HIK VISION DS-2CC5181PN-VF User manual

Day/Night High-definition
Dome Camera
User Manual V1.1.0

Day/Night High-definition Dome Camera·User Manual
1
Thank you for purchasing our product. If there are any questions,
or requests, please do not hesitate to contact the dealer.
This manual applies to DS-2CC5181P(N)-VF, DS-2CC5191P(N)-VF,
DS-2CC51A1P(N)-VF dome Camera.
This manual may contain several technical incorrect places or
printing errors, and the content is subject to change without notice.
The updates will be added to the new version of this manual. We
will readily improve or update the products or procedures
described in the manual.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of
this product. UL has only tested for fire, shock or casualty hazards
as outlined in UL’s Standard(s) for Safety, UL60950-1. UL
Certification does not cover the performance or reliability of the
security or signaling aspects of this product. UL MAKES NO
REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS
WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY
OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS
PRODUCT.”

Day/Night High-definition Dome Camera·User Manual
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized
European standards listed under the Low Voltage Directive
2006/95/EC, the EMC Directive 2004/108/EC.
2

Day/Night High-definition Dome Camera·User Manual
2002/96/EC (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
hase of equivalent new equipment, or dispose of it at
designated collection points. For more information see:
upon the purc
www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd),
lead (Pb), or mercury (Hg). For proper recycling, return the battery
to your supplier or to a designated collection point. For more
information see: www.recyclethis.info.
3

Day/Night High-definition Dome Camera·User Manual
Safety Warnings and Cautions
Please pay attention to the following warnings and
cautions:
Hazardous Voltage may be present: Special
measures and precautions must be taken when
using this device. Some potentials (voltages) on the
device may present a hazard to the user. This device
should only be used by Employees from our company with
knowledge and training in working with these types of devices that
contain live circuits.
Power Supply Hazardous Voltage: AC mains voltages
are present within the power supply assembly. This device must be
connected to a UL approved, completely enclosed power supply, of
the proper rated voltage and current. No user serviceable parts
inside the power supply.
System Grounding (Earthing): To avoid shock, ensure
that all AC wiring is not exposed and that the earth grounding is
maintained. Ensure that any equipment to which this device will be
4

Day/Night High-definition Dome Camera·User Manual
attached is also connected to properly wired grounded receptacles
and are approved medical devices.
Power Connect and Disconnect: The AC
power supply cord is the main disconnect device to
mains (AC power).The socket outlet shall be
installed near the equipment and shall be readily
accessible.
Installation and Maintenance: Do not connect/disconnect
any cables to or perform installation/maintenance on this device
during an electrical storm.
Power Cord Requirements: The connector
that plugs into the wall outlet must be a
grounding-type male plug designed for use in your
region. It must have certification marks showing certification by an
agency in your region. The connector that plugs into the AC
receptacle on the power supply must be an IEC 320, sheet C13,
female connector. See the following website for more information
http://kropla.com/electric2.htm.
Lithium Battery: This device contains a Lithium Battery. There
is a risk of explosion if the battery is replaced by an incorrect type.
Dispose of used batteries according to the vendor’s instructions
and in accordance with local environmental regulations.
5

Day/Night High-definition Dome Camera·User Manual
Perchlorate Material: Special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is
required by California Code of Regulations, Title 22, Division 4.5,
Chapter 33: Best Management Practices for Perchlorate Materials.
This device includes a battery which contains perchlorate material.
Taiwan battery recycling:
Please recycle batteries.
Thermal and Mechanical Injury: Some
components such as heat sinks, power re
and processors may be hot; care should be tak
to avoid contact with these components.
gulators,
en
Electro Magnetic Interference: This equipment has not
been tested for compliance with emissions limits of FCC and similar
international regulations. This device is not, and may not be,
offered for sale or lease, or sold, or leased until authorization from
the United States FCC or its equivalent in other countries has been
obtained. Use of this equipment in a residential location is
prohibited. This equipment generates, uses and can radiate radio
frequency energy which may result in harmful interference to radio
communications. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment on and off, the user is
required to take measures to eliminate the interference or
discontinue the use of this equipment.
6

Day/Night High-definition Dome Camera·User Manual
Lead Content:
Please recycle this device in a responsible
manner. Refer to local environmental
regulations for proper recycling; do not dispose
rted municipal waste.of device in unso
7

Day/Night High-definition Dome Camera·User Manual
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the
warnings are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.
Warnings
In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region.
Input voltage should meet both the SELV(Safety Extra Low
Voltage).
the Limited Power Source with AC 24V or DC 12V according to
the IEC60950-1 standard.
Please refer to technical specifications for detailed information.
8

