HIK VISION DS-2AE4215T-D User manual

HD-TVI Speed Dome
User Manual

HD-TVI Speed Dome User Manual
ii
User Manual
©2023 Hangzhou Hikvision Digital Technology Co., Ltd.
This user manual is intended for users of HD-TVI Speed Dome. It includes instructions on how to use
the Product. The software embodied in the Product is governed by the user license agreement
covering that Product.
About this Manual
This Manual is subject to domestic and international copyright protection. Hangzhou Hikvision
Digital Technology Co., Ltd. (“Hikvision”) reserves all rights to this manual. This manual cannot be
reproduced, changed, translated, or distributed, partially or wholly, by any means, without the
prior written permission of Hikvision.
Trademarks
and other Hikvision marks are the property of Hikvision and are registered
trademarks or the subject of applications for the same by Hikvision and/or its affiliates. Other
trademarks mentioned in this manual are the properties of their respective owners. No right of
license is given to use such trademarks without express permission.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION MAKES NO WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL.
HIKVISION DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE
USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR RELIABILITY OF INFORMATION
CONTAINED HEREIN. YOU USE THIS MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE
WHOLLY AT YOUR OWN RISK AND RESPONSIBILITY.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT WILL HIKVISION, ITS
DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES
FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, SECURITY BREACHES, OR LOSS OF DATA
OR DOCUMENTATION, IN CONNECTION WITH THE USE OF OR RELIANCE ON THIS MANUAL, EVEN IF
HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OR CERTAIN
DAMAGES, SO SOME OR ALL OF THE ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO
YOU.
Support
Should you have any questions, please do not hesitate to contact your local dealer.
Thank you for purchasing our product. If there are any questions, or requests, please do not
hesitate to contact the dealer.

HD-TVI Speed Dome User Manual
iii
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the Low Voltage Directive 2014/35/EU, the EMC Directive 2014/30/EU, the
RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the battery to your supplier or to a designated
collection point. For more information, see: www.recyclethis.info.
030510221222

HD-TVI Speed Dome User Manual
iv
Safety Instruction
These instructions are intended to ensure that the user can use the product correctly to avoid
danger or property loss.
The precaution measure is divided into ‘Warnings’ and ‘Cautions’:
Warnings: Serious injury or death may be caused if any of these warnings are neglected.
Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
Warnings Follow these safeguards to
prevent serious injury or death.
Cautions Follow these precautions to
prevent potential injury or material
damage.
Warnings:
Adopt the power adapter which can meet the safety extra low voltage (SELV) standard. Refer to
the specification manual for the standard of power adapter and the power consumption cannot
be less than the required value.
Do not connect several devices to one power adapter as an adapter overload may cause
over-heating and can be a fire hazard.
When the product is installed on a wall or ceiling, the device should be firmly fixed.
To reduce the risk of fire or electrical shock, do not expose the indoor used product to rain or
moisture.
This installation should be made by a qualified service person and should conform to all the local
codes.
Install blackouts equipment into the power supply circuit for convenient supply interruption.
If the product does not work properly, please contact your dealer or the nearest service center.
Never attempt to disassemble the product yourself. (We shall not assume any responsibility for
problems caused by unauthorized repair or maintenance.)

HD-TVI Speed Dome User Manual
v
Cautions:
Make sure the power supply voltage is correct before using the product.
Do not drop the product or subject it to physical shock. Do not install the product on vibratory
surface or places.
Do not expose it to high electromagnetic radiating environment.
Do not aim the lens at the strong light such as sun or incandescent lamp. The strong light can
cause fatal damage to the product.
The sensor may be burned out by a laser beam, so when any laser equipment is being used,
make sure that the surface of the sensor not be exposed to the laser beam.
Do not place the dome in extremely hot, cold, dusty or damp locations, otherwise fire or
electrical shock will occur. Refer to the Specification for the details of operating temperature.
To avoid heat accumulation, good ventilation is required for a proper operating environment.
While shipping, the product should be packed in its original packing.
Use the provided glove when open up the product cover. Do not touch the product cover with
fingers directly, because the acidic sweat of the fingers may erode the surface coating of the
product cover.
Use a soft and dry cloth when clean inside and outside surfaces of the product cover. Do not use
alkaline detergents.
Improper use or replacement of the battery may result in hazard of explosion. Please use the
manufacturer recommended battery type.

