HIKOKI DV 18DL User manual

Read through carefully and understand these instructions before use.
Diese Anleitung vor Benutzung des Werkzeugs sorgfältig durchlesen und verstehen.
Lire soigneusement et bien assimiler ces instructions avant usage.
Prima dell’uso leggere attentamente e comprendere queste instruzioni.
Deze gebruiksaanwijzing s.v.p. voor gebruik zorgvuldig doorlezen.
Leer cuidadosamente y comprender estas instrucciones antes del uso.
Antes de usar, leia com cuidado para assimilar estas instruções.
∆ιαβάστε προσεκτικά και κατανοήσετε αυτέσ τισ οδηγίεσ πριν τη χρήση.
Variable speed
DV 14DL •DV 18DL
Cordless Impact Driver Drill
Akku-Schlagbohrschrauber
Perceuse percussion/visseuse à batterie
Trapano avvitatore a percussione a batteria
Snoerloze klop-boor-schroefmachine
Taladro atornillador de impacto a batería
Berbequim aparafusador de impacto a bateria
∆ραπανοκατσάβιδο µπαταρίασ κρουστικ
Handling instructions
Bedienungsanleitung
Mode d’emploi
Istruzioni per l’uso
Gebruiksaanwijzing
Instrucciones de manejo
Instruções de uso
Οδηγίεσ χειρισµού
DV18DL

1
3
12
3
6
5
4
1
2
8
79
1
2
3132
11
22
9
8
7
L
K
J
G
I
G
H
A
C
F
0
A
BC
D
E
0
32
1
3
2
1
45
67
89

2
M
N
O
Q
P
TU
R
WX
Y
Z
S
1
45
2
3
W
(A)
(B)
T
V
1
45
2(A)
(B)
3
R
18
10 11
16 17
19
13 14
12
15

3
ac
b
e
d
f
j
h
i
3mm
11.5mm
g
\]
`
W
\
]
[
20 21
22 23
24 25
26 27

4
English Deutsch Français Italiano
14.4 V Rechargeable
battery (For DV14DL)
18 V Rechargeable
battery (For DV18DL)
Latch
Pull out
Insert
Handle
Insert
Pilot lamp
Hole for connecting the
rechargeable battery
Drill mark
Hammer mark
Cap
Triangle mark
Weak
Strong
Black line
Shift knob
Low speed
High speed
Rotation change lever
Save mode (S)
Power mode (P)
Sleeve
Tighten
Loose
Trigger switch
Selector button
Hook
Loosen
Screw
Spring
Larger diameter faces
away
Hook with light
Phillips-head screwdriver
Screw
Arrow
Hook cover
Indentation
Protuberance
AAAA batteries
Concave
Side handle
Rotate preventing protrusion
Slip preventing protrusion
Tighten
Loosen
Wear limit
Nail of carbon brush
Protrusion of carbon
brush
Contact portion outside
brush tube
1
2
3
4
5
6
7
8
9
0
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
[
\
]
`
a
b
c
d
e
f
g
h
i
j
Batterie rechargeable
14,4 V (Pour DV14DL)
Batterie rechargeable
18 V (Pour DV18DL)
Taquet
Tirer vers l’extérieur
Insérer
Poignée
Insérer
Lampe témoin
Orifice de raccordemente
de la batterie echargeable
Indice de forage
Repère de percussion
Capot
Triangle
Faible
Fort
Trait noir
Bouton de décalage
Vitesse ralentie
Vitesse élevée
Levier de changement de rotation
Mode économie (S)
Mode pleine puissance (P)
Manchon
Serrer
Desserrer
Déclencheur
Sélecteur
Crochet
Desserrer
Vis
Ressort
Gros diamètre dirigé
vers l’extérieur
Crochet muni d’un
éclairage
Tournevis à tête
Phillips
Vis
Flèche
Cache de crochet
Entaille
Saillie
Piles AAAA
Concave
Poignée latérale
Saillie anti-rotation
Saillie anti-glissement
Serrer
Desserrer
Limite d’usure
Clou de balai en carbone
Saillie de balai en
carbone
Section de contact à
l’extérieur du tube de balai
14,4 V aufladbare
Batterie (Für DV14DL)
18 V aufladbare Batterie
(Für DV18DL)
Verriegelung
Herausziehen
Einsetzen
Handgriff
Einsetzen
Kontrollampe
Anschlußloch für
Ladebatterir
Bohrer-Zeichen
Hammermarkierung
Kappe
Dreiecksmarkierung
Schwach
Stark
Schwarze Linie
Schaltknopf
Kleine Geschwindigkeit
Große Geschwindigkeit
Drehrichtungs-Wahlhebel
Energiesparmodus (S)
Leistungsmodus (P)
Manschette
Anziehen
Lösen
Trigger
Wählhebel
Haken
Lösen
Schraube
Feder
Der große Durchmesser
weist zur anderen Seite
Haken mit Beleuchtung
Kreuzschlitzschrauben-
zieher
Schraube
Pfeil
Hakenabdeckung
Einkerbung
Vorsprung
Batterien der Größe AAAA
Konkav
Seitengriff
Schlupfverhütungsvorsprung
Drehverhütungsvorsprung
Anziehen
Lösen
Verschließgrenze
Klaue der Kohlebürste
Krempe der
Kohlebürste
Kontaktteil außerhalb
des Bürstenrohrs
Batteria ricaricabile da
14,4 V (Per DV14DL)
Batteria ricaricabile da
18 V (Per DV18DL)
Fermo
Estrarre
Inserire
Impugnatura
Inserire
Spia
Foro di collegamento
della batteria ricaricabile
Simbolo di foratura
Segno del martello
Cappuccio
Simbolo del triangolo
Debol
Forte
Linea nera
Manopola di comando
Bassa velocità
Alta velocità
Leva per il cambio di rotazione
Modalità risparmio energetico (S)
Modalità alimentazione (P)
C ollare
Stringere
Allentare
Interruttore
Selettore
Gancio
Allentare
Vite
Molla
Diametro più grande
lontano da sé
Gancio munito di
lampada
Cacciavite con testa a
croce
Vite
Freccia
Coperchio gancio
Tacca
Sporgenza
Pile AAAA
Concavo
Maniglia laterale
Sporgenza di prevenzione rotazione
Sporgenza di protezione da scivolamenti
Stringere
Allentare
Limite di usura
Chiodo di spazzola di carbone
Sporgenza di spazzola
di carbone
Parte di contatto fuori dal
tubo spazzola

