HIK VISION DS-1100KI User manual

DS-1100KI & DS-1105KI Network Keyboard
User Manual

DS-1100KI & DS-1105KI Network Keyboard User Manual
i
Preface
This section is to ensure that you can avoid danger or property loss in the process of using the
product. Before using the product, please read the user manual carefully and keep it for future
reference.
Get More Information
Visit our website (http://www.hikvision.com/) for user manuals, application tools and
development materials.
Applicable Model
This manual is applicable to DS-1100KI and DS-1105KI Network Keyboard.
Important Clause
Please strictly abide by the applicable laws and regulations for the use and maintenance of
monitoring interface. It is illegal to use video monitoring device for illegal purposes, or to explore
other people's privacy.
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Danger
Indicates a hazardous situation which, if not avoided, will or could
result in death or serious injury.
Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Note
Provides additional information to emphasize or supplement
important points of the main text.

DS-1100KI & DS-1105KI Network Keyboard User Manual
ii
Operation Convention
The following operations may be found in this document are defined as follows.
Operation
Description
Press Number + REGION
●Press a numeric button and REGION button to select a region.
●Number represents region ID. Go to region menu for the ID.
Press Number + WALL
●Press a numeric button and WALL button to select a video wall.
●Number represents video wall ID. Go to video wall client for the
ID.
Press Number + WIN
●Press a numeric button and WIN button to select a sub-window.
●In video wall mode, if the monitor is divided in to multiple
windows, the number represents sub-window ID.
Press Number + MON
●If device is video wall or decoder:
○Press a numeric button and MON button to select a monitor.
○Number represents monitor ID. Go to video wall client for the
ID.
●
●If device is video recorder:
○Press a numeric button and MON button to select an output
channel.
○Number represents output channel ID. Go to Keyboard →
Channel → Output Channel for the ID.
Press Number + CAM
Keyboard mode:
○Press a numeric button and CAM button to select an output
channel.
○Number represents input channel ID. Go to Keyboard →
Channel → Input Channel for the ID.
●HikCentral/iSecure mode:
○Press a numeric button and CAM button to select a camera.
○Number represents camera ID. Check camera ID in resource
list.
Press Number + CAM-G
●Press a numeric button and CAM-G button to select an input
channel group.
●Number represents input channel group ID. Go to Keyboard →

DS-1100KI & DS-1105KI Network Keyboard User Manual
iii
Operation
Description
Channel → Camera Group for the ID.
Press Number + MACRO
●Press a numeric button and MACRO button to select a macro.
●Number represents macro ID. Go to Keyboard → Macro for the
ID.
Press Number + GROUP
●Press a numeric button and GROUP button to select a group.
●Number represents group ID. Go to Keyboard > Group for the ID.
Press Number + MULT
●Press a numeric button and MULT button to divide monitor.
●Number represents sub-window quantity.
Press Number + SCENE
●Press a numeric button and SCENE button to switch video wall
scene.
●Number represents scene ID. Check the ID in video wall mode.

DS-1100KI & DS-1105KI Network Keyboard User Manual
iv
Contents
Chapter 1 Product Introduction ..................................................................................................1
Chapter 2 Activation...................................................................................................................2
2.1 Local Menu Activation...........................................................................................................2
2.2 SADP Activation.....................................................................................................................3
2.3 Web Activation......................................................................................................................3
Chapter 3 Network.....................................................................................................................4
Chapter 4 Keyboard ...................................................................................................................5
4.1 Login.......................................................................................................................................5
4.2 Add Devices ...........................................................................................................................6
4.2.1 Manually Add .............................................................................................................6
4.2.2 Add in Batches............................................................................................................8
4.3 Local Live View ......................................................................................................................9
4.3.1 Preview by Operating Touchscreen...........................................................................9
4.3.2 Preview by Operating Keyboard Shortcut.................................................................9
4.3.3 PTZ Control ...............................................................................................................10
4.4 Video Wall ...........................................................................................................................14
4.4.1 Video Wall Configuration.........................................................................................14
4.4.2 Video Wall Control ...................................................................................................16
4.4.3 PTZ Control ...............................................................................................................19
4.4.4 Group and Macro .....................................................................................................19
4.5 Playback...............................................................................................................................20
4.5.1 Local Playback ..........................................................................................................20
4.5.2 Video Wall Playback.................................................................................................21
4.6 Channel Management.........................................................................................................22
4.6.1 Edit Channel..............................................................................................................22
4.6.2 Output Channel........................................................................................................23
4.6.3 Camera Group ..........................................................................................................23
4.7 User Management...............................................................................................................25
4.8 Video Recorder....................................................................................................................26

