HIK VISION PanoVu iDS-2PT9122IX-DE/S Quick guide

Configuration & Installation Guidance of
PanoVu Seires PT Camera

1. PanoVu Seires PT Camera
Introduction
1.1 Overview
Hikvision iDS-2PT9122IX-DE/S (5-50mm) (4mm) PanoVu Seires PT Camera 2MP +
2MP 10× Network PTZ Camera, with the integration design, is able to capture distant
view images as well as close-up images. Base on deep learning algorithm, PanoVu
Seires PT Camera can realize accuracy human body capture.
This series of camera can be widely used for wide ranges of high-definition, such as
the entrance/exit, airport, port, wharf, reservoir, square, park, scenic spot and
station, etc.
1.2 Key Features
Distant View Camera
1/2.7" progressive scan CMOS
Up to 1920 × 1080 resolution
Horizontal field of view: 92°
Min. illumination:
Color: 0.002 Lux@(F1.2, AGC ON),
B/W: 0.0002 Lux@(F1.2, AGC ON)
Tracking PTZ Camera
1/2.7" progressive scan CMOS
Up to 1920 × 1080 resolution
Horizontal field of view: 61.3°to 6.26°
Pan and tilt range: 210°(Pan), -22°o 22°(Tilt)
Min. illumination:
Color: 0.0035 Lux@(F1.6, AGC ON)
0 Lux with IR
10× Optical Zoom, 16× Digital Zoom

1.3 Mount Option
DS-2601ZJ Wall Mounting Bracket
DS-2664ZJ Pendant Mounting Bracket
DS-2665ZJ-P Table mounting Bracket
2. Installation Guidance
2.1 Mounting Applications
PanoVu Seires PT Camera support various mounting modes, including wall mounting
and pendant mounting. Please use Pole mounting hoop when mount to a pole.
2.2 Steps
A. Drill the screw hole and the cable hole according to the supplied drill template.
Fix the mounting base to the ceiling. Note that the logo should be at the top.
.
B. Push the bracket into the camera hangers, secure the camera to the bracket with
M5 and M6 screws.

M6 Screw
M5
Screw
.
C. Put the wires into the junction box. And tighten up the waterproof endcap.
.
Junction box
Waterproof
cables
Waterproof
endcap
D. Hook the bracket to the bracket base with the safety rope.
Safe rope
E. Fix the bracket to the base.
Bottom
screw
Side
screw
Junction box
screws
F. Ceiling mounting.

Side screw
Horizontal
screws
Junction box
screws
G. Angle Adjusting: After the camera mounted, you can adjust the angle of the
camera to get a good image performance.
Loosen the lock screws in the above picture to adjust the panning position.
Loosen the lock screws in the above picture to adjust the tilting position.
H. Power Supply
PanoVu Seires PT Camera use DC12V, 5A power supply. DC12V, 5A.
I. Installing the SD card
If you need local storage, insert the SD card to the SD card slot to get it installed.
Micro SD card slot

2.3 Installation Height
Suggestion installation height is 3.5m to 6m. And make sure no obstacle before the
camera.
2.4 Monitoring Range
The fixed camera can get human body information within 50m, and the PTZ camera
can cover 100m.
Fixed camera image
PTZ camera image
2.5 Dimensions and protection level
Dimensions: Φ195.1×280.8mm；

Weight: 2.5kg;
Protection Level: IP66，TVS 6000V Lightning Protection, Surge Protection and
Voltage Transient Protection
3. Product Positioning
PanoVu Seires PT
Camera
Box + PTZ
Appearance
Features
Up to 50m human body
capture. With deep learning
algorithm, realize high capture
speed and accuracy. All in one
design.
Composed of box cameras and
smart PTZ dome cameras.
Support multiple smart event
linkage. But the capture speed
is slower than PT camera and
may have miss capture.
Application
Scenario
Common scene, within 100m.
Such as gate, hall, corridor,
school.
Further distance scene (100m
to 300m), such as parking
apron, playground.
4. Configuration Guidance
4.1 Rapid Focus
After this function is enabled, perform calibration and the focus can be quicker than
quick focus.
1. Enter the Rapid Focus settings interface:
Configuration > PTZ > Rapid Focus

2. Check the Enable checkbox to enable the Rapid Focus function.
3. Click Add to add a scene, up to 4 scenes can be set.
4. For each scene, drag the red line on the live view image to the calibration position. You can
drag the ends of the red line to adjust the length of the line.
5. Click Start Calibration. There is the notice Calibrating on the live view image and the camera
lens performs auto focus.
6. After calibration, there is the notice Calibration succeeded on the live view image.
Click Save to save the settings.
4.2 Calibration
4.2.1 Auto Calibration
(1) Select Auto from the calibration mode. And click Start Calibration.

(2) The pop up auto calibration box like below. The whole process will be automatically. After the
process is 100%, click auto calibrating succeeded.
(3) Enable tracking and save the settings.
4.2.2 Manual Calibration
(1) Select Manual Calibrating from the calibration list.
(2) Drag the crosses of the panoramic view “ ” and move them to the scene evenly.
(3) Select a calibration site and adjust the PTZ view by controlling PTZ and zooming in/ out to
ensure the cross in the center of the PTZ view is almost the same with the site of the
calibration site of panoramic view.
(4) Click to save the setting of calibration No. 1.

(5) Select calibration site No. 2 to No. 9, and repeat the step above to add the manual calibration
sites.
(6) Click Start Calibration to perform the calibration
4.3 VCA settings
1. PanoVu series PT camera support face capture, human body capture, and vehicle capture.
2. Go to System > System Settings > VCA Resourve. There are 3 capture models. You can check
Enable Scheduled Switch to enable scheduled switch function.

3. Target Capture: The panoramic camera recognizes and captures the vehicle, the human face,
and the human body, and the tracking PTZ camera captures the human face through linkage
tracking and positioning. The captured pictures are uploaded to the central platform.
3.1 Add a new rule. Click to add a new rule. You can edit the region name for the
new rule.
3.2 Set the rule area. Click to draw the rule area. Left click the mouse to start
to draw the area and right click to finish drawing. Check the Enable checkbox to
enable the rule and click Save to save the settings.
3.3 Set shield region. Shield region is the area where the rules are invalid. Four shield

regions can be set.
3.4 Set arming schedule. The time of each period cannot be overlapped. Up to 8
periods can be configured for each day.
4. Face Capture: The tracking PTZ camera captures the human face that meets
the pupil distance demand. The captured pictures are uploaded to the central
platform.
4 detection scene can be set for face detection. Set rules and scene according below
picture.

4.2 Set arming schedule for each scene.
4.3 Set patrol for scenes.

5. Perimeter Capture: The panoramic camera detects the perimeter of an area,
and the tracking PTZ camera captures the human body or the human face.
The captured pictures are uploaded to the central platform. Configuration
method is the same with target capture mode.

5. Result Show
5.1 4200
Use the latest version 4200
Install iVMS 4200.
Add camera in the device management interface.
Go to control panel, add human capture alarm module.
Go to human capture alarm interface. It will takes several minutes to show the capture images.
5.2 DEMO Tool
Steps:
1. Download latest version SDK, install it to PC. And run ClientDemoEn.exe.

2. Add device to client demo.
3. Choose the camera and go to Others→ Guard/Unguard.

4. The demo will pop up a window. Choose the camera name and click Guard/Unguard.
5. Then demo will store all the captured picture to the PC. The local path can be set at Config → Local Setup.

6. Go to the local path and find all the pictures.