HD-TVI Speed Dome User Manual
vi
Table of Contents
Chapter 1 Overview..................................................................................................................1
1.1 Description...............................................................................................................................1
1.2 Functions..................................................................................................................................1
Chapter 2 Getting Started.........................................................................................................4
2.1 Power-up Action.......................................................................................................................4
2.2 Basic Operations ......................................................................................................................4
2.3 System-defined Presets............................................................................................................5
2.4 On-screen Displays...................................................................................................................5
Chapter 3 Menu Operation.......................................................................................................7
3.1 Accessing and Operating the Menu.........................................................................................8
3.2 Configuring System Information ..............................................................................................8
3.2.1 Checking System Information...............................................................................................8
3.2.2 Configuring System Parameters ...........................................................................................9
3.3 Configuring Image Parameters...............................................................................................13
3.3.1 Configuring Camera Parameters.........................................................................................13
3.3.2 Configuring Privacy Mask ...................................................................................................18
3.3.3 Configuring Output Standard .............................................................................................20
3.3.4 Configuring IR Parameters..................................................................................................20
3.4 Configuring PTZ Control Parameters......................................................................................21
3.4.1 Configuring PTZ Parameters ...............................................................................................21
3.4.2 Configuring Presets.............................................................................................................23
3.4.3 Configuring Patrols .............................................................................................................24
3.4.4 Configuring Patterns...........................................................................................................26
3.4.5 Configuring Timing Tasks....................................................................................................27
3.4.6 Configuring Zone ................................................................................................................29
3.5 Configuring and Handling Alarms ..........................................................................................31
3.5.1 Configuring Alarm Input and Linkage Actions....................................................................31
3.5.2 Configuring Alarm Parameters ...........................................................................................32
3.5.3 Configuring Alarm Output ..................................................................................................33
3.6 Others.....................................................................................................................................34
3.6.1 Restoring Default Dome Settings........................................................................................34
3.6.2 Restoring Default Camera Settings.....................................................................................34
3.6.3 Rebooting the Dome ..........................................................................................................34
Appendix..................................................................................................................................................................34
Appendix 1 Lightning & Surge Protection ........................................................................................35
Appendix 2 RS485 Bus Connection ..................................................................................................36
Appendix 3 24 VAC Wire Gauge & Transmission Distance...............................................................39
Appendix 4 Wire Gauge Standards ..................................................................................................40

HD-TVI Speed Dome User Manual
1
Chapter 1 Overview
1.1 Description
Integrated with the built-in pan/tilt unit, the HD-TVI speed dome features highly sensitive response
and reliable performance. The speed dome can be adopted in various video security scenes with its
full-integral functions and features, such as corridor, large venue, meeting room, station,
neighborhoods, etc.
1.2 Functions
The functions vary according to the different models of the speed dome.
Coaxial Control
The speed dome with a specified DVR or controller can be sent the control signals via coaxial cable
(BNC cable).
High-Definition Output
The resolution of the output image can be up to 1080p.
Limits
The speed dome can be programmed to move within the limits (left/right, up/down).
Self-adaptive Protocol
While using RS-485 control, the speed dome is compatible with PELCO-D, PELCO-P and
PRIVATE-Code, etc., and is capable of being self-adaptive to these protocols without selecting
protocol by DIP switch settings. While using coaxial control, the speed dome is self-adaptive to
PELCO-D and PRIVATE-Code protocols.
Keyboard Control
The pan/tilt movement and zoom actions of dome can be controlled by the control keyboard, DVR,
matrix, etc.
Scan Modes
The dome provides 5 scan modes: auto scan, tilt scan, and panorama scan.
Preset Freezing
This feature freezes the scene on the monitor when the dome is moving to a preset. This allows for
smooth transition from one preset scene to another. It also guarantees that masked area will not be
revealed when the dome is moving to a preset.
Presets
A preset is a predefined image position. When the preset is called, the dome will automatically
move to the defined position. The presets can be added, modified, deleted and called.
Label Display
The on-screen label of the preset title, PT display, zoom, and time can be displayed on the monitor.
Auto Flips

