HIKOKI WH 18DDX User manual

WH 18DDX
Handling instructions
0000BookWH18DDX.indb10000BookWH18DDX.indb1 2020/05/2712:52:502020/05/2712:52:50

2
1
2 3
4 5
3200 min-1
0
0000BookWH18DDX.indb20000BookWH18DDX.indb2 2020/05/2712:52:502020/05/2712:52:50

3
67
8
0000BookWH18DDX.indb30000BookWH18DDX.indb3 2020/05/2712:52:502020/05/2712:52:50

4
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool.
Carrying power tools with your finger on the switch
or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part of
the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts.
Loose clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
h) Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles.
A careless action can cause severe injury within a
fraction of a second.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and safer
at the rate for which it was designed.
b) Do not use the power tool if the switch does not
turn it on and off.
Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power toolʼs operation. If
damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions,
taking into account the working conditions and
the work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.
GENERAL POWER TOOL SAFETY
WARNINGS
WARNING
Read all safety warnings, instructions, illustrations and
specifications provided with this power tool.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the dust
or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
Unmodified plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if your
body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the
risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always
wear eye protection.
Protective equipment such as a dust mask, non-skid
safety shoes, hard hat or hearing protection used for
appropriate conditions will reduce personal injuries.
0000BookWH18DDX.indb40000BookWH18DDX.indb4 2020/05/2712:52:512020/05/2712:52:51

5
h) Keep handles and grasping surfaces dry, clean
and free from oil and grease.
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer.
A charger that is suitable for one type of battery pack
may create a risk of fire when used with another
battery pack.
b) Use power tools only with specifically
designated battery packs.
Use of any other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another.
Shorting the battery terminals together may cause
burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
e) Do not use a battery pack or tool that is damaged
or modified.
Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion
or risk of injury.
f) Do not expose a battery pack or tool to fire or
excessive temperature.
Exposure to fire or temperature above 130°C may
cause explosion.
g) Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement
parts.
This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs.
Service of battery packs should only be performed
by the manufacturer or authorized service providers.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
CORDLESS IMPACT DRIVER SAFETY
WARNINGS
Hold the power tool by insulated gripping surfaces,
when performing an operation where the fastener may
contact hidden wiring. Fasteners contacting a “live” wire
may make exposed metal parts of the power tool “live” and
could give the operator an electric shock.
ADDITIONAL SAFETY WARNINGS
1. This is a portable tool for tightening and loosening
screws, bolts and nuts. Use it only for these operation.
2. Make sure to securely hold the tool during operation.
Failure to do so can result in accidents or injuries.
(Fig. 8)
3. Make sure that the battery is installed firmly. If it is as all
loose it could come offand cause an accident.
4. Preparing and checking the work environment. Make
sure that the work site meets all the conditions laid forth
in the precautions.
5. Do not allow foreign matter to enter the hole for
connecting the rechargeable battery.
6. Never disassemble the rechargeable battery and
charger.
7. Never short-circuit the rechargeable battery. Short-
circuiting the battery will cause a great electric current
and overheat. It results in burn or damage to the battery.
8. Do not dispose of the battery in fire. If the battery is burnt,
it may explode.
9. Bring the battery to the shop from which it was purchased
as soon as the post-charging battery life becomes too
short for practical use. Do not dispose of the exhausted
battery.
10. Do not insert object into the air ventilation slots of the
charger. Inserting metal objects or inflammables into the
charger air ventilation slots will result in electrical shock
hazard or damaged charger.
11. Check the actual tightening torque with a toruqe wrench.
12. Stop the tool before switching the direction of rotation.
Always release the switch and wait for tool to stop before
switching the direction of rotation.
13. Never touch the turning part. Do not allow the turning
part section to get near your hands or any other part of
your body. You could be cut or caught in the turning part.
Also, be careful not to touch the turning part after using
continuously it for a long time. It gets quite hot and could
burn you.
14. Please use the designated attachments which are
listed in the operations manual and HiKOKI’s catalog.
Accidents or injuries could result from not doing so.
15. Make sure to firmly install the attachments in the anvil. If
the attachments is not firmly installed it might come out
and cause injuries.
After installing the driver bit, pull lightly out the bit to
make sure that it does not come loose during use. If the
guide sleeve does not return to its original position, then
the bit is not installed properly.
16. Resting the unit after continuous work.
17. The power tool is equipped with a temperature
protection circuit to protect the motor. Continuous work
may cause the temperature of the unit to rise, activating
the temperature protection circuit and automatically
stopping operation. If this happens, allow the power tool
to cool before resuming use.
18. The motor may stop in the event the tool is overloaded. In
this should occur, release the tool’s switch and eliminate
the cause of the overload.
Avoid touching the front case which can heat up during
continuous operation.
19. The use of the battery in a cold condition (below 0 degree
Centigrade) can sometimes result in the weakened
tightening torque and reduced amount of work. This,
however, is a temporary phenomenon, and returns to
normal when the battery warms up.
20. Install securely the hook. Unless the hook is securely
installed, it may cause an injury while using.
When electing to carry the tool hooked to your hip belt,
make sure to detach the tool bit and side handle. Failure
to do so may result in unexpected injury.
21. Do not touch the metal parts, as it gets very hot during
continuous work.
0000BookWH18DDX.indb50000BookWH18DDX.indb5 2020/05/2712:52:512020/05/2712:52:51