DS-1100KI & DS-1105KI Network Keyboard User Manual
v
4.8.1 Remote Panel ...........................................................................................................26
4.8.2 Live View...................................................................................................................29
4.8.3 PTZ Control ...............................................................................................................29
4.8.4 Playback....................................................................................................................29
4.9 Connect the Device Through Serial Ports...........................................................................29
4.9.1 Connect Video Recorders.........................................................................................29
4.9.2 Connect Analog Matrix ............................................................................................31
4.9.3 Connect Analog Dome..............................................................................................32
Chapter 5 iSecure Mode ...........................................................................................................35
5.1 Login.....................................................................................................................................35
5.2 Resource List........................................................................................................................36
5.3 Local Live View ....................................................................................................................37
5.3.1 Enable Local Live View .............................................................................................37
5.3.2 PTZ Operation...........................................................................................................37
5.4 Video Wall Operation..........................................................................................................37
5.4.1 Region Configuration ...............................................................................................37
5.4.2 Video Wall Control ...................................................................................................38
5.4.3 PTZ Operation...........................................................................................................38
5.5 Video Wall Playback............................................................................................................39
Chapter 6 HikCentral Mode ......................................................................................................40
6.1 Login.....................................................................................................................................40
6.2 Resource List........................................................................................................................41
6.3 Local Live View ....................................................................................................................41
6.3.1 Enable Local Live View .............................................................................................41
6.3.2 PTZ Operation...........................................................................................................42
6.4 Video Wall Operation..........................................................................................................43
6.4.1 Region Configuration ...............................................................................................43
6.4.2 Video Wall Control ...................................................................................................43
6.4.3 PTZ Operation...........................................................................................................44
6.5 Video Wall Playback............................................................................................................44

DS-1100KI & DS-1105KI Network Keyboard User Manual
vi
Chapter 7 System .....................................................................................................................45
7.1 Language..............................................................................................................................45
7.2 Hardware .............................................................................................................................45
7.3 Storage.................................................................................................................................46
7.3.1 FTP Storage...............................................................................................................46
7.3.2 USB Storage ..............................................................................................................47
7.4 Upgrade ...............................................................................................................................47
7.4.1 FTP Upgrade .............................................................................................................47
7.4.2 USB Flash Drive Upgrade .........................................................................................48
7.5 Import/Export Configuration File .......................................................................................48
7.6 Factory Default....................................................................................................................48
7.7 Auxiliary Key........................................................................................................................49
7.8 Lock Keyboard .....................................................................................................................49
Chapter 8 Web Configuration ...................................................................................................50
8.1 Login.....................................................................................................................................50
8.2 Add Devices .........................................................................................................................50
8.2.1 Manually Add ...........................................................................................................50
8.2.2 Import Input Channels in Batches ...........................................................................53
8.3 Channel Management.........................................................................................................53
8.3.1 Edit Channel..............................................................................................................53
8.3.2 Camera Group ..........................................................................................................54
8.4 Serial Port Settings ..............................................................................................................55
8.5 Network...............................................................................................................................56
8.6 System Settings ...................................................................................................................57
8.6.1 Version......................................................................................................................57
8.6.2 User Management....................................................................................................57
8.6.3 System Maintenance................................................................................................59
8.6.4 Log Management......................................................................................................60
8.6.5 Security Settings.......................................................................................................61

DS-1100KI & DS-1105KI Network Keyboard User Manual
1
Chapter 1 Product Introduction
DS-1100KI and DS-1105KI are network keyboard independently developed by Hikvision. It features
in 7-inch full view multi-touch LCD screen and four-dimensional joystick. It supports network
access to DVR, DVS, NVR, network camera, network dome, video integrated platform, decoder,
iSecure, HikCentral and other platform software, with powerful functions and quick and simple
operations. It can be widely used in finance, public security, telecommunication, transportation,
electric power, education, water conservancy and other fields.

DS-1100KI & DS-1105KI Network Keyboard User Manual
2
Chapter 2 Activation
You can activate network keyboard via local menu, SADP client or Web interface.
2.1 Local Menu Activation
For the first-time access, you need to activate the network keyboard by setting an admin
password.
Steps
1. Connect your network keyboard power supply to an electrical outlet, and turn on the network
keyboard.
The activation interface will be popped up automatically.
2. Set password and confirm it.
Caution
We highly recommend you create a strong password of your own choosing (Using a minimum of
8 characters, including at least three of the following categories: upper case letters, lower case
letters, numbers, and special characters.) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
resetting the password monthly or weekly can better protect your product.
Figure 2-1 Activation
3. Tap Activate.

