HIK VISION PanoVu Mini User manual

Network PTZ Camera·Quick Start Guide
i
PanoVu Mini
Network PTZ Camera
Quick Start Guide

Network PTZ Camera·Quick Start Guide
i
Quick Start Guide
COPYRIGHT © 2018 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of
Hikvision. Unless otherwise stipulated, Hikvision does not make any
warranties, guarantees or representations, express or implied,
regarding to the Manual.
About this Manual
This Manual is applicable to PanoVu Mini Network PTZ Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions. Other trademarks and
logos mentioned below are the properties of their respective
owners.

Network PTZ Camera·Quick Start Guide
ii
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION,
ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO
YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR
DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.

Network PTZ Camera·Quick Start Guide
iii
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
0504111080130

Network PTZ Camera·Quick Start Guide
iv
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the EMC Directive

Network PTZ Camera·Quick Start Guide
v
2014/30/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information,
please see: www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information,
please see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.
Waring:
This is a class A product. In a domestic environment this product may
cause radio inter-ference in which case the user may be required to
take adequate measures.

Network PTZ Camera·Quick Start Guide
vi
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
Input voltage should meet both the SELV (Safety Extra Low Voltage)
and the Limited Power Source with 12 VDC according to the
IEC60950-1 standard. Refer to technical specifications for detailed
information.
Do not connect several devices to one power adapter as adapter
overload may cause over-heating or a fire hazard.
Make sure that the plug is firmly connected to the power socket.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

Network PTZ Camera·Quick Start Guide
vii
Make sure that the power has been disconnected before you wire,
install or dismantle the PTZ camera.
When the camera is mounted on wall or ceiling, the device shall
be firmly fixed.
If smoke, odor or noise rise from the device, turn off the power at
once and unplug the power cable, and then contact the service
center.
If the camera does not work properly, contact your dealer or the
nearest service center. Never attempt to disassemble the camera
yourself. (We shall not assume any responsibility for problems
caused by unauthorized repair or maintenance.)
Cautions
If the camera fails to synchronize local time with that of the
network, you need to set up camera time manually. Visit the
camera (via web browser or client software) and enter system
settings interface for time settings.
Make sure the power supply voltage is correct before using the
camera.
Do not drop the camera or subject it to physical shock, and do not
expose it to high electromagnetism radiation. Avoid installation on
vibrations surface or places subject to shock (ignorance can cause
device damage).
Do not touch senor modules with fingers. If cleaning is necessary,
use clean cloth with a bit of ethanol and wipe it gently. If the

Network PTZ Camera·Quick Start Guide
viii
camera will not be used for an extended period, replace the lens
cap to protect the sensor from dirt.
Do not aim the camera at the sun or extra bright places. Blooming
or smearing may occur otherwise (which is not a malfunction),
and affect the endurance of sensor at the same time.
The sensor may be burned out by a laser beam, so when any laser
equipment is in using, make sure that the surface of sensor will
not be exposed to the laser beam.
Do not place the camera in extremely hot, cold, dusty or damp
locations, and do not expose it to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for
operating environment.
Keep the camera away from liquid while in use.
While in delivery, the camera shall be packed in its original packing,
or packing of the same texture.
Improper use or replacement of the battery may result in hazard
of explosion. Replace with the same or equivalent type only.
Dispose of used batteries according to the instructions provided
by the battery manufacturer.
This product is not for household use.

Network PTZ Camera·Quick Start Guide
ix
Table of Contents
1 Overview......................................................................................... 1
1.1 Introduction ............................................................................. 1
1.1.1 Overview of Type I Camera................................................ 1
1.1.2 Overview of Type II Camera ............................................... 2
1.1.3 Overview of Type III Camera .............................................. 3
1.1.4 Overview of Type IV Camera.............................................. 4
1.1.5 Overview of Type V Camera............................................... 5
2 Installation...................................................................................... 6
2.1 Installing Type I Camera............................................................ 6
2.1.1 Installing the Memory Card ............................................... 6
2.1.2 Ceiling Mounting ............................................................... 7
2.1.3 Wall Mounting................................................................. 10
2.1.4 Pendant Mounting .......................................................... 12
2.2 Installing Type II Camera......................................................... 14
2.3 Installing Type III Camera........................................................ 14
2.4 Installing Type IV Camera........................................................ 14
2.4.1 Installing the Memory Card ............................................. 14
2.4.2 Wall Mounting................................................................. 16
2.4.3 Corner Mounting............................................................. 18
2.4.4 Pendant Mounting .......................................................... 19
2.4.5 Adjust the Surveillance Angle .......................................... 19
2.5 Installing Type V Camera......................................................... 21
3 Setting the PTZ Camera over the LAN........................................... 22
3.1 Wiring .................................................................................... 22
3.2 Activating the Camera ............................................................ 23
3.2.1 Activation via Web Browser............................................. 23
3.2.2 Activation via SADP Software .......................................... 25