6
22. Do not look directly into the light. Such actions could
result in eye injury.
Wipe offany dirt or grime attached to the lens of the LED
light with a soft cloth, being careful not to scratch the
lens.
Scratches on the lens of the LED light can result in
decreased brightness.
23. Always use the tool and battery at temperatures between
-5oC and 40oC.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips with the
protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor may stop.
This is not the trouble but the result of protection function.
1. When the battery power remaining runs out, the motor
stops.
In such a case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes of
overloading. After that, you can use it again.
3. If the battery is overheated under overload work, the
battery power may stop.
In this case, stop using the battery and let the battery
cool. After that, you can use it again.
Furthermore, please heed the following warning and caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand, please
be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
○During work make sure that swarf and dust do not fall on
the battery.
○Make sure that any swarf and dust falling on the power
tool during work do not collect on the battery.
○Do not store an unused battery in a location exposed to
swarf and dust.
○Before storing a battery, remove any swarf and dust that
may adhere to it and do not store it together with metal
parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject the
battery to severe physical shock.
3. Do not use an apparently damaged or deformed battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or car
cigarette lighter sockets.
6. Do not use the battery for a purpose other than those
specified.
7. If the battery charging fails to complete even when a
specified recharging time has elapsed, immediately stop
further recharging.
8. Do not put or subject the battery to high temperatures or
high pressure such as into a microwave oven, dryer, or
high pressure container.
9. Keep away from fire immediately when leakage or foul
odor are detected.
10. Do not use in a location where strong static electricity
generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears abnormal
during use, recharging or storage, immediately remove it
from the equipment or battery charger, and stop use.
12. Do not immerse the battery or allow any fluids to flow
inside. Conductive liquid ingress, such as water, can
cause damage resulting in fire or explosion. Store your
battery in a cool, dry place, away from combustible and
flammable items. Corrosive gas atmospheres must be
avoided.
CAUTION
1. If liquid leaking from the battery gets into your eyes,
do not rub your eyes and wash them well with fresh
clean water such as tap water and contact a doctor
immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well with
clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using the
battery for the first time, do not use and return it to your
supplier or vendor.
WARNING
If a conductive foreign matter enters in the terminal of lithium
ion battery, the battery may be shorted, causing fire. When
storing the lithium ion battery, obey surely the rules of
following contents.
○Do not place conductive debris, nail and wires such as
iron wire and copper wire in the storage case.
○To prevent shorting from occurring, load the battery in
the tool or insert securely the battery cover for storing
until the ventilator is not seen.
REGARDING LITHIUM-ION BATTERY
TRANSPORTATION
When transporting a lithium-ion battery, please observe the
following precautions.
WARNING
Notify the transporting company that a package contains a
lithium-ion battery, inform the company of its power output
and follow the instructions of the transportation company
when arranging transport.
○Lithium-ion batteries that exceed a power output of
100 Wh are considered to be in the freight classification
of Dangerous Goods and will require special application
procedures.
○For transportation abroad, you must comply with
international law and the rules and regulations of the
destination country.
Wh
Power Output
2 to 3 digit number
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
WH18DDX: Cordless Impact Driver
To reduce the risk of injury, user must read
instruction manual.
0000BookWH18DDX.indb60000BookWH18DDX.indb6 2020/05/2712:52:512020/05/2712:52:51

