HIK VISION iDS-TCM403-B/0832 Instruction sheet

Network Trac Camera
Conguraon Manual

Iniaves on the Use of Video Products
Thank you for choosing Hikvision products.
Technology aects every aspect of our life. As a high-tech company, we are increasingly aware of
the role technology plays in improving business eciency and quality of life, but at the same me,
the potenal harm of its improper usage. For example, video products are capable of recording
real, complete and clear images. This provides a high value in retrospect and preserving real-me
facts. However, it may also result in the infringement of a third party's legimate rights and
interests if improper distribuon, use and/or processing of video data takes place. With the
philosophy of "Technology for the Good", Hikvision requests that every end user of video
technology and video products shall comply with all the applicable laws and regulaons, as well as
ethical customs, aiming to jointly create a beer community.
Please read the following iniaves carefully:
●Everyone has a reasonable expectaon of privacy, and the installaon of video products should
not be in conict with this reasonable expectaon. Therefore, a warning noce shall be given in
a reasonable and eecve manner and clarify the monitoring range, when installing video
products in public areas. For non-public areas, a third party's rights and interests shall be
evaluated when installing video products, including but not limited to, installing video products
only aer obtaining the consent of the stakeholders, and not installing highly-invisible video
products.
●The purpose of video products is to record real acvies within a specic me and space and
under specic condions. Therefore, every user shall rst reasonably dene his/her own rights in
such specic scope, in order to avoid infringing on a third party's portraits, privacy or other
legimate rights.
●During the use of video products, video image data derived from real scenes will connue to be
generated, including a large amount of biological data (such as facial images), and the data could
be further applied or reprocessed. Video products themselves could not disnguish good from
bad regarding how to use the data based solely on the images captured by the video products.
The result of data usage depends on the method and purpose of use of the data controllers.
Therefore, data controllers shall not only comply with all the applicable laws and regulaons and
other normave requirements, but also respect internaonal norms, social morality, good
morals, common pracces and other non-mandatory requirements, and respect individual
privacy, portrait and other rights and interests.
●The rights, values and other demands of various stakeholders should always be considered when
processing video data that is connuously generated by video products. In this regard, product
security and data security are extremely crucial. Therefore, every end user and data controller,
shall undertake all reasonable and necessary measures to ensure data security and avoid data
leakage, improper disclosure and improper use, including but not limited to, seng up access
Network Trac Camera Conguraon Manual
i

control, selecng a suitable network environment (the Internet or Intranet) where video
products are connected, establishing and constantly opmizing network security.
●Video products have made great contribuons to the improvement of social security around the
world, and we believe that these products will also play an acve role in more aspects of social
life. Any abuse of video products in violaon of human rights or leading to criminal acvies are
contrary to the original intent of technological innovaon and product development. Therefore,
each user shall establish an evaluaon and tracking mechanism of their product applicaon to
ensure that every product is used in a proper and reasonable manner and with good faith.
Network Trac Camera Conguraon Manual
ii

Legal Informaon
©2021 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS IS" AND "WITH
ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
Network Trac Camera Conguraon Manual
iii

DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATTER
PREVAILS.
Network Trac Camera Conguraon Manual
iv

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, the LVD Direcve 2014/35/EU, the RoHS
Direcve 2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collecon points. For
more informaon see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include leering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the baery to your supplier or to a
designated collecon point. For more informaon see: www.recyclethis.info
Network Trac Camera Conguraon Manual
v

Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
Network Trac Camera Conguraon Manual
vi

Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note Provides addional informaon to emphasize or supplement
important points of the main text.
Network Trac Camera Conguraon Manual
vii

Safety Instrucon
Regulatory Informaon
This is a class A product and may cause radio interference in which case the user may be required
to take adequate measures.
Laws and Regulaons
Use of the product must be in strict compliance with the local laws and regulaons. Please shut
down the device in prohibited area.
Power Supply
●Use of the product must be in strict compliance with the local electrical safety regulaons.
●Use the power adapter provided by qualied manufacturer. Refer to the product specicaon for
detailed power requirements.
●It is recommended to provide independent power adapter for each device as adapter overload
may cause over-heang or a re hazard.
●Make sure that the power has been disconnected before you wire, install, or disassemble the
device in the authorized way according to the descripon in the manual.
●To avoid electric shock, DO NOT directly touch exposed contacts and components once the
device is powered up.
●DO NOT use damaged power supply devices (e.g., cable, power adapter, etc.) to avoid electric
shock, re hazard, and explosion.
●DO NOT directly cut the power supply to shut down the device. Please shut down the device
normally and then unplug the power cord to avoid data loss.
●The socket-outlet shall be installed near the equipment and shall be easily accessible.
●Make sure the power supply has been disconnected if the power adapter is idle.
●Connect to earth before connecng to the power supply.
Transportaon, Use, and Storage
●To avoid heat accumulaon, good venlaon is required for a proper operang environment.
●Store the device in dry, well-venlated, corrosive-gas-free, no direct sunlight, and no heang
source environment.
●Avoid re, water, and explosive environment when using the device.
●Install the device in such a way that lightning strikes can be avoided. Provide a surge suppressor
at the inlet opening of the equipment under special condions such as the mountain top, iron
tower, and forest.
●Keep the device away from magnec interference.
●Avoid device installaon on vibratory surfaces or places. Failure to comply with this may cause
device damage.
●DO NOT touch the heat dissipaon component to avoid burns.
Network Trac Camera Conguraon Manual
viii

