HIK VISION DS-2TS36-100VI/W User manual

Handheld Thermal Multi-function Binocular Camera
User Manual
.

User Manual of Handheld Thermal Multi-function Binocular Camera
ii
© 2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
This Manual is the property of Hangzhou Hikvision Digital Technology Co., Ltd. or its
affiliates (hereinafter referred to as “Hikvision”), and it cannot be reproduced, changed,
translated, or distributed, partially or wholly, by any means, without the prior written
permission of Hikvision. Unless otherwise expressly stated herein, Hikvision does not
make any warranties, guarantees or representations, express or implied, regarding to
the Manual, any information contained herein.
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts,
images and all other information hereinafter are for description and explanation only.
The information contained in the Manual is subject to change, without notice, due to
firmware updates or other reasons. Please find the latest version of this Manual at the
Hikvision website (http://www.hikvision.com/).
Please use this Manual with the guidance and assistance of professionals trained in
supporting the Product.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the properties of
Hikvision in various jurisdictions.
Other trademarks and logos mentioned are the properties of their respective
owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE
PROVIDED “AS IS” AND “WITH ALL FAULTS AND ERRORS”. HIKVISION MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE.
THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF

User Manual of Handheld Thermal Multi-function Binocular Camera
iii
THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT
SECURITY RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR
ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM
CYBER-ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY
RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND
YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE
APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A
MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING
WITHOUT LIMITATION, RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR
DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT
FOR ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF
WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF CHEMICAL
OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR
EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS
ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW,
THE LATER PREVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particdular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the

User Manual of Handheld Thermal Multi-function Binocular Camera
iv
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This equipment should be installed and operated with a minimum distance 20cm
between the radiator and your body.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation
EU Conformity Statement
This product and, if applicable, the supplied accessories are marked with
“CE” and comply therefore with the applicable harmonized European
standards listed under the Radio Equipment Directive 2014/53/EU, the
EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot
be disposed of as unsorted municipal waste in the European Union. For
proper recycling, return this product to your local supplier upon the
purchase of equivalent new equipment, or dispose of it at designated
collection points. For more information see: www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that
cannot be disposed of as unsorted municipal waste in the European
Union. See the product documentation for specific battery information.
The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the
battery to your supplier or to a designated collection point. For more information see:
www.recyclethis.info.

User Manual of Handheld Thermal Multi-function Binocular Camera
v
Symbol Convention
The symbols that may be found in this document are defined as follows.
Symbol
Description
Provides additional information to emphasize or supplement
important points of the main text.
Indicates a potentially hazardous situation, which if not
avoided, could result in equipment damage, data loss,
performance degradation, or unexpected results.
Indicates a hazard with a high level of risk, which if not
avoided, will result in death or serious injury.
Safety Instructions
These instructions are intended to ensure that user can use the product correctly to
avoid danger or property loss.
Laws and Regulations
●Use of the product must be in strict compliance with the local electrical safety
regulations.
Transportation and Storage
●Keep the device in original or similar packaging while transporting it.
●Keep all wrappers after unpacking them for future use. In case of any failure
occurred, you need to return the device to the factory with the original wrapper.
Transportation without the original wrapper may result in damage on the device
and the company shall not take any responsibilities.
●Do not drop the product or subject it to physical shock. Keep the device away from
magnetic interference.
Power Supply
●Please use the power adapter, which is provided by normal company. Input voltage
should meet the Limited Power Source (5 VDC, 2A) according to the IEC61010-1
standard. Please refer to technical specifications for detailed information.
●Make sure the plug is properly connected to the power socket.
●DO NOT connect multiple devices to one power adapter, to avoid over-heating or
fire hazards caused by overload.
Battery
●Improper use or replacement of the battery may result in explosion hazard. Replace
with the same or equivalent type only. The battery type is 18650, and the rated

