HIK VISION DS-UAC W Series User manual

Wireless Conference Speakerphone
User Manual

1
User Manual
Speakerphone
USB Dongle
(at the bottom of the speakerphone)
USB Dongle: The accessory is included in some models.
Packing List

Enable/Disable Microphone
Status Light
Answer/Reject
Phone Calls
Speakerphone Volume-/+
Power On/Off Enable/Disable Bluetooth
Bluetooth Light
Power Light
Microphone
Enable/Disable
Phone Calls
Answer/Reject
Speakerphone Volume
Functions Lights
Operations
USB Cable
USB Dongle
2
• When someone calls you, press the button to answer the call,
and hold the button for 2 seconds to reject the call.
• When you call someone, hold the button for 2 seconds to
abandon the call.
• when you are on a call, press the button to hang up the call.
• Press the button to adjust the speaker volume by level.
• Hold the button to adjust the speaker volume continuously.
• Press the button to enable/disable the microphone.
Status Light
• When someone calls you/When you call someone: Five
LED indicators flash white continuously.
• When you are on a call: 5 LED indicators are white.
• When you hang up a call: 5 LED indicators flash white for
three times.
Status Light
Five LED indicators indicate 10 levels of volume, whith each
indicator indicates 2 levels of volume by brightness and
darkness.
Status Light
• Microphone is working: 5 LED indicators are white.
• Microphone is not working: 5 LED indicators are red.
/
Functions
USB Dongle: The accessory is included in some models.

3
Hold the button to start
pairing.
Power Light
• Charging: Flash White
• Charging is complete: Solid White
Status Light
• 80% ＜power ≤ 100%：5 LED indicators are solid white.
• 60% ＜power ≤ 80%：4 LED indicators are solid white.
• 40% ＜power ≤ 60%：3 LED indicators are solid white.
• 20% ＜power ≤ 40%：2 LED indicators are solid white.
• 0% ＜power ≤ 20%：1 LED indicator is solid white.
Status Light & Power Light
When the power is less than 15%, 5 LED indicators flash red 3 times
and the power light is solid red.
Status Light & Power Light & Bluetooth Light
• Power On: All lights are solid white.
• Power Off: All lights are off.
Bluetooth Light
• Bluetooth Enabled: Solid White. Previously connected devices can
be reconnected.
The device enters this state automatically after powering on. If no connection is
made within 3 minutes, Bluetooth will be disabled automatically and the Bluetooth
light will be off.
• Bluetooth Disabled: Bluetooth Light Off.
Bluetooth Light
• Pairing: Flash Blue
• Pairing is successfully: Solid Blue
Hold the button to
turn on/off the device.
Press the button to
display current battery
level .
Press the button to
enable/disable Bluetooth
Low batttery alert.
No operations required.
Charging indication.
No button operation required.
Functions Lights Operations
Bluetooth
Enable/Disable
Power
On/Off

4
USB3.0
After a successful cable connection, if you want to switch the connection method, please disconnect the USB cable first.
Connect the device to intelligent terminals, such as computers and conference flat panels.
It is recommended to plug into USB3.0 interface of the terminal. If the device is plugged into a USB hub, and there are multiple devices
on the hub, the power supply may be inadequate. It is recommended to connect the device to the computer directly.
Connection
USB Cable Connection

5
After a successful Bluetooth connection, if you connect a USB cable, the cable will be used for charging only. To switch the connection
method, please disconnect from Bluetooth first.
Bluetooth Connection

6
USB Dongle Connection: Models with a USB dongle support this connection method.
Turn on the microphone speaker and the terminal, and plug in the USB dongle at the terminal, the device will be
automatically connected, and the Bluetooth light will be on.
After a successful Bluetooth connection, if you want to switch the connection method, please disconnect the USB dongle first.
USB Dongle Connection

Please fully charge the device before first use.
7
Charging
Charging Methods
• Use the supplied cable to connect the speakerphone and the USB 3.0 interface of a laptop to charge the device.
• Use a power adapter to charge the speakerphone. It is recommended to use a charging adapter with power above 5 V/1 A.