DS-1100KI & DS-1105KI Network Keyboard User Manual
3
2.2 SADP Activation
SADP software is used for detecting the online device, activating the device, and resetting its
password.
Get the SADP software from the supplied disk or the official website, and install the SADP
according to the prompts.
Steps
1. Connect your network keyboard power supply to an electrical outlet, and turn on the network
keyboard.
2. Run the SADP software downloaded from our website to search the online devices.
3. Check the keyboard status from the device list, and select the inactive keyboard.
4. Enter the new password in the password field, and confirm it.
Caution
We highly recommend you create a strong password of your own choosing (Using a minimum of
8 characters, including at least three of the following categories: upper case letters, lower case
letters, numbers, and special characters.) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
resetting the password monthly or weekly can better protect your product.
5. Click Activate.
2.3 Web Activation
After editing the PC and the network keyboard to the same network segment, you can directly log
in to the web interface of the network keyboard to activate.

DS-1100KI & DS-1105KI Network Keyboard User Manual
4
Chapter 3 Network
Network parameters must be properly configured before you can add network devices and
operate the network keyboard over network.
Steps
1. Go to System → Network.
2. Configure network parameters.
●Enable DHCP to obtain IP settings automatically.
●Manually enter IP address, subnet mask, and gateway.
●Enable SADP to search devices, change IP addresses through SADP software.
3. Tap Save.
Figure 3-1 Network Parameters

DS-1100KI & DS-1105KI Network Keyboard User Manual
5
Chapter 4 Keyboard
Keyboard mode is mainly applied to small-sized projects. Network keyboard works as a control
center and manages security devices in it.
4.1 Login
Steps
1. Tap Keyboard at home page.
Figure 4-1 Login
2. Enter user name and password.
3. Optional: Check Remember.
4. Tap Login.
Note
If you enter the wrong password 7 times for administrator or 5 times for operator, the current
user account will be locked for 30 minutes.

DS-1100KI & DS-1105KI Network Keyboard User Manual
6
4.2 Add Devices
Up to 4000 devices can be added.
4.2.1 Manually Add
Steps
1. Go to Keyboard → Device.
Figure 4-2 Device Management
2. Tap Center Device or IPC/IP Dome as desired.
3. Tap .
4. Enter device IP address, port, user name, and password.
Note
●The device name is obtained automatically or can be configured as required.
●If you enable the stream encryption for the device, you need to enter the verification code
when adding the device.
5. Check or uncheck Add Video Recorder Output.
Note
Check Add Video Recorder Output, and the output port type, channel number and other
information will be listed in the output port list.
6. Tap OK.

DS-1100KI & DS-1105KI Network Keyboard User Manual
7
Figure 4-3 Add Center Device
Figure 4-4 Add Network Camera

DS-1100KI & DS-1105KI Network Keyboard User Manual
8
4.2.2 Add in Batches
Add Online Devices in Batches
You can add the devices with the same user name and password in batches.
Steps
1. Go to Keyboard → Device.
Figure 4-5 Device Management
2. Tap to enter Add by SADP interface.
Figure 4-6 Online Devices
3. Check the devices to be added and tap .
4. Enter user name and password.
5. Tap Add.
Import Input Channels in Batches
The information of added input channel can be generated into an excel file and exported to the

DS-1100KI & DS-1105KI Network Keyboard User Manual
9
USB flash drive for backup.
Before You Start
Connect an USB flash drive to the network keyboard.
Steps
1. Go to Keyboard → Channel.
2. Export input channel template.
1) Tap to export an excel file.
2) Edit the file on your computer, like adding or deleting input channels.
3) Copy the file to an USB flash drive and connect it to your network keyboard.
3. Tap to import input channels.
4.3 Local Live View
Preview an input channel in keyboard touchscreen.
4.3.1 Preview by Operating Touchscreen
Steps
1. Go to Keyboard → Channel.
2. Select the channel and tap to preview.
4.3.2 Preview by Operating Keyboard Shortcut
Press the keys of the keyboard to preview the input channel.
Steps
1. Press 0+MON.
2. Preview the channel as desired.
●Press Num + CAM to preview the signal of the corresponding channel.
●Press Num + CAM-G to preview the camera group.
●Tap in the touchscreen and select the channel or the camera group as desired to
preview.