User Manual of Handheld Thermal Multi-function Binocular Camera
vi
voltage and capacity is 3.6 VDC/3.3 Ah (11.88Wh). Dispose of used batteries in
conformance with the instructions provided by the battery manufacturer.
●Do not charge other battery types with the supplied charger. Confirm there is no
flammable material within 2 m of the charger during charging.
●For long-term storage of the battery, make sure it is fully charged every half year to
ensure the battery quality. Otherwise, damage may occur.
●DO NOT place the battery near heating or fire source. Avoid direct sunlight.
●DO NOT swallow the battery to avoid chemical burns.
●DO NOT place the battery in the reach of children.
Maintenance
●Clean the lens with soft and dry cloth or wiping paper to avoid scratching it.
●Wipe the device gently with a clean cloth and a small quantity of ethanol, if
necessary.
●If the product does not work properly, please contact your dealer or the nearest
service center. We shall not assume any responsibility for problems caused by
unauthorized repair or maintenance.
●If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the device may be impaired.
Using Environment
●DO NOT expose the device to extremely hot, cold, dusty, corrosive, saline-alkali, or
damp environments. Make sure the running environment meets the requirement of
the device. The operating temperature shall be -30 °C to 60 °C (-22 °F to 140 °F), and
the operating humidity shall be 95% or less.
●This device can only be safely used in the region below 2000 meters above the sea
level.
●Avoid equipment installation on vibratory surface or places subject to shock (neglect
may cause equipment damage).
●Do not aim the lens at the sun or any other bright light.
Emergency
●If smoke, odor, or noise arises from the device, immediately turn off the power,
unplug the power cable, and contact the service center.
Laser
●When any laser equipment is in use, make sure that the device lens is not exposed
to the laser beam, or it may burn out.

User Manual of Handheld Thermal Multi-function Binocular Camera
vii
The laser radiation emitted from the device can cause eye injuries,
burning of skin or inflammable substances. Before enabling the light
supplement function, make sure no human or inflammable substances are
in front of the laser lens.
●Do not place the device where minors can fetch it.
Manufacture Address
No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China
Hangzhou Hikvision Digital Technology Co.,Ltd.
User Manual of Electronic Version
Scan the QR code to view the user manual on your mobile phone. Note that mobile
data charges may apply if Wi-Fi is unavailable.

User Manual of Handheld Thermal Multi-function Binocular Camera
viii
Table of Contents
1Overview ..............................................................................................1
1.1 Device Description ..................................................................................... 1
1.2 Function ................................................................................................... 1
1.3 Appearance............................................................................................... 2
1.3.1 Button................................................................................................ 2
1.3.2 Interface............................................................................................. 3
1.3.3 Cable.................................................................................................. 4
2Preparation...........................................................................................5
2.1 Packaging List ............................................................................................ 5
2.2 Charge Device ........................................................................................... 5
2.3 Install Battery ............................................................................................ 6
2.4 Mount Interchangeable Lens....................................................................... 7
2.5 Power On/Off ............................................................................................ 8
2.6 Menu Description ...................................................................................... 8
2.7 Cable Connection....................................................................................... 9
3Image Settings ....................................................................................10
3.1 Set Focus ................................................................................................ 10
3.2 Adjust Brightness..................................................................................... 10
3.3 Adjust Contrast.........................................................................................11
3.4 Switch Mode ............................................................................................11
3.5 Set Palettes ..............................................................................................11
3.6 Fusion Target........................................................................................... 12
3.7 Adjust Digital Zoom.................................................................................. 13
3.8 Set OSD .................................................................................................. 13
3.9 Display Time ........................................................................................... 13
3.9.1 Synchronize Time .............................................................................. 13
4Distance Measurement and Target Positioning .....................................14
5Enable GPS .........................................................................................15
6Picture and Video ...............................................................................16
6.1 Capture Snapshots................................................................................... 16
6.2 Record Video........................................................................................... 16
6.3 View Snapshots ....................................................................................... 16
6.4 Export File .............................................................................................. 16
7T-Vision Connection ............................................................................17
8CVBS Output.......................................................................................17
9Maintenance.......................................................................................18
9.1 Restore Device......................................................................................... 18

User Manual of Handheld Thermal Multi-function Binocular Camera
ix
9.2 Upgrade Device ....................................................................................... 18
10 Appendix .........................................................................................19
10.1 Device Command ................................................................................. 19
10.2 Device Communication Matrix ............................................................... 19