Day/Night High-definition Dome Camera·User Manual
the Limited Power Source with AC 24V or DC 12V according to
the IEC60950-1 standard.
Please refer to technical specifications for detailed information.
Input voltage should meet both the SELV(Safety Extra Low
Voltage) and the Limited Power Source with AC 24V or DC 12V
according to the IEC60950-1 standard. Please refer to
technical specifications for detailed information.
Do not connect several devices to one power adapter as
adapter overload may cause over-heating or a fire hazard.
Please make sure that the plug is firmly connected to the
power socket.
When the product is mounted on wall or ceiling, the device
shall be firmly fixed.
If smoke, odor or noise rise from the device, turn off the power
at once and unplug the power cable, and then please contact
the service center.
If the product does not work properly, please contact your
dealer or the nearest service center. Never attempt to
disassemble the camera yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)
Cautions
Make sure the power supply voltage is correct before using the
camera.
9

Day/Night High-definition Dome Camera·User Manual
10
Do not drop the camera or subject it to physical shock.
Do not touch CCD (Charge Coupled Device) modules with
fingers. If cleaning is necessary, use clean cloth with a bit of
ethanol and wipe it gently. If the camera will not be used for an
extended period, please replace the lens cap to protect the
CCD from dirt.
Do not aim the camera at the sun or extra bright places.
Blooming or smearing may occur otherwise (which is not a
malfunction), and affect the endurance of CCD at the same
time.
The CCD may be burned out by a laser beam, so when any
laser equipment is in using, make sure that the surface of CCD
will not be exposed to the laser beam.
Do not place the camera in extremely hot, cold(the operating
temperature shall be-10℃~+60℃), dusty or damp locations,
and do not expose it to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for
operating environment.
Keep the camera away from liquid while in use.
While in delivery, the camera shall be packed in its original
packing, or packing of the same texture.
Improper use or replacement of the battery may result in
hazard of explosion. Replace with the same or equivalent type
only. Dispose of used batteries according to the instructions
provided by the battery manufacturer.

Day/Night High-definition Dome Camera·User Manual
11
Table of Contents
1 Introduction.................................................................. 1
1.1 Product Features ..................................................1
1.2 Function Summary ...............................................2
2 Installation ................................................................... 5
2.1 Ceiling mounting ..................................................5
2.2 In ceiling mounting with gang box ..........................9
2.3 In ceiling mounting without gang box ...................14
3 Menu Description ........................................................ 19
3.1 MAIN MENU .......................................................19
3.2 LENS Setting .....................................................20
3.3 SHUTTER/AGC Setting ........................................21
3.4 WHITE BALANCE Setting .....................................23
3.5 BACKLIGHT Setting ............................................26
3.6 PICTURE ADJUST Setting.....................................27
3.7 ATR Setting .......................................................28
3.8 MOTION DETECTION Setting................................29
3.9 PRIVACY MASK Setting........................................32
3.10 DAY/NIGHT Setting...........................................33
3.11 NR Setting .......................................................35
3.12 CAMERA ID Setting ...........................................36
3.13 SYNC/PIXEL CORRECT Setting............................38
3.14 LANGUAGE Setting ...........................................39
3.15 CAMERA RESET Setting .....................................39
Appendix........................................................................ 40
Table 1 DS-2CC5181P(N)-VF .....................................40
Table 2 DS-2CC5191P(N)-VF .....................................43
Table 3 DS-2CC51A1P(N)-VF .....................................46

Day/Night High-definition Dome Camera·User Manual
1
1Introduction
1.1 Product Features
This camera adopts high performance CCD and advanced print
circuit board design technology. It possesses of high resolution,
low distortion, and low noise features, etc. It is extremely suitable
for supervisory system and image process system.
Adopt high performance SONY CCD, and supply high definition
and clear image, up to 700TVL
Low illumination, Color: 0.001Lux@F1.2, B/W:
0.0001Lux@F1.2
Support ICR filter auto switch
Support OSD menu controlling, enable user to configure the
detail parameters
Adopt advanced stepping motor and sleep mode to avoid ICR
oscillation
Support BLC with programmable BLC area
Support auto white balance with high color rendition
High SNR give rise to clear and pleased image
Support digital noise reduction to get clear and fine image.
Support auto electronic shutter control to adapt to different
environments
Support auto gain control, adaptive brightness

