HIK VISION DS-2CD762MF-FBH Series User manual

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
1
DS-2CD762MF-FB(H) Network Camera
Technical Manual

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2011 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusine[email protected]
Find out more about HIKVISION at
www.hikvision.com

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Order Models
4. Dimension
5. Accessories

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
4
1.Key Features
Up to 1.3 megapixel (1280 × 960) resolution, real time video at HD 720P
H.264 or MPEG-4 video compression with high compression ratio
Progressive scan CCD, capture motion video without sawtooth
Support dual streams, and the sub stream used for the mobile phone surveillance
Up to 32 GB SD/SDHC card local storage
Two-way audio
PoE (Power over Ethernet)
Auto iris, electronic shutter for different environment
Complete function: PTZ control, alarm, and so on
3-axis (pan/tilt/rotation) positioning allows adjustment for optimum camera rotation and placement
Weather Proof Rating: IP66
Impact Protection: IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
5
2.Specifications
Model
Parameter
DS-2CD762MF-FB(H)
1.3 Megapixel CCD Weather-proof Vandal-proof IP Dome Camera
Camera
Image Sensor 1/3” Progressive Scan CCD
Signal System PAL
Min. Illumination
Color: 0.1 Lux @ (F1.2, AGC ON)
B/W: 0.01 Lux @ (F1.2, AGC ON)
Color: 0.14 Lux @ (F1.4, AGC ON)
B/W: 0.014 Lux @ (F1.4, AGC ON)
Shutter Time 1/4 s to 1/100,000 s
Lens 2.7 – 9 mm @ F1.4
Angle of view: 89° - 24°
Lens Mount Φ14
Auto Iris DC drive
Angle Adjustment Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360°
Day & Night Electronic
Compression Standard
Video Compression H.264 (MPEG-4 optional)
Bit Rate 32 Kbps - 8 Mbps
Audio Compression OggVorbis
Dual Stream Yes
Max. Image Resolution 1280 × 960
Frame Rate 50Hz:12.5fps (1280×960),25fps (1280×720)
60Hz:15fps (1280×960),24fps (1280×720)
Image Settings Saturation, Brightness, Contrast adjustable through client software or
web browser
Network
Alarm Trigger Motion detection
Protocols TCP/IP, HTTP, DHCP, DNS, RTP/RTCP, PPPoE
(FTP, SMTP, NTP, SNMP optional)
Security Password protection
Interface
Audio Input 1-ch, 3.5 mm audio interface (2.0 - 2.4 Vp-p, 1 kΩ)
Audio Output 1-ch, 3.5 mm audio interface (Line level, 600 Ω)
Communication Interface 1 RJ45 10 M/100 M Ethernet port and 1 RS-485 interface
Alarm Input 1

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
6
Alarm Output 1
Video Output 1Vp-p composite output (75 Ω/BNC)
Local Storage Built-in SD/SDHC slot, up to 32 GB
General
Operating Conditions
-10 °C – 60 °C (14 °F – 140 °F)
Humidity 90% or less (non-condensing)
-H: -40°C - 60°C (-40 °F – 140 °F) with heater and fan on
Power Supply
24 V AC ± 10%, 12 V DC ± 10%
-H: 24 V AC ± 10%
PoE (802.3af)
Power Consumption Max. 6 W with IR cut filter on
-H: Max. 16 W with heater and fan on
Impact Protection IEC60068-2-75Eh, 50J; EN50102, up to IK10
Weather Proof Rating IP66
Dimension Φ 160 × 134.5 mm (Φ 6.30” × 5.30”)
Weight 1400 g (3.09 lbs)
*“H” series supports heater.

Hikvision Technical Manual
©2006 – 2011 by HIKVISION. All rights reserved.
7
3.Order Models
DS-2CD762MF-FB, DS-2CD762MF-FBH
4.Dimension
Unit: mm
5.Accessories
Wall Mount
DS-1217ZJ