DS-1100KI & DS-1105KI Network Keyboard User Manual
10
Figure 4-7 Local Live View
3. You can do the following operations.
4-Screen Preview
●Press 4 + MULT to switch the current image into 4 screens, and tap
any screen to preview the images of different cameras.
●Press 1 + MULIT to return the previous image.
Switch Channels
Press PREV/NEXT to switch to the previous or next channel.
Full Screen
Press ESC to switch to the full screen.
Capture Images
Press the top of the rocker to capture a image.
Clip Videos
Press to start clipping and press it again to stop clipping.
4. Press 0+CAM to stop previewing.
Note
●You can preview the channel with up to 4K resolution.
●Press Num + CAM to control PTZ without previewing images from speed domes.
●The captured image and the recording can be saved in USB flash drive or uploaded to FTP
server. For FTP configuration, see Storage.
4.3.3 PTZ Control
You can control the added speed dome. For example, you can control PTZ movement, turn on/off
light, turn on/off wiper, zoom in/out, increase/decrease focus, increase/decrease iris, and set/call

DS-1100KI & DS-1105KI Network Keyboard User Manual
11
preset, patrol and pattern.
General Operation
Steps
1. Preview speed dome image.
Note
For detailed steps, see Preview by Operating Touchscreen and Preview by Operating Keyboard
Shortcut.
2. Move joystick and press buttons of keyboard to control PTZ.
Table 4-1 Buttons Description
Button
Description
Button
Description
LIGHT
Turn on/off light.
WIPER
Turn on/off wiper.
FOCUS+
Increase focus.
FOCUS-
Decrease focus.
IRIS+
Increase iris.
IRIS-
Decrease iris.
ZOOM+
Zoom in.
ZOOM-
Zoom out.
PRESET
Set/call preset.
PATROL
Set/call patrol.
PATTERN
Set/call pattern and
start/stop auto-scan.
Joystick
Rotate PTZ.
Set and Call Preset
You can record the horizontal positions, vertical positions, and lens magnification of the preset
point by setting a preset point. To quickly monitor a certain target, you can call out the preset
position by operating the keyboard.
By Operating Touchscreen
1. Preview speed dome image. For detailed steps, see Preview by Operating Touchscreen and
Preview by Operating Keyboard Shortcut.
2. Set a preset.
1) Tap .
2) Tap Preset.
3) Rotate the joystick to move PTZ to a desired position.
4) Tap to set a preset.
3. Tap to call the preset.

DS-1100KI & DS-1105KI Network Keyboard User Manual
12
By Operating Keyboard Shortcut
1. Preview speed dome image. For detailed steps, see Preview by Operating Touchscreen and
Preview by Operating Keyboard Shortcut.
2. Rotate the joystick to move PTZ to a desired position.
3. Set a preset.
1) Press SET to start setting. The SET button turns red.
2) Press Num + PRESET to set the current position as corresponding preset.
3) Press SET to finish setting.
4. Press Num + PRESET to call the preset.
Set and Call Patrol
Patrol means that PTZ moves among several presets. PTZ will stay in a preset for a duration before
moving on to the next preset.
By Operating Touchscreen
1. Preview speed dome image. For detailed steps, see Preview by Operating Keyboard Shortcut
and Preview by Operating Touchscreen.
2. Set a patrol.
1) Tap .
2) Tap Patrol.
3) Tap of a desired patrol.
4) Tap Add Preset to add presets, including their speed and duration time, in the patrol.
5) Tap OK.
3. Tap to call the patrol.
By Operating Keyboard Shortcut
1. Preview speed dome image. For detailed steps, see Preview by Operating Keyboard Shortcut
and Preview by Operating Touchscreen.
2. Press SET to start setting.
The SET button turns red.
3. Press Num + PATROL to select which patrol to set.
Preset
It determines the order at which the PTZ will follow while moving through the patrol.
Speed
It defines the speed at which the PTZ will move from one preset to the next.
Duration
It refers to the time span to stay at the preset.

DS-1100KI & DS-1105KI Network Keyboard User Manual
13
Figure 4-8 Edit Patrol
4. Press Num + ENTER to select preset.
5. Press Num + ENTER to set duration.
6. Press Num + ENTER to set speed.
Note
If you press Num + PATROL during steps 4 to 6, the settings will be cleared.
7. Repeat steps 4 to 6 to set more points of the patrol.
8. Press SET to finish setting.
Note
Press Num + PATROL again to clear all parameters set. Press SET to reset.
9. Press Num + PATROL to call the patrol.
Note
You can also tap in Local Live View interface to select Patrol, set and call patrol.
Set and Call Pattern
Pattern records the movement of the PTZ. You can call the pattern to automatically move the PTZ
according to the predefined path.
By Operating Touchscreen
1. Preview speed dome image. For detailed steps, see Preview by Operating Touchscreen and
Preview by Operating Keyboard Shortcut.
