SeaView ADA-BLANK User manual

INSTALLATION
INSTRUCTIONS
For Seaview Modular Top Plate:
ADA-BLANK
WWW.SEAVIEWGLOBAL.COM
Refer to website for most up to
date instructions and videos.

x4
5⁄16” - 18
x8
5⁄16” - 11⁄4”
x1 AD-AFN-M2BLANK
3⁄16” = 4.763mm
x1 AD-AFN-M1P
PARTS INCLUDED
TOOLS NEEDED
1
Sudbury Elastomeric Marine
Sealant is recommended. To
purchase call 800-655-7922 or visit
www.seaviewglobal.com

Place the rubber gasket into
the grove on the top of the
Seaview mount. Note, that
the rubber gasket is included
in the Seaview mount kit.
Place the AD-AFN-M1P ontop
of the mount, be sure to line
up the four mounting holes.
1Insert the four nuts into the
underside of the
AD-AFN-M1P plate.
5⁄16” - 18
x4
2
3
2

Bolt the AD-AFN-M1P down
with four 5⁄16” - 1-1⁄4” bolts
using a allen wrench.
Carefully drill and mount
your search light to the
AD-AFN-M2BLANK plate.
Secure the search light using
the hardware provided by
the manufacturer.
Apply marine adhesive
sealant to the groove on the
underside of the
ADA-FN-M2BLANK plate.
4
5
6
5⁄16” - 1¼”
x4
3

Bolt the ADA-FN-M2BLANK
plate down with four 5⁄16”
- 11⁄4” bolts using a allen
wrench.
The four holes on the
back of the ADA-F2 are
for securing the optional
Seaview Light Bar to the top
plate.
7
8
5⁄16” - 1¼”
x4
4