●DO NOT expose the device to extremely hot, cold, or humidity environments. For temperature
and humidity requirements, see device specicaon.
●No naked ame sources, such as lighted candles, should be placed on the equipment.
●DO NOT touch the sharp edges or corners.
●To prevent possible hearing damage, DO NOT listen at high volume levels for long periods.
Maintenance
●If smoke, odor, or noise arises from the device, immediately turn o the power, unplug the
power cable, and contact the service center.
●If the device cannot work properly, contact the store you purchased it or the nearest service
center. DO NOT disassemble or modify the device in the unauthorized way (For the problems
caused by unauthorized modicaon or maintenance, the company shall not take any
responsibility).
●Keep all packaging aer unpacking them for future use. In case of any failure occurred, you need
to return the device to the factory with the original packaging. Transportaon without the
original packaging may result in damage to the device and the company shall not take any
responsibility.
Network
●Please enforce the protecon for the personal informaon and the data security as the device
may be confronted with the network security problems when it is connected to the Internet.
Contact us if network security risks occur.
●Please understand that you have the responsibility to congure all the passwords and other
security sengs about the device, and keep your user name and password.
Lens
●DO NOT touch the lens with ngers directly in case the acidic sweat of the ngers erodes the
surface coang of the lens.
●DO NOT aim the lens at the strong light such as sun or incandescent lamp. The strong light can
cause fatal damage to the device.
Data
DO NOT disconnect the power during formang, uploading, and downloading. Or les may be
damaged.
Network Trac Camera Conguraon Manual
ix

Contents
Chapter 1 Applicaon Mode Conguraon ................................................................................. 1
1.1 Set Checkpoint Capture ......................................................................................................... 1
1.1.1 Set Checkpoint Single I/O .............................................................................................. 1
1.1.2 Set RS-485 Radar ........................................................................................................... 4
1.1.3 Set Mixed-Trac Lane ................................................................................................... 7
1.2 Set Intersecon Violaon System Capture ........................................................................... 10
1.3 Set Smart Monitoring Capture ............................................................................................. 13
1.4 Set License Plate Recognion System Capture .................................................................... 15
1.5 Set Applicaon Mode Detailed Parameters ......................................................................... 18
1.5.1 Set Violaon and Incident Detecon .......................................................................... 18
1.5.2 Set Linked Lane Parameters ........................................................................................ 22
1.5.3 Set Connuous Capture Parameters ........................................................................... 23
1.5.4 Set Scene Mode .......................................................................................................... 23
1.5.5 Set Radar Parameters .................................................................................................. 24
1.5.6 Set Violaon Recording Parameters ............................................................................ 25
1.5.7 Set Supplement Light Linkage ..................................................................................... 26
1.5.8 Set Lane Speed Limit Parameters ................................................................................ 27
1.5.9 Set Trac Light Detecon Parameters ........................................................................ 28
1.6 Set Capture Parameters ....................................................................................................... 29
1.6.1 Set Captured Image Parameters ................................................................................. 29
1.6.2 Set License Plate Recognion Parameters .................................................................. 31
1.6.3 Set Supplement Light Parameters ............................................................................... 31
1.6.4 Set Picture Composion .............................................................................................. 33
1.6.5 Set Informaon Overlay .............................................................................................. 35
1.6.6 Set Body Picture Mang ............................................................................................ 38
1.6.7 Set Trac Light ............................................................................................................ 38
Network Trac Camera Conguraon Manual
x

1.6.8 Set Vehicle Feature Parameters .................................................................................. 41
1.6.9 Set Image Encoding Parameters .................................................................................. 42
1.7 Set Barrier Gate Linkage ....................................................................................................... 42
1.7.1 Set Allowlist and Blocklist ........................................................................................... 43
1.7.2 Control Barrier Gate .................................................................................................... 44
1.7.3 Set Wiegand Parameters ............................................................................................. 45
Chapter 2 Radar Detecon ........................................................................................................ 46
Chapter 3 View Real-Time Picture ............................................................................................. 49
Chapter 4 Search Picture .......................................................................................................... 51
Chapter 5 View Trac Stascs ................................................................................................ 52
5.1 View Real-Time Trac Stascs .......................................................................................... 52
5.2 View Trac Flow Stascs ................................................................................................... 52
Chapter 6 View Trac Light Status ............................................................................................ 53
Network Trac Camera Conguraon Manual
xi