7
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2012/19/EU
on waste electrical and electronic equipment
and its implementation in accordance with
national law, electric tools that have reached
the end of their life must be collected separately
and returned to an environmentally compatible
recycling facility.
Direct current
V Rated voltage
n0No-load speed
min-1 Oscillation per minute
Bpm Impact rate
SSmall screw
Ordinary bolt
HHigh tension bolt
MT Tightening torque (Maximum)
Hex. drive size
kg Weight*
(According to EPTA-Procedure 01/2014)
Switching ON
Switching OFF
Disconnect the battery
Clockwise rotation
Counterclockwise rotation
Warning
* Depending on attached battery. The heaviest weight is
measured with BSL36B18 (sold separately).
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed on page 11.
Standard accessories are subject to change without notice.
APPLICATIONS
Driving and removing of machine screws, wood screws,
tapping screws, etc.
SPECIFICATIONS
The specifications of this machine are listed in the Table on
page 11.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger’s power cord to the receptacle.
When connecting the plug of the charger to a receptacle,
the pilot lamp will blink in red (At 1- second intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the charger as shown in
Fig. 2 (on page 2).
3. Charging
When inserting a battery in the charger, charging will
commence and the pilot lamp will light continuously in
red.
When the battery becomes fully recharged, the pilot lamp
will blink in red. (At 1-second intervals) (See Table 1)
●Pilot lamp indication
The indications of the pilot lamp will be as shown in
Table 1, according to the condition of the charger or the
rechargeable battery.
Table 1
Indications of the pilot lamp
Pilot lamp
(red)
Before charging Blinks Lights for 0.5 seconds. Does not light for 0.5 seconds. (offfor 0.5 seconds)
While charging Lights Lights continuously
Charging
complete Blinks Lights for 0.5 seconds. Does not light for
0.5 seconds. (offfor 0.5 seconds)
Overheat
standby Blinks Lights for 1 second. Does not light for
0.5 seconds. (offfor 0.5 seconds) Battery overheated. Unable
to charge. (Charging will
commence when battery cools)
Charging
impossible Flickers Lights for 0.1 seconds. Does not light for
0.1 seconds. (offfor 0.1 seconds) Malfunction in the battery or
the charger
0000BookWH18DDX.indb70000BookWH18DDX.indb7 2020/05/2712:52:512020/05/2712:52:51

8
●Regarding the temperatures and charging time of the
battery.
The temperatures and charging time will become as
shown in Table 2.
Table 2
Charger
Battery UC18YFSL
Charging voltage V 14.4 – 18
Weight kg 0.5
Temperatures at which the
battery can be recharged 0oC – 50oC
Charging time for battery
capacity, approx. (At 20oC)
1.5 Ah
2.0 Ah
2.5 Ah
3.0 Ah
4.0 Ah
5.0 Ah
6.0 Ah
8.0 Ah
min.
min.
min.
min.
min.
min.
min.
min.
22
30
35
45
60
75
90
120
Number of battery cells 4 – 10
NOTE
The recharging time may vary according to temperature
and power source voltage.
CAUTION
When the battery charger has been continuously used,
the battery charger will be heated, thus constituting
the cause of the failures. Once the charging has been
completed, give 15 minutes rest until the next charging.
4. Disconnect the charger’s power cord from the
receptacle.
5. Hold the charger firmly and pull out the battery.
NOTE
Be sure to pull out the battery from the charger after use,
and then keep it.
CAUTION
○If the battery is charged while it is heated because it has
been left for a long time in a location subject to direct
sunlight or because the battery has just been used, the
pilot lamp of the charger lights for 1 second, does not
light for 0.5 seconds (offfor 0.5 seconds). In such a case,
first let the battery cool, then start charging.
○When the pilot lamp flickers (at 0.2-second intervals),
check for and take out any foreign objects in the charger’s
battery connector. If there are no foreign objects, it is
probable that the battery or charger is malfunctioning.
Take it to your authorized Service Center.
○Since the built-in micro computer takes about 3 seconds
to confirm that the battery being charged with charger
is taken out, wait for a minimum of 3 seconds before
reinserting it to continue charging. If the battery is
reinserted within 3 seconds, the battery may not be
properly charged.
MOUNTING AND OPERATION
Action Figure Page
Removing and inserting the battery 1 2
Charging 2 2
Mounting the bit 3 2
Reversing the rotational direction 4 2
Switch operation 5 2
How to use the LED light 6 3
Mounting and removing the hook
(sold separately) 73
Selecting accessories ―12
LED LIGHT WARNING SIGNALS
This product features functions that are designed to protect
the tool itself as well as the battery. While the switch is
pulled, if any of the safeguard functions are triggered
during operation, the LED light will blink as described in
Table 3. When any of the safeguard functions are triggered,
immediately remove your finger from the switch and follow
the instructions described under corrective action.
Table 3
Safeguard Function LED Light Display Corrective Action
Overburden Protection On 0.1 second/off0.5 second Remove the cause of the overburdening.
Temperature Protection On 0.3 second/off0.3 second Allow the tool and battery to thoroughly cool.
0000BookWH18DDX.indb80000BookWH18DDX.indb8 2020/05/2712:52:522020/05/2712:52:52

