About this Manual
This Manual is applicable to DS-3E0108P-E, DS-3E0109P-E/M, DS-3E0318P-E/M, and DS-3E0326P-E/M.
The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The information contained in the Manual is subject to change,
without notice, due to firmware updates or other reasons. Please find the latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the properties of Hikvision in various jurisdictions. Other
trademarks and logos mentioned below are the properties of their respective owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS
HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND
HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS DIRECTORS, OFFICERS,
EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF
THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT
YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR
JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED
WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.

Safety Instruction
These instructions are intended to ensure that user can user the product correctly to avoid danger or property loss.
The precaution measure is divided into “Warning” and “Caution”
Warning: Serious injury or death may occur if any of the warning is neglected.
Caution: Injury or equipment damage may occur if any of the caution is neglected.
Warning Follow these safeguards to
prevent serious injury or death.
Caution Follow these precautions to
prevent potential injury or material
damage.
Warning
Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.
In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and
region. Refer to technical specifications for detailed information.
Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 100-240 V
AC or 12 V DC according to the IEC60950-1 standard. Refer to technical specifications for detailed information.
Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire hazard.
Make sure that the plug is firmly connected to the power socket.
If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then contact the
service center.

Preventive and Cautionary Tips
Before connecting and operating your device, please be advised of the following tips:
Ensure unit is installed in a well-ventilated, dust-free environment.
Unit is designed for indoor use only.
Keep all liquids away from the device.
Ensure environmental conditions meet factory specifications.
Ensure unit is properly secured to a subrack or shelf.
Major shocks or jolts to the unit as a result of dropping it may cause damage to the sensitive electronics within the
unit.
Use the device in conjunction with an UPS if possible.
Power down the unit before connecting and disconnecting accessories and peripherals.
A factory recommended HDD should be used for this device.
Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent
type only. Dispose of used batteries according to the instructions provided by the battery manufacturer.
Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.
The figures in the manual are for reference only.
This manual is applicable to the models listed in the following table.
Model
DS-3E0108P-E
DS-3E0109P-E/M
DS-3E0318P-E/M
DS-3E0326P-E/M

Contents
Chapter 1 Product Overview.........................................................................................................................................1
1.1 Overview ...........................................................................................................................................................1
1.2 Packing List .......................................................................................................................................................1
1.3 Appearance ........................................................................................................................................................2
Chapter 2 Device Installation........................................................................................................................................8
2.1 Installation Notes ...............................................................................................................................................8
2.2 Installation .........................................................................................................................................................9
2.3 Grounding........................................................................................................................................................ 11
Chapter 3 Physical Connection ...................................................................................................................................14
RJ45 Port Connection ............................................................................................................................................ 14
SFP Port Connection.............................................................................................................................................. 14
Checking ............................................................................................................................................................... 15
Power Supply.........................................................................................................................................................16
Appendix Technical Specifications..............................................................................................................................17

