himbol ZOlink Series User manual

Item Model: ZO500
Transmitter*1
Receiver*1
2
User Manual*1
3
Type-c power cable*1
4
Wireless Video Transmission System
ZOlink series
Manual
Shenzhen ZO Video Technology Co., Ltd.
02/Packing list
FT
500
Transmit Range
Ultra-low-power Multiple power supply
Latency
80ms
Built-in antenna
antenna
Multiple monitoring
App
NPF/TYPE-C
01/Features
Fanless

1
3
2
4
OLED Display screen
Direction button
USB-C Port
HDMI Input( TX)/ Output(RX)
HDMI Output(TX/RX)
5
7
6
Menu button
Power switch
C Please press button #2 for 3 seconds to display QR code on the connected monitoring device
with HDMI, and kindly use APP to scan it, then go to monitor extremely fast on your connected
mobile phone
BPlease press button # 3 key for 3 seconds to enter the main menu interface for function setting
03/How to use 04/Product Description
Monitor
Phone
Director
导播台
Video camera
RX
TX
APlease press button # 2 and # 3 at the same time for 5 seconds to enter the U disk upgrade mode
1
23
4
5
6
7
HDMI HDMI
ON
OFF

Interface
Powered By
Power
consumption
Transmitter Receiver
Weight
Size
Transmission
frequency
band
Transmit power
Transmission delay
Receiving sensitivity
HDMI Input
HDMI Input/HDMI Output HDMI Output*2
<3W
120g
5GHz
17dBm
80ms,Noisy RF environment 120ms typical
-80dBm
103*63.5*16mm 103*63.5*16mm
120g
720P@50/60Hz
1080I@50/60Hz
1080P@24/25/30/50/60Hz
720P@50/60Hz
1080I@50/60Hz
1080P@24/25/30/50/60Hz
720P@50/60Hz
1080I@50/60Hz
1080P@24/25/30/50/60Hz
/
<2.5W
HDMI Output
5V Type-C/NP-F Battery 5V Type-C/NP-F Battery
05/Technical Parameters
Tel:[phone]
URL:www.zeroone-video.com
Address:2C, 2nd Floor, Building 6, Longbi Industrial Park
No.27 Dafa Road, Bantian Street, Longgang District, Shenzhen
Shenzhen ZO Video Technology Co., Ltd.
Download “shimbol” APP on Apple App Store.
W52 Band :5GHz product for indoor use only