9
MAINTENANCE AND INSPECTION
1. Inspecting the driver bit
Using a broken bit or one with a worn out tip is dangerous
because the bit can slip. Replace it.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool. Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
4. Cleaning on the outside
When the power tool is stained, wipe with a soft dry cloth
or a cloth moistened with soapy water. Do not use chloric
solvents, gasoline or paint thinner, for they melt plastics.
5. Storage
Store the power tool in a place in which the temperature
is less than 40°C and out of reach of children.
NOTE
Storing lithium-ion batteries.
Make sure the lithium-ion batteries have been fully
charged before storing them.
Prolonged storage (3 months or more) of batteries with
a low charge may result in performance deterioration,
significantly reducing battery usage time or rendering
the batteries incapable of holding a charge.
However, significantly reduced battery usage time may
be recovered by repeatedly charging and using the
batteries two to five times.
If the battery usage time is extremely short despite
repeated charging and use, consider the batteries dead
and purchase new batteries.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
Important notice on the batteries for the HiKOKI
cordless power tools
Please always use one of our designated genuine
batteries. We cannot guarantee the safety and
performance of our cordless power tool when used with
batteries other than these designated by us, or when
the battery is disassembled and modified (such as
disassembly and replacement of cells or other internal
parts).
GUARANTEE
We guarantee HiKOKI Power Tools in accordance with statutory/
country specific regulation. This guarantee does not cover defects
or damage due to misuse, abuse, or normal wear and tear. In case
of complaint, please send the Power Tool, undismantled, with the
GUARANTEE CERTIFICATE found at the end of this Handling
instruction, to a HiKOKI Authorized Service Center.
Information concerning airborne noise and vibration
The measured values were determined according to
EN62841 and declared in accordance with ISO 4871.
Measured A-weighted sound power level: 100 dB (A)
Measured A-weighted sound pressure level: 89 dB (A)
Uncertainty K: 3 dB (A).
Wear hearing protection.
Vibration total values (triax vector sum) determined
according to EN62841.
Impact tightening of fasteners of the maximum capacity of
the tool:
Vibration emission value ah= 13.0 m/s2
Uncertainty K = 1.5 m/s2
The declared vibration total value has been measured in
accordance with a standard test method and may be used
for comparing one tool with another.
It may also be used in a preliminary assessment of exposure.
WARNING
○The vibration emission during actual use of the power
tool can differ from the declared total value depending in
the ways in which the tool is used.
○
Identify safety measures to protect the operator that are
based on an estimation of exposure in the actual conditions
of use (taking account of all parts of the operating cycle
such as the times when the tool is switched offand when it
is running idle in addition to the trigger time).
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
0000BookWH18DDX.indb90000BookWH18DDX.indb9 2020/05/2712:52:522020/05/2712:52:52