Unmanaged PoE Switch/User Manual
1
Chapter 1 Product Overview
1.1 Overview
DS-3E0108P-E
Hikvision unmanaged PoE switch, DS-3E0108P-E, provides 8 * 100 Mbps RJ45 ports, and ports 1 – 4 can provide power
to IEEE 802.3af/IEEE 802.3at standard powered devices, such as access point, IP camera, IP phone and so on. The power
output totals 58 W.
DS-3E0109P-E/M
Hikvision unmanaged PoE switch, DS-3E0109P-E/M, provides 8 * 100 Mbps downlink RJ45 ports, and one 100 Mbps
uplink RJ45 port. Ports 1 - 8 can provide power to IEEE 802.3af/IEEE 802.3at standard powered devices, such as access
point, IP camera, IP phone and so on. The power output totals 58 W.
DS-3E0318P-E/M
Hikvision unmanaged PoE switch, DS-3E0318P-E/M provides 16 * 100 Mbps downlink RJ45 ports, one 1000 Mbps
uplink RJ45 port, and one 1000 Mbps independent uplink SFP port. Ports 1 - 16 can provide power to IEEE 802.3af/IEEE
802.3at standard powered devices, such as access point, IP camera, IP phone and so on. The power output totals 135 W.
DS-3E0326P-E/M
Hikvision unmanaged PoE switch, DS-3E0326P-E/M, provides 24 * 100 Mbps downlink RJ45 ports, one 1000 Mbps
uplink RJ45 port, and one 1000 Mbps independent uplink SFP port. Ports 1 - 24 can provide power to IEEE 802.3af/IEEE
802.3at standard powered devices, such as access point, IP camera, IP phone and so on. The power output totals 225 W.
In addition, DS-3E0109P-E/M, DS-3E0318P-E/M and DS-3E0326P-E/M are equipped with a network mode switch.
DS-3E0109P-E/M can enable/disable EXTEND mode by flipping the switch between EXTEND ON and EXTEND OFF.
DS-3E0318P-E/M and DS-3E0326P-E/M can use this switch to change the network mode to Priority, Standard, Isolate, or
EXTEND.
1.2 Packing List
Model
DS-3E0108P-E
DS-3E0109P-E/M
DS-3E0318P-E/M
DS-3E0326P-E/M
Switch
*Take DS-3E0109P-E/M as an
example
√
√
√
√
Pads
√
×
√
√

Unmanaged PoE Switch/User Manual
2
L-shaped bracket
×
×
√
√
Power adapter
√
√
×
×
Power cord
√
√
√
√
Expansion bolt
√
√
×
×
Screw
√
×
3 Pairs
3 Pairs
User manual
√
√
√
√
If any item is missing, or damaged, please keep the original package and contact the local reseller or distributor
immediately.
1.3 Appearance
Front Panel
DS-3E0108P-E
DS-3E0109P-E/M
LED Indicator
Specific description of the LED indicators is shown as following:
LINK/ACT LED
PoE LED
100 M LED
Power LED
Downlink RJ45 Ports
Uplink RJ45 Ports

Unmanaged PoE Switch/User Manual
3
LED
State
Description
Power
Solid on
The switch is connected to a power supply properly.
Off
The switch is not connected to a power supply properly or not
connected to a power supply.
PoE Max
*Available only
on
DS-3E0108P-E
Solid on
The PoE power output reaches the alarm threshold, and the powered
device is powered properly.
Blinking
The PoE power output reaches the maximum power, and some of
power devices are not powered properly.
Off
The PoE power output does NOT reach the alarm threshold, and the
powered device is powered properly.
PoE Status
Solid on
The port is connected to a powered device and is supplying power.
Blinking
The PoE output of the port exceeds 40 W.
Off
The port is not supplying power or not connected to a powered
device.
Link/Act
Solid on
The port is connected properly.
Blinking
The port is transmitting data.
Off
The port is not connected properly or not connected to a device.
100 Mbps
*Available only
on
DS-3E0109P-E/M
Solid on
The transmission rate of this port is 100 Mbps.
Off
The transmission rate of this port is 10 Mbps when the LINK/ACT
LED of corresponding port lights up.
The port is not connected to a device when the LINK/ACT LED of
corresponding port is off.
Rear Panel
DS-3E0108P-E
PoE Ports
RJ45 Ports
Power Jack

