Hill Audio ZPR4620 User manual

USER MANUAL
ZPR4620
6+2 Channel Rack Zoning Mixer
ENGLISH Page 2-15
RevA 04/2013 Order code: 12-020-0293-80200-1-01

User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 2
■Introduction
Dear customer,
congratulations on the purchase of this quality mixing desk. To meet your requirements,
this unit has been designed and built to the highest standards, so that we can assure
you that you have made a good and satisfying investment. To take full advantage of all
possibilities and for your own safety and the safety of your environment, please read
these operating instructions carefully before you start using the unit.
■Product description
The ZPR4620 6+2 Channel Rack Zoning Mixer is a stereo mixing console with 2
microphone inputs, 6 stereo inputs, adjustable talk-over and one balanced master
stereo output plus three balanced mono zone outputs with installation-specific features,
which make this unit a very versatile choice in any environment from leisure to
commercial applications.
■Security advice before use
Warning: Read this section carefully before installing, powering,
operating, cleaning or servicing this product!
The following symbols are used to identify important safety information in this manual:
DANGER!
Safety hazard. Risk
of injury or death.
WARNING!
Hazardous voltage.
Risk of severe or
fatal electric shock.
WARNING!
Fire hazard.
WARNING!
Read manual before
installation and
operation.
General advice:
1. Read this manual completely before using the product.
2. Keep this manual in your records for future reference.
3. Follow all instruction printed in this manual, otherwise warranty
may be void.
4. Follow all printed security advice on the product itself. The lighting
flash with arrowhead within an equilateral triangle makes you
aware of non-insulated AC mains voltage inside the unit. The
exclamation mark within an equilateral triangle makes you aware of
important operating and maintenance instructions in the literature
attached to this product.
5. Take care of enough distance between this product and sources of
User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 15

User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 14
■Block Diagram
User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 3
hum and noise like electric motors and transformers.
6. Carry this product with greatest care. Punches, big forces and
heavy vibration may damage this product mechanically.
7. The manufacturer takes no responsibility for injury or damage
caused by not following the safety precautions and instructions
printed in this manual.
Protection from electric shock:
1. Only connect this unit to a mains socket outlet with protective earth
connection, ground-fault (earth-fault) protection and overload
protection.
2. Where the mains plug or an appliance coupler is used as a dis-
connect device, the disconnect device shall remain readily
operable.
3. To pull the AC Cord out of the wall outlet or the unit’s AC socket,
never pull the cable itself, but only the AC plug.
4. Disconnect the unit from AC supply by pulling the AC plug out of
the wall outlet or the unit’s AC socket before any kind of cleaning
on the product. Use smooth and dry cloth only for cleaning. Check
all connection cables before reconnecting the unit.
5. Do not expose this unit to any dripping or splashing liquids, and do
not place objects filled with liquids, such as vases, on the unit. Do
not operate this unit near to open water or in high humidity.
6. Choose the position of the AC cord according to the lowest risk of
damage by foot steps or by squeezing it. Take especially care of
the AC cord outlet on the unit as well as the AC plug and wall outlet
at the other end of the cable.
7. Do not open the unit for service purpose, as there are no user-
serviceable parts inside. Warranty will be void in any case of
unauthorized service by the user or other not authorized persons.
Protection from fire:
1. Take care of not placing the unit near sources of heat (e.g.
powerful amplifiers, fog machines).
2. Take always care of sufficient air convection in the unit’s
environment to avoid overheating, especially when mounting in a
closed environment. Make sure air convection slots – if any - are
not blocked. Do not operate this unit in environmental temperatures
exceeding 40 degrees Celsius.
3. Check the total maximum power of your AC wall outlet if you
connect several units to one wall outlet and avoid any overloading.
Protection from injury and damage:
1. Never use any accessories or modifications not authorized by the
manufacturer of this unit.
2. Choose a location for operation where the unit is protected from

User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 4
vibration and where a fixed mounting position is provided.
3. Before plugging the AC cord in the wall outlet, check whether the
AC mains voltage and frequency is the same as this product is
specified for. Whenever your AC plug should not match the wall
outlet, contact you dealer immediately.
4. If fluids have spilled into the unit or small parts have intruded the
unit, immediately switch off the unit and hand it over to the
authorized service for a security check.
5. Disconnect the unit from AC supply by pulling the AC plug out of
the wall outlet or the unit’s AC socket during a thunder-storm in
order to avoid any damage on the unit due to AC voltage peaks.
6. In cause of not correct function of this unit or damaged AC cord or
other damaged parts, pull immediately the AC plug out of the wall
outlet and hand the unit over to the authorized service for a
security check.
7. To meet all aspects of functionality and security during mainte-
nance work to be performed on this unit, all parts should be
replaced by genuine spare parts. Consequently, take care of your
dealer or maintenance company to be authorized by the
manufacturer.
■Health advice
This unit produces and absorbs electromagnetic radiation. The strength of radiation and
the sensitivity for disturbing interference matches the CE and FCC requirements. A
corresponding sign is printed on the backside of the unit. Any change or modification
may affect the behavior of the unit concerning electromagnetic radiation, with the CE
requirements eventually not to be met any more. The manufacturer takes no
responsibility in this case.
■Functional advice
This unit is immune to the presence of electromagnetic disturbances – both conducted
and radiated - up to a certain level. Under peak conditions, the unit is classified to show
a “class C” performance criteria and may encounter temporary degradation or loss of
function which may need manual help to recover. In such case, disconnect the AC
power from the unit and reconnect it again to recover.
■Environmental advice
This unit is build to conform to the ROHS standards and the WEEE
directive 2002/96/EC of the European Parliament and of the Council of
the European Union. Under these regulations, the product shall not be
discarded into regular garbage at the end of its life, but shall be returned
to authorized recycling stations.
User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 13
Further to that, this unit does not need regular maintenance. The internal electronics
are protected by a 5x20mm fuse. The fuse can be accessed by the small drawer at the
AC inlet. To change the fuse, unplug the AC cord first, pull out the fuse drawer and
replace the fuse ONLY with a fuse of SAME voltage and rating. If the fuse blows again
after replacement, hand over the unit to qualified service personnel.
■Technical Data
Mains Input EU version…...……………………………......……………AC220-250V~ 50Hz
Mains Input US version…...……………………………......……………AC110-120V~ 60Hz
Power consumption…………………………………………………………….……max. 24W
Frequency response…………………………….……………………..20Hz-20kHz ±1.0 dBu
S/N………………………………………………………………...……………………….>82dB
THD+N………………………………………………………… ……………..< 0.07% @ 1kHz
Dimensions…...………………………………………………..W 483× H133.5x D 183.5mm
Weight ……………………………………………………………………………………..4.2 kg
■Standards
This product complies with the following standards:
EU safety...........................................................................................EN 60065:2001 +A1
EU EMC................................................................... EN55103-1:1997, EN55103-2: 1997
US safety ………….…………..………………………………………………………UL60065
US EMC………………………..…………………………………………………..FCC Part 15
This product meets both the EMC Directive 2004/108/EC and the Low Voltage Directive
2006/95/EC.
For further information ask your dealer or visit the website of the manufacturer.

User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 12
■Operation
Apart from using good equipment, good sound comes from using it correctly. Level
setting mistakes are one of the common reasons why even good equipment may not
perform as desired. For setting levels, please be reminded that two guidelines need to
be followed:
Avoid distortion by leaving some headroom. Never overrun any audio-
equipment’s inputs. Level meters and displays allow you to make sure that
signals do not enter critical levels.
Avoid unnecessary amplification by using as little attenuation as possible. For
example, if you turn down the input gain of a mixer to minimum, and then
increase the main output of the mixer to maximum to drive your amplifier
properly, you will create unnecessary noise, as you first dispose of some
already existing signal level, and then later apply amplification (tainted with
noise) to make it up.
Obviously, these two requirements are marking a levelling window that the operator
must match to achieve a good sound with as little distortion and noise as possible.
DANGER: Excessive volume levels on headphones or other sound
systems may cause hearing damage. Always turn the volume control to
minimum when you switch the unit on, and do not exceed healthy
listening levels.
■Maintenance and warranty
While we have chosen the best components to make this product as rugged and
reliable as possible, some parts in audio products (potentiometers, faders, switches)
are subject to wear which is a matter of operation cycles, and not of time. While
providing a full time-based warranty according to the country’s of purchase
requirements on the function of the electronic circuitry, we hence have to limit the
warranty on such electro-mechanical parts to 90 days from the date of purchase.
In many cases, malfunction of electro-mechanical parts occurs due to dust
contamination, which may require cleaning of such parts. As the inside of such parts is
not accessible, a common practice is to use cleaning fluids in the shape of sprays.
Please be reminded that many of such fluids contain chemicals which may wash away
the dust but at the same time corrode or damage contact surface and may cause
cosmetic damage to other parts. We hence explicitly exclude any claims for exchange
of damaged part due to mechanical or chemical impact.
Without liability, we recommend CaiLube MCL fader cleaner and lubricant available
from CAIG Laboratories if the need of cleaning for electro-mechanical parts occurs.
User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 5
■Unpacking
Please check that the box contains the following items:
Main parts: 1 pcs. ZPR4620 main unit
1 pcs. Mains cable
1 pcs. Operation manual
If any part is missing, please contact your dealer immediately for replacement.
Warning: After unpacking, and before plugging the AC cord in the wall
outlet, check whether the AC mains voltage and frequency is the same
as this product is specified for (see rear panel of product). Whenever
the specified voltage or your AC plug should not match the local
conditions, do NOT plug the AC cord into the wall outlet and contact
you dealer immediately.
■Back Panel
1. AC inlet and fuse holder. Use the supplied AC cord to connect the unit to AC
mains. Make sure voltage and frequency stated on the unit comply with your
local AC supply. The fuse can be accessed by the small drawer at the AC
inlet. To change the fuse, unplug the AC cord first, pull out the fuse drawer
and replace the fuse ONLY with a fuse of SAME voltage and rating. If the fuse
blows again after replacement, hand over the unit to qualified service
personnel.
2. Stereo Master output. This is a balanced stereo XLR output carrying the main
output signal controlled by (36).
3. Stereo Master output. This is an unbalanced RCA output carrying the same
signal as output (2).

User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 6
4. Stereo Master output. This is a balanced terminal block output carrying the
same signal as output (2)
5. Equalizer for Stereo Master output. This is a 3-band stereo equalizer to adjust
the frequency response of the Stereo Master output. Adjustments shall be
made with a small screw driver. Note that the total angle is 300 degrees and
do not apply excessive force with the screw driver.
6. Maximum level setting for Stereo Master output. This control allows to limit the
maximum level at the outputs (2)/(3)/(4) in order to match the connected
sound system. Adjustments made on this control will not be displayed by the
output level meter (37). Adjustments shall be made with a small screw driver.
Note that the total angle is 300 degrees and do not apply excessive force with
the screw driver.
7. Talkover adjustment for Stereo Master output. These two controls allow to set
the level at which the talkover is enabled (SENSITIVITY) and the amount of
damping which is applied once the talkover is active (DAMPING). If no
talkover effect is required for the stereo master output, the DAMPING control
can be set to “off”. Adjustments shall be made with a small screw driver. Note
that the total angle is 300 degrees and do not apply excessive force with the
screw driver.
8. Zone A/B/C mono outputs. These are balanced mono XLR outputs carrying
the zone output signals controlled by (38) respectively.
9. Zone A/B/C mono outputs. These are balanced terminal block outputs carrying
the same signal as outputs (8)
10. Equalizers for Zone A/B/C outputs. These are 2-band stereo equalizers to
adjust the frequency response of the Mono zone outputs. Adjustments shall be
made with a small screw driver. Note that the total angle is 300 degrees and
do not apply excessive force with the screw driver.
11. Maximum level setting for Zone A/B/C outputs. These controls allows to limit
the maximum level at the outputs (8)/(9) in order to match the connected
sound system. Adjustments made on this control will not be displayed by the
output level meter (40). Adjustments shall be made with a small screw driver.
Note that the total angle is 300 degrees and do not apply excessive force with
the screw driver.
12. Talkover adjustment for Mono zone outputs. These controls allow to set the
amount of damping which is applied once the talkover is active (DAMPING). If
no talkover effect is required for any of these mono zone outputs, the
DAMPING control can be set to “off” for the respective zone. Adjustments
shall be made with a small screw driver. Note that the total angle is 300
degrees and do not apply excessive force with the screw driver.
13. 100Hz High-Pass filter for Mono zone outputs. This helps to reduce the low-
frequency energy on outputs (8)/(9) which is specifically useful if a zone is
used to feed a background music system which may consist of relatively small
wall or ceiling speakers.
14. Microphone include/exclude switch for Mono zone outputs. Pressing this
switch will include the microphone signal into the respective zone output,
releasing the switch will exclude the microphone signal from the respective
User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 11
■Connections
For connecting this unit to AC mains, please note:
Check whether the AC mains voltage and frequency is the same as this
product is specified for (see rear panel of product). Whenever the specified
voltage or your AC plug should not match the local conditions, do NOT plug
the AC cord into the wall outlet and contact you dealer immediately.
Do not operate this unit without the line cord earth ground connected. To do
so may increase the risk of electric shock and increase line cord conducted
emissions.
For making audio signal connections, always remember that good and reliable
connections are a basic requirement for good sound and reliable operation. Bad
soldering of cables can result in intermittent audio signals or temporarily lost ground
connections, hence always use good cables. In case of doubt about making proper
connections, please see check the standard pin assignments required for proper
operation in the appendix of this manual.
It is also essential that high-gain inputs are terminated properly to avoid excess noise
contribution. Specifically, this applies to the PHONO inputs. If these inputs are not used
and the sensitivity is switched to “PHONO”, the inputs shall be terminated with the
supplied termination plugs (as factory-inserted at delivery).
■Powering up
Following a proper power-up sequence protects your equipment – specifically speakers
– and your ears. Follow the below procedure:
Turn down all output volume controls of any equipment in your audio system.
Switch on your audio sources first (Turntables, CD Players, PC’s with
soundcards, Tapedecks, etc.)
Switch on the audio mixer
Switch on any audio processor between the mixer and the amplifier(s) [if any].
Switch on the amplifier(s).
Turn up the audio level on your sources if such controls are provided.
Set the audio output of your mixer to a low level.
Set the audio output of any audio processor between the mixer and the
amplifier(s) to a medium level [if any such processors].
Turn up the volume controls of your amplifier(s) slowly.
Make adjustments to all volume settings as needed.
For switching off, follow the inverse sequence – always switch off your amplifier(s) first,
then any processors between mixer and amplifier(s), then the mixer, then the sources.

User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 10
■Microphone routing
Depending on the application, user habits and local safety requirements, it can be
useful to either enable or disable the local microphones during an emergency case
where an incoming emergency signal into the emergency input (21) shuts down all
program signals. The advantage of disabling the microphones for this case is that the
local user can not interfere the legibility of the emergency announcement by using his
own microphone, the disadvantage is that if for whatever reason the emergency
announcement does not stop, the local user can still give emergency/evacuation
guidance by means of the local microphone. As a factory default, the microphones are
not muted during an incoming emergency message. To change this, a qualified installer
or technician must open the unit after disconnecting it from AC supply, and follow below
instructions.
User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 7
zone output. Note that once the microphone is excluded from a specific zone,
the DAMPING control (12) of the talkover in this zone shall be set to “OFF” as
otherwise a microphone signal could not be heard but would still reduce the
program signal when the microphone is in use.
15. Record output. This is an unbalanced stereo output carrying the same signal
as the main outputs (2)/(3)/(4), but not influenced by the main volume control
(36). This is normally used for recording the output to an external tape, CD or
memory device.
16. FOH input. This is a ¼’’ TRS balanced stereo input specifically designed to
allow the connection of the output of a stage mixer, in order to use the
connected sound system for the replay of the stage mixer’s signal. This is
useful in applications where apart from stereo source replay also live music is
performed over the same sound system. The FOH input is routed to input
channel 6 and will replace the LINE6 signal once the relative front-panel
switch (35) is set to “ON”. It is in parallel to the front-panel FOH input (34).
17. Line inputs. These RCA connectors provide inputs for line-level signals to the
assigned channels. LINE2 and LINE5 can be switched to PHONO sensitivity
by means of the switches (18) and LINE6 can be switched to the FOH input by
means of the front-panel switch (35).
18. PHONO conversion switches for LINE inputs. These switches change the
sensitivity of the LINE inputs to PHONO (RIAA equalized) level.
19. Microphone input for MIC1 and MIC2. These are balanced ¼” TRS connector
without phantom power provision, hence only suitable for dynamic
microphones. Please note that for MIC1, this connector has priority to the front
panel mic connector (23), so if you intend to use the front panel mic socket
(23), please do not plug anything into this rear-panel socket.
20. Music Mute input. This is a terminal block input which allows to remotely mute
all output signals (Stereo Master, Zone A/B/C) by simply shortening the
contacts. Please note that the unit can be set to include or exclude the
microphone signals from this muting process, please section “microphone
routing”.
21. Emergency input. This is an auto-sensing, balanced terminal block input which
allows the connection to an emergency evacuation system. Once a signal is
present on this input, all output signals (Stereo Master, Zone A/B/C) will be
muted and the emergency message/signal from this input will become audible
instead. Please note that the unit can be set to include or exclude the
microphone signals from this muting process, please section “microphone
routing”.
22. Emergency volume control. This control allows to set the level with which the
signal fed into the emergency input (21) will be replayed at the two master
outputs (2)/(3)/(4) and (8)/(9).

User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 8
■Front Panel
23. Microphone input for MIC1. This is a balanced Combo (XLR+TRS) connector
without phantom power provision, hence only suitable for dynamic
microphones. Please note that MIC2 can only be connected from the rear
panel connector (19).
24. Microphone Equalizer. Allows the adjustment of the tonal balance for the
microphone inputs in three voice-specific frequency bands with an adjustment
range of ±12dB. Please note the setting will affect both microphones inputs
simultaneously.
25. Level control for microphone inputs. Allow the individual adjustments of the
levels for MIC1 and MIC2.
26. On/Off (ON AIR) switch for the respective microphone.
27. Talkover on/off switch. Enables or disables the talkover circuit. Once enabled,
the parameters can be set independently for every output by means of the
rear-panel controls (7/12).
28. AUX Input for INPUT1. This is a 3.5mm Mini-TRS stereo socket which allows
to connect sources like MP3 players etc. without removing the mixer from its
mounting position.
29. Enable/Disable switch for AUX Input (28). Pressing this switch will disable the
LINE1 input on the rear panel and will route the signal of the AUX Input (28) to
INPUT1.
30. Gain control of input channels. Allows adjustment of the input sensitivity to
compensate for different source volumes. To facilitate proper setting of input
gain levels, the stereo inputs INPUT1/2/3/4/5/6 have an additional
SIGNAL/PEAK LED (34)
31. Signal/Peak LED. This LED will illuminate green when an input signal with
more than -30dB of signal level is present, and will turn to orange-red once the
input signal reaches 0dB. This facilitates to see which channels have a signal
present, without using the CUE function. It further helps to set the gain
controls (30) correctly for proper gain balance.
User Manual: ZPR4620 6+2 Channel Rack Zoning Mixer
V2.00 (04-2013) © Hill Audio 9
32. Channel fader for input channels. A high-grade dual rail 45mm fader
determines the volume of the respective channel.
33. CUE switch for stereo channels. Assigns the respective channel to the
headphone bus for pre-fader-listening (CUE) by means of the headphone
output (43). A LED indicates the pressed position.
34. FOH input. This is a ¼’’ TRS balanced stereo input specifically designed to
allow the connection of the output of a stage mixer, in order to use the
connected sound system for the replay of the stage mixer’s signal. This is
useful in applications where apart from stereo source replay also live music is
performed over the same sound system. The FOH input is routed to input
channel 6 and will replace the LINE6 signal once the relative switch (35) is set
to “ON”. This front-panel FOH input is in parallel to the rear-panel FOH input
(16) but has priority over the rear-side input; thus, once a jack is inserted into
the front-side FOH input, the rear-side FOH input (16) is disabled.
35. On/Off switch for FOH input. Enables and disables the FOH input. This switch
applies to both the front-side and rear-side FOH input.
36. Stereo Master output level control. Determines the main output level present
at outputs (2)/(3)/(4).
37. Stereo Master output level meter. Displays the output level of the stereo
master output (2)/(3)/(4). Note that the level limitation applied by means of the
rear-side maximum level control (6) is not displayed on this meter.
38. Mono Zone output level controls for zones A/B/C. Determine the main output
level present at outputs (8)/(9).
39. Mono zone source selection switches for zones A/B/C. These rotary switches
allow to either use the master mix bus [same signal as carried by the stereo
master output (2)/(3)/(4)] or any of the individual, assigned source signals to
the Inputs 1/2/3/4/5/6, to be used as a source signal for the respective zone.
40. Mono Zone output level meters. Display the output levels of the mono zones
A/B/C respectively. Note that the level limitations applied by means of the
rear-side maximum level controls (11) are not displayed on these meters.
41. Mono zone Cue switches. Pressing these switches will assign the respective
zone signal to the headphone bus for pre-fader-listening (CUE) by means of
the headphone output (43).
42. CUE level. Determines the signal volume at the headphone output (43).
Always set this control to minimum before putting on headphones, as sudden
high-volume impact may damage your ears. See further health advice below.
43. Headphones output. A ¼” TRS connector to connect a headphone. Turn the
CUE level (42) down before plugging in any headphones.
44. Power switch. Switches the unit on and off. Make sure to switch the unit off
when not in use.
45. Power LED. Indicates whether the unit is switched on or off.