User Manual of Handheld Thermal Multi-function Binocular Camera
1
1Overview
1.1 Device Description
The handheld thermal binocular (binocular for short) is a pair of
binoculars with both thermal observation function and target
searching function. The device can quickly discover and accurately
locate targets on the ground, at sea and in the river even under
extreme environment, such as smoke, fog, rain and snow. It can be
applied to various scenarios, such as patrol, law enforcement, search
and rescue, drug enforcement, anti-smuggling and suspect capture.
1.2 Function
Distance Detection
Device can detect the target distance with the cursor or the built-in
laser-distance detection module.
GPS
Device can locate the target position and can be located with GPS
system.
DMC
The DMC (Digital Magnetic Compass) module can detect the azimuth
angle and elevation angle of the target and show the direction
information on the screen.
Fusion
Device can display the fusion of thermal view and optical view.
Palette
Device supports multiple palettes, and you can set the palette mode
according to the scene.
Software Connection

User Manual of Handheld Thermal Multi-function Binocular Camera
2
You can capture snapshots, record videos, and set parameters of the
device via the client software.
1.3 Appearance
1.3.1Button
The main keys of the binocular are shown below.
Power Key
Focus Key +
Focus Key -
Capture Key Adjust Key
Measure Key
Menu Key
For the descriptions of the menu buttons, see the table below.
Button
Function
Power Key
Press the key to emphasize the
high-temperature target in the view in
fusion mode.
Hold the key to power on/off the device.
Menu Key
Press the key to switch the pallets.
Hold the key to enter the menu.
Measure Key
Press the key to switch between White Hot
mode and Black Hot mode.
Hold the key to detect the target distance
with the cursor or laser.
Adjust Key
Press the key to adjust the digit zoom.
Hold the key to correct nonuniformity of
display.
Capture Key
Press the key to capture the view.
Hold the key to start/stop recording.

User Manual of Handheld Thermal Multi-function Binocular Camera
3
Focus Key +
Press the key to forward focus step by step.
Hold the key to forward focus quickly.
Focus Key -
Press the key to reverse focus step by step.
Hold the key to reverse focus quickly.
The laser function only supported by certain camera models.
1.3.2Interface
Front View
Top View
Rear View
Thermal Lens
Visible Light Lens
Battery Compartment
Eyepieces
Eyeshades
Aviation Connector
Tripod Screw
Approaching Sensor
Laser Range Finder
Interface
Function
Eyeshades
Cover the eyes.

User Manual of Handheld Thermal Multi-function Binocular Camera
4
Eyepieces
View the target.
Visible Light Lens
Let the visible light in.
Laser Range Finder
Including a laser transmitter and a
laser receiver.
Thermal Lens
Let the infrared light in.
Battery Compartment
The battery is here.
Tripod Screw
Install the binocular on tripod.
Aviation Connector
Connect with the cables. See 0.
Approaching Sensor
Detect whether human eyes are
approaching to save power. If it
detects eyes, the OLED screen
turns on, otherwise the OLED
screen is off.
The laser function only supported by certain camera models.
1.3.3Cable
BNC
USB
DB9
Cable
Function
BNC
Connect it to the display screen.
USB
Connect it to your PC to backup videos/images.
DB9
Reserved.

User Manual of Handheld Thermal Multi-function Binocular Camera
5
2Preparation
2.1 Packaging List
+
-+
-+
-+
-
Thermal Binocular (×1)
USB Cable (×1)
Battery Charger (×1)
Manual (×1)
Battery (×8)
Straps (×2)
Aviation Plug Cables (×1)
Non-dust Cloth (×1)
2.2 Charge Device
Purpose:
For the first use, when the device is running in low battery, charge
the batteries.
Steps:
1. Take out the USB cable from the package.
2. Connect the USB cable with battery charger and appropriate
adaptor.