Unmanaged PoE Switch/User Manual
4
DS-3E0109P-E/M
RJ45 Port
DS-3E0108P-E provides 8 * 10/100 Mbps RJ45 ports, and ports 1 - 4 comply with IEEE 802.3af and IEEE 802.3at.
DS-3E0109P-E/M provides 9 * 10/100 Mbps RJ45 ports. Ports 1 - 8 are downlink ports and comply with IEEE 802.3af
and IEEE 802.3at. Port 9 is uplink port. Ports 1-2 of DS-3E0109P-E/M are default high-priority ports.
Power Jack
The power jack is used to connect the switch to a power supply using the included power core.
Grounding Terminal
Used for connecting the grounding cable for lightning protection. For details, refer to section “2.3 Grounding”.
EXTEND Mode Switch
State
Description
EXTEND OFF
Standard mode. In this mode, the maximum transmission rate of ports 1 - 8
is 100 Mbps, and the maximum transmission distance is 150 meters.
EXTEND ON
EXTEND mode. In this mode, the maximum negotiation rate of ports 1 - 8
reduces to 10 Mbps, and the maximum transmission distance is 250 meters.
To ensure that the performance of the switch in EXTEND mode , use CAT 5e or better Ethernet cables and set the speed
and duplex of the peer device to Auto Negotiation.
In EXTEND mode, to ensure timely video data transmission, set the Data Rate to a value less than 8 Mbps.
Note
To avoid damage to the switch, use the included power adapter and power core for power supply.
EXTEND mode switch
Power Jack
Grounding Terminal

Unmanaged PoE Switch/User Manual
5
Front Panel
DS-3E0318P-E/M
DS-3E0326P-E/M
LED Indicator
Specific description of the LED indicators is shown as following:
LED
State
Description
Power
Solid on
The switch is connected to a power supply properly.
Off
The switch is not connected to a power supply properly or not
connected to a power supply.
G1 LED Link/Act LED
16 * 100 Mbps downlink RJ45 Ports
1000 Mbps uplink RJ45 port
1000 Mbps uplink SFP port
Power LED
PoE - MAX LED
SFP1 LED
Network mode switch
G1 LED Link/Act LED
24 * 100 Mbps downlink RJ45 Ports
Power LED
PoE - MAX LED
SFP1 LED
Network mode switch
1000 Mbps uplink RJ45 port
1000 Mbps uplink SFP port

Unmanaged PoE Switch/User Manual
6
PoE Max
Solid on
The PoE power output reaches the alarm threshold, and the powered
device is powered properly.
Blinking
The PoE power output reaches the maximum power, and some of
power devices are not powered properly.
Off
The PoE power output does NOT reach the alarm threshold, and the
powered device is powered properly.
Link/Act
Solid on
The port is connected properly.
Blinking
The port is transmitting data.
Off
The port is not connected properly or not connected to a device.
G1
Solid on
The port is connected to a device.
Blinking
The port is transmitting or receiving data.
Off
The port is not connected or not connected to a device properly.
SFP1
Solid on
The port is connected to a device.
Off
The port is not connected or not connected to a device properly.
RJ45 Port
DS-3E0318P-E/M provides 17 RJ45 ports and ports 1 - 16 are 10/100 Mbps downlink ports and comply with IEEE
802.3af and IEEE 802.3at. Port G1 is 10/100/1000 Mbps uplink port.
DS-3E0326P-E/M provides 25 * RJ45 ports and ports 1 - 24 are 10/100 Mbps downlink ports and comply with IEEE
802.3af and IEEE 802.3at. Port G1 is 10/100/1000 Mbps uplink port.
Ports 1 - 8 of DS-3E0318P-E/M and DS-3E0326P-E/M are default high-priority ports.
SEP Port
DS-3E0318P-E/M and DS-3E0326P-E/M respectively provide an independent gigabit SFP optical module port, which
can connect to gigabit SFP optical module.
Note
No SFP optical module is included in the switch package. Prepare the module yourself if it is required.
Network Mode Switch
Both DS-3E0318P-E/M and DS-3E0326P-E/M support four network modes: Priority, Standard, Isolate and Extend.
Priority
In this mode, the switch optimizes the cache capability of the ports. Ports 1 - 8 are high-priority ports, and all ports can