Day/Night High-definition Dome Camera·User Manual
Support auto iris
Support Privacy mask with 8 optional colors and 8 configurable
areas
Advanced 3-axis design allows this dome camera to be
adjusted 0-355° horizontally and 0-180° vertically to meet
different mounting requirements
Adopt advanced double-plate design to guarantee the heat
dissipation of CCD and the quality of image
1.2 Function Summary
Motion Detection: In the user-defined motion detection
surveillance area, the moving object can be detected and trigger
alarm. The sensitive level can be customized according to the
environment.
Privacy Mask: This function allows you to block or mask certain
area of a scene, thus prevent the personal privacy from recording
or live viewing. The number of privacy mask area is up to 8.
Figure 1-1 Privacy Mask
2

Day/Night High-definition Dome Camera·User Manual
3
DAY/NIGHT Auto Switch: The cameras deliver color images
during the day. And as light diminishes at night, the cameras
switch to night mode and deliver black and white images with high
quality.
AGC: AGC is a control circuit that automatically changes the gain
of a receiver or other piece of equipment, so that the desired
output signal remains essentially. When under low illumination,
AGC will regulate the gain and amplification of the video signal.
S/N ratio: It is the ratio of Signal voltage and noise voltage. The
ratio is larger, the effect of noise is less, and the image is clearer.
OSD (On Screen Display): The on-screen display (abbreviated
OSD) is an image superimposed on a screen picture, used for
displaying information and menu.
Synchronous System: Synchronization of the camera usually
contains power synchronization and internal synchronization.
Internal synchronization is realized by the synchronous signal
which is generated by the inside crystal oscillator.
White Balance: White balance can remove the unrealistic color
casts. White balance is the white rendition function of the camera
to adjust the color temperature according to the environment
automatically.
ICR Auto Switch: The filter will filter infrared light during the
daytime and change to normal filter at night to ensure a high
sensitivity and clear image.
BLC: If you focus on an object against strong backlight, the object
will be too dark to be seen clearly. The BLC (Backlight
Compensation) function can compensate light to the object in the

Day/Night High-definition Dome Camera·User Manual
front to make it clear, but this causes the over-exposure of the
background where the light is strong.
Figure 1-2 BLC OFF and BLC ON
4

Day/Night High-definition Dome Camera·User Manual
2Installation
Before you start:
Please make sure that the device in the package is in good
condition and all the assembly parts are included.
Note: Please ensure that the wall is strong enough to withstand
three times the weight of the camera and then install the camera
securely. If the wall is not strong enough, the camera may fall and
cause serious damage.
2.1 Ceiling mounting
Steps:
1. Rotate the lower dome anticlockwise to remove it.
2. Remove the inner black liner.
Black Liner
Anticlockwise
White Base
Figure 2-1 Black Liner Disassembling
5

Day/Night High-definition Dome Camera·User Manual
6
3. Attach the drill template (supplied) to the place where you
want to fix the camera.
4. Drill four screws holes according to the number 2 circles on the
drill template as shown in Figure 2-2.
Figure 2-2 The Drill Template
5. If you want to route the cables inside the ceiling, drill a hole in
the ceiling according to the circle in the centre of the template.
Skip this step, if you want to route the cables on the surface of
the ceiling.
6. Rotate the black base of the camera anticlockwise to take it
down from the camera.
7. Attach the black base to the ceiling by aligning the number 1
small holes of the base with the number 2 holes on the drill
template.
8. Secure the black base with 4 self-tapping screws as shown in
Figure 2-3.

Day/Night High-definition Dome Camera·User Manual
Note: Please use expansion screws if the dome camera is mounted
to cement wall.
Black Base
Ceiling
Screws
Figure 2-3 Mounting the Base
9. Route the cables through the hole in the center of the drill
template.
10. Align the camera with the black base. Rotate the camera
clockwise into the base.
11. Tighten the lock screw to secure the camera with the black
base as shown in Figure 2-4.
7
Camera
Black Base
Figure 2-4 Securing the Camera

Day/Night High-definition Dome Camera·User Manual
12. Connect the video output connector to the monitor. Connect
the power connector to the power supply.
13. Three-axis adjustment.
1). View the camera image using the monitor.
2). Rotate the panning table to adjust the panning position of
the camera. The adjusting range is from 0 degree to 355
degrees.
3). Loosen the tilting lock screw.
4). Rotate the tilting table to adjust the tilting position of the
camera. The adjusting range is from 0 degree to 80
degrees.
5). Tighten the tilting lock screw.
6). Rotate the lens to adjust the azimuth angle of the image.
Tilting Lock
Screw
Panning Table
Figure 2-5 Lens Adjustment
14. Zoom and focus adjustment.
8
1). View the camera image using the monitor.