8
Setup Guide
Speaker
Volume
Microphone
Volume
Default Settings
Default Settings
4-mic Speakerphone
Audio
4-mic Speakerphone
Connect the speakerphone to intelligent terminals and run the conference/video software to use the speakerphone.
If the device cannot work in the conference/video software, check if the microphone and speaker of the software is set
as "4-mic Speakerphone" in the audio settings.
*If you use USB Dongle connection method, check if the microphone and speaker of the software is set as "multi-mic
Speakerphone" in the audio settings.

Warnings
Laws and Regulations
The device should be used in compliance with local laws, electrical safety regulations, and fire prevention regulations.
Electrical Safety
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Battery
CAUTION: Risk of explosion if the battery is replaced by an incorrect type.
Improper replacement of the battery with an incorrect type may defeat a safeguard (for example, in the case of some lithium battery types).
Do not dispose of the battery into fire or a hot oven, or mechanically crush or cut the battery, which may result in an explosion.
Do not leave the battery in an extremely high temperature surrounding environment, which may result in an explosion or the leakage of flammable liquid or
gas.
Do not subject the battery to extremely low air pressure, which may result in an explosion or the leakage of flammable liquid or gas.
Dispose of used batteries according to the instructions.
Cautions
Fire Prevention
No naked flame sources, such as lighted candles, should be placed on the equipment.
Transportation
Keep the device in original or similar packaging while transporting it.
DO NOT drop the product or subject it to physical shock.
Power Supply
EUT will be charged by specified source which the output circuit comply with LPS/PS 2.
Refer to the device label for the standard power supply. Please make sure your power supply matches with your device.
Use a power adapter provided by qualified manufacturers. It is recommended to provide an independent power adapter for each device as adapter
overload may cause over-heating or a fire hazard.
Maintenance
If the product does not work properly, please contact your dealer or the nearest service center. We shall not assume any responsibility for problems caused
by unauthorized repair or maintenance.
Cleaning
Please use a soft and dry cloth to clean the interior and exterior surfaces. Do not use alkaline detergents.
Using Environment
To avoid heat accumulation, good ventilation is required for a proper operating environment.
DO NOT expose the device to extremely hot, cold, dusty, corrosive, saline-alkali, or damp environments. For temperature and humidity requirements, see
device specification.
DO NOT expose the device to high electromagnetic radiation.
Emergency
If smoke, odor, or noise arises from the device, immediately turn off the power, unplug the power cable, and contact the service center.
Safety Instruction

Regulatory Information
These clauses apply only to the products bearing the corresponding mark or information.
FCC Information
Please take attention that changes or modification not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
FCC compliance: Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this product does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with minimum distance 20cm between the radiator & your body.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with the
applicable harmonized European standards listed under Directive 2014/53/EU (RED), the Directive 2014/30/EU (EMCD),
Directive 2014/35/EU (LVD), Directive 2011/65/EU (RoHS).
Directive 2012/19/EU (WEEE Directive): Products marked with this symbol cannot be disposed of as unsorted municipal
waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
Directive 2006/66/EC and its amendment 2013/56/EU (Battery Directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information
see: www.recyclethis.info.

Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence. L'exploitation est
autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
ce matériel est conforme aux limites de dose d'exposition aux rayonnements, CNR-102 énoncée dans un autre
environnement.cette eqipment devrait être installé et exploité avec distance minimale de 20 entre le radiateur et votre corps.
Frequency Bands and Power (for CE/UKCA)
The frequency bands and transmitting power (radiated and/or conducted) nominal limits applicable to the following radio
equipment are as follows:
Equipment ModelEquipment Model
DS-UAC-*W* Bluetooth (2402 - 2480 MHz): 10 dbm
DS-UVC-*W*
Frequency Bands and Power
*W* refers to wireless models.
