HIK VISION DS-2CC5197P-VF User manual

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
1
Color Camera
Technical Manual

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2011 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
[e-mail]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
3
DS-2CC5197P(N)-VF
Key Features
Compact design
SONY Super HAD CCD II
Flickerless mode
75dB Wide Dynamic Range, suitable for strong backlight environment
3D-Digital Noise Reduction (3D-DNR)
Smart IR mode
High Light Reversion
Electronic image stabilization (EIS)
Min. illumination: 0.001 Lux @ F1.2 (Color) , 0.0001 Lux @ F1.2 (B/W)
IR cut filter with auto switch
OSD menu
Auto iris with DC drive
Auto white balance, auto gain control, electronic shutter control and backlight compensation
Support 2.8 - 12 mm auto iris lens
Internal or Power Synchronization
3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and placement
Specification
Model
Parameter
DS-2CC5197P(N)-VF
650 TVL CCD WDR ICR Dome Camera
Camera
Image Sensor
1/3” SONY Super HAD CCD II
Signal System
PAL/NTSC
Effective Pixels
PAL: 976 (H) × 582 (V)
NTSC: 976 (H) × 494 (V)

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
4
Min. Illumination
Color: 0.001 Lux @ (F1.2, AGC ON),
0.0001 Lux @ (F1.2, AGC ON, sensitivity × 512)
B/W: 0.0001 Lux @ (F1.2, AGC ON),
0.00001 Lux @ (F1.2, AGC ON, sensitivity × 512)
Color: 0.0014 Lux @ (F1.4, AGC ON),
0.00014 Lux @ (F1.4, AGC ON, sensitivity × 512)
B/W: 0.00014 Lux @ (F1.4, AGC ON),
0.000014 Lux @ (F1.4, AGC ON, sensitivity × 512)
Shutter Time
PAL: 1/50 s to 1/100,000 s
NTSC: 1/60 s to 1/100,000 s
Lens
2.8 - 12 mm @ F1.4
Angle of view: 92°- 27.2°
Lens Mount
φ14
Auto Iris
DC drive
Angle Adjustment
Pan: 0 - 355°, Tilt: 0 - 180°, Rotation: 0 - 355°
Day & Night
IR cut filter with auto switch
Horizontal Resolution
650 TVL (Color), 700 TVL (B/W)
Wide Dynamic Range
75 dB
Synchronization
Internal/Power synchronization
Video Output
1Vp-p composite output (75 Ω/BNC)
S/N Ratio
More than 62 dB
Menu
Camera ID
On/Off (26 letters, adjusted position)
Auto Gain
Low/Middle/High/Off
D/N Mode
Auto /Day/Night
White Balance
Auto trace WB1/Auto trace WB2/Manual/Auto Control
Private Mask
On/Off, maximum 12 zones
Motion Detection
On/Off
BLC
Area/Value/Off
WDR
Value/ Contrast / Return
Anti-Flicker
On/Off
Language
English/Chinese
Video
SMART IR, High Light Reversion, Digital Noise Reduction,
Sharpness, Brightness, Saturation, Resolution, Electronic
image stabilization, Digital Zoom, Mirror, Blemish
Detection
Scene
Indoor Standard , Indoor Backlight , Outdoor, Low
illumination , Customize
General
Operating Conditions
-10 °C - 60 °C (14 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply
24 V AC ± 10%, 12 V DC ± 10%

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
5
Power Consumption
Max. 4 W
(Max. 4.5 W with IR cut filter on)
Dimension
Φ 136 × 101 mm (Φ 5.35” × 3. 98”)
Weight
800 g (1.76 lbs)
Order Models
DS-2CC5197P-VF
DS-2CC5197N-VF
Dimension
Unit: mm