Unmanaged PoE Switch/User Manual
7
communicate with each other.
When several IP cameras are connected to the switch, this mode is recommended. To ensure the fluency of the monitoring
pictures, connect the G1 port and SFP1 port to the uplink device connected to a monitoring computer.
Standard
Default mode. In this mode, the switch is an ordinary switch, and all ports can communicate with each other.
Isolate
In this mode, all downlink ports of the switch cannot communicate with each other and can only communicate with G1
port and SFP port respectively.
Extend
In this mode, all ports can communicate with each other. In addition, the transmission rate of the ports 9 - 16 of
DS-3E0318P-E/M and ports 17 - 24 of DS-3E0326P-E/M reduces to 10 Mbps. The maximum transmission distance is up
to 250 meters.
In EXTEND mode, to ensure timely video data transmission, set the Data Rate to a value less than 8 Mbps.
Rear Panel
DS-3E0318P-E/M or DS-3E0326P-E/M
Power Jack
The power jack is used to connect the switch to a power supply using the included power core.
Grounding Terminal
Used for connecting the grounding cable for lightning protection. For details, refer to section “2.3 Grounding”.
Grounding Terminal
Power Jack

Unmanaged PoE Switch/User Manual
8
Chapter 2 Device Installation
2.1 Installation Notes
Follow the notes below to avoid device damages or personal injuries caused by misoperation.
Safety Alert
Wear ESD gloves before installation, and do not power on the switch before finishing installation.
Use the included power cord to power the switch.
Make sure that the input voltage matches the value specified on the label of the switch.
Place the switch in a well-ventilated and dry environment.
Do not remove the housing of the switch.
Disconnect the switch from the power supply before cleaning it. Do not scrub the switch with any liquid.
Position the switch away from powerline, electric lamp, and power system.
Note
There is a void sticker covering one of the screws on the housing of the switch. Do not remove the sticker without
permission of the local agent, otherwise you shall be responsible for any damage.
Environmental Requirements
Temperature and Humidity
For the temperature and humidity requirements, refer to “Appendix Technical Specifications”.
Anti-static Precautions
Electrostatic adsorption occurs if dust falls onto the switch, which may cause poor metal contact that disables the switch
to work properly. To prevent this problem, pay attention to the following:
Keep the air in the ambient environment clean. Regularly perform dedusting.
Make sure that the switch is grounded properly.
Lightning Protection
In thunderstorm weather, a sudden current caused by lightning stroke may damage the switch. To protect the switch
against lightning stroke or strong current:
Make sure that the device, workbench or subrack where the switch is mounted and receptacle in the wall are all
properly grounded.

Unmanaged PoE Switch/User Manual
9
Connect the cables to the switch properly to avoid generating internal lightning induction.
If outdoor cabling is required, it is advisable to deploy a signal lightning arrester.
Mounting Requirements
Follow the instructions below.
The desktop is stable and sturdy enough.
Place the switch in a clean, dry and well-ventilated environment. Keep at least 10cm gap on all sides for cooling.
Do not place any heavy or big object on the switch.
Keep at least 1.5 cm vertical distances between each device while installing it in stack.
2.2 Installation
Select a proper mounting type according the product and environment.
Desktop Mounting
All switches mentioned in this user manual can be mounted on desktops.
Procedure
If your switch is DS-3E0109P-E/M, skip step 1 and 2, and directly go to step 3.
Step 1: Place the switch upside down on a stable and flat desktop.
Step 2: Remove the protective paper on the four sticky sides of the pads and paste the four footpad stickers to the
corresponding four recesses on the bottom of the switch.
Take DS-3E0326P-E/M as an example
Step 3: Place the switch right side up on the desktop.
Rack Mounting
If a 19 inch standard subrack is prepared, DS-3E0318P-E/M or DS-3E0326P-E/M can be mounted on subrack.
Procedure
Step 1: Ensure that the subrack is stable and level, and properly grounded.
Step 2: Fix L-shaped brackets to the switch with screws. See the following figure.