HD-TVI Speed Dome User Manual
2
In manual tracking mode, when a target object goes directly beneath the dome, the video will be
automatically flipped 180 degrees in horizontal direction to maintain continuity of tracking. This
function can also be realized by auto mirror image depending on different camera models.
Privacy Mask
This function allows you to block or mask certain area of a scene, for preventing the personal
privacy from recording or live viewing. A masked area will move with pan and tilt functions and
automatically adjust in size as the lens zooms telephoto and wide.
3D Positioning
In the client software, use the left key of mouse to click on the desired position in the video image
and drag a rectangle area in the lower right direction, then the dome system will move the position
to the center and allow the rectangle area to zoom in. Use the left key of mouse to drag a rectangle
area in the upper left direction to move the position to the center and allow the rectangle area to
zoom out.
Proportional Pan/Tilt
Proportional pan/tilt automatically reduces or increases the pan and tilt speeds according to the
amount of zoom. At telephoto zoom settings, the pan and tilt speeds will be slower than at wide
zoom settings. This keeps the image from moving too fast on the live view image when there is a
large amount of zoom.
Auto Focus
The auto focus enables the camera to focus automatically to maintain clear video images.
Day/Night Auto Switch
The speed domes deliver color images during the day. And as light diminishes at night, the speed
domes switch to night mode and deliver black and white images with high quality.
Slow Shutter
In slow shutter mode, the shutter speed will automatically slowdown in low illumination conditions
to maintain clear video images by extending the exposure time. The feature can be enabled or
disabled.
Backlight Compensation (BLC)
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. The
BLC (Backlight Compensation) function can compensate light to the object in the front to make it
clear, but this causes the over-exposure of the background where the light is strong.
Wide Dynamic Range (WDR)
The wide dynamic range (WDR) function helps the camera provide clear images even under back
light circumstances. When there are both very bright and very dark areas simultaneously in the field
of view, WDR balances the brightness level of the whole image and provide clear images with
details.
White Balance (WB)
White balance can remove the unrealistic color casts. White balance is the white rendition function
of the camera to adjust the color temperature according to the environment automatically.
Patrol
A patrol is a memorized series of pre-defined preset function. The scanning speed between two
presets and the dwell time at the preset are programmable.
Pattern
A pattern is a memorized series of pan, tilt, zoom, and preset functions. By default, the focus and

HD-TVI Speed Dome User Manual
3
iris are in auto status during the pattern is being memorized.
Power Off Memory
The dome supports the power off memory capability with the predefined resume time. It allows the
dome to resume its previous position after power is restored.
Time Task
A time task is a preconfigured action that can be performed automatically at a specific date and
time. The programmable actions include: pan scan, patrol 1-8, pattern 1-4, preset 1-8, panorama
scan, tilt scan, day, night, and none.
Park Action
This feature allows the dome to start a predefined action automatically after a period of inactivity.

HD-TVI Speed Dome User Manual
4
Chapter 2 Getting Started
2.1 Power-up Action
After the speed dome is power-on, it will perform a series of self-test actions. The interface will be
shown as below:
XXXXX
SN XXXXXXXXX
ADDRESS 0
COM MODE 2400.8.1
PROTOCOL AUTO MATCH
FIRMWARE X.XX
HARDWARE X.XX
BUILD DATE XX XX XX
PAN SUCCESS
TILT SUCCESS
Figure 2-1 Original Interface
Table 2-1 Descriptions of the original interface
SN
The serial No. of the speed dome, which is unique.
ADDRESS
The default communication address of the speed dome.
COM MODE
The communication settings of the speed dome, including baud rate
(2400 by default), data bit (8 by default) and stop bit (1 by default)
digit).
PROTOCOL
It is for the communication with other devices.
FIRMWARE
The version of the firmware.
HARDWARE
The version of the hardware.
BUILD DATE
The date when the program of the software is compiled.
You have to configure the address and the baud rate for the speed dome the same as those in
the control devices.
The speed dome is self-adaptive to the PELCO-D, PELCO-P, and PRIVATE-Code protocols.
2.2 Basic Operations
You can operate the speed dome by using a control device, including the control keyboard, DVR,
DVS, etc. In this manual, accessing the speed dome via the web browser will be taken as the
example.

