How to Use Wi-Fi NVR to Add Wi-Fi Camera

Title:
How to use Wi-Fi NVR add in Wi-Fi Camera
Version:
v1.0
Date:
02/07/2021
Product:
Wi-Fi Camera, Wi-Fi NVR
Page:
1 of 5
Preparation
Camera：DS-2CV1021G1-IDW V5.5.120 build 200604
NVR：DS-7104NI-K1 / W/M(C) V3.4.103 build 200508
How to Use Wi-Fi NVR Add In Wi-Fi Camera
BackGround
Hikvision has professional Wi-Fi Kit, including Wi-Fi NVR and Wi-Fi IPC. IPC
in Wi-Fi kit could be connected to NVR automatically without any manual
configuration.
This document will introduce how to use Wi-Fi NVR add in Wi-Fi Camera which
are not in Wi-Fi kit.
1. Wi-Fi Configuration in NVR
Enter Configuration-Wi-Fi，set Wi-Fi configuration, like encryption type and key.
Click Apply to save. Then NVR Wi-Fi hotspots function will be enabled.
2. Wi-Fi camera activation
After camera power on, connect PC network port to camera network pot, then use
SADP to activate the camera. Then enable DHCP function, and camera will have a
IP address. (We will access IPC web interface with this IP address)

Title:
How to use Wi-Fi NVR add in Wi-Fi Camera
Version:
v1.0
Date:
02/07/2021
Product:
Wi-Fi Camera, Wi-Fi NVR
Page:
2 of 5
3. Add Wi-Fi camera to NVR
Login in Wi-Fi camera’s web interface, enter Configuration-Network-Advanced
Settings-Wi-Fi. Click Enable icon, then enable camera’s Wi-Fi function.

Title:
How to use Wi-Fi NVR add in Wi-Fi Camera
Version:
v1.0
Date:
02/07/2021
Product:
Wi-Fi Camera, Wi-Fi NVR
Page:
3 of 5
Click Search icon，then Wireless List will be refreshed.
Choose NVR’s Wi-Fi hotspot, and configure the Wi-Fi configuration as shown in
below picture.

Title:
How to use Wi-Fi NVR add in Wi-Fi Camera
Version:
v1.0
Date:
02/07/2021
Product:
Wi-Fi Camera, Wi-Fi NVR
Page:
4 of 5
Check the Security Mode, Encryption Type and Key to be same with NVR. Click
Save, and click Search, then the connection status will be Connected.
At the same time, enter NVR GUI, Camera Management-Camera-IP Camera. You
can also check the camera status.
4. Maintenance
After Wi-Fi camera are added, you can enter System Maintenance--System Info--
Wi-Fi in NVR GUI, and check the online camera list, Bit rate and bandwidth parameters.