Chapter 1 Applicaon Mode Conguraon
Note
●The supported applicaon modes vary with dierent models. The actual device prevails.
●If the applicaon mode supports area drawing, you can check Display All Areas to display all the
lines and areas, convenient to view the eect of all the lines and areas. If you uncheck it, only
the current selected lane will be displayed, convenient to draw the current lane.
Cauon
You can click Default to restore all the set parameters to the default sengs. Please operate with
care.
1.1 Set Checkpoint Capture
1.1.1 Set Checkpoint Single I/O
Set checkpoint single I/O if capture is triggered by external I/O signal (digital signal). In this mode,
the informaon including the vehicle passing me, vehicle overview, license plate number, license
plate color, vehicle color, the facial features of the driver and the front passenger, etc. will be
recorded.
Before You Start
Connect F+ of the I/O signal to the T interface of the device, and F- to the GND of the device.
Steps
1. Go to Conguraon → Capture → Applicaon Mode .
2. Select Applicaon Mode as Checkpoint Single I/O.
Network Trac Camera Conguraon Manual
1

Figure 1-1 Set Checkpoint Single I/O
3. Oponal: Select the violaon type(s) to be detected, and set the corresponding parameters.
Refer to Set Violaon and Incident Detecon for details.
4. Check the corresponding External Input according to the connected I/O signal.
Note
Each input corresponds to one lane.
5. Oponal: Check Occupy Emergency Lane Capture if you want to detect the violaon of
occupying emergency lane.
6. Set the lane parameters. Refer to Set Linked Lane Parameters for details.
7. Set the parameters below.
Level Status
Capture is triggered according to the level signal status. If you select Falling Edge, the device
will trigger capture at the moment that the high level falls to low level. If you select Rising
Edge, the device will trigger capture at the moment that the low level rises to high level.
Network Trac Camera Conguraon Manual
2

Capture Interval
Select Time, and set Interval (the me between the adjacent captures).
Capture Pictures
The number of captured picture(s).
8. Link supplement light(s) to the specic lane(s). Refer to Set Supplement Light Linkage for details.
9. Oponal: Check the other external input channel(s) to copy the same sengs.
10. Draw lane lines.
1) Click Draw Lane Line.
2) Select the default lane line and right border line, and drag the two end points of the line or
drag the whole line to adjust its posion according to the actual scene.
3) Click OK.
Figure 1-2 Draw Lane Line
11. Click Save.
Network Trac Camera Conguraon Manual
3

1.1.2 Set RS-485 Radar
Set RS-485 radar if RS-485 signal (speed detecon or capture via radar) is connected, and capture is
triggered by radar. In this mode, the informaon including the vehicle speed, vehicle passing me,
vehicle overview, license plate number, license plate color, vehicle color, the facial features of the
driver and the front passenger, etc. will be recorded.
Before You Start
●Install the radar.
●Connect the D+ and D- of the radar RS-485 interface to the D+ and D- of the device RS-485
interface.
Steps
1. Go to Conguraon → Capture → Applicaon Mode .
2. Select Applicaon Mode as RS-485 Radar.
Network Trac Camera Conguraon Manual
4

Figure 1-3 Set RS-485 Radar
Network Trac Camera Conguraon Manual
5

3. Oponal: Select the violaon type(s) to be detected, and set the corresponding parameters.
Refer to Set Violaon and Incident Detecon for details.
4. Set the lane parameters. Refer to Set Linked Lane Parameters for details.
5. Set connuous capture parameters. Refer to Set Connuous Capture Parameters for details.
6. Set speed limit parameters. Refer to Set Lane Speed Limit Parameters for details.
7. Link supplement light(s) to the specic lane(s). Refer to Set Supplement Light Linkage for details.
8. Set radar parameters. Refer to Set Radar Parameters for details.
9. Oponal: Check the other lane(s) to copy the same sengs.
10. Draw lane lines.
1) Click Draw Lane Line.
2) Select the default lane lines and right border line, and drag the two end points of the line or
drag the whole line to adjust its posion according to the actual scene.
3) Click OK.
Figure 1-4 Draw Lane Line
Network Trac Camera Conguraon Manual
6

11. Click Save.
1.1.3 Set Mixed-Trac Lane
Set mix-trac lane if capture is triggered by virtual coils (video or radar detecon). In this mode,
the informaon including the vehicle speed, vehicle passing me, vehicle overview, license plate
number, license plate color, vehicle color, the facial features of the driver and the front passenger,
etc. will be recorded.
Before You Start
●Install the radar if speed detecon is needed.
●Connect the D+ and D- of the radar RS-485 interface to the D+ and D- of the device RS-485
interface.
Steps
1. Go to Conguraon → Capture → Applicaon Mode .
2. Select Applicaon Mode as Mixed-Trac Lane.
Network Trac Camera Conguraon Manual
7

Figure 1-5 Set Mixed-Trac Lane
Network Trac Camera Conguraon Manual
8