Unmanaged PoE Switch/User Manual
10
Take DS-3E0326P-E/M as an example
Step 3: Mount the switch at a proper height on the subrack with screws and fix the switch to the subrack with screws.
Take DS-3E0326P-E/M as an example
Wall Mounting
* Applicable only to DS-3E0108P-E or DS-3E0109P-E/M.
Procedure
Step 1: Create two horizontally aligned holes about 6 mm in diameter with percussion drill. The distance between the two
holes should be 150 mm for DS-3E0108P-E and 113.5mm for DS-3E0109P-E/M.
Step 2: Knock the expansion bolts into the holes with the rubber hammer until the expansion bolts are flush with the wall.
Step 3: Fix the screws with the Phillips screwdriver and keep at least 2.5mm distance between the inner edge of the screw
head and the outer edge of the expansion bolt to ensure that the switch can be hung on the screws firmly.
Step 4: Align the two hanging holes in the housing of the switch with the screws, and hook the switch firmly onto the

Unmanaged PoE Switch/User Manual
11
screws.
2.3 Grounding
Grounding is not only a measure to release the overvoltage and overcurrent caused by lightning as soon as possible, but
also for personal safety. Select the proper method to ground your switch according to the installation environment.
Note
DS-3E0108P-E has no grounding terminal. So if your switch is DS-3E0108P-E, skip this part.
With the grounding bar
If a grounding bar is available at the installation site, use either of the following installation methods to ground the switch.
A. Connect the switch to the grounding bar directly.
Procedure
Step 1: Connect one end of the grounding cable to the binding post on the grounding bar.
Step 2: Connect the other end of the grounding cable to the grounding terminal and fasten the screw.
Take DS-3E0326P-E/M as an example
B. Connect the switch to another grounded device.
Procedure
Step 1: Connect one end of the grounding cable to the grounding terminal of a grounded device and fasten the screw.
Step 2: Connect the other end of the grounding cable to the grounding terminal and fasten the screw.

Unmanaged PoE Switch/User Manual
12
Take DS-3E0326P-E/M as an example
Note
Connect the grounding cable to the grounding system in the equipment room. Do not connect it to a fire main or lightning
rod.
Without the grounding bar
If there is no grounding bar but the grounding body can be buried, follow steps below:
Step 1: Bury an angle steel or steel pipe (Length ≥ 0.5 m) into the land.
Step 2: Weld one end of the grounding cable to the angle steel or steel pipe and protect the welding point against
corrosion (electroplating or coating).
Step 3: Connect the other end of the grounding cable to the grounding terminal.
Take DS-3E0326P-E/M as an example

Unmanaged PoE Switch/User Manual
13
If both ground bar and the environment for burying the grounding body are not available, use the protecting earth (PE)
wire.
Make sure that the switch adopts 3-core cable with the PE wire, and the PE wire of the AC power supply has been well
grounded in the power distribution room or at the side of the AC power supply transformer.
Take DS-3E0326P-E/M as an example

Unmanaged PoE Switch/User Manual
14
Chapter 3 Physical Connection
RJ45 Port Connection
Connect the RJ45 ports of the switch to the RJ45 ports of peer devices. The ports marked with “Uplink” and “G1” are the
uplink ports, and the other ports are downlink ports. All ports of DS-3E0108P-E are ordinary RJ45 ports, not being
divided into uplink and downlink ports.
Ports 1 - 4 of DS-3E0108P-E and all downlink ports of DS-3E0109P-E/M, DS-3E0109P-E/M, and DS-3E0326P-E/M
support PoE power supply, and can provide power for IEEE 802.3af and IEEE 802.3at powered devices, such as AP, IP
phone, IP camera, and so on.
The switch supports auto MDI/MDIX. That is, you can use straight-through cable or crossover cable to connect the switch
to the peer device. CAT 5 or better Ethernet cable is recommended.
SFP Port Connection
Procedure
* Available only on DS-3E0318P-E/M and DS-3E0326P-E/M.
Step 1: Connect your optical module to the SFP port. Ensure that the direction of the optical module is correct.

Unmanaged PoE Switch/User Manual
15
Take DS-3E0326P-E/M as an example
Step 2: Connect the Rx module to Rx port and Tx module to Tx port.
Take DS-3E0326P-E/M as an example
Checking
Before powering on the switch, check the cabling as follows.
The power supply should accord with the rated input standard.
Port cables and grounding cable are correctly connected.
If an outdoor cable is required, connect a lightning protector to the cable before you connect the cable to the port.
