HIK VISION DS-2TP31B-3AUF User manual

Handheld Thermography Camera
User Manual
.

© 2020 Hangzhou Hikvision Digital Technology Co., Ltd.
All rights reserved.
About this Manual
The Manual includes instructions for using and
managing the Product. Pictures, charts, images and all
other information hereinafter are for description and
explanation only. The information contained in the
Manual is subject to change, without notice, due to
firmware updates or other reasons. Please find the
latest version of this Manual at the Hikvision website
(https://www.hikvision.com/).
Please use this Manual with the guidance and
assistance of professionals trained in supporting the
Product.
Trademarks Acknowledgement
 and other Hikvision’s
trademarks and logos are the properties of
Hikvision in various jurisdictions.
Other trademarks and logos mentioned are the
properties of their respective owners.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, THIS MANUAL AND THE PRODUCT DESCRIBED,
WITH ITS HARDWARE, SOFTWARE AND FIRMWARE,
ARE PROVIDED “AS IS” AND “WITH ALL FAULTS AND
ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS
FOR A PARTICULAR PURPOSE. THE USE OF THE
PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS
OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF
CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE
USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE
INTERNET PROVIDES FOR INHERENT SECURITY RISKS,
AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES
FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR
OTHER DAMAGES RESULTING FROM CYBER-ATTACK,
HACKER ATTACK, VIRUS INFECTION, OR OTHER
INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL
PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE
WITH ALL APPLICABLE LAWS, AND YOU ARE SOLELY
RESPONSIBLE FOR ENSURING THAT YOUR USE

CONFORMS TO THE APPLICABLE LAW. ESPECIALLY, YOU
ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A
MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF
THIRD PARTIES, INCLUDING WITHOUT LIMITATION,
RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS,
OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY
PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF
MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS,
ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY
NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE,
OR IN SUPPORT OF HUMAN RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS
MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Regulatory Information
FCC Information
Please take attention that changes or modification
not expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
FCC compliance: This equipment has been tested
and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment
and receiver.
—Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV
technician for help
FCC Conditions
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference
received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and, if applicable, the
supplied accessories are marked
with “CE” and comply therefore with
the applicable harmonized European
standards listed under the Radio
Equipment Directive 2014/53/EU,

the EMC Directive 2014/30/EU, the RoHS Directive
2011/65/EU.
2012/19/EU (WEEE directive):
Products marked with this symbol
cannot be disposed of as unsorted
municipal waste in the European
Union. For proper recycling, return
this product to your local supplier
upon the purchase of equivalent
new equipment, or dispose of it at
designated collection points. For
more information see:
www.recyclethis.info.
2006/66/EC (battery directive): This
product contains a battery that
cannot be disposed of as unsorted
municipal waste in the European
Union. See the product
documentation for specific battery information. The
battery is marked with this symbol, which may include
lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery
to your supplier or to a designated collection point. For
more information see: www.recyclethis.info.
Industry Canada ICES-003
Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B)
standards requirements.
이 기기는 업무용 환경에서 사용할 목적으로
적합성평가를 받은 기기로서 가정용 환경에서
사용하는 경우 전파간섭의 우려가 있습니다.
Safety Instruction
These instructions are intended to ensure that user
can use the product correctly to avoid danger or
property loss.
Laws and Regulations
●Use of the product must be in strict compliance
with the local electrical safety regulations.
Transportation
●Keep the device in original or similar packaging
while transporting it.
●Keep all wrappers after unpacking them for future
use. In case of any failure occurred, you need to
return the device to the factory with the original
wrapper. Transportation without the original
wrapper may result in damage on the device and
the company shall not take any responsibilities.
●Do not drop the product or subject it to physical
shock. Keep the device away from magnetic
interference.
Power Supply
●Please purchase the charger by yourself. Input
voltage should meet the Limited Power Source (5
VDC, 0.3 A) according to the IEC61010-1 standard.
Please refer to technical specifications for detailed
information.
●Make sure the plug is properly connected to the
power socket.
●DO NOT connect multiple devices to one power
adapter, to avoid over-heating or fire hazards
caused by overload.
Battery
●The built-in battery cannot be dismantled. Please
contact the manufacture for repair if necessary.
●For long-term storage of the battery, make sure it is
fully charged every half year to ensure the battery

quality. Otherwise, damage may occur.
Maintenance
●If the product does not work properly, please
contact your dealer or the nearest service center.
We shall not assume any responsibility for
problems caused by unauthorized repair or
maintenance.
●Wipe the device gently with a clean cloth and a
small quantity of ethanol, if necessary.
●If the equipment is used in a manner not specified
by the manufacturer, the protection provided by
the device may be impaired.
Using Environment
●Make sure the running environment meets the
requirement of the device. The operating
temperature shall be 10 °C to 35 °C (50 °F to 95 °F),
and the operating humidity shall be 90% or less.
●DO NOT expose the device to high electromagnetic
radiation or dusty environments.
●DO NOT aim the lens at the sun or any other bright
light.
Emergency
If smoke, odor, or noise arises from the device,
immediately turn off the power, unplug the power
cable, and contact the service center.
Laser Light Supplement Warning
Warning: The laser
radiation emitted from the
device can cause eye
injuries, burning of skin or
inflammable substances. Before enabling the Light
Supplement function, make sure no human or
inflammable substances are in front of the laser lens.
Manufacture address:
No.555 Qianmo Road, Binjiang District, Hangzhou
310052, China
Hangzhou Hikvision Digital Technology Co.,Ltd
COMPLIANCE NOTICE: The thermal series products
might be subject to export controls in various
countries or regions, including without limitation,
the United States, European Union, United
Kingdom and/or other member countries of the
Wassenaar Arrangement. Please consult your
professional legal or compliance expert or local
government authorities for any necessary export
license requirements if you intend to transfer,
export, re-export the thermal series products
between different countries.
SAVE THIS MANUAL FOR FUTURE
REFERENCE
0504062001221

1Introduction
1.1 Box Content
Handheld Thermography Camera (×1)
Power Adapter (×1)
USB Cable (×1)
Wrist Strap (x1)
Manual (x1)
Note: The Handheld Thermography Camera
includes one battery and one micro SD card.
1.2 Product Introduction
The handheld Thermography camera is a camera
with thermal images. It can do thermometry,
and snapshot capturing. The built-in
high-sensitivity IR detector and
high-performance sensor detects the
temperature change and measure the real-time
temperature. The temperature measurement
range is 30 °C to 45 °C (86 °F to 113 °F) with
thermometry accuracy ±0.5 °C.
It helps the users to find the risky part and lower
their property loss. The device supports live
viewing, and capturing, etc.
The handheld Thermography camera, adopting
ergonomic design, is easy to use.
The device is not for medical use.

2Appearance
2.1 Dimensions
59mm(2.32")
196mm(7.72")
78mm(3.07")
The dimension may vary according to different
camera model.
2.2 Interfaces
Screen
Charging
Indicator Back
Navigation
On/OK/Menu
Hold: Power On/Off
Press: Display menu or confirm
operation
Exit the menu or return to
previous menu.
Navigation Button
Press the ▽, △button to select
parameters.
Press the button to
confirm.

IR Lens
Cover
Trigger
USB Interface
Micro SD Slot
Tripod
Interface
Charging
Indicator
When the device is charging,
the LED indicator is red.
When the device is fully
charged, the LED indicator is
green.
USB
Interface
Charge the battery and
export snapshots with the
USB cable.
Trigger
Pull the trigger to capture
snapshots.
2.3 Install Memory Card
Insert memory card to record videos, capture
snapshots, and mark and save important data.
Steps:
1. Open the top cover of the device.
2. Insert memory card slowly into the
micro SD slot. When you hear the click
sound, the memory card is installed.
3. Close the cover after installation.
3Basic Operations
3.1 Charging the Device
Steps:
1. Open the top cover of the device.
2. Connect the USB interface and the
power adaptor with USB cable.
USB interface

3.2 Interface Description
Color-
Temperature
Scale
Min. Temperature
Display Emissivity
Real-time
Temperature
Center Temperature
Display
Unit Status Icons
Max. Temperature Display
Real-time Center
Temperature
3.3 Format Micro SD Card
Before you start:
Confirm the Micro SD card is properly installed
before use.
Steps:
1. In the live view interface, press
button to show the menu bar.
2. Press / button to select
Format Micro SD.
3. Press button and select OK to
start format Micro SD Card.
Note:
Format Micro SD Card before first use of it.
3.4 Capture Snapshots
Steps:
1. In the live view interface, pull the trigger
to capture snapshot. The live view
freezes and device displays the snapshot
with temperature information.
2. Press button to save the picture,
press button to cancel it.
Note:
You cannot capture when the device is
connected with PC.
3.5 View Snapshots
Steps:
1. Go to Menu > Picture to view the
capture snapshots.
2. Press button to view the selected
picture, press / button to
switch pictures.
3. (Optional) Press button to delete
picture in picture view interface.

