Highfield Boats
Driver’s Seat Installation Guide
(PA500)
DSIG2021V1

Corrosion Inhibitor
Installation Guide
(Driver’s Seat: FS700)
Caution
Before installing consoles or seats over fuel tank access compartments, please remove the cover and check that all fuel
fitting are secure. Please also check that electrical wiring and fuel lines are clear of the soon to be drilled cable access
hole.
When tank cover is reinstalled use a silicone sealer on the lid.
① Red stickers indicate the location of holes for installation. Tear off the stickers and cut the anti-skid
PVC decking to expose the holes. Do not remove the anti-skid fabric.
② Use insulating compound to eliminate corrosion between the aluminum and the stainless steel
screws.
Recommended corrosion inhibitor: Duralac, Tef-Gel, Lanocote
Page 1/3

Installation Guide
(Driver’s Seat: FS700)
③Gently clean the deck. Secure the seat using polyurethane marine grade adhesive such as 3M 5200,
Sika 291, Fixtech Fix 15.
④ Use insulating compound on the M8 stainless steel screws supplied with the seat. Fasten the seat to
the deck using the screws.
Page 2/3
1—Screw M8×25mm;
2—Stainless steel spring washer M8×13mm
3—Stainless steel flat washer M8×24mm
4—Seat base;
5
—
Deck
polyurethane marine grade adhesive

Installation Guide
(Driver’s Seat: FS700)
Congratulations, you have successfully installed the driver’s seat.
Page 3/3