10
TROUBLESHOOTING
Use the inspections in the table below if the tool does not operate normally. If this does not remedy the problem, consult your
dealer or the HiKOKI Authorized Service Center.
Symptom Possible cause Remedy
Tool doesn’t run No remaining battery power Charge the battery.
The trigger switch was held down while the
battery was inserted. The safety function was activated.
If the trigger switch is released once and
then pulled again, the tool will run.
Tool suddenly stopped Tool was overburdened Get rid of the problem causing the
overburden.
The battery is overheated. Let the battery cool down.
The trigger switch was held down for
5 minutes or more. This is not a malfunction.
The motor was automatically stopped to
prevent failure of the tool.
Tool bits
-can’t be attached
-fall off
The shape of the attachment portion
doesn’t match Use a bit with a hexagonal shaft that has a
width across flats of 6.35 mm.
If you are using an L-type tool bit, replace it
with an S-type bit.
Switch can’t be pulled Forward/reverse selector button is
positioned halfway Press the button firmly into position for the
desired direction of rotation.
An abnormal high-pitched
noise occurs when the
trigger switch is pulled.
The trigger switch is being pulled only
slightly. This is not a malfunction.
It does not occur if the trigger switch is
pulled more fully.
Screw head slips or comes
loose. Bit number doesn’t match with the screw size Install a suitable bit.
The bit is worn Replace with a new bit.
The pilot lamp is rapidly
flickers red, and battery
charging doesn’t begin.
The battery is not inserted all the way. Insert the battery firmly.
There is foreign matter in the battery
terminal or where the battery is attached. Remove the foreign matter.
The pilot lamp blinks red,
and battery charging doesn’t
begin.
The battery is not inserted all the way. Insert the battery firmly.
The battery is overheated. If left alone, the battery will automatically
begin charging if its temperature decreases,
but this may reduce battery life. It is
recommended that the battery be cooled in
a well-ventilated location away from direct
sunlight before charging it.
Battery usage time is short
even though the battery is
fully charged.
The battery’s life is depleted. Replace the battery with a new one.
The battery takes a long
time to charge. The temperature of the battery, the charger, or the surrounding environment is
extremely low.
Charge the battery indoors or in another
warmer environment.
The charger’s vents are blocked, causing
its internal components to overheat. Avoid blocking the vents.
The cooling fan is not running. Contact a HiKOKI Authorized Service
Center for repairs.
0000BookWH18DDX.indb100000BookWH18DDX.indb10 2020/05/2712:52:522020/05/2712:52:52

11
WH18DDX 1 2 1 1
WH18DDX
(NN) ――――
WH18DDX
VV18
n0min-1 0 –3200
Smm 4 –8
mm M5 –M14
Hmm M5 –M12
MT N∙m 140
mm 6.35 (1/4˝)
kg kg 1.2 –1.8
0000BookWH18DDX.indb110000BookWH18DDX.indb11 2020/05/2712:52:532020/05/2712:52:53

12
329897
336642
376358
UC-18YFSL
(14.4 V –18 V)
18 V (Li-ion)
0000BookWH18DDX.indb120000BookWH18DDX.indb12 2020/05/2712:52:532020/05/2712:52:53