3.6 Export File
Purpose:
Connect the handheld Thermography camera
to your PC with USB cable, you can export the
captured snapshots.
Steps:
1. Open the USB cover.
2. Connect the camera to your PC with
USB cable and open the detected disk.
3. Select and copy the snapshots to PC and
view the files.
4. Disconnect the device from your PC.
Note:
For the first time connection, the driver will be
installed automatically.
Do not disconnect the USB connection from
PC or pull out the Micro SD card during drive
installation or it may cause the device damage.
3.7 Upgrade
Steps:
1. Connect the thermography camera to
your PC with USB cable and open the
detected disk.
2. Copy the upgrade file and replace it to
the root directory of the device.
3. Disconnect the device from your PC.
4. Reboot the device and then it will
upgrade automatically. The upgrading
process will be displayed in the main
interface.
Note: After the upgrading, the device
automatically reboots. You can view the current
version in Menu > About.
4Main Configurations
4.1 Temperature
Measurement
Purpose:
The thermometry (temperature measurement)
function provides the real-time temperature of
the scene and display it on the left of your
screen. The thermometry function is turned on
by default.
The thermometry parameters affect the
accuracy of temperature measurement.
Steps:
1In the live view interface, press
button show the menu bar.
2Press / button to select
desired setting bar.
3Press button to go to the setting
interface.

Emissivity: Set the emissivity of your
target as the effectiveness in emitting
energy as thermal radiation.
Note: Refer to the 6.1 Common
Material Emissivity Reference for
emissivity values.
Distance (m/feet): Set the straight-line
distance between the target and the
device.
Note: The recommended
thermometry distance is 0.2 m to 2
m with target size 80 × 80 mm.
Rule: Select Center Spot and Cold Spot
to show the center temperature and
min. temperature in the live view
interface.
4Press / button to select
desired parameter, and press
button to enable it.
5If necessary, press / button
to increases / decrease the setting
values. Hold / button to
change the value quickly.
6Press button to save and exit.
4.2 Set Palette
Different palette modes display different
temperature colors. You can analyze image by
different palette colors.
Steps:
1In the live view interface, press
button show the menu bar.
2Press / button to select
Palette.
3Press button to select palette
mode and the live view interface
displays the according palette color.
4Press button to save and exit.
4.3 Set Temperature Alarm
After enabling this function, when the device
detects temperature that is higher than the
set alarm threshold, Max. Temperature on the
live view interface will flash.
Steps:
1In the live view interface, press
button show the menu bar.
2Press / button to select
Temperature Alarm.
3Press , and press /
button to increase or decrease alarm
temperature threshold.
4Press button to exit.

Note: If the palette is set as Above Alarm,
when the detected temperature is higher than
the set alarm temperature, the target is
colored in the live view interface.
Note: Other parameters, such as temperature
measurement range, unit, palettes and so on,
can be configured as steps above.
5System Information
Go to Menu > About to view the device
information: Model, Version No., FPGA Version
No., Serial No., Capacity and so on.
You can also set the auto power-off duration,
date and time in Menu.
6Appendix
6.1 Common Material
Emissivity Reference
Material
Emissivity
Human Skin
0.98
PCB
0.91
Cement Concrete
0.95
Ceramics
0.92
Rubber
0.95
Paint
0.93
Wood
0.85
Asphalt
0.96
Brick
0.95
Sand
0.90
Soil
0.92
Cotton
0.98
Cardboard
0.90
White Paper
0.90
Water
0.96
6.2 Frequently Asked
Questions (FAQ)
Q: The charge indicator flashes red.
A:Examine the items below.

1. Examine whether the device is charged with
the standard power adapter.
2. Plug and unplug the battery once.
3. Make sure the environment temperature is
above 0°C (32°F).
Q:Capturing or recording fails.
A:Examine the items below:
1. Whether the device is connected to your PC
and the capture function is unavailable.
2. Whether the storage space is full.
3. Whether the device is low-battery.
Q:The PC cannot identify the camera.
A:Examine whether the device is connected to
your PC with standard USB cable.
Q:The camera cannot be operated or no
responding.
A:Hold button to reboot the camera.
UD18507B-A