HD-TVI Speed Dome User Manual
5
Panning and tilting:
Click the direction buttons to control the pan and tilt movement of the speed dome.
Zooming:
Click the ZOOM+ and ZOOM- buttons to control the zooming.
Focusing:
Click the FOCUS+ and FOCUS- buttons to adjust the focus.
Iris:
Click the IRIS+ and IRIS- buttons to adjust the iris.
2.3 System-defined Presets
Purpose:
The section lists the system-defined presets with special functions. These presets cannot be edited
but can be only called through a control device, e.g. a DVS or web browser. To call the
system-defined presets remotely, you can choose the preset number from the list in the PTZ control
panel. Please refer to table below for details.
For instance, preset 99 is the “Start auto scan”. If you call the preset 99, the speed dome starts auto
scan function.
Table 2-2 System-defined Presets
Preset NO.
Function
Preset NO.
Function
33
Auto-flip
92
Enable limits
34
Return to home position
93
Set manual limits
35
Patrol 1
94
Remote reboot
36
Patrol 2
95
Access main menu
37
Patrol 3
96
Stop scanning
38
Patrol 4
97
Start Random Scanning
39
IR cut filter in
98
Start Frame Scanning
40
IR cut filter out
99
Start auto scanning
41
Pattern 1
100
Start tilt scanning
42
Pattern 2
101
Start panorama scanning
43
Pattern 3
102
Patrol 5
44
Pattern 4
103
Patrol 6
46
Enable fast patrol
104
Patrol 7
90
Enable Wiper
105
Patrol 8
2.4 On-screen Displays
The speed dome supports following on-screen displays:
Zoom Ratio: Identifies the amount of magnification. The format is ZXXX. XXX is the zoom amount.
PT Angle: Displays panning and tilting direction, with the format of NEXXX/TXXX. The NE followed
with XXX indicates the degrees in north east direction, while the T followed with XXX indicates the
degrees in tilt position.

HD-TVI Speed Dome User Manual
6
Alarm: When an alarm is triggered, the corresponding information will be displayed.
Time: Displayed as Day/Month/Year/Day of Week/Hour/Minute. It supports 24-hour time system.
Preset Label: After you call the configured preset, the preset number is displayed if the lens moves
to the certain place where you’ve set a preset for.
Zone: Display the zone title.
Address: Display the address of the speed dome.
Error Rate: Display the error rate of the speed dome.
Fan and Heat: Display the heat information of the speed dome.

HD-TVI Speed Dome User Manual
7
Chapter 3 Menu Operation
The menu operation part is only for your reference. The actual display may vary with your
camera model.
You can click the left and right direction buttons in the PTZ control panel via the web browser of
the DVR to enter the next page or return to the previous page of the submenu if more than one
page is available.
MAIN MENUS
SYS
SETTINGS
SYS INFO
ADDRESS
COM MODE
PROTOCOL
FIRMWARE
HARDWARE
BUILD DATE
TEMPERATURE
SYS INFO
SETTINGS
CAMERA
PARAMETER
MOTION
PARAMETER
PRESETS
PATROLS
TIME TASKS
PATTERNS
PRIVACY
MASK
ALARMS
AUX
CLEAR
SETTINGS
RESTORE
DEFAULTS
RESTORE
CAMERA
REBOOT SYS
LANGUAGE
CAM VERSION
PARAM DATE
ZONES
IR
PARAMETER
VIDEO SET
VIDEO OUT
Figure 3-1 Menu Structure
Before you start:
You can operate the speed dome by using the on-screen display menu remotely by connecting to a
DVR or a DVS (encoder).
Examples of entering speed dome menu are listed as follows:
Enter the menu by pressing buttons: PTZ -> REC -> 9-> 5on the front panel of the DVR.
Enter the menu by pressing buttons: CALL -> 9-> 5-> ENTER on the keyboard.
Enter the menu via the web browser of a DVR/DVS.
Menu operations via the web browser of a DVR will be taken as an example in this chapter.