5
Nederlands Español Português Ελληνικά
14,4 V oplaadbare batterij
(Voor DV14DL)
18 V oplaadbare batterij
(Voor DV18DL)
Vergrendeling
Uittrekken
Insteken
Handgreep
Insteken
Controlelampje
Aansluiting voor
oplaadbare batterij
Boor-markering
Hammer markering
Kap
Driehoekje
Zwak
Sterk
Zwarte lijn
Toerenschakelaar
Laag toerental
Hoog toerental
Draairichtingshendel
Spaarmodus (S)
Power-modus (P)
Klembus
Aandraaien
Losdraaien
Trekkerschakelaar
Omzetschakelaar
Haak
Losdraaien
Schroef
Veer
De grotere diameter
wijst van u vandaan
Haak met lamp
Kruiskopschroevendraaier
Schroef
Pijl
Afdekking haak
Inkeping
Uitsteeksel
AAAA batterijen
Hol
Zijhandgreep
Rotatiestopper
Slipstopper
Aandraaien
Losdraaien
Slijtagegrens Límite de uso
Nagel van koolborstel Uña de escobilla de carbón
Uitsteeksel van Saliente de escobilla de
koolborstel carbón
Contact-gedeelte buiten Tubo exterior de la parte de
contacto de la escobilla de carbón
Batería recargable de
14,4 V (Para DV14DL)
Batería recargable de
18 V (Para DV18DL)
Cierre
Sacar
Insertar
Asidero
Insertar
Lámpara piloto
Agujero para conectar
la batería recargable
Marca del taladro
Marca de martillo
Tapa
Marca de triángulo
Débil
Fuerte
Línea negra
Mando de cambio
Velocidad alta
Velocidad baja
Palanca de cambio de rotación
Modo de ahorro (S)
Modo de plena potencia (P)
Manguito
Apretar
Aflojar
Conmutador de gatillo
Botón selector
Gancho
Aflojar
Tornillo
Resorte
El diámetro más grande
queda en dirección opuesta
Gancho con luz
Destornillador con
cabeza Phillips
Tornillo
Flecha
Cubierta del gancho
Indentación
Saliente
Pilas AAAA
Cóncavo
Asa lateral
Saliente de prevención de rotación
Saliente de prevención de deslizamiento
Apretar
Aflojar
Bateria recarregável de
14,4 V (Para DV14DL)
Bateria recarregável de
18 V (Para DV18DL)
Lingüeta
Retirar
Inserir
Cabo
Inserir
Lâmpada piloto
Orifício para conectar
a bateria recarregável
Símbolo da broca
Marca do martelo
Tampa
Marca de triângulo
Fraco
Forte
Linha preta
Comutador
Velocidade baixa
Velocidade alta
Alavanca de mudança de rotação
Modo poupança (S)
Modo
potência (P)
Manguito
Apertar
Afrouxar
Interruptor de comando
Botão seletor
Gancho
Afrouxar
Parafuso
Mola
O diâmetro maior dá
para fora
Gancho com luz
Chave Phillips
Parafuso
Seta
Tampa do gancho
Entalhe
Protuberância
Pilhas AAAA
Côncavo
Empunhadeira lateral
Protuberância anti-derrapante
Protuberância anti-giratória
Apertar
Afrouxar
Limite de desgaste
Prego da escova de carvão
Saliência da escova de
carvão
Segmento de contato no
exterior do tubo da escova
1
2
3
4
5
6
7
8
9
0
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
[
\
]
`
a
b
c
d
e
f
g
h
i
j
14,4 V
Επαναφορτιζµενη
µπαταρία (Για DV14DL)
18 V Επαναφορτιζµενη
µπαταρία (Για DV18DL)
Μάνδαλο
Τραβήξτε έξω
Εισχωρήστε
Χερούλι
Εισχωρήσετε
∆οκιµαστική λάµπα
Τρύπα για την σύνδεση τησ
επαναφορτιζµενησ µπαταρίασ
Σηµάδι τρυπανιού
Σηµάδι σφύρασ
Κάλυµµα
Σηµάδι τριγώνου
Αδύνατο
∆υνατ
Μαύρη γραµµή
Κουµπί αλλαγήσ
Χαµηλή ταχύτητα
Υψηλή ταχύτητα
Μοχλσ αλλαγήσ περιστροφήσ
Οικονοµικσ τρποσ
λειτουργίασ αποθήκευσησ (S)
Ισχυρσ τρποσ λειτουργίασ (P)
Περίβληµα
Σφίξτε
Χαλαρώστε
Σκανδάλη διακπτησ
Κουµπί επιλογέα
Γάντζοσ
Xαλαρώστε
Βίδα
Ελατήριο
Η µεγαλύτερη διάµετροσ
βλέπει προσ άλλη κατεύθυνση
Γάντζοσ µε φωσ
Κατσαβίδι κεφαλήσ
Phillips
Βίδα
Βέλοσ
Κάλυµµα αγκίστρου
Αυλάκωση
Προεξοχή
ΑΑΑΑ µπαταρίεσ
Κοίλο
Πλευρική λαβή
Προεξοχή αποτροπήσ περιστροφήσ
Προεξοχή αποτροπήσ ολίσθησησ
Σφίξτε
Χαλαρώστε
ριο φθοράσ
Καρφί καρβουνακιού
Προεξοχή
καρβουνακιού
Τµήµα επαφήσ έξω απ
το σωλήνα τησ ψήκτρασ

6
Símbolos
AVISO
A seguir aparecem os
símbolos utilizados pela
máquina. Assimile bem
seus significados antes
do uso.
Simboli
AVVERTENZA
Di seguito mostriamo i
simboli usati per la
macchina. Assicurarsi di
comprenderne il
significato prima dell’uso.
Leggere tutti gli avvertimenti
di sicurezza e tutte le
istruzioni.
La mancata osservanza degli
avvertimenti e delle istruzioni
potrebbe essere causa di
scosse elettriche, incendi e/o
gravi lesioni.
Solo per Paesi UE
Non gettare le
apparecchiature elettriche tra i
rifiuti domestici.
Secondo la Direttiva Europea
2002/96/CE sui rifiuti di
apparecchiature elettriche ed
elettroniche e la sua
attuazione in conformità alle
norme nazionali, le
apparecchiature elettriche
esauste devono essere
raccolte separatamente, al fine
di essere reimpiegate in modo
eco-compatibile.
Symbols
WARNING
The following show
symbols used for the
machine. Be sure that
you understand their
meaning before use.
Symbole
WARNUNG
Die folgenden Symbole
werden für diese Maschine
verwendet. Achten Sie
darauf, diese vor der
Verwendung zu verstehen.
Symboles
AVERTISSEMENT
Les symboles suivants
sont utilisés pour l’outil.
Bien se familiariser avec
leur signification avant
d’utiliser l’outil.
Read all safety
warnings and all
instructions.
Failure to follow the
warnings and
instructions may result
in electric shock, fire
and/or serious injury.
Lesen Sie sämtliche
Sicherheitshinweise und
Anweisungen durch.
Wenn die Warnungen und
Anweisungen nicht befolgt
werden, kann es zu
Stromschlag, Brand und/
oder ernsthaften
Verletzungen kommen.
Lire tous les avertissements
de sécurité et toutes les
instructions.
Tout manquement à observer
ces avertissements et
instructions peut engendrer
des chocs électriques, des
incendies et/ou des blessures
graves.
Symbolen
WAARSCHUWING
Hieronder staan symbolen
afgebeeld die van toepassing
zijn op deze machine. U
moet de betekenis hiervan
begrijpen voor gebruik.
Símbolos
ADVERTENCIA
A continuación se muestran
los símbolos usados para la
máquina. Asegúrese de
comprender su significado
antes del uso.
Lees alle waarschuwingen en
instructies aandachtig door.
Nalating om de
waarschuwingen en
instructies op te volgen kan in
een elektrische schok, brand
en/of ernstig letsel resulteren.
Lea todas las instrucciones y
advertencias de seguridad.
Si no se siguen las
advertencias e instrucciones,
podría producirse una
descarga eléctrica, un
incendio y/o daños graves.
Leia todas as instruções e
avisos de segurança.
Se não seguir todas as
instruções e os avisos, pode
provocar um choque eléctrico,
incêndio e/ou ferimentos
graves.
Only for EU countries
Do not dispose of electric
tools together with household
waste material!
In observance of European
Directive 2002/96/EC on waste
electrical and electronic
equipment and its
implementation in accordance
with national law, electric
tools that have reached the
end of their life must be
collected separately and
returned to an
environmentally compatible
recycling facility.
Nur für EU-Länder
Werfen Sie Elektrowerkzeuge
nicht in den Hausmüll!
Gemäss Europäischer
Richtlinie 2002/96/EG über
Elektro- und Elektronik-
Altgeräte und Umsetzung in
nationales Recht müssen
verbrauchte Elektrowerkzeuge
getrennt gesammelt und einer
umweltgerechten
Wiederververtung zugeführt
werden.
Pour les pays européens
uniquement
Ne pas jeter les appareils
électriques dans les ordures
ménagères!
Conformément à la directive
européenne 2002/96/EG relative
aux déchets d’équipements
électriques ou électroniques
(DEEE), et à sa transposition
dans la législation nationale, les
appareils électriques doivent
être collectés à part et être
soumis à un recyclage
respectueux de
l’environnement.
Alleen voor EU-landen
Geef elektrisch gereedschap
niet met het huisvuil mee!
Volgens de Europese richtlijn
2002/96/EG inzake oude
elektrische en elektronische
apparaten en de toepassing
daarvan binnen de nationale
wetgeving, dient gebruikt
elektrisch gereedschap
gescheiden te worden
ingezameld en te worden
afgevoerd naar een recycle
bedrijf dat voldoet aan de
geldende milieu-eisen.
Sólo para países de la Unión
Europea
¡No deseche los aparatos
eléctricos junto con los residuos
domésticos!
De conformidad con la Directiva
Europea 2002/96/CE sobre
residuos de aparatos eléctricos y
electrónicos y su aplicación de
acuerdo con la legislación
nacional, las herramientas
eléctricas cuya vida útil haya
llegado a su fin se deberán recoger
por separado y trasladar a una
planta de reciclaje que cumpla con
las exigencias ecológicas.
Apenas para países da UE
Não deite ferramentas
eléctricas no lixo doméstico!
De acordo com a directiva
europeia 2002/96/CE sobre
ferramentas eléctricas e
electrónicas usadas e a
transposição para as leis
nacionais, as ferramentas
eléctricas usadas devem ser
recolhidas em separado e
encaminhadas a uma
instalação de reciclagem dos
materiais ecológica.
™‡Ì‚ÔÏ·
¶ƒ√™√Ã∏
Τα παρακάτω δείχνουν τα
σύµβολα που χρησιµοποιούνται
στο µηχάνηµα. Βεβαιωθείτε τι
κατανοείτε τη σηµασίασ τουσ πριν
τη χρήση.
∆ιαβάζετε λες τις
προειδοποιήσεις ασφαλείας και
λες τις οδηγίες.
Η µη τήρηση των
προειδοποιήσεων και οδηγιών
µπορεί να προκαλέσει
ηλεκτροπληξία, πυρκαγιά και/ή
σοβαρ τραυµατισµ.
Mvo για τισ χώρεσ τησ EE
Mηv πετάτε τα ηλεκτρικά
εργαλεία στov κάδo oικιακώv
απoρριµµάτωv!
Σύµφωvα µε τηv εuρωπαϊκή
oδηγία 2002/96/EK περί
ηλεκτρικώv και ηλεκτρovικώv
σuσκεuώv και τηv
εvσωµάτωσή τησ στo εθvικ
δίκαιo, τα ηλεκτρικά εργαλεία
πρέπει vα σuλλέγovται
ξεχωριστά και vα
επιστρέφovται για
αvακύκλωση µε τρπo φιλικ
πρoσ τo περιβάλλov.