13
English Dansk Română
GUARANTEE CERTIFICATE
Model No.
Serial No.
Date of Purchase
Customer Name and Address
Dealer Name and Address
(Please stamp dealer name and address)
GARANTIBEVIS
Modelnummer
Serienummer
Købsdato
Kundes navn og adresse
Forhandlers navn og adresse
(Indsæt stempel med forhandlers navn og
adresse)
CERTIFICAT DE GARANŢIE
Model nr.
Nr. de serie
Data cumpărării
Numele și adresa clientului
Numele și adresa distribuitorului
(Vărugăm aplicaţi ștampila cu numele și adresa
distribuitorului)
Deutsch Norsk Slovenščina
GARANTIESCHEIN
Modell-Nr.
Serien-Nr.
Kaufdaturn
Name und Anschrift des Kunden
Name und Anschrift des Händlers
(Bitte mit Namen und Anschrift des Handlers
abstempeln)
GARANTISERTIFIKAT
Modellnr.
Serienr.
Kjøpsdato
Kundens navn og adresse
Forhandlerens navn og adresse
(Vennligst stemple forhandlerens navn og adresse)
GARANCIJSKO POTRDILO
Št. modela
Serijska št.
Datum nakupa
Ime in naslov kupca
Ime in naslov prodajalca
(Prosimo vtisnite žig z imenom in naslovom
prodajalca)
Français Suomi Slovenčina
CERTIFICAT DE GARANTIE
No. de modèle
No de série
Date dʼachat
Nom et adresse du client
Nom et adresse du revendeur
(Cachet portant le nom et lʼadresse du revendeur)
TAKUUTODISTUS
Malli nro
Sarja nro
Ostopäivämäärä
Asiakkaan nimi ja osoite
Myyjän nimi ja osoite
(Leimaa myyjän nimi ja osoite)
ZÁRUČNÝ LISTA
Č. modelu
Sériové č.
Dátum zakúpenia
Meno a adresa zákazníka
Názov a adresa predajcu
(Pečiatka s názvom a adresou predajcu)
Italiano Ελληνικά Български
CERTIFICATO DI GARANZIA
Modello
N° di serie
Data di acquisto
Nome e indirizzo dellʼacquirente
Nome e indirizzo del rivenditore
(Si prega di apporre il timbro con questi dati)
ΠΙΣΤΟΠΟΙΗΤΙΚΟ ΕΓΓΥΗΣΗΣ
Αρ. Μοντέλου
Αύξων Αρ.
Ημερομηνία αγοράς
Όνομα και διεύθυνση πελάτη
Όνομα και διεύθυνση μεταπωλητή
(Παρακαλούμε να χρησιμοποιηθεί σφραγίδα)
ГАРАНЦИОНЕН СЕРТИФИКАТ
Модел №
Сериен №
Дата за закупуване
Име иадрес на клиента
Име иадрес на търговеца
(Моля, отпечатайте името иадрес на дилъра)
Nederlands Polski Srpski
GARANTIEBEWIJS
Modelnummer
Serienummer
Datum van aankoop
Naam en adres van de gebruiker
Naam en adres van de handelaar
(Stempel a.u.b. naam en adres vande de
handelaar)
GWARANCJA
Model
Numer seryjny
Data zakupu
Nazwa klienta i adres
Nazwa dealera i adres
(Pieczęć punktu sprzedaży)
GARANTNI SERTIFIKAT
Br. modela.
Serijski br.
Datum kupovine
Ime i adresa kupca
Ime i adresa prodavca
(Molimo da stavite pečat na ime i adresu trgovca)
Español Magyar Hrvatski
CERTIFICADO DE GARANTÍA
Número de modelo
Número de serie
Fecha de adquisición
Nombre y dirección del cliente
Nombre y dirección del distribudor
(Se ruega poner el sello del distribudor con su
nombre y dirección)
GARANCIA BIZONYLAT
Típusszám
Sorozatszám
A vásárlás dátuma
A Vásárló neve és címe
A Kereskedőneve és címe
(Kérjük ide elhelyezni a Kereskedőnevének és
címének pecsétjét)
JAMSTVENI CERTIFIKAT
Br modela.
Serijski br.
Datum kupnje
Ime i adresa kupca
Ime i adresa trgovca
(Molimo stavite pečat na ime i adresu trgovca)
Português Čeština
CERTIFICADO DE GARANTIA
Número do modelo
Número do série
Data de compra
Nome e morada do cliente
Nome e morada do distribuidor
(Por favor, carímbe o nome e morada do
distribuidor)
ZÁRUČNÍ LIST
Model č.
Série č.
Datum nákupu
Jméno a adresa zákazníka
Jméno a adresa prodejce
(Prosíme o razítko se jménem a adresou prodejce)
Svenska Türkçe
GARANTICERTIFIKAT
Modellnr
Serienr
Inköpsdatum
Kundens namn och adress
Försäljarens namn och adress
(Stämpla försäljarens namn och adress)
GARANTİSERTİFİKASI
Model No.
Seri No.
Satın Alma Tarihi
Müşteri Adıve Adresi
Bayi Adıve Adresi
(Lütfen bayi adınıve adresini kaşe olarak basın)
0000BookWH18DDX.indb130000BookWH18DDX.indb13 2020/05/2712:52:532020/05/2712:52:53

14
0000BookWH18DDX.indb140000BookWH18DDX.indb14 2020/05/2712:52:552020/05/2712:52:55

15
Hikoki PowerTools Deutschland GmbH
Siemensring 34, 47877 willich, Germany
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.de
Hikoki Power Tools Netherlands B.V.
Brabanthaven 11, 3433 PJ Nieuwegein, The Netherlands
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.nl
Hikoki Power Tools (U.K.) Ltd.
Precedent Drive, Rooksley, Milton Keynes, MK 13, 8PJ,
United Kingdom
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.uk
Hikoki Power Tools France S.A.S.
Parc de l’Eglantier 22, rue des Cerisiers, Lisses-C.E. 1541,
91015 EVRY CEDEX, France
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.fr
Hikoki Power Tools Belgium N.V./S.A.
Koningin Astridlaan 51, B-1780 Wemmel, Belgium
Tel: [phone]
Fax: [phone]
URL http://www.hikoki-powertools.be
Hikoki Power Tools Italia S.p.A
Via Piave 35, 36077, Altavilla Vicentina (VI), Italy
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.it
Hikoki Power Tools lbérica, S.A.
C/ Puigbarral, 26-28, Pol. Ind. Can Petit, 08227 Terrassa
(Barcelona), Spain
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.es
Hikoki Power Tools Österreich GmbH
IndustrieZentrum NÖ –Süd, Straße 7, Obj. 58/A6 2355
Wiener Neudorf, Austria
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.at
Hikoki Power Tools Norway AS
Kjeller Vest 7, N-2007 Kjeller, Norway
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.no
Hikoki Power Tools Sweden AB
Rotebergsvagen 2B SE-192 78 Sollentuna, Sweden
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.se
Hikoki Power Tools Denmark A/S
Lillebaeltsvej 90, 6715 Esbjerg N, Denmark
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.dk
Hikoki Power Tools Finland Oy
Tupalankatu 9, 15680 Lahti, Finland
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.fi
Hikoki Power Tools Hungary Kft.
1106 Bogáncsvirág u.5-7, Budapest, Hungary
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.hu
Hikoki Power Tools Polska Sp. z o. o.
ul. Gierdziejewskiego 1
02-495 Warszawa, Poland
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-narzedzia.pl
Hikoki Power Tools Czech s.r.o.
Modřická 205, 664 48 Moravany, Czech Republic
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.cz
Hikoki Power Tools Romania S.R.L.
Ring Road, No. 66, Mustang Traco Warehouses, Warehouse
No.1, Pantelimon City, 077145, Ilfov County, Romania
Tel: [phone]
Fax: [phone]
URL: http://www.hikoki-powertools.ro
0000BookWH18DDX.indb150000BookWH18DDX.indb15 2020/05/2712:52:552020/05/2712:52:55

EC DECLARATION OF CONFORMITY
We declare under our sole responsibility that Cordless Impact Driver, identified by type and specific identification
code *1), is in conformity with all relevant requirements of the directives *2) and standards *3). Technical file at *4) –See
below.
The European Standard Manager at the representative office in Europe is authorized to compile the technical file.
The declaration is applicable to the product affixed CE marking.
*1) WH18DDX C359892R
*2) 2006/42/EC, 2014/30/EU, 2014/35/EU, 2011/65/EU
*3) EN62841-1:2015
EN62841-2-2:2014
EN60335-1:2012+A11:2014
EN60335-2-29:2004+A2:2010
EN55014-1:2006+A1:2009+A2:2011
EN55014-2:1997+A1:2001+A2:2008
*4) Representative office in Europe
Hikoki Power Tools Deutschland GmbH
Siemensring 34, 47877 Willich, Germany
Head office in Japan
Koki Holdings Co., Ltd.
Shinagawa Intercity Tower A, 15-1, Konan 2-chome,
Minato-ku, Tokyo, Japan
30. 6. 2020
Akihisa Yahagi
European Standard Manager
30. 6. 2020
A. Nakagawa
Corporate Officer
006
Code No. C99258211 G
Printed in China
0000BookWH18DDX.indb160000BookWH18DDX.indb16 2020/05/2712:52:552020/05/2712:52:55