HD-TVI Speed Dome User Manual
8
3.1 Accessing and Operating the Menu
To call the main menu:
Steps:
1. Connect the video and RS-485 cables of speed dome to a DVR.
2. Visit the DVR via the web browser.
3. View the live video of the speed dome.
4. For PELCO-P/D and other private PTZ protocols, call preset 95 from the preset list in the PTZ
control panel of the DVR.
MAIN MENUS
<SYS INFO>
<SYS SETTINGS>
<RESTORE DEFAULTS>
<RESTORE CAMERA>
<REBOOT SYS>
LANGUAGE ENGLISH
EXIT
Figure 3-2 Main Menu
To move the cursor and operate the menu:
Move the cursor up/down: On the live view page of the web browser, click up/down direction
buttons or FOCUS + and FOCUS - buttons in the PTZ control panel to move the cursor up and
down.
Enter/Exit: On the live view page of the web browser, click IRIS+ to enter a submenu; move the
cursor to Exit and click IRIS+ to exit.
To change the value of a parameter:
Steps:
1. Move the cursor to the target item and click IRIS+ button.
2. Click the up/down or left/right buttons in the PTZ control panel to choose the value from the
selectable value list.
3. Press IRIS+ to confirm the change or click IRIS- to cancel and restore to the original value. You
can see the shape of cursor changes again.
3.2 Configuring System Information
3.2.1 Checking System Information
Purpose:
System information menu displays the current system information of the speed dome, including
model, address, protocol, etc. The information shown on this submenu is similar to the system

HD-TVI Speed Dome User Manual
9
information shown after the power-up action. Please refer to Section 2.1 for more details.
Enter the system information display menu:
MAIN MENUS > SYS INFO
SYS INFO
XXXXX
ADDRESS 0
COM MODE 2400.8.1
PROTOCOL AUTO MATCH
FIRMWARE 3.50
HARDWARE 1.00
BUILD DATE 19 01 17
BACK EXIT
SYS INFO
CAM VERSION 3.23-680
PARAM DATE 0 0 0
TEMPERATURE 30
VIDEO OUT TVI
BACK EXIT
Figure 3-3 System Information
Information on this menu cannot be edited.
The temperature refers to the internal temperature of the speed dome.
3.2.2 Configuring System Parameters
Purpose:
You can check and also edit the system information of software address, baud rate, system time, etc.
on the system information settings menu.
MAIN MENUS > SYS SETTINGS > SYSTEM INFO SETTING
SYS INFO SETTING
SOFT ADDRESS 1
SOFT ADDR ACT OFF
SOFT BAUD 2400
SOFT BAUD ACT OFF
BROADCAST ADDR ON
PELCO CHECKSUM ON
SYS TIME
BACK EXIT
SYS INFO SETTING
ZERO ANGLE
<DISPLAY SETTINGS>
HEAT CONTROL TEMP
FAN CONTROL TEMP
EIS FUNCTION OFF
EIS LEVEL N/A
PRESET FOCUS OFF
BACK EXIT
SYS INFO SETTING
PROTOCOL STATUS OFF
PROTOCOL AUTO MATCH
485 CHECK AUTO
POWER MEMORY 180S
NEAR FOCUS LEVEL 1
COAXITION ACT ON
PROTOCOL-C AUTO
BACK EXIT
Figure 3-4 System Information Settings
You can click the left and right direction buttons in the PTZ control panel via the web browser of
the encoder to enter the next page and return to the previous page of the submenu if more
than one page is available.

