HIK VISION DS-2CC51A7N-VP User manual

Day/Night High-definition
Dome Camera
User Manual
V1.2.0

Day/Night High-definition Dome Camera·User Manual
1
1
Thank you for purchasing our product. If there are any questions,
or requests, please do not hesitate to contact the dealer.
This manual applies to DS-2CC5181P-VP(IR)(H),
DS-2CC5191P-VP(IR)(H), DS-2CC51A1P-VP(IR)(H) dome
Camera.
This manual may contain several technical incorrect places or
printing errors, and the content is subject to change without notice.
The updates will be added to the new version of this manual. We
will readily improve or update the products or procedures
described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested for fire, shock or casualty hazards
as outlined in UL’s Standard(s) for Safety, UL60950-1. UL
Certification does not cover the performance or reliability of the
security or signaling aspects of this product. UL MAKES NO
REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS
WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY
OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS
PRODUCT.”

Day/Night High-definition Dome Camera·User Manual
2
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized
European standards listed under the Low Voltage Directive
2006/95/EC, the EMC Directive 2004/108/EC.

Day/Night High-definition Dome Camera·User Manual
3
3
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd),
lead (Pb), or mercury (Hg). For proper recycling, return the battery
to your supplier or to a designated collection point. For more
information see: www.recyclethis.info.

Day/Night High-definition Dome Camera·User Manual
4
4
Safety Warnings and Cautions
Please pay attention to the following warnings and
cautions:
Hazardous Voltage may be present: Special
measures and precautions must be taken when
using this device. Some potentials (voltages) on the
device may present a hazard to the user. This device
should only be used by Employees from our company with
knowledge and training in working with these types of devices that
contain live circuits.
Power Supply Hazardous Voltage: AC mains voltages
are present within the power supply assembly. This device must be
connected to a UL approved, completely enclosed power supply, of
the proper rated voltage and current. No user serviceable parts
inside the power supply.
System Grounding (Earthing): To avoid shock, ensure
that all AC wiring is not exposed and that the earth grounding is
maintained. Ensure that any equipment to which this device will be

Day/Night High-definition Dome Camera·User Manual
5
5
attached is also connected to properly wired grounded receptacles
and are approved medical devices.
Power Connect and Disconnect: The AC
power supply cord is the main disconnect device to
mains (AC power).The socket outlet shall be
installed near the equipment and shall be readily
accessible.
Installation and Maintenance: Do not connect/disconnect
any cables to or perform installation/maintenance on this device
during an electrical storm.
Power Cord Requirements: The connector
that plugs into the wall outlet must be a
grounding-type male plug designed for use in your
region. It must have certification marks showing certification by an
agency in your region. The connector that plugs into the AC
receptacle on the power supply must be an IEC 320, sheet C13,
female connector. See the following website for more information
http://kropla.com/electric2.htm.
Lithium Battery: This device contains a Lithium Battery. There
is a risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to the vendor’s instructions
and in accordance with local environmental regulations.

Day/Night High-definition Dome Camera·User Manual
6
6
Perchlorate Material: Special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is
required by California Code of Regulations, Title 22, Division 4.5,
Chapter 33: Best Management Practices for Perchlorate Materials.
This device includes a battery which contains perchlorate material.
Taiwan battery recycling:
Please recycle batteries.
Thermal and Mechanical Injury: Some
components such as heat sinks, power regulators,
and processors may be hot; care should be taken
to avoid contact with these components.
Electro Magnetic Interference: This equipment has not
been tested for compliance with emissions limits of FCC and similar
international regulations. This device is not, and may not be,
offered for sale or lease, or sold, or leased until authorization from
the United States FCC or its equivalent in other countries has been
obtained. Use of this equipment in a residential location is
prohibited. This equipment generates, uses and can radiate radio
frequency energy which may result in harmful interference to radio
communications. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment on and off, the user is
required to take measures to eliminate the interference or
discontinue the use of this equipment.

Day/Night High-definition Dome Camera·User Manual
7
7
Lead Content:
Please recycle this device in a responsible
manner. Refer to local environmental
regulations for proper recycling; do not dispose
of device in unsorted municipal waste.

Day/Night High-definition Dome Camera·User Manual
8
8
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the
warnings are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
Please adopt the power adapter which can meet the safety
extra low voltage (SELV) request. And source with DC 12V or
AC 24V (depending on models) according to the IEC60950-1
and Limited Power Source standard.
If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

Day/Night High-definition Dome Camera·User Manual
9
9
responsibility for problems caused by unauthorized repair or
maintenance.)
To reduce the risk of fire or electrical shock, do not expose this
product to rain or moisture.
This installation should be made by a qualified service person
and should conform to all local codes.
Please install blackouts equipment into the power supply
circuit for convenient supply interruption.
Please make sure that the ceiling can support more than 50(N)
Newton gravities if the camera is fixed to the ceiling.
Cautions
Make sure the power supply voltage is correct before using the
camera.
Do not drop the camera or subject it to physical shock.
Do not touch sensor modules with fingers. If cleaning is
necessary, use a clean cloth with a bit of ethanol and wipe it
gently. If the camera will not be used for an extended period of
time, put on the lens cap to protect the sensor from dirt.
Do not aim the camera at the sun or extra bright places. A
blooming or smear may occur otherwise (which is not a
malfunction however), and affecting the endurance of sensor
at the same time.

Day/Night High-definition Dome Camera·User Manual
10
10
The sensor may be burned out by a laser beam, so when any
laser equipment is being used, make sure that the surface of
the sensor will not be exposed to the laser beam.
Do not place the camera in extremely hot or cold temperatures
(the operating temperature should be between -10°C ~ 60°C ,
dusty or damp locations, and do not expose it to high
electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for a
proper operating environment.
Do not let water and any liquid flow into the camera.
While shipping, the camera should be packed in its original
packing, or packing of the same texture.
Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.

Day/Night High-definition Dome Camera·User Manual
11
11
Table of Contents
1 Introduction.................................................................. 1
1.1 Product Features ..................................................1
1.2 Function Summary ...............................................2
1.3 Overview.............................................................5
2 Installation ................................................................... 6
2.1 Disassembling......................................................6
2.2 Mounting .............................................................7
2.2.1 Ceiling Mounting ..........................................7
2.2.2 In-ceiling Mounting with gang box................10
2.2.3 In-ceiling Mounting without gang box ...........13
2.2.4 Outdoor Wall Mounting ...............................16
2.2.5 Indoor Wall Mounting..................................20
2.3 Image and Focus Adjusting..................................22
3 Menu Description ........................................................ 25
3.1 MAIN MENU .......................................................25
3.2 LENS Setting......................................................26
3.3 SHUTTER/AGC Setting.........................................27
3.4 WHITE BALANCE Setting .....................................29
3.5 BACKLIGHT Setting ............................................32
3.6 PICTURE ADJUST Setting.....................................33
3.7 ATR Setting .......................................................34
3.8 MOTION DETECTION Setting................................35
3.9 PRIVACY MASK Setting........................................38
3.10 DAY/NIGHT Setting ...........................................39
3.11 NR Setting .......................................................41
3.12 CAMERA ID Setting ...........................................42
3.13 SYNC/PIXEL CORRECT Setting............................44

Day/Night High-definition Dome Camera·User Manual
12
12
3.14 LANGUAGE Setting............................................45
3.15 CAMERA RESET Setting .....................................45
Appendix........................................................................ 46
Table 1 DS-2CC5181P(N)-VP(IR)(H) ...........................46
Table 2 DS-2CC5191P(N)-VP(IR)(H) ...........................50
Table 3 DS-2CC51A1P(N)-VP(IR)(H) ...........................54

Day/Night High-definition Dome Camera·User Manual
1
1
1Introduction
1.1 Product Features
This camera adopts high performance CCD and advanced print
circuit board design technology. It possesses of high resolution,
low distortion, and low noise features, etc. It is extremely suitable
for supervisory system and image process system.
Adopt high performance SONY CCD, and supply high definition
and clear image, up to 700TVL
Low illumination, Color: [email protected], B/W:
[email protected]
Support ICR filter auto switch
Support OSD menu controlling, enable user to configure the
detail parameters
Adopt advanced stepping motor and sleep mode to avoid ICR
oscillation
Support auto white balance with high color rendition
High SNR give rise to clear and pleased image
Support SMART IR
Support auto electronic shutter control to adapt to different
environments
Support auto gain control, adaptive brightness
Support auto iris

Day/Night High-definition Dome Camera·User Manual
2
2
Support Privacy mask with 8 optional colors and 8 configurable
areas
Advanced design technology with high reliability
Advanced 3-axis design allows this dome camera to be
adjusted 0-355°horizontally and 0-180°vertically to meet
different mounting requirements
Adopt advanced double-plate design to guarantee the heat
dissipation of the CCD and image quality
Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up
to IK10
Weather proof rating: IP66
1.2 Function Summary
Motion Detection: In the user-defined motion detection
surveillance area, the moving object can be detected and trigger
alarm. The sensitive level can be customized according to the
environment.
Privacy Mask: This function allows you to block or mask certain
area of a scene, thus prevent the personal privacy from recording
or live viewing.

Day/Night High-definition Dome Camera·User Manual
3
3
Figure 1-1 Privacy Mask
DAY/NIGHT Auto Switch: The cameras deliver color images
during the day. And as light diminishes at night, the cameras
switch to night mode and deliver black and white images with high
quality.
AGC: AGC is a control circuit that automatically changes the gain
of a receiver or other piece of equipment, so that the desired
output signal remains essentially. When under low illumination,
AGC will regulate the gain and amplification of the video signal.
S/N ratio: It is the ratio of Signal voltage and noise voltage. The
ratio is larger, the effect of noise is less, and the image is clearer.
OSD (On Screen Display): The on-screen display (abbreviated
OSD) is an image superimposed on a screen picture, used for
displaying information and menu.
Synchronous System: Synchronization of the camera usually
contains power synchronization and internal synchronization.

Day/Night High-definition Dome Camera·User Manual
4
4
Internal synchronization is realized by the synchronous signal
which is generated by the inside crystal oscillator.
White Balance: White balance can remove the unrealistic color
casts. White balance is the white rendition function of the camera
to adjust the color temperature according to the environment
automatically.
ICR Auto Switch: The filter will filter infrared light during the
daytime and change to normal filter at night to ensure a high
sensitivity and clear image.
BLC: If you focus on an object against strong backlight, the object
will be too dark to be seen clearly. The BLC (Backlight
Compensation) function can compensate light to the object in the
front to make it clear, but this causes the over-exposure of the
background where the light is strong.
Figure 1-2 BLC OFF and BLC ON

Day/Night High-definition Dome Camera·User Manual
5
5
1.3 Overview
Figure 1-3 Dome Overview

Day/Night High-definition Dome Camera·User Manual
6
6
2Installation
Before you start:
Please make sure that the device in the package is in good
condition and all the assembly parts are included.
Note: Please ensure that the wall is strong enough to withstand
three times the weight of the camera. If the wall is not strong
enough, the camera may fall and cause serious damage.
2.1 Disassembling
Steps:
1. Loosen the three screws on the edge of the lower dome with
the supplied screw driver.
2. Loosen the screw that secures the leash of the lower dome to
the camera. Remove the lower dome.
3. Remove the inner black liner.
Screws

Day/Night High-definition Dome Camera·User Manual
7
7
Figure 2-1 Removing the Lower Dome
4. Loosen the three screws as shown in Figure 2-2 with the
supplied screw driver.
5. Remove the camera from the back box.
Figure 2-2 Removing the Camera
2.2 Mounting
2.2.1 Ceiling Mounting
Steps:
1. Attach the drill template (supplied) to the place where you
want to fix the camera.
2. According to the circles on the drill template as shown in Figure
2-3, drill screws holes in the ceiling on your demand.
Set Screws