Network PTZ Camera·Quick Start Guide
x
3.3 Modifying the IP Address........................................................ 26
4 Accessing via Web Browser .......................................................... 29
5 Operating via Hik-Connect App .................................................... 32
5.1 Enable Hik-Connect Service on Camera .................................. 32
5.1.1 Enable Hik-Connect Service via SADP Software ............... 32
5.1.2 Enable Hik-Connect Service via Web Browser ................. 33
5.2 Hik-Connect Setup.................................................................. 34
5.3 Adding Camera to Hik-Connect............................................... 34
5.4 Initializing the Memory Card .................................................. 36

Network PTZ Camera·Quick Start Guide
1
1Overview
1.1 Introduction
PanoVu Mini Series Network PTZ Camera has five types:
Type I: Indoor Camera with 3+1 Lenses
Type II: Indoor Camera with 1+1 Lenses
Type III: Indoor Camera with 3+0 Lenses
Type IV: Outdoor Camera with 3+0 Lenses
Type V: Outdoor Camera with 3+1 Lenses
1.1.1 Overview of Type I Camera
Three Lenses
Figure 1-1 Overview of Type I Camera

Network PTZ Camera·Quick Start Guide
2
Audio Output
Audio Input
Power Supply
(12 VDC)
Network Interface (PoE)
Memory Card Slot
Reset Button
Figure 1-2 Interfaces of Type I Camera
1.1.2 Overview of Type II Camera
Lens Cover
Figure 1-3 Overview of Type II Camera

Network PTZ Camera·Quick Start Guide
3
Audio Output
Audio Input
Power Supply
(12 VDC)
Network Interface (PoE)
Memory Card Slot
Reset Button
Figure 1-4 Interfaces of Type II Camera
1.1.3 Overview of Type III Camera
Three Lenses
Figure 1-5 Overview of Type III Camera
Audio Output
Audio Input
Power Supply
(12 VDC)
Network Interface (PoE)
Memory Card Slot
Reset Button
Figure 1-6 Interfaces of Type III Camera

Network PTZ Camera·Quick Start Guide
4
Note:
Press RESET when the camera is powering on or rebooting to restore
the default settings, including the user name, password, IP address,
and port No., etc.
1.1.4 Overview of Type IV Camera
Figure 1-7 Overview of Type IV Camera
Audio Interface
Alarm Interface
Power Cord
GND
Network Interface
Figure 1-8 Cable Interfaces of Type IV Camera

Network PTZ Camera·Quick Start Guide
5
1.1.5 Overview of Type V Camera
Figure 1-9 Overview of Type V Camera
Note:
Cable interfaces of Type V camera are the same as cable interfaces of
Type IV camera. Refer to Figure 1-8.

Network PTZ Camera·Quick Start Guide
6
2Installation
Before you start:
Check the package contents and make sure that the device in the
package is in good condition and all the assembly parts are included.
Note:
Do not power the camera up until the installation is finished. To
ensure the safety of personnel and equipment, all the installation
steps should be done with power supply off.
2.1 Installing Type I Camera
2.1.1 Installing the Memory Card
(Optional) You can install the memory card for local storage.
Steps:
1. Rotate the installation plate anticlockwise to separate it from
the camera as shown in Figure 2-1.
Note:
Keep the installation plate for camera mounting.

Network PTZ Camera·Quick Start Guide
7
OPEN
Figure 2-1 Remove the Installation Plate
2. Insert the memory card into the memory card slot as shown in
Figure 2-2.
Figure 2-2 Insert the Memory Card
2.1.2 Ceiling Mounting
Before you start:
The thickness of the ceiling shall be no less than 5 mm.
Make sure the ceiling is strong enough to withstand more than
four times the weight of the camera and its accessories.
Steps:
1. Install the installation plate.

Network PTZ Camera·Quick Start Guide
8
1) Rotate the installation plate anticlockwise to separate it from
the camera.
2) Drill three screw holes on the ceiling according to the
installation plate as shown in Figure 2-3.
Front
Screw Holes
Figure 2-3 Drill Screw Holes
3) Insert three expansion screws into the screw holes.
4) Fix the installation plate onto the ceiling with three screws.
Figure 2-4 Install the Installation Plate
2. Route the cables.

Network PTZ Camera·Quick Start Guide
9
Cables of the network PTZ camera can be routed either from
top or side of the camera back box, as shown in Figure 2-5 and
Figure 2-6.
Figure 2-5 Route the Cables from Top
Figure 2-6 Route the Cables from Side
3. Install the camera.
1) Align the camera with the installation plate, and rotate the
camera clockwise to fix the camera onto the installation
plate.