HD-TVI Speed Dome User Manual
10
Dome address settings
To Set the Soft Address of the Speed Dome
If the SOFT ADDR ACT is set to ON, the soft address is the valid address for connecting the speed
dome.
If the SOFT ADDR ACT is set to OFF, the hard address set by the DIP switch is the valid address of
the speed dome.
Before you set the soft address of the speed dome, you need to confirm that it is within the
control range of the control device (e.g. the DVR).
After you enable/disable the soft address, the speed dome will reboot automatically to activate
the settings.
To Set the Broadcast Address of the Speed Dome
When the BROADCAST ADDR is set to ON, the control device with address 0 is capable of
controlling all domes connected to it.
Soft Baud Rate Settings
If the SOFT BAUD is set to ON, the soft baud rate is the valid baud rate for the speed dome, with
2400, 4800, 9600 and 19200 are selectable.
If the SOFT BAUD is set to OFF, the baud rate should be set by the DIP switch.
After you enable/disable the soft baud rate, the speed dome will reboot automatically to
activate the settings.
PELCO CHECKSUM
The PELCO CHECKSUM is used for Pelco-P and Pelco-D protocols. If the video turns to slack or
uncontrollable, you can set the PELCO CHECKSUM to ON to improve the video quality.
System Time Configuration
(1) Move the cursor to SYS TIME using the direction buttons and click IRIS+ to enter.
(2) Click the left/right direction buttons to position the cursor on the specific item
(year/month/day or hour/minute/second) of which you want to change the value.
(3) Click the up/down direction buttons to increase/decrease the value.
(4) Click IRIS+ button to confirm the settings and exit.

HD-TVI Speed Dome User Manual
11
Y - M - D 19 01 05
H - M - S 15 08 05
IRIS +: OK
IRIS -: CANCEL
Figure 3-5 Set the System Time
Zero Angle Configuration
Purpose:
You can define the zero angle of the speed dome on the ZERO ANGLE submenu.
Steps:
1. Move the cursor to ZERO ANGLE using the direction buttons and click IRIS+ to enter.
2. Click the left/right/up/down direction buttons to adjust the monitor angle of the speed dome.
3. Click IRIS+ button to confirm the settings and exit.
Display Settings
Purpose:
You can enable or disable the on-screen display of PTZ movements, time, preset, zone, address,
error rate, and fan/heat show, etc.
Steps:
1. Move the cursor to DISPLAY SETTINGS using the direction buttons and click IRIS+ to enter it.
2. Move the cursor to the target item and click IRIS+ and click up/down direction buttons to
choose each display mode as ON or OFF, and define each display time as 2 seconds, 5 seconds
or 10 seconds.
3. Click IRIS+ button to confirm the settings.
If you enable the OSD for both ZOOM SHOW and P/T ANGLE, while calling a preset, the preset
No. will be displayed on the screen till the preset scene passes.

HD-TVI Speed Dome User Manual
12
DISPLAY SETTINGS
ZOOM SHOW OFF
P T SHOW OFF
TIME SHOW OFF
PRESET SHOW OFF
ZONE SHOW OFF
ADDRESS SHOW OFF
ERROR RATE SHOW OFF
BACK EXIT
Figure 3-6 Display Settings
The speed dome shows the viewing direction when you manually control it to rotate.
Table 1-1 Viewing Direction Display
Display
N
NE
E
SE
S
SW
W
NW
Indication
North
Northeast
East
Southeast
South
Southwest
West
Northwest
The north direction refers to the angle zero.
Heat Parameter Configuration
You can set the HEAT CONTROL to TEMP (controlled by the temperature), ON or OFF.
Fan Parameter Configuration
You can set the FAN CONTROL to TEMP (controlled by the temperature), ON or OFF.
EIS (Electronic Image Stabilization) Configuration
You can set the EIS FUNCTION to ON or OFF.
Preset Focus
You can set the preset focus function ON/OFF on PRESET FOCUS submenu.
Protocol and RS-485 settings
Select the protocol.
Choose the protocol on PROTOCAL submenu. You can configure it as AUTO MATCH, PELCO-P,
PELCO-D, or HIKVISION. When you choose AUTO MATCH, it is protocol self-adaptive.
Set the protocol status.
Set the PROTOCOL STATUS to ON to enable the user-defined protocol.
Enable the RS-485 configuration diagnosis.
You can set 485 CHECK to ON or AUTO for automatic RS-485 configuration diagnosis. If the
configuration is incorrect, an alert will be received; if you set the value as AUTO, it will
automatically stop the diagnosis when no errors exist.