User Manual of Handheld Thermal Multi-function Binocular Camera
6
3. Insert the batteries in the charger with corresponding
positive/negative terminals.
When the charger is powered on, the LCD display automatically lights
up. The charger will detect the battery and charge it.
Status
Description
Unlighted
Power-saving mode, press any
button to activate it.
Good
Battery is healthy.
Poor
Battery is damaged.
EE EE
Battery reverse connected or
short circuit.
END
Battery is charged more than 20h.
4. Complete battery charging and disassemble the battery.
2.3 Install Battery
Purpose:
Insert the batteries into the battery compartment.
Steps:
1. Rotate the battery cover anticlockwise to disassemble it.
1
2
2. Insert four batteries with positive/negative marks to match
those of the battery compartment

User Manual of Handheld Thermal Multi-function Binocular Camera
7
Batteries
3. Align the shape of battery cover with that of the batteries and
cover the batteries.
4. Rotate the battery cover clockwise to fix it.
2.4 Mount Interchangeable Lens
Step:
Align the two red spots on the interchangeable lens and the
objective, then rotate the interchangeable lens clockwise to finish
mounting.
Red Spots
Rotate the interchangeable lens anticlockwise to dismount it.

User Manual of Handheld Thermal Multi-function Binocular Camera
8
2.5 Power On/Off
When the binocular is fully charged, press the key to power on
it.
When the binocular is running, hold the key to power off it.
Turn the device according to the figure below after starting up. You
can use the DMC function when the calibration level in the upper
left corner of the screen is three.
Only models without laser distance measurement require the operation
in the figure, please take the actual model for reference.
See the battery icon for the electricity quantity. means battery is
fully charged, and means that the battery runs low.
When the low power note shows, charge the battery.
2.6 Menu Description
Step:
Hold the button to show the menu.
In the menu, the direction keys, OK key, and the Exit key are shown
below.
Previous
NextOK
Back
See the figure below for the menu interface.
The figure below is only for reference, the font size is readjusted for
better viewing.

User Manual of Handheld Thermal Multi-function Binocular Camera
9
Digital Zoom Storage Battery
Palettes Hot Spot
GPS DMC
2.7 Cable Connection
DO NOT drag the cables when you are connecting the cables, or the
cables are connected.
To plug in/out the cable, hold the cable end and then plug in/out it. DO
NOT twist the cables, or the pins inside may be damaged.
Purpose:
Connect the binocular with the aviation cable, and you can connect
the device to your PC via USB interface or the display via the BNC
interface.
Step:
Connect the aviation cable with the aviation Interface. Make sure
the anchor points match with each other and insert the cable.
Anchor
Point
To disconnect the cable, lift the cable.

User Manual of Handheld Thermal Multi-function Binocular Camera
10
3Image Settings
3.1 Set Focus
DO NOT touch the lens directly with your finger, or place any sharp
objects near it.
Steps:
1. Slightly rotate the focus wheel to focus the eyepiece.
Rotate Left/Right
2. In the live view interface, press or hold the key and
key to focus the objective. Press the key to focus step by step.
Hold the key to focus quickly.
3.2 Adjust Brightness
Steps:
1. Hold the key to show the menu of binocular.
2. Press the key and key to move the cursor to Display
submenu.
3. Press the key to confirm.
4. Press the key and key to move the cursor to
Brightness submenu.
5. Press the key to confirm.
6. Press the key or key, and press the key to adjust
the brightness value. The higher, the brighter.
7. Press the key to save and exit.

User Manual of Handheld Thermal Multi-function Binocular Camera
11
3.3 Adjust Contrast
Steps:
1. Hold the key to show the menu of binocular.
2. Press the key and key to move the cursor to Display
submenu.
3. Press the key to confirm.
4. Press the key and key to move the cursor to Contrast
submenu.
5. Press the key to confirm.
6. Press the key or key, and press the key to adjust
the contrast value. The higher, the more contrasting.
7. Press the key to save and exit.
3.4 Switch Mode
Purpose:
The change of environment temperature will affect the display effect.
You can switch the mode between Winter and Summer to get a
better view.
Steps:
1. Hold the key to show the menu of binocular.
2. Press the key and key to move the cursor to Display
submenu.
3. Press the key to confirm.
4. Press the key and key to move the cursor to Mode
submenu.
The submenu is not displayed in Visible mode.
5. Press the key to switch mode between winter and
summer.
6. Press the key to save and exit.
3.5 Set Palettes
Purpose:
The binocular has dual-lens: thermal and visible light lens. You can
set the thermal/optical view to show thermal channel, visible light
channel, or both of them. For thermal view, you can set the palettes.
Step:
