HIK VISION DS-2CD8153F-E User manual

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
1
Network Camera
Technical Manual

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2012 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
[e-mail]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
3
DS-2CD8153F-E(I)(W)
Key Features
Up to 2 megapixel (1600 × 1200) resolution
Standard video compression with high compression ratio
Progressive scan CMOS, capture motion video without incised margin
Support e-PTZ function
Support dual stream, and the sub-stream for mobile surveillance
Up to 32 GB Micro SD card for on-board storage
Built-in microphone and speaker
Two-way audio
PoE (Power over Ethernet)
Specification
Model
Parameter
DS-2CD8153F-E(I)(W)
2 megapixel CMOS Network Cube Camera
Camera
Image Sensor
1/3” Progressive Scan CMOS
Min. Illumination
0.5 Lux @ (F1.2, AGC ON), 0.1 Lux @ (F1.2, AGC ON, sensitivity × 5)
1.1 Lux @ (F1.8, AGC ON), 0.2 Lux @ (F1.8, AGC ON, sensitivity × 5)
Shutter Speed
1/25 s to 1/100,000 s
Lens
4 mm @ F1.8
Angle of view:68°
Lens Mount
M12
Day & Night
Electronic
Compression Standard

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
4
Video
Compression
H.264/MPEG4/MJPEG
Video Bit Rate
32 Kbps –16 Mbps
Audio
Compression
G.711/G.726
Audio Bit Rate
64Kbps(G.711) / 16Kbps(G.726)
Dual Stream
Yes
Max. Resolution
1600 x 1200
Frame Rate
50 Hz: 12.5 fps (1600 × 1200), 12.5 fps (1600 × 912), 25 fps (1280 × 960), 25
fps (1280 × 720)
60 Hz: 15 fps (1600 × 1200), 15 fps (1600 × 912), 25 fps (1280 × 960), 30 fps
(1280 × 720)
Image Setting
Saturation, Brightness, Contrast adjustable by client software or web
browser
Network
Network Storage
NAS (iSCSI optional)
Alarm Trigger
Motion detection, Tampering alarm, Storage exception
Protocols
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP,UPnP,
ICMP,IGMP,SNMP, FTP, 802.1x, QoS, HTTPS ( SIP,SRTP,IPv6 optional )
Security
User Authentication, Watermark
Standard
ONVIF, PSIA, CGI
Interface
Audio
Internal Microphone and Speaker
Communication
Interface
1 RJ45 10M/100M Ethernet port
On-board storage
Built-in Micro SD slot, up to 32 GB
Reset Button
Yes
Wi-Fi Specification(Only for the products with Wi-Fi module built-in)
Wireless Standards
IEEE802.11b, 802.11g, 802.11n Draft
Frequency Range
2.4 GHz ~ 2.4835 GHz
Channel
Bandwidth
20/40MHz Support
Protocols
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM
Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmit Output
Power
11b: 17±1.5dBm @ 11Mbps
11g: 14±1.5dBm @ 54Mbps
11n: 12.5±1.5dBm
Receive Sensitivity
11b: -90dBm @ 11Mbps (Typical)
11g: -75dBm @ 54Mpbs (Typical)

Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
5
11n: -74dBm (Typical)
Transfer Rates
11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps
Wireless Range
Outdoor：200m，Indoor：50m（depend on environment）
General
Operating
Conditions
-25 °C –60 °C (-13 °F –140 °F)
Humidity 95% or less (non-condensing)
Power Supply
5V DC ± 10%
PoE (802.3af)
Power
Consumption
Max. 4 W
-I: Max. 5 W
-W: Max. 5.5W
IR Range
-I: Approx. 2-5 meters
Dimensions
110 × 70.4 × 47.6 mm (4.33” ×2.77” × 1.87”)
Weight
250 g (0.55 lbs)
* “-W” series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support
the 802.1x protocol.
* “-I” series support 2-5 meters IR Range
* A mount is provided with the camera in the package
Order Models
DS-2CD8153F-E, DS-2CD8153F-EI
DS-2CD8153F-EW,DS-2CD8153F-EIW
Dimensions
Unit: mm