English
7
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts.
Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection.
Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or
carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on.
A wrench or a key left attached to a rotating part
of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times.
This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts.
Loose clothes, jewellery or long hair can be
caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off.
Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tools operation.
If damaged, have the power tool repaired before
use.
Many accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and tool bits
etc. in accordance with these instructions, taking
into account the working conditions and the
work to be performed.
Use of the power tool for operations different from
those intended could result in a hazardous situation.

English
8
5) Battery tool use and care
a) Recharge only with the charger specified by the
manufacturer.
A charger that is suitable for one type of battery
pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically designated
battery packs.
Use of any other battery packs may create a risk
of injury and fire.
c) When battery pack is not in use, keep it away
from other metal objects like paper clips, coins,
keys, nails, screws, or other small metal objects
that can make a connection from one terminal
to another.
Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause
irritation or burns.
6) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool
is maintained.
PRECAUTION
Keep children and infirm persons away.
When not in use, tools should be stored out of reach of
children and infirm persons.
CORDLESS IMPACT DRIVER DRILL SAFETY
WARNINGS
1. Wear ear protectors with impact drills.
Exposure to noise can cause hearing loss.
2. Use auxiliary handles supplied with the tool.
Loss of control can cause personal injury.
3. When drilling in wall, floor or ceiling, check for
buried electric power cord, etc.
4. When mounting a bit into the keyless chuck, tighten
the sleeve adequately. If the sleeve is not tight, the
bit may slip or fall out, causing injury.
5. Always charge the battery at a temperature of 0 –
50°C. A temperature of less than 0°C will result in
over charging which is dangerous. The battery
cannot be charged at a temperature higher than
50°C.
The most suitable temperature for charging is that
of 20 – 25°C.
6. When one charging is completed, leave the charger
for about 15 minutes before the next charging of
battery.
Do not charge more than two batteries
consecutively.
7. Do not allow foreign matter to enter the hole for
connecting the rechargeable battery.
8. Never disassemble the rechargeable battery and
charger.
9. Never short-circuit the rechargeable battery. Short-
circuiting the battery will cause a great electric
current and overheat. It results in burn or damage
to the battery.
10. Do not dispose of the battery in fire.
If the battery is burnt, it may explode.
11. Bring the battery to the shop from which it was
purchased as soon as the post-charging battery life
becomes too short for practical use. Do not dispose
of the exhausted battery.
12. Using an exhausted battery will damage the charger.
13. Do not insert object into the air ventilation slots of
the charger.
Inserting metal objects or inflammables into the
charger air ventilation slots will result in electrical
shock hazard or damaged charger.
CAUTION ON LITHIUM-ION BATTERY
To extend the lifetime, the lithium-ion battery equips
with the protection function to stop the output.
In the cases of 1 to 3 described below, when using this
product, even if you are pulling the switch, the motor
may stop. This is not the trouble but the result of
protection function.
1. When the battery power remaining runs out, the
motor stops.
In such case, charge it up immediately.
2. If the tool is overloaded, the motor may stop. In this
case, release the switch of tool and eliminate causes
of overloading. After that, you can use it again.
3. If the battery is overheated under overload work,
the battery power may stop.
In this case, stop using the battery and let the
battery cool. After that, you can use it again. (only
BCL1415 and BCL1815)
BCL1415 and BCL1815 are exclusively for the driver
drill. Never use with any other heavy-duty power
tools (i.e. Circular saw, Reciprocating saw, Disc
grinder and Blower etc.).
Furthermore, please heed the following warning and
caution.
WARNING
In order to prevent any battery leakage, heat generation,
smoke emission, explosion and ignition beforehand,
please be sure to heed the following precautions.
1. Make sure that swarf and dust do not collect on the
battery.
䡬During work make sure that swarf and dust do not
fall on the battery.
䡬Make sure that any swarf and dust falling on the
power tool during work do not collect on the battery.
䡬Do not store an unused battery in a location exposed
to swarf and dust.
䡬Before storing a battery, remove any swarf and
dust that may adhere to it and do not store it together
with metal parts (screws, nails, etc.).
2. Do not pierce battery with a sharp object such as a
nail, strike with a hammer, step on, throw or subject
the battery to severe physical shock.
3. Do not use an apparently damaged or deformed
battery.
4. Do not use the battery in reverse polarity.
5. Do not connect directly to an electrical outlets or
car cigarette lighter sockets.
6. Do not use the battery for a purpose other than
those specified.
7. If the battery charging fails to complete even when
a specified recharging time has elapsed,
immediately stop further recharging.

English
9
8. Do not put or subject the battery to high
temperatures or high pressure such as into a
microwave oven, dryer, or high pressure container.
9. Keep away from fire immediately when leakage or
foul odor are detected.
10. Do not use in a location where strong static
electricity generates.
11. If there is battery leakage, foul odor, heat generated,
discolored or deformed, or in any way appears
abnormal during use, recharging or storage,
immediately remove it from the equipment or
battery charger, and stop use.
CAUTION
1. If liquid leaking from the battery gets into your
eyes, do not rub your eyes and wash them well
with fresh clean water such as tap water and contact
a doctor immediately.
If left untreated, the liquid may cause eye-problems.
2. If liquid leaks onto your skin or clothes, wash well
with clean water such as tap water immediately.
There is a possibility that this can cause skin irritation.
3. If you find rust, foul odor, overheating, discolor,
deformation, and/or other irregularities when using
the battery for the first time, do not use and return it
to your supplier or vendor.
STANDARD ACCESSORIES
Standard accessories are subject to change without notice.
SPECIFICATIONS
POWER TOOL
Model DV14DL DV18DL
No-load speed Low (Save MODE) 0-200 min–1 0-200 min–1
Low (Power MODE) 0-400 min–1 0-400 min–1
High (Save MODE) 0-850 min–1 0-900 min–1
High (Power MODE) 0-1750 min–1 0-1800 min–1
No-load impact rate (Low/High) 0 – 4800 / 0 – 21000 min–1 0–4800 / 0 – 21600 min–1
Brick
(Depth 30 mm)
14 mm 16 mm
Wood
Drilling
(Thickness 18 mm)
45 mm 50 mm
Metal Steel: 13 mm,
(Thickness 1.6 mm) Aluminum: 13 mm
Machine screw 6 mm
Driving Wood screw
8 mm (diameter) ×75 mm (length) 8 mm (diameter) ×100 mm (length)
(Requires a pilot hole) (Requires a pilot hole)
Rechargeable battery BCL1415: Li-ion14.4 V (1.5 Ah 4 cells) BCL1815: Li-ion 18 V (1.5 Ah 5 cells)
BCL1430: Li-ion 14.4 V (3.0 Ah 8 cells) EBM1830: Li-ion 18 V (3.0 Ah 10 cells)
EBL1430: Li-ion 14.4 V (3.0 Ah 4 cells)
Weight 2.1 kg 2.2 kg
Capacity
1Plus driver bit (No. 2 ×65L) ...... 1
2Charger (UC18YRL or UC18YGL2 ) .... 1
DV14DL 3 Battery (BCL1415 or BCL1430 or
EBL1430) ........................................... 2
4Side handle ...................................... 1
5Plastic case ....................................... 1
1Plus driver bit (No. 2 ×65L) ...... 1
2Charger (UC18YRL or UC18YGL2 ) .... 1
3 Battery (BCL1815 or EBM1830) ...... 2
DV18DL
4Side handle ...................................... 1
5Plastic case ....................................... 1
DV14DL (NN) Without Plus driver bit, Charger, Battery,
DV18DL (NN) Side handle and Plastic case
CHARGER
Model UC18YRL UC18YGL2
Charging voltage 7.2 – 18 V
Weight 0.6 kg 0.4 kg

English
10
OPTIONAL ACCESSORIES (sold separately)
1. Battery ( BCL1415, BCL1430, EBL1430 ) (For DV14DL)
2. Battery (BCL1815, EBM1830) (For DV18DL)
Optional accessories are subject to change without notice.
APPLICATIONS
䡬Drilling of brick and concrete block, etc.
䡬Driving and removing of machine screws, wood
screws, tapping screws, etc.
䡬Drilling of various metals
䡬Drilling of various woods
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery latch (2
pcs.) to remove the battery (see Figs. 1 and 2).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 2).
CHARGING
〈UC18YRL〉
Before using the impact driver drill, charge the battery as
follows.
1. Connect the charger’s power cord to a receptacle
When the power cord is connected, the charger’s
pilot lamp will blink in red (At 1-second intervals).
2. Insert the battery into the charger
Firmly insert the battery into the charger till it contacts
the bottom of the charger and checking the polarities
as shown in Fig. 3.
CAUTION
䡬If the batteries are inserted in the reverse direction,
not only recharging will become impossible, but it
may also cause problems in the charger such as a
deformed recharging terminal.
3. Charging
When inserting a battery in the charger, charging will
commence and the pilot lamp will light continuously
in red.
When the battery becomes fully recharged, the pilot
lamp will blink in red (At 1-second intervals) (See
Table 1).
(1) Pilot lamp indication
The indications of the pilot lamp will be as shown in
Table 1, according to the condition of the charger or
the rechargeable battery.
Lightsfor0.5seconds.Doesnotlightfor0.5
seconds. (off for 0.5 seconds)
Lights continuously
Lights for 0.5 seconds. Does not light for 0.5
seconds. (off for 0.5 seconds)
Lights for 0.1 seconds. Does not light for 0.1
seconds. (off for 0.1 seconds)
Lights continuously
Before
charging
While
charging
Charging
complete
Charging
impossible
Blinks
(RED)
Lights
(RED)
Blinks
(RED)
Flickers
(RED)
Lights
(GREEN)
Malfunction in the battery
or the charger.
Battery overheated.
Unable to charge.
(Chargingwillcommence
when battery cools)
Table 1
Indications of the pilot lamp
Overheat
standby
NOTE: When standby for cooling battery, UC18YRL cools the overheated battery by cooling fan.
Charge status
lamp (RED)
Overheat lamp
(GREEN)

English
11
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate,
and the battery life will be shortened. Leave the battery
and recharge it after it has cooled for a while.
CAUTION
䡬When the battery charger has been continuosly used,
the battery charger will be heated, thus constituting
the cause of the failures. Once the charging has been
completed, give 15 minutes rest until the next
charging.
䡬If the battery is recharged when it is warm due to
battery use or exposure to sunlight, the pilot lamp
map light in green.
The battery will not be recharged. In such a case, let
the battery cool before charging.
䡬When the pilot lamp flickers in red (at 0.2-second
intervals), check for and take out any foreign objects
in the charger’s battery installation hole. If there are
no foreign objects, it is probable that the battery or
charger is malfunctioning. Take it to your authorized
Service Center.
〈UC18YGL2〉
Before using the power tool, charge the battery as follows.
1. Connect the charger’s power cord to a receptacle
When the power cord is connected, the charger’s
pilot lamp will blink in red (At 1-second intervals).
2. Insert the battery into the charger
Firmly insert the battery into the charger till it contacts
the bottom of the charger and checking the polarities
as shown in Fig. 4.
CAUTION
䡬If the battery is inserted in the reverse direction, not
only recharging will become impossible, but it may
also cause problems in the charger such as deformed
recharging terminal.
3. Charging
When inserting a battery in the charger, charging will
commence and the pilot lamp will light up
continuously in red.
When the battery becomes fully recharged, the pilot
lamp will blink in red (At 1-second intervals) (See
Table 4).
(1) Pilot lamp indication
The indications of the pilot lamp will be as shown in
Table 4, according to the condition of the charger or
the rechargeable battery.
(2) Regarding the temperatures of the rechargeable
battery
The temperatures for rechargeable batteries are as
shown in Table 2, and batteries that have become
hot should be cooled for a while before being
recharged.
Table 2 Recharging ranges of batteries
(3) Regarding recharging time
Depending on the combination of the charger and
batteries, the charging time will become as shown
in Table 3.
Table 3 Charging time (At 20°C)
NOTE
The charging time may vary according to temperature
and power source voltage.
4. Disconnect the charger’s power cord from the
receptacle
5. Hold the charger firmly and pull out the battery
NOTE
After operation, pull out batteries from the charger
first, and then keep the batteries properly.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries
and batteries that have not been used for an extended
period is not activated, the electric discharge might
be low when using them the first and second time.
This is a temporary phenomenon, and normal time
required for recharging will be restored by recharging
the batteries 2 – 3 times.
How to make the batteries perform longer.
(1) Recharge the batteries before they become completely
exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery.
If you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
Temperatures at which the
Rechargeable batteries battery can be recharged
BCL1415, BCL1430,
EBL1430, BCL1815
,
EBM1830
0°C – 50°C
Charger UC18YRL
Battery
BCL1415, BCL1815 Approx. 20 min.
BCL1430, EBL1430, EBM1830 Approx. 45 min.

English
12
(2) Regarding the temperatures of the rechargeable
battery
The temperatures for rechargeable batteries are as
shown in Table 5, and batteries that have become
hot should be cooled for a while before being
recharged.
Table 5 Recharging ranges of batteries
(3) Regarding recharging time
Depending on the combination of the charger and
batteries, the charging time will become as shown in
Table 6.
Table 6 Charging time (At 20°C)
NOTE:
The charging time may vary according to temperature
and power source voltage.
4. Disconnect the charger’s power cord from the
receptacle
5. Hold the charger firmly and pull out the battery
NOTE:
After charging, pull out batteries from the charger
first, and then keep the batteries properly.
Regarding electric discharge in case of new
batteries, etc.
As the internal chemical substance of new batteries
and batteries that have not been used for an extended
period is not activated, the electric discharge might
be low when using them the first and second time.
This is a temporary phenomenon, and normal time
required for recharging will be restored by recharging
the batteries 2 – 3 times.
Lights for 0.5 seconds. Does not light for
0.5 seconds. (off for 0.5 seconds)
Lights continuously
Lights for 0.5 seconds. Does not light for
0.5 seconds. (off for 0.5 seconds)
Lights for 1 second. Does not light for 0.5
seconds. (off for 0.5 seconds)
Before
charging
While
charging
Charging
complete
Overheat
standby
Blinks
Lights
Blinks
Flikers
Battery overheated. Unable
to charge (Charging will
commence when battery
cools).
Table 4
Indications of the pilot lamps
Pilot lamp
(red)
Temperatures at
Rechargeable batteries
which the battery
can be recharged
BCL1415, BCL1430, EBL1430,
0°C – 50°C
BCL1815, EBM1830
How to make the batteries perform longer
(1) Recharge the batteries before they become completely
exhausted.
When you feel that the power of the tool becomes
weaker, stop using the tool and recharge its battery.
If you continue to use the tool and exhaust the electric
current, the battery may be damaged and its life will
become shorter.
(2) Avoid recharging at high temperatures.
A rechargeable battery will be hot immediately after
use. If such a battery is recharged immediately after
use, its internal chemical substance will deteriorate,
and the battery life will be shortened. Leave the battery
and recharge it after it has cooled for a while.
CAUTION:
䡬When the battery charger has been continuosly used,
the battery charger will be heated, thus constituting
the cause of the failures. Once the charging has been
completed, give 15 minutes rest until the next
charging.
䡬If the battery is recharged when it is warm due to
battery use or exposure to sunlight, the pilot lamp
lights for 1 second, does not light for 0.5 seconds (off
for 0.5 seconds).
The battery will not be recharged. In such a case, let
the battery cool before charging.
PRIOR TO OPERATION
1. Setting up and checking the work environment
Check if the work environment is suitable by following
the precautions.
HOW TO USE
1. Confirm the cap position (see Fig. 5)
The three modes of screwdriver, drill and impact drill
can be switched by the position of the cap in this unit.
(1) When using this unit as a screwdriver, line up the one
of the numbers “1, 4, 7 ... 22” on the cap, or the black
dots, with the triangle mark on the outer body.
(2) When using this unit as a drill, align the cap drill mark
“” with the triangle mark on the outer body.
(3) When using this unit as an impact drill, align the cap
hammer mark “ ” with the triangle mark on the
outer body.
Charger UC18YGL2
Battery
BCL1815, BCL1415 Approx. 40 min.
BCL1430, EBL1430, EBM1830 Approx. 90 min.

English
13
CAUTION
䡬The cap cannot be set between the numerals “1, 4, 7
... 22” or the black dots.
䡬Do not use with the cap numeral between “22” and
the black line at the middle of the drill mark. Doing so
may cause damage (See Fig. 6).
2. Tightening torque adjustment
(1) Tightening torque
Tightening torque should correspond in its intensity
to the screw diameter. When too strong torque is
used, the screw head may be broken or be injured.
Be sure to adjust the cap position according to the
screw diameter.
(2) Tightening torque indication
The tightening torque differs depending on the type
of screw and the material being tightened.
The unit indicates the tightening torque with the
numbers “1, 4, 7 ... 22” on the cap, and the black
dots. The tightening toque at position “1” is the
weakest and the torque is strongest at the highest
number (See Fig. 5).
(3) Adjusting the tightening torque
Rotate the cap and line up the numbers “1, 4, 7 ... 22”
on the cap, or the black dots, with the triangle mark on
the outer body. Adjust the cap in the weak or the strong
torque direction according to the torque you need.
CAUTION
䡬The motor rotation may be locked to cease while the
unit is used as drill. While operating the impact driver
drill, take care not to lock the motor.
䡬Too long hammering may cause the screw broken
due to excessive tightening.
3. Rotation to Impact changeover (See Fig. 5)
The “Rotation (Rotation only)” and “Impact (Impact
+ Rotation)” can be switched by aligning the drill
mark “ ” or the hammer mark “ ” with the triangle
mark on the outer body.
䡬To make holes in the metal, wood or plastic, switch
to “Rotation (Rotation only)”.
䡬To make holes in bricks or concrete blocks, switch to
“Impact (Impact + Rotation)”.
CAUTION
If an operation which is normally performed at the
“Rotation” setting is performed at “Impact “ setting,
the effect of making holes does not only increase but
it may also damage the bit or other parts.
4. Change rotation speed
By making a combination of the switch-over of “HIGH”
or “LOW” with the shift knob and the switch-over of
Power mode (P) or Save mode (S) with the lever on
the side of the handle, the rotational speed can be set
to four (4) steps. (See “SPECIFICATIONS”.)
䡬How to switch over “HIGH” or “LOW”
Operate the shift knob to change the rotational speed.
Move the shift knob in the direction of the arrow (see
Figs. 7 and 8).
When the shift knob is set to “LOW”, the drill rotates
at a low speed. When set to “HIGH”, the drill rotates
at a high speed.
䡬How to switch over the Power mode (P) or Save
mode (S)
To set to the Power mode (P), slide the lever on the
side of handle to the lower side, and to set to the Save
mode (S), slide the lever to the upper side. (Fig. 9)
CAUTION
䡬When changing the rotational speed with the shift
knob, confirm that the switch is off.
Changing the speed while the motor is rotating will
damage the gears.
䡬When setting the shift knob to “HIGH” (high speed)
and the position of the cap is bitween “16” and “22”,
it may happen that the clutch does not engaged and
that the motor is locked. In such a case, please set the
shift knob to “LOW” (low speed).
䡬If the motor is locked, immediately turn the power
off. If the motor is locked for a while, the motor or
battery may be burnt.
䡬In the work of the save mode (S), avoid the continuous
screw-tightening as temperature of electronic
components of the converter switch increases.
䡬To extend the lifetime, the lithium-ion battery equips
with the protection function to stop the output.
Therefore, if the tool is overloaded, the motor may
stop. However, this is not the trouble but the result of
protection function. In this case, release the switch of
tool and eliminate the causes of overloading.
5. The scope and suggestions for uses
The usable scope for various types of work based on
the mechanical structure of this unit is shown in
Table 7.
Work Suggestions
Brick
Drilling Wood Use for drilling purpose.
Steel
Aluminum
Machine screw Use the bit or socket matching the screw diameter.
Driving Wood screw Use after drilling a pilot hole.
Table 7

English
14
CAUTION
䡬The selection examples shown in Table 8 should be
considered as general standard. As different types of
tightening screws and different materials to be
tightened are used in actual works proper adjustments
are naturally necessary.
䡬When using the impact driver drill with a machine
screw at HIGH (high speed), a screw may damage or
a bit may loose due to the tightning torque is too
strong. Use the impact driver drill at LOW (low speed)
when using a machine screw.
NOTE
The use of the Li-ion battery in a cold condition
(below 0 degree Centigrade) can sometimes result in
the weakened tightening torque and reduced amount
of work. This, however, is a temporary phenomenon,
and returns to normal when the battery warms up.
7. Mounting and dismounting of the bit
(1) Mounting the bit
Loosen the sleeve by turning it toward the left (in the
counterclockwise direction as viewed from the front)
to open the clip on the keyless chuck. After inserting
a driver bit, etc., into the keyless drill chuck, and
tighten the sleeve by turning it toward the right (in
the clockwise direction as viewed from the front)
(See Fig. 10).
䡬If the sleeve becomes loose during operation, tighten
it further.
The tightening force becomes stronger when the
sleeve is tightened additionally.
(2) Dismounting the bit
Loosen the sleeve by turning it toward the left (in the
counterclockwise direction as viewed from the front),
and then take out the bit, etc. (See Fig. 10).
NOTE
If the sleeve is tightened in a state where the clip of
the keyless chuck is opened to a maximum limit, a
click noise may occur. This is the noise that occurs
when the loosening of the keyless chuck is prevented
and is not a malfunction.
CAUTION
䡬When it is no longer possible to loosen the sleeve,
use a vise or similar instrument to secure the bit. Set
the clutch mode between 1 and 7 and then turn the
sleeve to the loose side (left side) while operating the
clutch. It should be easy now to loosen the sleeve.
8. Automatic spindle-lock mechanism
This unit has automatic spindle-lock mechanism for
quick bit changes.
9. Confirm that the battery is mounted correctly
10. Check the rotational direction
The bit rotates clockwise (viewed from the rear side)
by pushing the R-side of the selector button.
The L-side of the selector button is pushed to turn the
bit counterclockwise (See Fig. 11). (The
L
and
R
marks are provided on the selector button.)
CAUTION
䡬Always use this unit with clockwise rotation, when
using it as an impact drill.
11. Switch operation
䡬When the trigger switch is depressed, the tool rotates.
When the trigger is released, the tool stops.
䡬The rotational speed of the drill can be controlled by
varying the amount that the trigger switch is pulled.
Speed is low when the trigger switch is pulled slightly
and increases as the trigger switch is pulled more.
NOTE
䡬A buzzing noise is produced when the motor is about
to rotate. This is only a noise, not a machine failure.
12. For drilling into brick
Excessive pressing force never increases drilling
speed. It will not only damage the drill tip or reduce
working efficiency, but could also shorten the service
life of drill bit. Operate the impact driver drill within
10-15 kg pressing force while drilling into brick.
13. Using the hook
CAUTION
䡬When using the hook, pay sufficient attention so that
the main equipment does not fall. If the tool falls,
there is a risk of accident.
Table 8
Use Cap Position Rotating speed selection (Position of the shift knob)
LOW (Low speed) HIGH (High speed)
Machine screw 1 – 22 For 4 mm or smaller
diameter screws.
Driving
Wood screw 1 –
For 8 mm or smaller nominal
diameter screws.
Brick
For 14 mm or smaller
diameters. (DV14DL)
For 16 mm or smaller
diameters. (DV18DL)
Drilling Wood
For 45 mm or smaller
diameters. (DV14DL)
For 50 mm or smaller
diameters. (DV18DL)
Metal For drilling with a metal
working drill bit.
For 6 mm or smaller
diameter screws.
For 4.8 mm or smaller
nominal diameter screws.
For 10 mm or smaller
diameters. (DV14DL)
For 12 mm or smaller
diameters. (DV18DL)
For 20 mm or smaller
diameters. (DV14DL)
For 22 mm or smaller
diameters. (DV18DL)
6. How to select tightening torque and rotational speed

English
15
䡬Do not attach the tip tool except phillips bit to the tool
main unit when carrying the tool main unit with the
hook suspended from a waist belt.
Injury may result if you carry the equipment
suspended from the waist belt with sharp tipped
components such as drill bit attached.
The hook can be installed on the right or left side and the
angle can be adjusted in 5 steps between 0° and 80°.
(1) Operating the hook
(a) Pull out the hook toward you in the direction of
arrow (A) and turn in the direction of arrow (B)
(Fig. 12).
(b) The angle can be adjusted in 5 steps (0°, 20°, 40°,
60°, 80°).
Adjust the angle of the hook to the desired position
for use.
(2) Switching the hook position
CAUTION
Incomplete installation of the hook may result in
bodily injury when used.
(a) Securely hold the main unit and remove the screw
using a slotted head screwdriver or a coin (Fig. 13).
(b) Remove the hook and spring (Fig. 14).
(c) Install the hook and spring on the other side and
securely fasten with screw (Fig. 15).
NOTE
Pay attention to the spring orientation. Install the
spring with larger diameter away from you (Fig. 15).
(3) Using the bit holder (Hook with bit holder)
䡬Installing the bit
Slide the bit from the side, and then insert firmly
until the groove on the bit locks in the protruded
section of the hook.
䡬Removing the bit
Securely hold the main unit and pull out the bit by
holding the tip with your thumb (Fig. 16).
CAUTION
䡬 Only HiKOKI STANDARD ACCESSORIES phillips bit
(No. 2 ×65L; Code No. 983006) may be used. Do not
use other bits since they may come loose.
(4) Using as an auxiliary light (Hook with light)
(a) Press the switch to turn off the light.
If forgotten, the light will turn off automatically
after 15 minutes.
(b) The direction of the light can be adjusted within
the range of hook positions 1 - 5 (Fig. 17).
䡬Lighting time
AAAA manganese batteries: approx. 15 hrs.
AAAA alkali batteries: approx. 30 hrs.
CAUTION
Do not look directly into the light.
Such actions could result in eye injury.
(5) Replacing the batteries (Hook with light)
(a) Loosen the hook screw with a phillips-head
screwdriver (No. 1) (Fig. 18).
Remove the hook cover by pushing in the direction
of the arrow (Fig. 19).
(b) Remove the old batteries and insert the new
batteries. Align with the hook indications and
position the plus (+) and minus (–) terminals
correctly (Fig. 20).
(c) Align the indentation in the hook main body with
the protuberance of the hook cover, press the
hook cover in the direction opposite to that of the
arrow shown in Fig. 19 and then tighten the screw.
Use commercially available AAAA batteries
(1.5 V).
NOTE
Do not tighten the screw excessively. Such action
could strip the screw threads.
CAUTION
䡬Failure to observe the following can result in battery
leakage, rust or malfunction.
Position the plus (+) and minus (–) terminals correctly.
Replace both batteries at the same time. Do not mix
old and new batteries.
Remove exhausted batteries from the hook
immediately.
䡬Do not discard batteries together with normal trash
and do not throw batteries into fire.
䡬Store batteries out of the reach of children.
䡬Use batteries correctly in accordance with the battery
specifications and indications.
14. Using the bit holder
CAUTION
䡬Stow the bit in the specified location on the tool. If
the tool is used with the bit stowed improperly, the
bit may fall and cause bodily injury.
䡬Do not stow bits that are of a different length, gauge
or dimension than the plus driver bit (65 mm long)
included in the STANDARD ACCESSORIES.
The bit may fall and cause bodily injury.
(1) Removing the bit
Securely hold the main unit and pull out the bit by
holding the tip with your thumb (Fig. 21).
(2) Installing the Bit
Install the bit with steps opposite of when removing.
Insert the bit so that the right and left sides are equal,
as shown in Fig. 22.
15. Installing/Removing the side handle
CAUTION
䡬Firmly install the side handle. If loose, the side handle
may gyrate or fall out and cause bodily injury.
(1) Install the side handle so that the protrusions on the
main unit and grooves on the side handle interlock.
Tighten the grip after checking that the side handle is
not riding on the slip prevention protrusion (Fig. 23).
(2) Loosen the grip to remove the side handle.
MAINTENANCE AND INSPECTION
1. Inspecting the tool
Since use of as dull tool will degrade efficiency and
cause possible motor malfunction, sharpen or replace
the tool as soon as abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure
that they are properly tightened. Should any of the
screws be loose, retighten them immediately. Failure
to do so could result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the
power tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.

English
16
4.
NOTE
Inspecting the carbon brushes (Fig. 24)
The motor employs carbon brushes which are
consumable parts. Since and excessively worn carbon
brush can result in motor trouble, replace the carbon
brush with new ones when it becomes worn to or
near the “wear limit”. In addition, always keep carbon
brushes clean and ensure that they slide freely within
the brush holders.
When replacing the carbon brush with a new one, be
sure to use the HiKOKI Carbon Brush Code No. 999054.
5. Replacing carbon brushes
Take out the carbon brush by first removing the
brush cap and then hooking the protrusion of the
carbon brush with a flat head screw driver, etc., as
shown in Fig. 26.
When installing the carbon brush, choose the direction
so that the nail of the carbon brush agrees with the
contact portion outside the brush tube. Then push it
in with a finger as illustrated in Fig. 27. Lastly, install
the brush cap.
CAUTION
Be absolutely sure to insert the nail of the carbon
brush into the contact portion outside the brush tube.
(You can insert whichever one of the two nails
provided.)
Caution must be exercised since any error in this
operation can result in the deformed nail of the carbon
brush and may cause motor trouble at an early stage.
6. Cleaning on the outside
When the Impact driver drill is stained, wipe with a
soft dry cloth or a cloth moistened with soapy water.
Do not use chloric solvents, gasoline or paint thinner,
for they melt plastics.
7. Storage
Store the Impact driver drill in a place in which the
temperature is less than 40°C and out of reach of
children.
8. Service parts list
CAUTION
Repair, modification and inspection of HiKOKI Power
Tools must be carried out by a HiKOKI Authorized
Service Center.
This Parts List will be helpful if presented with the
tool to the HiKOKI Authorized Service Center when
requesting repair or other maintenance.
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
MODIFICATIONS
HiKOKI Power Tools are constantly being improved
and modified to incorporate the latest technological
advancements.
Accordingly, some parts may be changed without
prior notice.
GUARANTEE
We guarantee HiKOKI Power Tools in accordance with
statutory/countryspecific regulation.This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the Power Tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a HiKOKI Authorized Service Center.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifications herein are subject to
change without prior notice.
IMPORTANT
Correct connection of the plug
The wires of the mains lead are coloured in accordance
with the following code:
Blue: – Neutral
Brown: – Live
As the colours of the wires in the mains lead of this tool
may not correspond with the coloured markings
identifying the terminals in your plug proceed as follows:
The wire coloured blue must be connected to the terminal
marked with the letter N or coloured black.
The wire coloured brown must be connected to the
terminal marked with the letter L or coloured red.
Neither core must be connected to the earth terminal.
NOTE
This requirement is provided according to BRITISH
STANDARD 2769: 1984.
Therefore, the letter code and colour code may not be
applicable to other markets except United Kingdom.
Information concerning airborne noise and vibration
The measured values were determined according to
EN 60745 and declared in accordance with ISO 4871.
DV14DL
Measured A-weighted sound power level: 93 dB(A)
Measured A-weighted sound pressure level: 82 dB(A)
Uncertainty KpA: 3 dB(A)
The typical weighted root mean square acceleration
value: 7.6 m/s2.
DV18DL
Measured A-weighted sound power level: 93 dB(A)
Measured A-weighted sound pressure level: 82 dB(A)
Uncertainty KpA: 3 dB(A)
The typical weighted root mean square acceleration
value: 9.5 m/s2.
Wear ear protection.

Deutsch
17
ALLGEMEINE SICHERHEITSHINWEISE FÜR
ELEKTROGERÄTE
WARNUNG
Lesen Sie sämtliche Sicherheitshinweise und
Anweisungen durch
Wenn die Warnungen und Anweisungen nicht befolgt
werden, kann es zu Stromschlag, Brand und/oder
ernsthaften Verletzungen kommen.
Bittebewahren Sie alle Warnhinweise und Anweisungen
zum späteren Nachschlagen auf.
Der Begriff „Elektrowerkzeug“ bezieht sich in den
Warnhinweisen auf Elektrowerkzeuge mit Netz-
(schnurgebunden) oder Akkubetrieb (schnurlos).
1) Sicherheit im Arbeitsbereich
a) Sorgen Sie für einen sauberen und gut
ausgeleuchteten Arbeitsbereich.
Zugestellte oder dunkle Bereiche ziehen Unfälle
förmlich an.
b) Verwenden Sie Elektrowerkzeuge niemals an
Orten, an denen Explosionsgefahr besteht – zum
Beispiel in der Nähe von leicht entflammbaren
Flüssigkeiten, Gasen oder Stäuben.
Bei der Arbeit mit Elektrowerkzeugen kann es
zu Funkenbildung kommen, wodurch sich Stäube
oder Dämpfe entzünden können.
c) Sorgen Sie bei der Arbeit mit Elektrowerkzeugen
dafür, dass sich keine Zuschauer (insbesondere
Kinder) in der Nähe befinden.
Wenn Sie abgelenkt werden, können Sie die
Kontrolle über das Werkzeug verlieren.
2) Elektrische Sicherheit
a) Elektrowerkzeuge müssen mit passender
Stromversorgung betrieben werden.
Nehmen Sie niemals irgendwelche Änderungen
am Anschlussstecker vor.
Verwenden Sie bei Elektrowerkzeugen mit
Schutzkontakt (geerdet) niemals Adapterstecker.
Stecker im Originalzustand und passende
Steckdosen reduzieren das Stromschlagrisiko.
b) Vermeiden Sie Körperkontakt mit geerdeten
Gegenständen wie Rohrleitungen, Heizungen,
Herden oder Kühlschränken.
Bei Körperkontakt mit geerdeten Gegenständen
besteht ein erhöhtes Stromschlagrisiko.
c) Setzen Sie Elektrowerkzeuge niemals Regen oder
sonstiger Feuchtigkeit aus.
Wenn Flüssigkeiten in ein Elektrowerkzeug
eindringen, erhöht sich das Stromschlagrisiko.
d) Verwenden Sie die Anschlussschnur nicht
missbräuchlich. Tragen Sie das Elektrowerkzeug
niemals an der Anschlussschnur, ziehen Sie es
nicht damit heran und ziehen Sie den Stecker
nicht an der Anschlussschnur aus der Steckdose.
Halten Sie die Anschlussschnur von Hitzequellen,
Öl, scharfen Kanten und beweglichen Teilen fern.
Beschädigte oder verdrehte Anschlussschnüre
erhöhen das Stromschlagrisiko.
e) Wenn Sie ein Elektrowerkzeug im Freien
benutzen, verwenden Sie ein für den
Außeneinsatz geeignetes Verlängerungskabel.
Ein für den Außeneinsatz geeignetes Kabel
vermindert das Stromschlagrisiko.
f) Falls sich der Betrieb des Elektrowerkzeuges in
feuchter Umgebung nicht vermeiden lässt,
verwenden Sie eine Stromversorgung mit
Fehlerstromschutzeinrichtung (Residual Current
Device, RCD).
Durch den Einsatz einer
Fehlerstromschutzeinrichtung wird das Risiko
eines elektrischen Schlages reduziert.
3) Persönliche Sicherheit
a) Bleiben Sie wachsam, achten Sie auf das, was
Sie tun, und setzen Sie Ihren Verstand ein,
wenn Sie mit Elektrowerkzeugen arbeiten.
Benutzen Sie keine Elektrowerkzeuge, wenn Sie
müde sind oder unter Einfluss von Drogen,
Alkohol oder Medikamenten stehen.
Bei der Arbeit mit Elektrowerkzeugen können
bereits kurze Phasen der Unaufmerksamkeit zu
schweren Verletzungen führen.
b) Benutzen Sie eine persönliche Schutzausrüstung.
Tragen Sie immer einen Augenschutz.
Schutzausrüstung wie Staubmaske, rutschsichere
Sicherheitsschuhe, Schutzhelm und Gehörschutz
senken das Verletzungsrisiko bei angemessenem
Einsatz.
c) Vermeiden Sie unbeabsichtigten Anlauf. Achten
Sie darauf, dass sich der Schalter in der Aus-
(Off-) Position befindet, ehe Sie das Gerät mit
der Stromversorgung und/oder
Batteriestromversorgung verbinden, es aufheben
oder herumtragen.
Das Herumtragen von Elektrowerkzeugen mit dem
Finger am Schalter oder das Herstellen der
Stromversorgung bei betätigtem Schalter zieht
Unfälle regelrecht an.
d) Entfernen Sie sämtliche Einstellwerkzeuge
(Einstellschlüssel), ehe Sie das Elektrowerkzeug
einschalten.
Ein an einem beweglichen Teil des Elektrowerkzeugs
angebrachter Schlüssel kann zu Verletzungen führen.
e) Sorgen Sie für einen festen Stand. Achten Sie
jederzeit darauf, sicher zu stehen und das
Gleichgewicht zu bewahren.
Dadurch haben Sie das Elektrowerkzeug in
unerwarteten Situationen besser im Griff.
f) Kleiden Sie sich richtig. Tragen Sie keine lose
Kleidung oder Schmuck. Halten Sie Haar, Kleidung
und Handschuhe von beweglichen Teilen fern.
Lose Kleidung, Schmuck oder langes Haar kann
von beweglichen Teilen erfasst werden.
g) Wenn Anschlüsse für Staubabsaug- und -
sammelvorrichtungen vorhanden sind, sorgen
Sie dafür, dass diese richtig angeschlossen und
eingesetzt werden.
Durch Entfernen des Staubes können
staubbezogene Gefahren vermindert werden.
4) Einsatz und Pflege von Elektrowerkzeugen
a) Überanspruchen Sie Elektrowerkzeuge nicht.
Benutzen Sie das richtige Elektrowerkzeug für
Ihren Einsatzzweck.
Das richtige Elektrowerkzeug erledigt seine Arbeit
bei bestimmungsgemäßem Einsatz besser und
sicherer.
b) Benutzen Sie das Elektrowerkzeug nicht, wenn es
sich nicht am Schalter ein- und ausschalten lässt.
Jedes Elektrowerkzeug, das nicht mit dem
Schalter betätigt werden kann, stellt eine Gefahr
dar und muss repariert werden.
c) Stecken Sie den Stecker der Stromversorgung
oder Batteriestromversorgung vom Gerät ab,
ehe Sie Einstellarbeiten vornehmen, Zubehörteile
tauschen oder das Elektrowerkzeug verstauen.
Solche präventiven Sicherheitsmaßnahmen
verhindern den unbeabsichtigten Anlauf des
Elektrowerkzeugs und die damit verbundenen
Gefahren.

Deutsch
18
d) Lagern Sie nicht benutzte Elektrowerkzeuge
außerhalb der Reichweite von Kindern, lassen
Sie nicht zu, dass Personen das Elektrowerkzeug
bedienen, die nicht mit dem Werkzeug selbst
und/oder diesen Anweisungen vertraut sind.
Elektrowerkzeuge in ungeschulten Händen sind
gefährlich.
e) Halten Sie Elektrowerkzeuge in Stand. Prüfen
Sie auf Fehlausrichtungen, sicheren Halt und
Leichtgängigkeit beweglicher Teile,
Beschädigungen von Teilen und auf jegliche
andere Zustände, die sich auf den Betrieb des
Elektrowerkzeugs auswirken können.
Bei Beschädigungen lassen Sie das
Elektrowerkzeug reparieren, ehe Sie es benutzen.
Viele Unfälle mit Elektrowerkzeugen sind auf
schlechte Wartung zurückzuführen.
f) Halten Sie Schneidwerkzeuge scharf und sauber.
Richtig gewartete Schneidwerkzeuge mit scharfen
Schneidkanten bleiben weniger häufig hängen
und sind einfacher zu beherrschen.
g) Benutzen Sie Elektrowerkzeuge, Zubehör,
Werkzeugspitzen und Ähnliches in
Übereinstimmung mit diesen Anweisungen –
beachten Sie dabei die jeweiligen
Arbeitsbedingungen und die Art und Weise der
auszuführenden Arbeiten.
Der Gebrauch des Elektrowerkzeuges für andere
als die vorgesehenen Anwendungen kann zu
gefährlichen Situationen führen.
5) Verwendung und Pflege der Batterie
a) Laden Sie das Gerät nur mit dem vom Hersteller
empfohlenen Ladegerät auf.
Ein Ladegerät für einen speziellen Batterietyp
kann bei Verwendung mit anderen Batterien zu
Gefahren führen.
b) Verwenden Sie für das Gerät nur die speziell
empfohlenen Batterien.
Eine Verwendung von anderen Batterien kann
zu Verletzungen und Bränden führen.
c) Ist die Batterie nicht in Gebrauch, achten Sie
darauf, dass sie nicht mit metallischen
Gegenständen, beispielsweise Büroklammern,
Münzen, Schlüssel, Nägel, Schrauben in Kontakt
kommt, da diese Gegenstände einen Kurzschluss
der Anschlüsse verursachen könnten.
Ein Kurzschluss der Batterieanschlüsse kann zu
Verbrennungen oder Bränden führen.
d) Im Falle von Störungen, kann Flüssigkeit aus
der Batterie austreten. Vermeiden Sie in diesem
Fall jeglichen Kontakt. Sollten Sie dennoch mit
der Batterie in Berührung kommen, waschen
Sie die betroffene Stelle gründlich mit Wasser
ab. Ist die Flüssigkeit ins Auge geraten, suchen
Sie einen Arzt auf.
Ausgetretene Batterieflüssigkeiten können zu
Reizungen oder Verbrennungen führen.
6) Service
a) Lassen Sie Elektrowerkzeuge durch qualifizierte
Fachkräfte und unter Einsatz passender,
zugelassener Originalteile warten.
Dies sorgt dafür, dass die Sicherheit des
Elektrowerkzeugs nicht beeinträchtigt wird.
VORSICHT
Von Kindern und gebrechlichen Personen fernhalten.
Werkzeuge sollten bei Nichtgebrauch außerhalb der
Reichweite von Kindern und gebrechlichen Personen
aufbewahrt werden.
SICHERHEITSHINWEISE FÜR AKKU-
SCHLAGSCHRAUBER
1. Tragen Sie bei der Arbeit mit Schlagbohrmaschinen
einen Gehörschutz.
Starke und/oder dauerhafte Lärmbelastung kann zu
Gehörverlust führen.
2. Benutzen Sie die mit dem Werkzeug gelieferten
Zusatzgriffe.
Wenn Sie die Kontrolle über das Werkzeug verlieren,
kann es zu Verletzungen kommen.
3. Beim Bohren von Wand, Boden oder Decke,
nachprüfen ob keine versenkten Kabel, usw.
vorhanden sind.
4. Beim Einspannen von Bohrspitzen oder
Stangenbohrern in das schlüssellose Spannfutter
die Bohrhülse ausreichend festdrehen. Bei nicht
ausreichend festgedrehter Bohrhülse kann die
Bohrspitze verrutschen oder herausfallen und
Verletzungen verursachen.
5. Die Batterie immer bei einer Temperatur von 0 –
50°C laden. Laden bei einer Temperatur, die
niedriger als 0°C ist, wird gefährliche Überladung
verursachen. Die Batterie kann nicht bei einer
Temperatur über 50°C geladen werden.
Die beste Temperatur zum Laden wäre von 20 – 25°C.
6. Nach Beendung einer Ladung, lassen Sie das
Ladegerät ungefähr 15 Minuten ruhen bevor die
nächste Batterieladung unternommen wird.
Nicht mehr als zwei Batterien nacheinander laden.
7. Keine Fremdkörper durch das Anschlußloch der
Batterie eindringen lassen.
8. Niemals die Batterie und das Ladegerät
auseinandernehmen.
9. Niemals die Batterie kurzschließen. Kurzschluß der
Batterie verursacht eine zu große Stromzufuhr und
überhitzung, wodurch Durchbrennen oder Schaden
beider Batterie entsteht.
10. Die Batterie nicht ins Feuer werfen.
Sie könnte dabei explodieren.
11. Bringen Sie die Batterie zum Geschäft, wo Sie ihn
gekauft haben sobald die Lebensdauer der Batterie
abrinnt. Die erschöpfte Batterie nicht wegwerfen.
12. Benutzung verbrauchter Batterie beschädigt den
Auflader.
13. Darauf achten, daß keine Gegenstände durch
Belüftungsschlitze des Aufladers in das Gerät
eindringen.
Wenn Metallobjekte oder entzündliche Gegenstände
durch die Belüftungsschlitze des Aufladers
eindringen, kann dies zu elektrischen Schlägen
führen oder den Auflader beschadigen.
WARNUNG ZUM LITHIUM-IONEN-AKKU
Um die Lebensdauer des Lithium-Ionen-Akkus zu
verlängern, ist dieser mit einer Schutzfunktion zum
Stoppen der Leistungsabgabe ausgestattet.
In den unten beschriebenen Fällen 1 bis 3 kann bei der
Benutzung dieses Produkts der Motor abschalten, selbst
wenn Sie den Schalter drücken. Dies ist kein Defekt
sondern das Resultat der Schutzfunktion.
1. Wenn die verbleibende Akkuleistung nicht mehr
ausreicht, schaltet der Motor ab.
Laden Sie in einem solchen Fall den Akku umgehend
auf.

Deutsch
19
2. Wenn das Werkzeug überlastet ist, kann es zum
Abschalten des Motors kommen. Lassen Sie in
diesem Fall den Schalter des Geräts los und
beseitigen Sie die Ursache der Überlastung. Danach
können Sie das Gerät wieder verwenden.
3. Kommt es während des Betriebs zu einer Erhitzung
der Batterie, wird das Gerät unter Umständen
angehalten. Unterbrechen Sie in diesem Fall Ihre
Arbeit und lassen Sie die Batterie abkühlen.
Anschließend können Sie das Gerät wieder normal
verwenden. (Nur BCL1415 und BCL1815)
BCL1415 und BCL1815 sind exlusiv für den
Bohrschrauber. Verwenden Sie die Batterie
keinesfalls für schwere Werkzeuge (z. B. Kreissäge,
Gattersäge, Abrichtschleifmaschine, Lüfter usw.).
Bitte beachten Sie die folgenden Warnhinweise.
WARNUNG
Zur Vermeidung einer ausgelaufenen Batterie,
Erwärmung, Rauchentwicklung, Explosionen und
vorzeitiger Zündung beachten Sie bitte die folgenden
Vorsichtsmaßnahmen.
1. Stellen Sie sicher, dass sich Späne und Staub nicht
auf der Batterie ansammeln.
䡬Stellen Sie während der Arbeit sicher, dass Späne
und Staub nicht auf die Batterie fallen.
䡬Stellen Sie sicher, dass Staub und Späne, die
während der Bearbeitung auf das Elektrowerkzeug
fallen, nicht in die Batterie gelangen.
䡬Lagern Sie ungebrauchte Batterien nicht an Plätzen,
an denen Staub oder Späne anfallen.
䡬Vor dem Einlagern einer Batterie sind sämtlicher
Staub und Späne zu entfernen. Weiterhin ist zu
berücksichtigen, dass die Batterie nicht gemeinsam
mit Metallteilen (Schrauben, Nägel, usw.) zu lagern
ist.
2. Achten Sie darauf, dass die Batterie nicht durch
einen spitzen Gegenstand, beispielsweise einen
Nagel, beschädigt wird. Vermeiden Sie Schläge mit
dem Hammer. Treten Sie nicht gegen die Batterie,
werfen Sie diese nicht, und vermeiden Sie Stöße.
3. Beschädigte oder verformte Batterien dürfen nicht
weiter verwendet werden.
4. Achten Sie auf den richtigen Anschluss der Pole.
5. Schließen Sie die Batterie nicht direkt an elektrische
Ausgänge oder Zigarettenanzünder im Auto an.
6. Verwenden Sie die Batterie nur für den
angegebenen Zweck.
7. Falls die Batterie nach Verstreichen der
angegebenen Ladezeit nicht vollständig aufgeladen
ist, brechen Sie den Ladevorgang unverzüglich ab.
8. Vermeiden Sie hohe Temperaturen und hohen
Druck, wie er beispielsweise in der Mikrowelle,
einem Trockner oder einem Hochdruckbehälter
auftritt.
9. Wenn Sie ein Leck oder Rußgeruch feststellen,
vermeiden Sie jeglichen Kontakt mit Feuerstellen.
10. Vermeiden Sie eine Verwendung an Orten, an denen
starke statische Elektrizität erzeugt wird.
11. Werden ein Leck, Rußgeruch, Erwärmung,
Verfärbungen, Verformungen oder sonstige
Anomalitäten während der Verwendung, des
Aufladens oder der Lagerung festgestellt, entfernen
Sie die Batterie unverzüglich vom Gerät oder dem
Ladegerät und beenden Sie die Anwendung.
VORSICHT
1. Tritt die auslaufende Flüssigkeit in Kontakt mit Ihren
Augen, reiben Sie diese nicht, sondern waschen Sie
sie mit sauberem (Leitungs-) Wasser gut aus und
suchen Sie unverzüglich einen Arzt auf.
Ohne sachgemäße Behandlung können
Augenverletzungen auftreten.
2. Wenn die ausgelaufene Flüssigkeit auf Haut oder
Kleidung trifft, waschen Sie diese unverzüglich mit
sauberem Wasser ab.
Es besteht die Gefahr von Hautreizungen.
3. Beim Auftreten von Rost, Rußgeruch, Erwärmung,
Verfärbungen, Verformungen oder sonstigen
Anomalitäten während der ersten Verwendung der
Batterie, ist diese nicht weiter zu verwenden. Bringen
Sie die Batterie zum Händler oder Verkäufer zurück.
