Note: The information in this user’s manual is subject to change without notice. The
photos and function explanations in the manual are for reference. If any discrepancy
exists, please contact your local dealer for assistance.
Trademark
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
LLC in the United States and other countries.
Other trademarks, product and company names mentioned herein are the property of their
respective owners.

User’s Manual
1
Safety Instruction
Read following items carefully before operating your new VAST receiver.
Installation
This receiver should be installed horizontally. Unbalanced installation may cause damage.
Install the receiver in a place with:
Good ventilation (leave space not less than 10cm around this receiver)
No heat source (radiator, heater, fireplace, amplifier, etc)
Low humidity (especially not bathroom, kitchen, etc)
No direct sunlight
Low vibration
Maintenance
Unplug this receiver from power socket before changing connections between this unit and
other related equipments.
Don’t unplug or insert signal, audio and video cables when this receiver is on.
To avoid the risk of lightning strike, unplug power adapter of the receiver from power socket
in lightning storm.
Unplug power adapter from power socket when the unit is not going to be used for a long
time or is damaged.
When moving this receiver from hot to cold or vice versa, turn the unit off for 1 hour before
to prevent moisture build up.
To avoid the risk of fire or electric shock, don’t expose this receiver to rain, water and don’t
put object with liquid on this unit.
Do not cover vents of this receiver with paper, table cloth, curtains, etc.
Don’t put heavy objects on this receiver.
Unplug power adapter of this receiver from power socket before cleaning. To reduce
damage, clean this unit with dry cloth. Do not let liquid spill or spray liquid into this device to
avoid serious damage.
Power Socket and Power Adapter
Make sure the power pack is not covered as this pack will get warm.
Do not insert or pull out power adapter with wet hands to avoid electric shock.
Do not use damaged power adapter. If power adapter is damaged, contact your local
dealer for replacement to avoid risk of fire or electric shock.
RCU Battery
Batteries should be installed in accordance with the polarity markings (+/-) on battery
compartment.
Remove batteries if RCU is not used for a long period of time.
Replace batteries if there is not enough power and dispose of battery waste with the envi-
ronment in mind.
Accessory
Only use accessories specified by the manufacturer, as other unsupported accessories
may cause damage to the receiver.

User’s Manual
2
Contents
1. Before Using the Receiver ..................................................................................................4
1.1 Main Features...............................................................................................................4
1.2 Front Panel ...................................................................................................................5
1.3 Conditional Access (CA)...............................................................................................5
1.4 Rear Panel....................................................................................................................6
1.5 Remote Control Unit (RCU) ..........................................................................................7
1.6 Learning Instructions..................................................................................................... 8
2. Installation ............................................................................................................................ 9
2.1 Connect TV...................................................................................................................9
2.2 Connect Optional IR Target.........................................................................................13
2.3 Connect other Device .................................................................................................13
2.4 Power on.....................................................................................................................14
2.5 Search Channel ..........................................................................................................14
3. Basic Operation.................................................................................................................. 15
3.1 Channel Change.........................................................................................................15
3.2 Volume Control ...........................................................................................................15
3.3 Channel Information Bar.............................................................................................15
3.4 Channel List................................................................................................................ 16
3.5 Audio Selection ...........................................................................................................16
3.6 Aspect Mode ............................................................................................................... 16
3.7 Teletext........................................................................................................................16
3.8 Closed Caption (Subtitles) ..........................................................................................16
3.9 PVR Hotkey Menu ......................................................................................................17
4. Personal Video Recording (PVR)......................................................................................17
4.1 HDD Speed Test .........................................................................................................17
4.2 Set Recording Parameter ...........................................................................................17
4.3 Quick Recording .........................................................................................................18
4.4 Schedule Recording.................................................................................................... 18
4.5 Operation while Recording..........................................................................................19
4.6 Playback Recorded File..............................................................................................20
4.7 Edit Recorded File ......................................................................................................21
4.8 Time Shift....................................................................................................................23
5. USB Application................................................................................................................. 23
5.1 MP3.............................................................................................................................23
5.2 Digital Photo................................................................................................................ 24
6. HDD Management ..............................................................................................................24
6.1 Clean up USB device..................................................................................................24
6.2 Format USB Device .................................................................................................... 24
7. Electronic Program Guide (EPG)......................................................................................24
7.1 View EPG Information................................................................................................. 24
7.2 Schedule Program ......................................................................................................25
7.3 Schedule Manage....................................................................................................... 25
8. Channel Search.................................................................................................................. 25
8.1 Signal Finding .............................................................................................................25
8.2 Installation...................................................................................................................26
8.3 TP Edit ........................................................................................................................26
9. Settings ............................................................................................................................... 27
9.1 Common Setting .........................................................................................................27

User’s Manual
3
9.2 AV Setting....................................................................................................................27
9.3 Factory Default............................................................................................................28
9.4 Modify System Password............................................................................................28
9.5 Parental Control.......................................................................................................... 28
10. USB Upgrade.................................................................................................................... 29
11. Over the Air (OTA) Upgrade............................................................................................29
12. Information........................................................................................................................ 29
12.1 Smart Card Status ....................................................................................................29
12.2 Softcell Service Status..............................................................................................29
12.3 Loader Status............................................................................................................ 30
12.4 Mail Information ........................................................................................................ 30
12.5 Help Information........................................................................................................ 30
13. Appendix........................................................................................................................... 30
13.1 Troubleshooting/Help................................................................................................30
13.2 Specifications............................................................................................................33
14. Acronym............................................................................................................................ 35

User’s Manual
4
1. Before Using the Receiver
1.1 Main Features
VAST Certified
High Definition Mpeg2/4 Compliant
12V/240V Operation, for Home or RV use
Signal Finder with Beeper
USB PVR Ready
STi-7111 450MHz Main Processor
Time Shift Function
Infrared target to place the receiver out of view (optional)
MP3 Playback and Photo Browse
8 Day Electronic Program Guide
Subtitles Supported
Parental Control Function
System Password Supported
PAL/NTSC Video System
Over the Air Secure Software Download
Standby with Low Power Consumption
HDMI Output
Component Output
CVBS Output
Dolby Digital Audio
Coaxial & S/P DIF Digital Audio Outputs
Stereo Audio Outputs
USB 2.0 interface
RF Modulator Function
DiSEqC1.0/1.2 supported
Irdeto Secure Silicon Conditional Access

User’s Manual
5
1.2 Front Panel
Name Function
1. STANDBY Switch between operation and standby modes
2. RESET Press the reset button in the event the unit freezes
3. DISPLAY Clock is displayed when unit is in Standby, CH# when on
4. IR Infrared remote sensor
5. MENU Display/exit from main menu
6/9.

Adjust volume or move cursor left/right
7/8.

Change channels or move cursor up/down
10. OK Display channel list or confirm operation
11. Smart card slot Open the cover to insert smart card
1.3 Conditional Access (CA)
Your VAST receiver requires the smart card to be inserted at all times to enjoy programs.
Note: The VAST smart card is already inserted
Insert Smart Card
1. Open the right-hand cover on front panel.
2. Face the side with electronic chip downwards and insert
the smart card into the lower slot horizontally according to
arrow direction.
Notes:
•The Smart Card number is displayed under Informa-
tion in the system setting menu.
•Please note the smart card number in case of queries.
•Do not bend or damage the smart card.
•Do not place the smart card in hot environment or under direct sunlight.

User’s Manual
6
•Use a dry soft cloth too clean the surface of the smart card gently.
•Do not place into liquid or cleaning agent.
•If the smart card does not work properly, please contact your local dealer.
1.4 Rear Panel
Name Function
1. LNB IN Connect to satellite dish
2. LOOP OUT Loop out the satellite signal to another receiver
3. D-AUDIO Output digital audio signal to amplifier
4. S/P DIF Output digital audio signal to amplifier
5. IR Connect to IR extender (optional, contact dealer to purchase)
6. USB Connect to USB device for recording, pictures or upgrading
7. ETHERNET Connect to Ethernet
8. HDMI
Output video and audio signal to TV (support high definition
output)
9. Y/Pb/Pr Output Y/Pb/Pr video signal to TV (support high definition
output)
10/11. R/L-AUDIO Output right/left audio signal to TV or amplifier
12. VIDEO Output CVBS video signal to TV
13. RF OUT Output analog signal to TV
14. RF IN Input terrestrial TV signal
15. DC power input port (2.1mm)
16. RS-232 Serial port used for software upgrade (Authorised personnel
only)

User’s Manual
7
1.5 Remote Control Unit (RCU)
Name Function
1. Learning buttons
SET To program learning remote function
TV/AV Change TV source
TV Turn TV On/Off
VOL+/- Turn TV volume up/down
CH+/- Change channel on TV
2. Buttons on the Remote Control Unit
Switch between operation and standby
modes
MUTE Mute/restore sound
TV/RADIO Switch between TV and radio modes
INFO Display channel information bar
AUDIO Display audio select window
HELP Display help information window
TEXT Display Teletext information (If Available)
SUBT Display Close Caption (Subtitles)
ASPECT Adjust aspect ratio to suit TV
CH+/- Change channels
PAGE

/

Page up/down
V+/- Adjust volume
EPG Display electronic program guide
RECALL Back to previously viewed channel

Change channels or move cursor up/down

Adjust volume or move cursor left/right
OK Display channel list or confirm operation
MENU Display/exit from main menu
EXIT Back to previous menu or exit from opera-
tion
0 ~ 9 Change channels by entering numbers
Colour keys Functions depend on specific applications

User’s Manual
8
3. Buttons for PVR functions
INFO Display playback progress bar or time
shift progress bar

Small jump backward when playback

Small jump forward when playback
PVR Display short cut window
PLAY/PAUSE Pause playback or pause playing to
start time shift
STOP
Stop playback, recording or time shift
REC
Record current program or display
recording information
Fast backward (x2, x4, x8, x16, x32
speed)
Fast forward (x2, x4, x8, x16, x32
speed)
Notes:
•The buttons mentioned in the manual refer to RCU
keys.
•Please operate according to instructions on screen.
1.6 Learning Instructions
The RM-06 has learning ability to take over the use of the main TV remote for the basic func-
tions:
1) Source
2) Volume+/-
3) Existing ATV or DTV channel control +/- where available
Instructions:
1. Depress SET key of the STB RCU for 3secs, the red light will increase in intensity.
2. Aim TV RCU at the sensor of the STB RCU, then press key on the STB RCU that you want
to pair. The light will flash slowly and when complete the light will flash fast.
3. When pairing of buttons is completed press the SET key to exit learning mode.
