Hi-Tec MINIMA 6S User manual

Hitec Service
12115 Paine St. Poway CA 92064
1-858-748-6948
E-mail: [email protected]om
Introduction
Service & Support
Hitec Customer Service
Help is available from the Hitec office through phone support and e-mail inquiries.
Our US office is generally open Monday thru Friday, 8:00AM to 4:30PM PST.These
hours and days may vary by season. Every attempt is made to answer every incoming
service call. Should you reach our voicemail, leave your name and number and a staff
member will return your call.
Hitec Web Site
Make plans to visit the Hitec website, www.hitecrcd.com, on a regular basis. Not only is it
full of specs and other information about the entire Hitec product line, our website’s FAQ
pages will eventually hold valuable information and program updates about the Spectra
2.4 module and Optima series of receivers.
The On-Line Community
One of the benefits of the extensive R/C online community is the vast wealth of archived
knowledge available. Hitec sponsors forums on most of the popular R/C websites where
a Hitec staff member or representative tries to answer all manner of product related
questions. Bringing together strangers with common interests is proving to be one of the
greatest gifts of the internet. If past history is any guide to the future, we are certain
forums will be started about the Hitec 2.4 system and several are certain to stand out as
valuable archives of information.
Warranty and Non-Warranty Service
All Hitec products carry a two year from date-of-purchase warranty against
manufacturer’s defects. Our trained and professional service representatives will
determine if the item will be repaired or replaced. To provide all the necessary information
we need to administrate your repair, visit our website at www.hitecrcd.com and download
the repair form, fill it out and send in your item for repair.
Thank you for your purchase of the HitecAdaptive Frequency Hopping Spread Spectrum
(AFHSS) 2.4GHz module and receiver system. This manual contains the complete
directions on how to use the Minima 6S receiver. We encourage you to review the entire
manual before using these products.
Size : 1.19 X 0.81 X 0.27in (30.4 X 20.8 X 7.11mm)
Weight : 0.19oz (5.25g)
Stock Number: #26615
Operating Voltage : 3.7~8.4V From receiver battery power or
speed control (ESC) power
Max Current Consumption : 50mA
Minima 6S Features
1. Function Button
- Used for binding the receiver to a module or Hitec 2.4 built-in transmitters,
2. Single LED Status Indicator
- Indicates the set-up process codes and single status of the receiver.
3. Channel Output and Battery Input Ports
- The ports for battery power input and servos, gyros and other accessories output port
are located at the side end of the Minima 6S receiver
Compatibility
- The Minima 6S Receiver is compatible with transmitters using Hitec’sAFHSS
2.4 GHz system such as Spectra 2.4 module or dedicated built-in moduleAFHSS 2.4
Hitec transmitters.
HITEC 2.4GHz
Receiver Instruction
version 2.0
Warning!
1. For maximum performance, it is recommended to position the antenna at a
90 degree angle as shown in the picture shown below.
2. The receiver antenna should not be placed near the engine, metal parts,
or high current batteries.
3. When using a large number of high-power digital servos in a model, it is highly
recommended to use the SPC feature to insure the receiver always gets the
power it needs in high load conditions. If not, use the system with enough
receiver battery capacity.
4. There could be a possible time-delay in receiving telemetry data from
HTS-SS(sensor-station) depending on the conditions in the area you fly.
5. It is strongly recommended to use Hitec ‘s genuine Heavy Duty High Channel
Switch Harness with Receiver Charger Cord (Stock#. 54407S) for all
Optima series receivers.
Recommended Position
Park plane AFHSS 2.4GHz Receivers
MINIMA 6S
MINIMA 6S
• Risk of explosion if battery is replaced by an incorrect type.
Dispose of used battery according to the instructions.
European CE notice to users and product statements
- Frequency Range : 2409.2 MHz ~ 2474.0 MHz
- Hereby, HITEC RCD INC, declares that our (RE type : MINIMA6S) is in
compliance with RED 2014/53/EU.
The full text of the EU DoC is available at the following internet address:
www.multiplex-rc.de
• FRANCE Frequency Range : 2.4056GHz~ 2.4482GHz
FCC notice to users and product statements
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
Operation is subject to the following two conditions;
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
CAUTION:
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

Antenna installation
Receiver Connection Diagrams
ID-Setup A.K.A, Link or Bind
Glow, Gas, Nitro or Electric-PoweredAircraft Using a Separate Receiver Battery
Use this method on electric planes using ESCs providing power to the receiver and
servo functions
The Minima 6S antenna system is made for high directivity consisting of two antennas.
In order to secure the clear range, please install Minima 6S antenna as shown below.
TX
TX TX
TX
RX
90˚
Recommended installation
method to optimize
receiver performance
2.4GHz 6 Channel
2.4GHz 6 Channel
Aircraft Receiver
Aircraft Receiver
2.4GHz 6 Channel
2.4GHz 6 Channel
Aircraft Receiver
Aircraft Receiver
Link (ID-Setting)
Too Close: Less than 50Cm(18in)
Too Far: More than 5M(15ft)
- Link must be done within 15ft(5m). of the transmitter and receiver.
- Transmitter and receiver need to be at least 18in(50cm).
from each other to link properly.
Note
Link (ID-Setup or Bind)
Your HitecAFHSS system uses a communication protocol that links and binds the Hitec
2.4GHz receiver to your transmitter. Once the receiver and module are “bound,” no other
transmitter can interfere with your receiver during its operation. In the case of multiple
model memory transmitters, you can bind as many Hitec
2.4GHz receivers to your transmitter, one per model memory as necessary.
Each module and receiver set is paired at the factory for your convenience.
Use one of the following binding methods to bind additional Hitec 2.4GHz receivers to
your transmitter.
Non-telemetry RXs (MINIMA 6S)
Press and hold the link button on the
Receiver and turn on the power.
Press and hold the
button on the
module and
turn on the
transmitter.
BLUE LEDs on the Receiver will blink rapidly
to find the transmitter signal.
Release the link button when the
BLUE LED on the receiver glows steady.
When the link is completed,
the BLUE LED on the module
will blink.
Release the link button.
To save the setting, please reboot both the
Transmitter and Receiver
When they are turned on again,
the RED LED on the Radio
and the BLUE LED on the
Receiver will glow steady.
Check if BLUE LED is blinking.
If RED LED is blinking, press
the link button for 2 sec., so
that LED changes to the BLUE.
