thomann T.Bone IEM 150 User manual

IEM 150
UHF wireless system
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
12.06.2019, ID: 439536, 439537, 439539, 439541, 439542, 439543 (V3)

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 7
2 Safety instructions..................................................................................................................................... 9
3 Features and scope of delivery......................................................................................................... 15
4 Installation.................................................................................................................................................. 19
4.1 General Information........................................................................................................................ 19
4.2 Transmitter......................................................................................................................................... 20
4.3 Receiver............................................................................................................................................... 22
4.4 Taking system in operation.......................................................................................................... 23
5 Connections and controls................................................................................................................... 24
5.1 Transmitter......................................................................................................................................... 24
5.2 Receiver............................................................................................................................................... 30
Table of contents
IEM 150
3

6 Operating.................................................................................................................................................... 36
6.1 Setting up the transmitter............................................................................................................ 36
6.2 Setting up the receiver................................................................................................................... 39
7 Technical specications....................................................................................................................... 42
7.1 Transmitter......................................................................................................................................... 42
7.2 Receiver............................................................................................................................................... 45
8 Plug and connection assignment.................................................................................................... 47
9 Troubleshooting...................................................................................................................................... 50
10 Protecting the environment.............................................................................................................. 53
Table of contents
UHF wireless system
4

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
IEM 150
5

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
UHF wireless system
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
Displays
General information
IEM 150
7

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General information
UHF wireless system
8

2 Safety instructions
This device is intended to be used for the wireless transmission of audio signals to earplugs.
Use the device only as described in this user manual. Any other use or use under other oper‐
ating conditions is considered to be improper and may result in personal injury or property
damage. No liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
Intended use
Safety
Safety instructions
IEM 150
9

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or re. If in doubt, seek advice from a regis‐
tered electrician.
Safety instructions
UHF wireless system
10

CAUTION!
Possible hearing impairment
The use of earphones at high volume over a longer period of time can cause per‐
manent hearing damage.
Adjust the output volume of your audio device to a medium value and use the
earphones no longer than about one hour a day.
Safety instructions
IEM 150
11

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctua‐
tions and do not switch the device on immediately after it was exposed to tem‐
perature uctuations (for example after transport at low outside temperatures).
Dust and dirt inside can damage the unit. When operated in harmful ambient
conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other
malfunction.
Safety instructions
UHF wireless system
12

NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur‐
rent circuit breaker. Failure to do so could result in damage to the device and pos‐
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
re.
NOTICE!
Risk of re due to incorrect polarity
Incorrectly inserted batteries may destroy the device or the batteries.
Ensure that proper polarity is observed when inserting batteries.
Safety instructions
IEM 150
13

NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device.
Take batteries out of the device if it is not going to be used for a longer period.
NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react
with the coating of your parquet, linoleum, laminate or PVC oor and after some
time cause permanent dark stains.
In case of doubt, do not put the rubber feet directly on the oor, but use felt-pad
oor protectors or a carpet.
Safety instructions
UHF wireless system
14

3 Features and scope of delivery
The UHF wireless system IEM 150 is suitable as an in-ear monitoring system especially for pro‐
fessional events, on rock stages and in concert halls, theatres and musicals.
Features and scope of delivery
IEM 150
15

Your UHF wireless system IEM 150 640 MHz consists of the following components:
n9.5" stereo transmitter IEM 150 T
– Very high sensitivity at very high signal-to-noise ratio
– Signal inputs: two XLR sockets
– Output for headphones (3.5 mm and 6.35 mm phone jack) with adjustable volume
– Two outputs for transmitting the input signal to other audio devices (6.35 mm phone
jack)
– Power supply via supplied power adapter
nBodypack receiver IEM 150 R 640 MHz (also available separately; article No. 439541)
– Earplug outlet (1/8" mini phone socket) with volume control
– Control for volume and balance
– Voltage supply: 2 AA cells (LR6, 1.5 V)
nEarphone EP 4
8 systems can be operated simultaneously. The system operates within a frequency range of
640 MHz to 665 MHz, divided into three frequency groups.
Included accessories: earplugs in various sizes and fastening material for rack mounting
the t.bone IEM 150 640 MHz
(item No. 439536)
Features and scope of delivery
UHF wireless system
16

Your UHF wireless system IEM 150 823 MHz consists of the following components:
n9.5" stereo transmitter IEM 150 T
– Very high sensitivity at very high signal-to-noise ratio
– Signal inputs: two XLR sockets
– Output for headphones (3.5 mm and 6.35 mm phone jack) with adjustable volume
– Two outputs for transmitting the input signal to other audio devices (6.35 mm phone
jack)
– Power supply via supplied power adapter
nBodypack receiver IEM 150 R (also available separately; article No. 439542)
– Earplug outlet (1/8" mini phone socket) with volume control
– Control for volume and balance
– Voltage supply: 2 AA cells (LR6, 1.5 V)
nEarphone EP 4
4 systems can be operated simultaneously. The system operates within a frequency range of
823 MHz to 832 MHz, divided into four frequency groups.
Included accessories: earplugs in various sizes and fastening material for rack mounting
the t.bone IEM 150 823 MHz
(item No. 439537)
Features and scope of delivery
IEM 150
17

Your UHF wireless system IEM 150 863 MHz consists of the following components:
n9.5" stereo transmitter IEM 150 T
– Very high sensitivity at very high signal-to-noise ratio
– Signal inputs: two XLR sockets
– Output for headphones (3.5 mm and 6.35 mm phone jack) with adjustable volume
– Two outputs for transmitting the input signal to other audio devices (6.35 mm phone
jack)
– Power supply via supplied power adapter
nBodypack receiver IEM 150 R (also available separately; article No. 439543)
– Earplug outlet (1/8" mini phone socket) with volume control
– Control for volume and balance
– Voltage supply: 2 AA cells (LR6, 1.5 V)
nEarphone EP 4
2 systems can be operated simultaneously. The system operates within a frequency range of
863 MHz to 865 MHz, divided into four frequency groups.
Included accessories: silicon ear pads and fastening material for rack mounting
the t.bone IEM 150 863 MHz
(item No. 439539)
Features and scope of delivery
UHF wireless system
18

4 Installation
4.1 General Information
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Installation
IEM 150
19

nThis device utilizes frequencies that are not harmonized within the European Union (EU)
and therefore may only be used in certain EU member states. In all European countries, the
frequencies used for the transmission of audio signals are strictly regulated. Before you
start, make sure the frequencies are allowed in the respective country and check whether
the operation must be reported to the appropriate authority.
For more information, please visit: http://www.thomann.de.
nMake sure that transmitter and receiver are both tuned to the same channel.
nNever set multiple transmitters to the same channel.
nMake sure that there are no metal objects between the transmitter and receiver.
nAvoid interference from other radio or in-ear systems.
4.2 Transmitter
The unit has been designed for rack mounting in a standard 9.5" rack; it occupies one rack unit.
The xing material required for assembly is included.
Attach the included antenna to the rear panel of the transmitter. To improve the transmission
quality and to adapt to the spatial conditions it is rotatable and swivelling.
Notes on wireless transmission
Rack mounting
Attaching the antenna
Installation
UHF wireless system
20