HD-TVI Speed Dome User Manual
13
Power Memory Settings
The dome can resume its previous PTZ status after it restarted from a power-off when it stops at a
position longer than the predefined time. You can set the memory time to 10S, 30S, 60S, 180S, and
300S.
Coaxitron Control
The Coaxial transmission function can be enabled to transmit the RS485 signal along with the video
signal via the BNC cable. If the connected encoding device also supports the Coaxial transmission,
the RS485 cable will not be necessary.
Steps:
1) Enable the Coaxial control function by setting the option of COAXITRON ACT to ON.
2) Select the Coaxial control protocol, with HIK-C is selectable.
The transmission protocol of the connected encoding device should be set the same as the
speed dome to support the coaxial transmission.
3.3 Configuring Image Parameters
3.3.1 Configuring Camera Parameters
Purpose:
You can set the camera parameters including focus, shutter speed, iris, etc.
Enter the camera parameters settings menu:
MAIN MENUS > SYS SETTINGS >CAMERA PARAMETER
CAMERA
FOCUS HAF
ZOOM LIMIT 32
ZOOM SPEED HIGH
SLOW SHUTTER 0
IRCUT FILTER DAY
D/N LEVEL 1
SHARPNESS 7
BACK EXIT
CAMERA
BLC/WDR OFF
BLC LEVEL N/A
AE MODE AUTO
IRIS 10
SHUTTER 50
GAIN 1
EXPOSURE COMP 7
BACK EXIT

HD-TVI Speed Dome User Manual
14
CAMERA
WHITE BALAN ATW
RED 64
BLUE 64
IMAGE FLIP OFF
FOCUS LIMIT 5M
2D DNR 1
3D DNR 2
BACK EXIT
CAMERA
MIN. ZOOM LIMIT 1.0
CHROMA SUPPRESS 2
SATURATION 3
CONTRAST 2
SCENE MODE INDOOR
HLC 0
SHARPNESS COMP 2
BACK EXIT
CAMERA
GAIN LIMIT 15
DEFOG OFF
INIT LENS OFF
BACK EXIT
Figure 3-7 Camera Settings
Task 1: Configure the focus settings.
Setting the focus mode
Steps:
1. Move the cursor to FOCUS using the direction buttons and click IRIS+ to enter.
2. Click up/down direction buttons to set the focus mode to AF, MF or HAF.
AF (Auto-focus): The lens remains in focus during PTZ movements.
MF (Manual Focus): You need to adjust the focus with Focus+ and Focus- buttons manually.
HAF (Half-auto Focus): The speed dome focuses automatically only once after panning,
tilting and zooming.
3. Click IRIS+ button to save the settings.
Setting the focus limit
Purpose:
This function is used to limit the minimum focus distance. You can configure the focus limit
longer when the target is in a distance, to avoid the speed dome focusing on the objects close to
it; or configure the focus limit shorter when the target is near the speed dome, and avoid it
focuses on the objects farther.
Task 2: Configure the zoom settings.
Setting the zoom limit
Purpose:
Zoom limit is a user-defined limitation of the zoom amount (Zoom amount=optical zoom× digital
zoom). If you set the zoom limit to the minimum value, the digital zoom will be invalid and the
optical zoom will reach the maximum value; if you set the zoom limit smaller, the digital zoom
will be enabled.
Steps:
1. Move the cursor to ZOOM LIMIT using the direction buttons and click IRIS+ to enter.
2. Click up/down direction buttons to choose the limit from 23, 46, 92, 184, and 368.
3. Click IRIS+ button to confirm.
If you set the ZOOM LIMIT to the minimum value 22, the digital zoom function will be
disabled, and the optical zoom function is at its maximum value.
Configure the zoom speed.
Purpose:
