ORIGINAL OPERATING INSTRUCTIONS
TE 30 / TE 30
ತ
AVR / TE 30
ತ
C
ತ
AVR / TE 30
ತ
M
ತ
AVR
rotary hammer
It is essential that the operating instructions
are read before the power tool is operated
for the first time.
Always keep these operating instructions
together with the power tool.
Ensure that the operating instructions are
with the power tool when it is given to other
persons.
Contents Page
1. General information 1
2. Description 2
3. Insert tools, accessories 5
4. Technical data 5
5. Safety instructions 7
6. Before use 10
7. Operation 10
8. Care and maintenance 12
9. Troubleshooting 13
10. Disposal 14
11. Manufacturer’s warranty - tools 14
12. EC declaration of conformity 15
1These numbers refer to the corresponding illustra-
tions. The illustrations can be found on the fold-out
cover pages. Keep these pages open while studying
the operating instructions.
In these operating instructions, the designation “the
power tool” always refers to the TE 30, TE 30ತAVR,
TE 30ತCತAVR or TE 30ತMತAVR rotary hammer.
Components, operating controls and indicators 1
@Chuck
;Function selector switch
=Control switch
%Forward / reverse switch
&Side handle with depth gauge
(TPS indicator (TE 30ತMತAVR)
)Signal receiving area for the TPS key
+AVR Active Vibration Reduction (optional)
1. General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that could lead
to serious bodily injury or fatality.
WARNING
Draws attention to a potentially dangerous situation
that could lead to serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation
that could lead to slight personal injury or damage to
the equipment or other property.
NOTE
Draws attention to an instruction or other useful
information.
1.2 Explanation of the pictograms and other
information
Warning signs
General
warning
Warning:
electricity
en
1

1 2
Obligation signs
Wear eye
protection
Wear a hard
hat
Wear ear
protection
Wear
protective
gloves
Wear
breathing
protection
Symbols
Read the
operating
instructions
before use
Equipped with
theft
protection
system
Lock symbol Return waste
material for
recycling.
Double
insulated
Drilling
without
hammering
Drilling
without
hammering,
1st gear
Drilling
without
hammering,
2nd gear
Hammer
drilling
Chiseling Chisel position
adjustment
Location of identification data on the power tool
The type designation can be found on the type iden-
tification plate and the serial number on the side of
the motor housing. Make a note of this data in your
operating instructions and always refer to it when
making an enquiry to your Hilti representative or
service department.
Type:
Generation: 01
Serial no.:
2. Description
2.1 Use of the product as directed
The power tool is an electrically-powered rotary hammer with pneumatic hammering mechanism.
The power tools are designed for drilling in concrete and masonry. The power tool can also be used for light
chiseling work on masonry and surface finishing on concrete.
Working on materials hazardous to the health (e.g. asbestos) is not permissible.
Nationally applicable industrial safety regulations must be observed.
The working environment may be as follows: construction site, workshop, renovation, conversion or new
construction.
The power tool may be operated only when connected to a power supply providing a voltage and frequency in
compliance with the information given on its type identification plate.
The power tool is designed for professional use and may be operated, serviced and maintained only by trained,
authorized personnel. This personnel must be informed of any special hazards that may be encountered. The
en
2

power tool and its ancillary equipment may present hazards when used incorrectly by untrained personnel or
when used not as directed.
To avoid the risk of injury, use only genuine Hilti accessories and insert tools.
Observe the information printed in the operating instructions concerning operation, care and maintenance.
Modification of the power tool or tampering with its parts is not permissible.
2.2 Chuck
TEತC (SDS plus) chuck
TEತT (SDS top) chuck
2.3 TPS TE 30
ತ
M
ತ
AVR theft protection system (optional)
The power tool may be equipped with the optional theft protection system. If the power tool is equipped with
this feature, it can be unlocked and made ready for operation only through use of the corresponding TPS key.
2.4 TE 30 / TE 30
ತ
AVR switch
Speed control switch for smooth starting.
Forward / reverse switch
Function selector switch:
Drilling without hammering
Hammer drilling
2.5 TE 30
ತ
C
ತ
AVR switch
Speed control switch for smooth starting.
Forward / reverse switch
Function selector switch:
Drilling without hammering
Hammer drilling
Chisel adjustment (12 positions)
Chiseling
2.6 TE 30
ತ
M
ತ
AVR switch
Speed control switch for smooth starting.
Forward / reverse switch
Function selector switch:
Drilling without hammering 2
Drilling without hammering 1
Hammer drilling
Chisel adjustment (12 positions)
Chiseling
2.7 Grips
Pivotable side handle with depth gauge
Vibration-absorbing grip
2.8 Protective feature
Mechanical slip clutch
en
3

2.9 Lubrication
Oil lubrication
2.10 Active vibration reduction (TE 30
ತ
AVR, TE 30
ತ
C
ತ
AVR, TE 30
ತ
M
ತ
AVR)
The power tool is equipped with an AVR active vibration reduction system which reduces vibration significantly
compared to power tools without AVR.
2.11 Items supplied as standard
1 Power tool
1TEತCorTEತT chuck
1 Side handle with depth gauge
1 Operating instructions
1 Hilti toolbox
1 Cleaning cloth
1 Grease
2.12 Using extension cords
Use only extension cords of a type approved for the application and with conductors of adequate cross section.
The power tool may otherwise loose performance and the extension cord may overheat. Check the extension
cord for damage at regular intervals. Replace damaged extension cords.
Recommended minimum conductor cross section and max. cable lengths
Conductor cross section 1.5 mm
t
2.0 mm
t
2.5 mm
t
3.5 mm
t
Mains voltage 100V 30 m 50 m
Mains voltage 110-120 V 20 m 30 m 40 m
Mains voltage 220-240 V 50 m 100 m
Do not use extension cords with 1.25 mmtconductor cross section.
2.13 Using extension cords outdoors
When working outdoors, use only extension cords that are approved and correspondingly marked for this
application.
2.14 Using a generator or transformer
This tool may be powered by a generator or transformer when the following conditions are fulfilled: AC voltage
and power output of at least 2,600 W, operating voltage must be within +5% and -15% of the rated voltage at
all times, frequency must be in the 50 – 60 Hz range and never above 65 Hz, and the unit must be equipped
with automatic voltage regulation and starting boost.
Never operate other power tools or appliances from the generator or transformer at the same time. Switching
other power tools or appliances on and off may cause undervoltage and / or overvoltage peaks, resulting in
damage to the power tool.
en
4

3. Insert tools, accessories
Insert tools and accessories for the TE 30, TE 30
ತ
AVR, TE 30
ತ
C and TE 30
ತ
M
Chuck TEತC (SDS Plus)
Chuck TEತT (SDS Top)
Hammer drill bits 5…25 mm
TEತC percussion core bits 66…90 mm
TEತT percussion core bits 50…90 mm
TEತC forming and installation drill bits 10…35 mm
Anchor-setting tools TEತCorTEತT connection end
Quick-release chuck for wood and metal drill bits For smooth or hex. shank
Wood drill bits 5…25 mm
Metal drill bits Max. 13 mm
Insert tools for the TE 30
ತ
C
ತ
AVR and TE 30
ತ
M
ತ
AVR
Pointed chisels TEತCorTEತT connection end
Flat chisel TEತCorTEತT connection end
Shaped chisels TEತCorTEತT connection end
Insert tools and accessories for the TE
ತ
C
ತ
AVR and TE 30
ತ
M
ತ
AVR
TEತC lightweight percussion core bits 25…68 mm
Multipurpose hole saws 35…105 mm, Hex. connection end
Metal drill bits / stepped drill bits 3…8 mm, (2nd gear) hex. connection end
Metal drill bits / stepped drill bits 8…13 mm, (1st gear) hex. connection end
Mixing paddles with smooth shank 80…150 mm, (for mixing non-flammable
materials)
TPS Theft Protection System with Company Card,
Company Remote and TPSತK key
Option, 206999
4. Technical data
Right of technical changes reserved.
NOTE
The power tool is available in various voltage ratings. Please refer to the power tool’s type identification plate
for details of its rated voltage and rated input power.
Power tool TE 30 / TE 30
ತ
AVR / TE 30
ತ
C
ತ
AVR TE 30
ತ
M
ತ
AVR
Rated power input 850 W 900 W
Rated current input Rated voltage 100 V: 9.2 A
Rated voltage 110 V: 8.3 A
Rated voltage 110…127 V: 8.3 A
Rated voltage 220 V: 4.2 A
Rated voltage 230 V: 4.0 A
Rated voltage 240 V: 3.8 A
Rated voltage 100 V: 10.4 A
Rated voltage 110 V: 9.6 A
Rated voltage 110…127 V: 9.6 A
Rated voltage 220 V: 5.4 A
Rated voltage 230 V: 5.3 A
Rated voltage 240 V: 5.1 A
Mains frequency 50…60 Hz 50…60 Hz
en
5

Power tool TE 30 TE 30
ತ
AVR TE 30
ತ
C
ತ
AVR TE 30
ತ
M
ತ
AVR
Weight in accord-
ance with EPTA
procedure 01/2003
4.0 kg 4.2 kg 4.2 kg 4.4 kg
Dimensions (L x W
xH)
359 mm x 93 mm x
213 mm
379 mm x 93 mm x
213 mm
379 mm x 93 mm x
213 mm
379 mm x 93 mm x
213 mm
Drilling speed
without hammer-
ing 2
1,100/min
Drilling speed
without hammer-
ing 1
750/min 750/min 750/min 750/min
Hammer drilling
speed
750/min 750/min 750/min 750/min
Single impact
energy
3.3 J 3.3 J 3.3 J 3.3 J
NOTE
The vibration emission level given in this information sheet has been measured in accordance with a
standardised test given in EN 60745 and may be used to compare one tool with another. It may be used for a
preliminary assessment of exposure. The declared vibration emission level represents the main applications of
the tool. However if the tool is used for different applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly increase the exposure level over the total working
period. An estimation of the level of exposure to vibration should also take into account the times when the
tool is switched off or when it is running but not actually doing the job. This may significantly reduce the
exposure level over the total working period. Identify additional safety measures to protect the operator from
the effects of vibration such as: maintain the tool and the accessories, keep the hands warm, organisation of
work patterns.
Noise and vibration information (measured in accordance with EN 60745):
Typical A-weighted sound power level 101 dB (A)
Typical A-weighted emission sound pressure level 90 dB (A)
Uncertainty for the given sound level as per EN 60745 3 dB (A)
Additional information in accordance with EN 60745
Triaxial vibration value for the TE 30 (vibration vector
sum)
measured in accordance with EN 60745-2-6
Hammer drilling in concrete, ah, HD 16.5 m/st
Triaxial vibration value for the TE 30ತAVR (vibration
vector sum)
measured in accordance with EN 60745-2-6
Hammer drilling in concrete, ah, HD 12 m/st
Triaxial vibration value TE 30-C-AVR / TE 30-M-AVR)
(vibration vector sum)
measured in accordance with EN 60745-2-6
Hammer drilling in concrete, ah, HD 12 m/st
Chiseling, ah, HD 11 m/st
Uncertainty (K) 1.5 m/st
